Introduction

This document describes typical configurations for EAA.

Prerequisites

The configuration examples were created and verified in a lab environment, and all the devices were started with the factory default configuration. When you are working on a live network, make sure you understand the potential impact of every command on your network.

This document assumes you are familiar with EAA features. For the same requirement, the implementation effects of TCL and CLI monitoring strategies are consistent. You can choose either strategy based on preference.

Example: Configuring an EAA TCL monitoring policy

Network configuration

Configure a TCL monitoring policy for the device to execute the following actions when the incoming traffic on Ten-GigabitEthernet1/0/1 reaches or exceeds 500 Mbps:

·     Generate logs for traffic that exceeds the range.

·     Display the current CPU state and save it to a file.

·     Display the state of Ten-GigabitEthernet1/0/1 and save it to a file.

If the subsequent incoming traffic reaches or exceeds 200Mbps, monitoring will restart. When the incoming traffic on the interface is detected to exceed 500Mbps again, the aforementioned operations are executed again.

Applicable hardware and software versions

Table 1 Applicable hardware and software versions

Product	Software version
S6812 series S6813 series	Release 6628Pxx
S6550XE-HI series	Release 8106Pxx
S6525XE-HI series	Release 8106Pxx
S5850 series	Release 8106Pxx
S5570S-EI series	Release 11xx
S5560X-EI series	Release 6628Pxx
S5560X-HI series	Release 6628Pxx
S5500V2-EI series	Release 6628Pxx
MS4520V2-30F	Release 6628Pxx
MS4520V2-30C MS4520V2-54C	Release 6628Pxx
MS4520V2-28S MS4520V2-24TP	Release 63xx
S6520X-HI series S6520X-EI series	Release 6628Pxx
S6520X-SI series S6520-SI series	Release 6628Pxx
S5000-EI series	Release 6628Pxx
MS4600 series	Release 6628Pxx
ES5500 series	Release 6628Pxx
S5560S-EI series S5560S-SI series	Release 63xx
S5500V3-24P-SI S5500V3-48P-SI	Release 63xx
S5500V3-SI series (excluding S5500V3-24P-SI and S5500V3-48P-SI)	Release 11xx
S5170-EI series	Release 11xx
S5130S-HI series S5130S-EI series S5130S-SI series S5130S-LI series	Release 63xx
S5120V2-SI series S5120V2-LI series	Release 63xx
S5120V3-EI series	Release 11xx
S5120V3-36F-SI S5120V3-28P-HPWR-SI S5120V3-54P-PWR-SI	Release 11xx
S5120V3-SI series (excluding S5120V3-36F-SI, S5120V3-28P-HPWR-SI, and S5120V3-54P-PWR-SI)	Release 63xx
S5120V3-LI series	Release 63xx
S3600V3-EI series	Release 11xx
S3600V3-SI series	Release 11xx
S3100V3-EI series S3100V3-SI series	Release 63xx
S5110V2 series	Release 63xx
S5110V2-SI series	Release 63xx
S5000V3-EI series S5000V5-EI series	Release 63xx
S5000E-X series S5000X-EI series	Release 63xx
E128C E152C E500C series E500D series	Release 63xx
MS4320V2 series MS4320V3 series MS4300V2 series MS4320 series MS4200 series	Release 63xx
WS5850-WiNet series	Release 63xx
WS5820-WiNet series WS5810-WiNet series	Release 63xx
WAS6000 series	Release 63xx
IE4300-12P-AC & IE4300-12P-PWR IE4300-M series IE4320 series	Release 63xx
IE4520 series	IE4520 series
S5135S-EI series	Release 6810 and later versions



Procedures

Editing the TCL script

# Use Notepad to edit the test.tcl file as follows:

# Define the monitored event. Configure interface Ten-GigabitEthernet1/0/1 to focus on inbound traffic. When the inbound traffic reaches or exceeds 500 Mbps, configure the device to execute the specified action. The condition to re-enable polling is when the interface traffic reaches or exceeds 200Mbps.

::comware::rtm::event_register interface ten-gigabitethernet1/0/1 monitor-obj rcv-bps start-op ge start-val 500000000 restart-op ge restart-val 200000000 user-role network-admin

# Configure the action to take when the monitored event occurs: Send log message XGE1/0/1 input rate exceeded 500000000bps with priority level 1 and device number local1.

::comware::rtm::action syslog priority 1 facility local1 msg "XGE1/0/1 input rate exceeded 500000000bps"

# Create the execution action for the monitored event.

::comware::create-cli

# Configure the device to execute the display cpu-usage command to display CPU usage statistics and save the information in XGE0_info.txt when the event occurs.

::comware::write-cli cli0 "display cpu-usage >> XGE0_info.txt"

# Configure the device to execute the display interface ten-gigabitetherne 1/0/1 command to display the current operating state and related information of Ten-GigabitEthernet1/0/1 and save the information in XGE0_info.txt when the event occurs.

::comware::write-cli cli0 "display interface ten-gigabitethernet1/0/1 >> XGE0_info.txt"

::comware::write-cli cli0 "end"

Configuring the device

# Configure the IP address of Ten-GigabitEthernet1/0/1.

<Device> system-view

[Device] interface ten-gigabitethernet 1/0/1

[Device-Ten-GigabitEthernet1/0/1] port link-mode route

[Device-Ten-GigabitEthernet1/0/1] ip address 192.168.100.66 255.255.255.0

[Device-Ten-GigabitEthernet1/0/1] quit

[Device] quit

# Download test.tcl to the device through TFTP.

<Device> tftp 192.168.100.14 get test.tcl

  % Total    % Received % Xferd  Average Speed   Time    Time     Time  Current

                                 Dload  Upload   Total   Spent    Left  Speed

100   189  100   189    0     0   7900      0 --:--:-- --:--:-- --:--:-- 12600

# Create and enable a TCL monitoring policy, and bind the policy to TCL script test.tcl.

<Device> system-view

[Device] rtm tcl-policy test test.tcl

[Device] quit

Verifying the configuration

# Use the display rtm policy registered command to view the policy named test with the type Tcl.

<Device> display rtm policy registered

Total number: 1

Type  Event      TimeRegistered        PolicyName

TCL   INTERFACE  May 05 06:46:20 2019  test

# When the inbound traffic on interface Ten-GigabitEthernet1/0/1 reaches or exceeds 500 Mbps, check all files and folder information in the device for the existence of XGE0_info.txt.

<Device> dir

Directory of cfa0:

   0 -rw-        3227 Nov 19 2019 17:28:36   1.cfg

   1 -rw-        2296 Apr 26 2019 18:55:08   5660_data.ak

   2 -rw-        2304 Apr 26 2019 18:54:56   5660_security.ak

   3 -rw-        2298 Apr 26 2019 18:55:16   5660_voice.ak

   4 -rw-        3227 Nov 19 2019 17:15:19   STARTUP110.CFG

   5 drw-           - Mar 10 2019 04:10:10   diagfile

   6 -rw-         567 Jul 17 2019 14:25:00   dsakey

   7 -rw-         223 Jul 17 2019 14:25:00   ecdsakey

   8 -rw-         278 Jul 17 2019 14:25:00   XGE0_info.txt

   9 -rw-         735 Jul 17 2019 14:25:00   hostkey

  10 -rw-         492 Nov 18 2019 16:40:50   ifindex.dat

  11 -rw-         276 Apr 23 2019 19:00:00   lauth.dat

  12 drw-           - Jul 17 2019 11:26:34   license

  13 drw-           - Apr 24 2019 12:39:38   logfile

  14 -rw-    18839552 Nov 14 2019 16:42:12   msr56-cmw710-boot-r000706.bin

  15 -rw-     1150976 Nov 14 2019 16:43:00   msr56-cmw710-data-r000706.bin

  16 -rw-    47470592 Nov 14 2019 16:42:24   msr56-cmw710-system-r000706.bin

  17 -rw-     2975744 Nov 14 2019 16:42:56   msr56-cmw710-voice-r000706.bin

  18 -rw-    70445056 Nov 14 2019 17:41:08   msr56.ipe

  19 -rw-    70445056 Nov 14 2019 16:40:00   msr56NN.ipe

  20 drw-           - Aug 21 2019 16:23:10   pkey

  21 -rw-         189 Nov 19 2019 17:49:34   test.tcl

  22 drw-           - Mar 10 2019 04:10:10   seclog

  23 -rw-         591 Jul 17 2019 14:25:00   serverkey

  24 -rw-        3227 Nov 18 2019 16:40:50   startup.cfg



507492 KB total (298412 KB free)

# Use the TFTP method to copy file XGE0_info.txt to the TFTP server.

<Device> tftp 192.168.100.14 put XGE0_info.txt

# View file XGE0_info.txt to display the current state of the CPU and interface Ten-GigabitEthernet1/0/1.

Unit CPU usage:

      15% in last 5 seconds

      14% in last 1 minute

      13% in last 5 minutes



Ten-GigabitEthernet1/0/1

Current state: UP

Line protocol state: UP

Description:  Ten-GigabitEthernet1/0/1 Interface

Bandwidth: 1000000 kbps

Maximum transmission unit: 1500

Allow jumbo frames to pass

Broadcast max-ratio: 100%

Multicast max-ratio: 100%

Unicast max-ratio: 100%

Internet address: 192.168.100.66/24 (primary)

IP packet frame type: Ethernet II, hardware address: 5cdd-7000-a07c

IPv6 packet frame type: Ethernet II, hardware address: 5cdd-7000-a07c

Loopback is not set

Media type is twisted pair, port hardware type is 1000_BASE_T

Port priority: 0

1000Mbps-speed mode, Full-duplex mode

Link speed type is autonegotiation, link duplex type is autonegotiation

Flow-control is not enabled

Maximum frame length: 9216

Last link flapping: 0 hours 0 minutes 14 seconds

Last clearing of counters: Never

 Peak input rate: 4 bytes/sec, at 2019-09-21 15:09:37

 Peak output rate: 1 bytes/sec, at 2019-09-21 15:09:37

 Last 300 seconds input rate: 568710000.25 bytes/sec, 64970 bits/sec, 4.96 packets/sec

 Last 300 seconds output rate: 568710000.25 bytes/sec, 64970 bits/sec, 4.96 packets/sec Input (total):  1703 packets, 2336882000 bytes

          0 unicasts, 0 broadcasts, 4 multicasts, 0 pauses

 Input (normal):  1703 packets, - bytes

          0 unicasts, 0 broadcasts, 4 multicasts, 0 pauses

 Input:  0 input errors, 0 runts, 0 giants, 0 throttles

          0 CRC, 0 frame, - overruns, 0 aborts

          - ignored, - parity errors

 Output (total): 1706 packets,  2337062000 bytes

          0 unicasts, 5 broadcasts, 0 multicasts, 0 pauses

 Output (normal): 1706 packets, - bytes

          0 unicasts, 5 broadcasts, 0 multicasts, 0 pauses

 Output: 0 output errors, - underruns, - buffer failures

          0 aborts, 0 deferred, 0 collisions, 0 late collisions

          0 lost carrier, - no carrier

Configuration files

·     Script text for test.tcl:

::comware::rtm::event_register interface ten-gigabitethernet1/0/1 monitor-obj rcv-bps start-op ge start-val 500000000 restart-op ge restart-val 200000000 user-role network-admin

::comware::rtm::action syslog priority 1 facility local1 msg "XGE1/0/1 input rate exceeded 500000000bps"

::comware::create-cli

::comware::write-cli cli0 "display cpu-usage >> XGE0_info.txt"

::comware::write-cli cli0 "display interface ten-gigabitethernet1/0/1 >> XGE0_info.txt"

::comware::write-cli cli0 "end"

·     Device:

#

interface Ten-GigabitEthernet1/0/1

 port link-mode route

 ip address 192.168.100.66 255.255.255.0

#

rtm tcl-policy test test.tcl

#

Example: Configuring an EAA CLI monitoring policy

Network configuration

Configure a CLI monitoring policy for the device to execute the following actions when the incoming traffic on Ten-GigabitEthernet1/0/1 reaches or exceeds 500 Mbps:

·     Generate logs for traffic that exceeds the range.

·     Display the current CPU state and save it to a file.

·     Display the state of Ten-GigabitEthernet1/0/1 and save it to a file.

If the subsequent incoming traffic reaches or exceeds 200Mbps, monitoring will restart. When the incoming traffic on the interface is detected to exceed 500Mbps again, the aforementioned operations are executed again.

Applicable hardware and software versions

Table 2 Applicable hardware and software versions

Product	Software version
S6812 series S6813 series	Release 6628Pxx
S6550XE-HI series	Release 8106Pxx
S6525XE-HI series	Release 8106Pxx
S5850 series	Release 8106Pxx
S5570S-EI series	Release 11xx
S5560X-EI series	Release 6628Pxx
S5560X-HI series	Release 6628Pxx
S5500V2-EI series	Release 6628Pxx
MS4520V2-30F	Release 6628Pxx
MS4520V2-30C MS4520V2-54C	Release 6628Pxx
MS4520V2-28S MS4520V2-24TP	Release 63xx
S6520X-HI series S6520X-EI series	Release 6628Pxx
S6520X-SI series S6520-SI series	Release 6628Pxx
S5000-EI series	Release 6628Pxx
MS4600 series	Release 6628Pxx
ES5500 series	Release 6628Pxx
S5560S-EI series S5560S-SI series	Release 63xx
S5500V3-24P-SI S5500V3-48P-SI	Release 63xx
S5500V3-SI series (excluding S5500V3-24P-SI and S5500V3-48P-SI)	Release 11xx
S5170-EI series	Release 11xx
S5130S-HI series S5130S-EI series S5130S-SI series S5130S-LI series	Release 63xx
S5120V2-SI series S5120V2-LI series	Release 63xx
S5120V3-EI series	Release 11xx
S5120V3-36F-SI S5120V3-28P-HPWR-SI S5120V3-54P-PWR-SI	Release 11xx
S5120V3-SI series (excluding S5120V3-36F-SI, S5120V3-28P-HPWR-SI, and S5120V3-54P-PWR-SI)	Release 63xx
S5120V3-LI series	Release 63xx
S3600V3-EI series	Release 11xx
S3600V3-SI series	Release 11xx
S3100V3-EI series S3100V3-SI series	Release 63xx
S5110V2 series	Release 63xx
S5110V2-SI series	Release 63xx
S5000V3-EI series S5000V5-EI series	Release 63xx
S5000E-X series S5000X-EI series	Release 63xx
E128C E152C E500C series E500D series	Release 63xx
MS4320V2 series MS4320V3 series MS4300V2 series MS4320 series MS4200 series	Release 63xx
WS5850-WiNet series	Release 63xx
WS5820-WiNet series WS5810-WiNet series	Release 63xx
WAS6000 series	Release 63xx
IE4300-12P-AC & IE4300-12P-PWR IE4300-M series IE4320 series	Release 63xx
IE4520 series	IE4520 series
S5135S-EI series	Release 6810 and later versions



Restrictions and guidelines

·     For a policy, you can configure only one trigger event and one running time. When you repeatedly execute the event or running-time commands, the most recently configured and committed changes take effect.

·     If the number of the newly configured action matches an existing action number, execute the commit command for the most recent configuration to take effect.

·     After configuring the event, action, user role, and running time for the CLI monitoring policy, you must execute the commit command to enable the policy and activate its configurations.

Procedures

# Configure the IP address of Ten-GigabitEthernet1/0/1.

<Device> system-view

[Device] interface ten-gigabitethernet 1/0/1

[Device-Ten-GigabitEthernet1/0/1] port link-mode route

[Device-Ten-GigabitEthernet1/0/1] ip address 192.168.100.66 255.255.255.0

[Device-Ten-GigabitEthernet1/0/1] quit

# Create CLI policy 1.

[Device] rtm cli-policy 1

# Configure the monitored event. Configure the device to execute the specified action when the inbound traffic on interface Ten-GigabitEthernet1/0/1 reaches or exceeds 500 Mbps. The condition to re-enable polling is when the interface traffic reaches or exceeds 200Mbps.

[Device-rtm-1] event interface ten-gigabitethernet 1/0/1 monitor-obj rcv-bps start-op ge start-val 500000000 restart-op ge restart-val 200000000

# Configure the action to take when the monitored event occurs: Send log message XGE1/0/1 input rate exceeded 500000000bps with priority level 1 and log recording tool local1.

[Device-rtm-1] action 1 syslog priority 1 facility local1 msg "XGE1/0/1 input rate exceeded 500000000bps"

# Configure the device to execute the display cpu-usage command to display CPU usage statistics and save the information in XGE0_info.txt when the event occurs.

[Device-rtm-1] action 2 cli display cpu-usage >> XGE0_info.txt

# Configure the device to execute the display interface ten-gigabitetherne 1/0/1 command to display the current operating state and related information of Ten-GigabitEthernet1/0/1 and save the information in XGE0_info.txt when the event occurs.

[Device-rtm-1] action 3 cli display interface ten-gigabitethernet 1/0/1 >> XGE0_info.txt

# Set the policy running time to 30 seconds.

[Device-rtm-1] running-time 30

# Specify user role network-admin for the execution of CLI monitoring policy 1.

[Device-rtm-1] user-role network-admin

# Enable CLI monitoring policy 1.

[Device-rtm-1] commit

[Device-rtm-1] quit

Verifying the configuration

# Use the display rtm policy registered command to view policy 1 with the type CLI.

<Device> display rtm policy registered

Total number: 1

Type  Event      TimeRegistered        PolicyName

CLI   INTERFACE  May 04 00:12:40 2019  1

# When the inbound traffic on interface Ten-GigabitEthernet1/0/1 reaches or exceeds 500 Mbps, check all files and folder information in the device for the existence of XGE0_info.txt.

<Device> dir

Directory of cfa0:

   0 -rw-        3227 Nov 19 2019 17:28:36   1.cfg

   1 -rw-        2296 Apr 26 2019 18:55:08   5660_data.ak

   2 -rw-        2304 Apr 26 2019 18:54:56   5660_security.ak

   3 -rw-        2298 Apr 26 2019 18:55:16   5660_voice.ak

   4 -rw-        3227 Nov 19 2019 17:15:19   STARTUP110.CFG

   5 drw-           - Mar 10 2019 04:10:10   diagfile

   6 -rw-         567 Jul 17 2019 14:25:00   dsakey

   7 -rw-         223 Jul 17 2019 14:25:00   ecdsakey

   8 -rw-         278 Jul 17 2019 14:25:00   XGE0_info.txt

   9 -rw-         735 Jul 17 2019 14:25:00   hostkey

  10 -rw-         492 Nov 18 2019 16:40:50   ifindex.dat

  11 -rw-         276 Apr 23 2019 19:00:00   lauth.dat

  12 drw-           - Jul 17 2019 11:26:34   license

  13 drw-           - Apr 24 2019 12:39:38   logfile

  14 -rw-    18839552 Nov 14 2019 16:42:12   msr56-cmw710-boot-r000706.bin

  15 -rw-     1150976 Nov 14 2019 16:43:00   msr56-cmw710-data-r000706.bin

  16 -rw-    47470592 Nov 14 2019 16:42:24   msr56-cmw710-system-r000706.bin

  17 -rw-     2975744 Nov 14 2019 16:42:56   msr56-cmw710-voice-r000706.bin

  18 -rw-    70445056 Nov 14 2019 17:41:08   msr56.ipe

  19 -rw-    70445056 Nov 14 2019 16:40:00   msr56NN.ipe

  20 drw-           - Aug 21 2019 16:23:10   pkey

  21 -rw-         189 Nov 19 2019 17:49:34   test.tcl

  22 drw-           - Mar 10 2019 04:10:10   seclog

  23 -rw-         591 Jul 17 2019 14:25:00   serverkey

  24 -rw-        3227 Nov 18 2019 16:40:50   startup.cfg



507492 KB total (298412 KB free)

# Use the TFTP method to copy file XGE0_info.txt to the TFTP server.

<Device> tftp 192.168.100.14 put XGE0_info.txt

# View file XGE0_info.txt to display the current state of the CPU and interface Ten-GigabitEthernet1/0/1.

Unit CPU usage:

      15% in last 5 seconds

      14% in last 1 minute

      13% in last 5 minutes



Ten-GigabitEthernet1/0/1

Current state: UP

Line protocol state: UP

Description:  Ten-GigabitEthernet1/0/1 Interface

Bandwidth: 1000000 kbps

Maximum transmission unit: 1500

Allow jumbo frames to pass

Broadcast max-ratio: 100%

Multicast max-ratio: 100%

Unicast max-ratio: 100%

Internet address: 192.168.100.66/24 (primary)

IP packet frame type: Ethernet II, hardware address: 5cdd-7000-a07c

IPv6 packet frame type: Ethernet II, hardware address: 5cdd-7000-a07c

Loopback is not set

Media type is twisted pair, port hardware type is 1000_BASE_T

Port priority: 0

1000Mbps-speed mode, Full-duplex mode

Link speed type is autonegotiation, link duplex type is autonegotiation

Flow-control is not enabled

Maximum frame length: 9216

Last link flapping: 0 hours 0 minutes 14 seconds

Last clearing of counters: Never

 Peak input rate: 4 bytes/sec, at 2019-09-21 15:09:37

 Peak output rate: 1 bytes/sec, at 2019-09-21 15:09:37

 Last 300 seconds input rate: 568710000.25 bytes/sec, 64970 bits/sec, 4.96 packets/sec

 Last 300 seconds output rate: 568710000.25 bytes/sec, 64970 bits/sec, 4.96 packets/sec Input (total):  1703 packets, 2336882000 bytes

          0 unicasts, 0 broadcasts, 4 multicasts, 0 pauses

 Input (normal):  1703 packets, - bytes

          0 unicasts, 0 broadcasts, 4 multicasts, 0 pauses

 Input:  0 input errors, 0 runts, 0 giants, 0 throttles

          0 CRC, 0 frame, - overruns, 0 aborts

          - ignored, - parity errors

 Output (total): 1706 packets,  2337062000 bytes

          0 unicasts, 5 broadcasts, 0 multicasts, 0 pauses

 Output (normal): 1706 packets, - bytes

          0 unicasts, 5 broadcasts, 0 multicasts, 0 pauses

 Output: 0 output errors, - underruns, - buffer failures

          0 aborts, 0 deferred, 0 collisions, 0 late collisions

          0 lost carrier, - no carrier

Configuration files

#

interface Ten-GigabitEthernet1/0/1

 port link-mode route

 ip address 192.168.100.66 255.255.255.0

#

rtm cli-policy 1

 event interface Ten-GigabitEthernet1/0/1 monitor-obj rcv-bps start-op ge start-val 500000000 restart-op ge restart-val 200000000

 action 1 syslog priority 1 facility local1 msg "XGE1/0/1 input rate exceeded 500000000bps"

 action 2 cli display cpu-usage >> XGE0_info.txt

 action 3 cli display interface ten-gigabitethernet 1/0/1 >> XGE0_info.txt

 running-time 30

 user-role network-admin

#

Example: Configuring EAA and track entry association

Network configuration

Device A has established BGP sessions with Device D and Device E. Normally, traffic from Device D and Device E to the Internet is forwarded through Device A. Configure EAA and track entry association to achieve the following: When the state of interface Ten-GigabitEthernet1/0/1 connecting Device A to Device C changes to Down, Device A automatically detects the port down event and blocks BGP sessions with Device D and Device E. Consequently, traffic from Device D and Device E to the external network can be rerouted through Device B.

Figure 1 Network diagram



Applicable hardware and software versions

Table 3 Applicable hardware and software versions

Product	Software version
S6812 series S6813 series	Release 6628Pxx
S6550XE-HI series	Release 8106Pxx
S6525XE-HI series	Release 8106Pxx
S5850 series	Release 8106Pxx
S5570S-EI series	Release 11xx
S5560X-EI series	Release 6628Pxx
S5560X-HI series	Release 6628Pxx
S5500V2-EI series	Release 6628Pxx
MS4520V2-30F	Release 6628Pxx
MS4520V2-30C MS4520V2-54C	Release 6628Pxx
MS4520V2-28S MS4520V2-24TP	Release 63xx
S6520X-HI series S6520X-EI series	Release 6628Pxx
S6520X-SI series S6520-SI series	Release 6628Pxx
S5000-EI series	Release 6628Pxx
MS4600 series	Release 6628Pxx
ES5500 series	Release 6628Pxx
S5560S-EI series S5560S-SI series	Release 63xx
S5500V3-24P-SI S5500V3-48P-SI	Release 63xx
S5500V3-SI series (excluding S5500V3-24P-SI and S5500V3-48P-SI)	Release 11xx
S5170-EI series	Release 11xx
S5130S-HI series S5130S-EI series S5130S-SI series S5130S-LI series	Release 63xx
S5120V2-SI series S5120V2-LI series	Release 63xx
S5120V3-EI series	Release 11xx
S5120V3-36F-SI S5120V3-28P-HPWR-SI S5120V3-54P-PWR-SI	Release 11xx
S5120V3-SI series (excluding S5120V3-36F-SI, S5120V3-28P-HPWR-SI, and S5120V3-54P-PWR-SI)	Release 63xx
S5120V3-LI series	Release 63xx
S3600V3-EI series	Release 11xx
S3600V3-SI series	Release 11xx
S3100V3-EI series S3100V3-SI series	Release 63xx
S5110V2 series	Release 63xx
S5110V2-SI series	Release 63xx
S5000V3-EI series S5000V5-EI series	Release 63xx
S5000E-X series S5000X-EI series	Release 63xx
E128C E152C E500C series E500D series	Release 63xx
MS4320V2 series MS4320V3 series MS4300V2 series MS4320 series MS4200 series	Release 63xx
WS5850-WiNet series	Release 63xx
WS5820-WiNet series WS5810-WiNet series	Release 63xx
WAS6000 series	Release 63xx
IE4300-12P-AC & IE4300-12P-PWR IE4300-M series IE4320 series	Release 63xx
IE4520 series	IE4520 series
S5135S-EI series	Release 6810 and later versions



Procedures

# View the current state and statistics of the BGP peers.

<DeviceA> display bgp peer ipv4



 BGP local router ID: 1.1.1.1

 Local AS number: 100

 Total number of peers: 3                  Peers in established state: 3



  * - Dynamically created peer

  Peer                    AS  MsgRcvd  MsgSent OutQ PrefRcv Up/Down  State



  10.2.1.2                200       13       16    0       0 00:16:12 Established

  10.3.1.2                300       13       16    0       0 00:10:34 Established

  10.3.2.2                300       13       16    0       0 00:10:38 Established

# Configure a track item to monitor the state of Ten-GigabitEthernet1/0/1.

<DeviceA> system-view

[DeviceA] track 1 interface ten-gigabitethernet 1/0/1

# Configure a TCL monitoring policy for Device A to automatically detect Ten-GigabitEthernet1/0/1 down events and prevent BGP sessions from being established with Device D and Device E.

[DeviceA] rtm cli-policy test

[DeviceA-rtm-test] event track 1 state negative

[DeviceA-rtm-test] action 0 cli system-view

[DeviceA-rtm-test] action 1 cli bgp 100

[DeviceA-rtm-test] action 2 cli peer 10.3.1.2 ignore

[DeviceA-rtm-test] action 3 cli peer 10.3.2.2 ignore

[DeviceA-rtm-test] user-role network-admin

[DeviceA-rtm-test] commit

[DeviceA-rtm-test] quit

Verifying the configuration

# Disable Ten-GigabitEthernet1/0/1.

[DeviceA] interface ten-gigabitethernet 1/0/1

[DeviceA-Ten-GigabitEthernet1/0/1] shutdown

# View the state and statistics of BGP peers. Verify that the number of BGP peers is 0.

<DeviceA> display bgp peer ipv4

 BGP local router ID: 1.1.1.1

 Local AS number: 100

 Total number of peers: 0                  Peers in established state: 0

  * - Dynamically created peer

  Peer                    AS  MsgRcvd  MsgSent OutQ PrefRcv Up/Down  State

Configuration files

#

rtm cli-policy test

 event track 1 state negative

 action 0 cli system-view

 action 1 cli bgp 100

 action 2 cli peer 10.3.1.2 ignore

 action 3 cli peer 10.3.2.2 ignore

 user-role network-operator

 user-role network-admin

#

track 1 interface ten-gigabitethernet 1/0/1

#
