H3C S6805 & S6825 & S6850 & S9850 & S9820
MPLS TE Configuration Examples

No part of this manual may be reproduced or transmitted in any form or by any means without prior written consent of New H3C Technologies Co., Ltd.

Except for the trademarks of New H3C Technologies Co., Ltd., any trademarks that may be mentioned in this document are the property of their respective owners.

The information in this document is subject to change without notice.

Contents

Introduction· 1

Prerequisites· 1

Example: Establishing MPLS TE tunnels with RSVP-TE·· 1

Network configuration· 1

Analysis· 1

Applicable hardware and software versions· 2

Restrictions and guidelines· 2

Procedures· 2

Verifying the configuration· 8

Configuration files· 11

Example: Configuring MPLS TE forwarding adjacency· 16

Network configuration· 16

Analysis· 17

Applicable hardware and software versions· 17

Procedures· 18

Verifying the configuration· 20

Configuration files· 21

Introduction

This document provides MPLS TE configuration examples.

Prerequisites

This document is not restricted to specific software or hardware versions.

The configuration examples in this document were created and verified in a lab environment, and all the devices were started with the factory default configuration. When you are working on a live network, make sure you understand the potential impact of every command on your network.

This document assumes that you have basic knowledge of MPLS TE.

Example: Establishing MPLS TE tunnels with RSVP-TE

Network configuration

As shown in Figure 1, use RSVP-TE to establish two MPLS TE tunnels between Switch A and Switch D. The MPLS TE tunnel for Enterprise A requires a bandwidth of 20000 kbps. The MPLS TE tunnel for Enterprise B requires a bandwidth of 30000 kbps.

The maximum bandwidth of the link that each tunnel traverses is 50000 kbps and the maximum reservable bandwidth is 40000 kbps.

Figure 1 Network diagram

Analysis

To establish MPLS TE tunnels through RSVP-TE, you must perform the following tasks:

· Enable MPLS, MPLS TE, and RSVP-TE on nodes that the MPLS TE tunnels traverse.

· On each interface that the MPLS TE tunnels traverse, configure link TE attributes, including the maximum link bandwidth and the maximum reservable bandwidth.

· On each node that the MPLS TE tunnels traverse, configure the IGP TE extension to advertise the link TE attributes, which generates a TEDB on each node.

Based on the TEDB, CSPF calculates the shortest, TE constraints-compliant path to the tunnel destination. If you do not configure the IGP TE extension, the path is created based on IGP routing. The supported IGP TE extensions are OSPF TE and ISIS TE. This example uses OSPF TE.

· Create a tunnel interface on the ingress node of each MPLS TE tunnel, and perform the following tasks on the tunnel interface:

¡ Specify the tunnel destination address.

¡ Specify the tunnel bandwidth as required (20000 kbps for Enterprise A and 30000 kbps for Enterprise B).

¡ Specify the MPLS TE signaling protocol as RSVP-TE.

RSVP-TE advertises labels to establish CRLSPs and reserves bandwidth resources on each node along the calculated path.

· On the ingress node of each MPLS TE tunnel, configure static routing to direct traffic to the MPLS TE tunnel.

Applicable hardware and software versions

The following matrix shows the hardware and software versions to which this configuration example is applicable:

Hardware	Software version
S6805 switch series	Release 6607, Release 6616, Release 6616P01, Release 6635 and later
S6825 switch series	Release 6616, Release 6616P01, Release 6635 and later
S6850 switch series S9850 switch series	Release 6555P01, Release 6607, Release 6616, Release 6616P01, Release 6635 and later
S9820-64H switch	Release 6555P01, Release 6607, Release 6616, Release 6616P01, Release 6635 and later
S9820-8C switch	Not supported

Restrictions and guidelines

Before configuration, disable the spanning tree feature globally or map each VLAN to an MSTI.

Procedures

1. Configure IP addresses for interfaces:

# Configure IP addresses and masks for interfaces on Switch A, including the loopback interface, as shown in Figure 1.

<SwitchA> system-view

[SwitchA] vlan 10

[SwitchA-vlan10] port hundredgige 1/0/1

[SwitchA-vlan10] quit

[SwitchA] interface vlan-interface 10

[SwitchA-Vlan-interface10] ip address 10.1.1.1 24

[SwitchA-Vlan-interface10] quit

[SwitchA] vlan 30

[SwitchA-vlan30] port hundredgige 1/0/2

[SwitchA-vlan30] quit

[SwitchA] interface vlan-interface 30

[SwitchA-Vlan-interface30] ip address 30.1.1.1 24

[SwitchA-Vlan-interface30] quit

[SwitchA] vlan 70

[SwitchA-vlan70] port hundredgige 1/0/3

[SwitchA-vlan70] quit

[SwitchA] interface vlan-interface 70

[SwitchA-Vlan-interface70] ip address 70.1.1.1 24

[SwitchA-Vlan-interface70] quit

[SwitchA] vlan 80

[SwitchA-vlan80] port hundredgige 1/0/4

[SwitchA-vlan80] quit

[SwitchA] interface vlan-interface 80

[SwitchA-Vlan-interface80] ip address 80.1.1.1 24

[SwitchA-Vlan-interface80] quit

[SwitchA] interface loopback 0

[SwitchA-LoopBack0] ip address 1.1.1.1 32

[SwitchA-LoopBack0] quit

# Configure other devices in the same way that Switch A is configured. (Details not shown.)

2. Configure OSPF to ensure IP connectivity among the switches:

# Configure Switch A.

[SwitchA] ospf

[SwitchA-ospf-1] area 0

[SwitchA-ospf-1-area-0.0.0.0] network 1.1.1.1 0.0.0.0

[SwitchA-ospf-1-area-0.0.0.0] network 10.1.1.0 0.0.0.255

[SwitchA-ospf-1-area-0.0.0.0] network 30.1.1.0 0.0.0.255

[SwitchA-ospf-1-area-0.0.0.0] quit

[SwitchA-ospf-1] quit

# Configure Switch B.

[SwitchB] ospf

[SwitchB-ospf-1] area 0

[SwitchB-ospf-1-area-0.0.0.0] network 2.2.2.2 0.0.0.0

[SwitchB-ospf-1-area-0.0.0.0] network 10.1.1.0 0.0.0.255

[SwitchB-ospf-1-area-0.0.0.0] network 20.1.1.0 0.0.0.255

[SwitchB-ospf-1-area-0.0.0.0] quit

[SwitchB-ospf-1] quit

# Configure Switch C.

[SwitchC] ospf

[SwitchC-ospf-1] area 0

[SwitchC-ospf-1-area-0.0.0.0] network 3.3.3.3 0.0.0.0

[SwitchC-ospf-1-area-0.0.0.0] network 30.1.1.0 0.0.0.255

[SwitchC-ospf-1-area-0.0.0.0] network 40.1.1.0 0.0.0.255

[SwitchC-ospf-1-area-0.0.0.0] quit

[SwitchC-ospf-1] quit

# Configure Switch D.

[SwitchD] ospf

[SwitchD-ospf-1] area 0

[SwitchD-ospf-1-area-0.0.0.0] network 4.4.4.4 0.0.0.0

[SwitchD-ospf-1-area-0.0.0.0] network 20.1.1.0 0.0.0.255

[SwitchD-ospf-1-area-0.0.0.0] network 40.1.1.0 0.0.0.255

[SwitchD-ospf-1-area-0.0.0.0] quit

[SwitchD-ospf-1] quit

# Execute the display ip routing-table command on each switch to verify that the switches have learned the routes to one another, including the routes to the loopback interfaces. The following shows the output on Switch A.

[SwitchA] display ip routing-table

Destinations : 24 Routes : 24

Destination/Mask Proto Pre Cost NextHop Interface

0.0.0.0/32 Direct 0 0 127.0.0.1 InLoop0

1.1.1.1/32 Direct 0 0 127.0.0.1 InLoop0

2.2.2.2/32 O_INTRA 10 1 10.1.1.2 Vlan10

3.3.3.3/32 O_INTRA 10 1 30.1.1.3 Vlan30

4.4.4.4/32 O_INTRA 10 2 10.1.1.2 Vlan10

8.1.1.0/24 Direct 0 0 8.1.1.1 Tun2

8.1.1.0/32 Direct 0 0 8.1.1.1 Tun2

8.1.1.1/32 Direct 0 0 127.0.0.1 InLoop0

8.1.1.255/32 Direct 0 0 8.1.1.1 Tun2

10.1.1.0/24 Direct 0 0 10.1.1.1 Vlan10

10.1.1.0/32 Direct 0 0 10.1.1.1 Vlan10

10.1.1.1/32 Direct 0 0 127.0.0.1 InLoop0

10.1.1.255/32 Direct 0 0 10.1.1.1 Vlan10

20.1.1.0/24 O_INTRA 10 2 10.1.1.2 Vlan10

30.1.1.0/24 Direct 0 0 30.1.1.1 Vlan30

30.1.1.0/32 Direct 0 0 30.1.1.1 Vlan30

30.1.1.1/32 Direct 0 0 127.0.0.1 InLoop0

30.1.1.255/32 Direct 0 0 30.1.1.1 Vlan30

40.1.1.0/24 Static 1 0 0.0.0.0 Tun2

127.0.0.0/8 Direct 0 0 127.0.0.1 InLoop0

127.0.0.0/32 Direct 0 0 127.0.0.1 InLoop0

127.0.0.1/32 Direct 0 0 127.0.0.1 InLoop0

127.255.255.255/32 Direct 0 0 127.0.0.1 InLoop0

255.255.255.255/32 Direct 0 0 127.0.0.1 InLoop0

3. Configure an LSR ID, and enable MPLS, MPLS TE, and RSVP-TE:

# Configure Switch A.

[SwitchA] mpls lsr-id 1.1.1.1

[SwitchA] mpls te

[SwitchA-te] quit

[SwitchA] rsvp

[SwitchA-rsvp] quit

[SwitchA] interface vlan-interface 10

[SwitchA-Vlan-interface10] mpls enable

[SwitchA-Vlan-interface10] mpls te enable

[SwitchA-Vlan-interface10] rsvp enable

[SwitchA-Vlan-interface10] quit

[SwitchA] interface vlan-interface 30

[SwitchA-Vlan-interface30] mpls enable

[SwitchA-Vlan-interface30] mpls te enable

[SwitchA-Vlan-interface30] rsvp enable

[SwitchA-Vlan-interface30] quit

# Configure Switch B.

[SwitchB] mpls lsr-id 2.2.2.2

[SwitchB] mpls te

[SwitchB-te] quit

[SwitchB] rsvp

[SwitchB-rsvp] quit

[SwitchB] interface vlan-interface 10

[SwitchB-Vlan-interface10] mpls enable

[SwitchB-Vlan-interface10] mpls te enable

[SwitchB-Vlan-interface10] rsvp enable

[SwitchB-Vlan-interface10] quit

[SwitchB] interface vlan-interface 20

[SwitchB-Vlan-interface20] mpls enable

[SwitchB-Vlan-interface20] mpls te enable

[SwitchB-Vlan-interface20] rsvp enable

[SwitchB-Vlan-interface20] quit

# Configure Switch C.

[SwitchC] mpls lsr-id 3.3.3.3

[SwitchC] mpls te

[SwitchC-te] quit

[SwitchC] rsvp

[SwitchC-rsvp] quit

[SwitchC] interface vlan-interface 30

[SwitchC-Vlan-interface30] mpls enable

[SwitchC-Vlan-interface30] mpls te enable

[SwitchC-Vlan-interface30] rsvp enable

[SwitchC-Vlan-interface30] quit

[SwitchC] interface vlan-interface 40

[SwitchC-Vlan-interface40] mpls enable

[SwitchC-Vlan-interface40] mpls te enable

[SwitchC-Vlan-interface40] rsvp enable

[SwitchC-Vlan-interface40] quit

# Configure Switch D.

[SwitchD] mpls lsr-id 4.4.4.4

[SwitchD] mpls te

[SwitchD-te] quit

[SwitchD] rsvp

[SwitchD-rsvp] quit

[SwitchD] interface vlan-interface 20

[SwitchD-Vlan-interface20] mpls enable

[SwitchD-Vlan-interface20] mpls te enable

[SwitchD-Vlan-interface20] rsvp enable

[SwitchD-Vlan-interface20] quit

[SwitchD] interface vlan-interface 40

[SwitchD-Vlan-interface40] mpls enable

[SwitchD-Vlan-interface40] mpls te enable

[SwitchD-Vlan-interface40] rsvp enable

[SwitchD-Vlan-interface40] quit

4. Configure MPLS TE attributes of links:

# Configure the maximum link bandwidth and maximum reservable bandwidth on Switch A.

[SwitchA] interface vlan-interface 10

[SwitchA-Vlan-interface10] mpls te max-link-bandwidth 50000

[SwitchA-Vlan-interface10] mpls te max-reservable-bandwidth 40000

[SwitchA-Vlan-interface10] quit

[SwitchA] interface vlan-interface 30

[SwitchA-Vlan-interface30] mpls te max-link-bandwidth 50000

[SwitchA-Vlan-interface30] mpls te max-reservable-bandwidth 40000

[SwitchA-Vlan-interface30] quit

# Configure the maximum link bandwidth and maximum reservable bandwidth on Switch B.

[SwitchB] interface vlan-interface 10

[SwitchB-Vlan-interface10] mpls te max-link-bandwidth 50000

[SwitchB-Vlan-interface10] mpls te max-reservable-bandwidth 40000

[SwitchB-Vlan-interface10] quit

[SwitchB] interface vlan-interface 20

[SwitchB-Vlan-interface20] mpls te max-link-bandwidth 50000

[SwitchB-Vlan-interface20] mpls te max-reservable-bandwidth 40000

[SwitchB-Vlan-interface20] quit

# Configure the maximum link bandwidth and maximum reservable bandwidth on Switch C.

[SwitchC] interface vlan-interface 30

[SwitchC-Vlan-interface30] mpls te max-link-bandwidth 50000

[SwitchC-Vlan-interface30] mpls te max-reservable-bandwidth 40000

[SwitchC-Vlan-interface30] quit

[SwitchC] interface vlan-interface 40

[SwitchC-Vlan-interface40] mpls te max-link-bandwidth 50000

[SwitchC-Vlan-interface40] mpls te max-reservable-bandwidth 40000

[SwitchC-Vlan-interface40] quit

# Configure the maximum link bandwidth and maximum reservable bandwidth on Switch D.

[SwitchD] interface vlan-interface 20

[SwitchD-Vlan-interface20] mpls te max-link-bandwidth 50000

[SwitchD-Vlan-interface20] mpls te max-reservable-bandwidth 40000

[SwitchD-Vlan-interface20] quit

[SwitchD] interface vlan-interface 40

[SwitchD-Vlan-interface40] mpls te max-link-bandwidth 50000

[SwitchD-Vlan-interface40] mpls te max-reservable-bandwidth 40000

[SwitchD-Vlan-interface40] quit

5. Configure OSPF TE to advertise link TE attributes:

# Enable opaque LSA advertisement and reception on Switch A. By default, the opaque LSA advertisement and reception capability is enabled.

[SwitchA] ospf

[SwitchA-ospf-1] opaque-capability enable

# Enable MPLS TE for OSPF area 0 on Switch A.

[SwitchA-ospf-1] area 0

[SwitchA-ospf-1-area-0.0.0.0] mpls te enable

[SwitchA-ospf-1-area-0.0.0.0] quit

[SwitchA-ospf-1] quit

# Enable opaque LSA advertisement and reception on Switch B. By default, the opaque LSA advertisement and reception capability is enabled.

[SwitchB] ospf

[SwitchB-ospf-1] opaque-capability enable

# Enable MPLS TE for OSPF area 0 on Switch B.

[SwitchB-ospf-1] area 0

[SwitchB-ospf-1-area-0.0.0.0] mpls te enable

[SwitchB-ospf-1-area-0.0.0.0] quit

[SwitchB-ospf-1] quit

# Enable opaque LSA advertisement and reception on Switch C. By default, the opaque LSA advertisement and reception capability is enabled.

[SwitchC] ospf

[SwitchC-ospf-1] opaque-capability enable

# Enable MPLS TE for OSPF area 0 on Switch C.

[SwitchC-ospf-1] area 0

[SwitchC-ospf-1-area-0.0.0.0] mpls te enable

[SwitchC-ospf-1-area-0.0.0.0] quit

[SwitchC-ospf-1] quit

# Enable opaque LSA advertisement and reception on Switch D. By default, the opaque LSA advertisement and reception capability is enabled.

[SwitchD] ospf

[SwitchD-ospf-1] opaque-capability enable

# Enable MPLS TE for OSPF area 0 on Switch D.

[SwitchD-ospf-1] area 0

[SwitchD-ospf-1-area-0.0.0.0] mpls te enable

[SwitchD-ospf-1-area-0.0.0.0] quit

[SwitchD-ospf-1] quit

6. Configure MPLS TE tunnels on Switch A:

# Configure MPLS TE tunnel interface Tunnel 1 to forward traffic of Enterprise A.

[SwitchA] interface tunnel 1 mode mpls-te

[SwitchA-Tunnel1] ip address 7.1.1.1 255.255.255.0

# Specify the tunnel destination address as the LSR ID of Switch D, use RSVP-TE to establish the tunnel, and assign 20000 kbps bandwidth to the tunnel.

[SwitchA-Tunnel1] destination 4.4.4.4

[SwitchA-Tunnel1] mpls te signaling rsvp-te

[SwitchA-Tunnel1] mpls te bandwidth 20000

# Enable route recording for MPLS TE tunnel 1.

[SwitchA-Tunnel1] mpls te record-route

[SwitchA-Tunnel1] quit

# Configure MPLS TE tunnel interface Tunnel 2 to forward traffic of Enterprise B.

[SwitchA] interface tunnel 2 mode mpls-te

[SwitchA-Tunnel2] ip address 8.1.1.1 255.255.255.0

# Specify the tunnel destination address as the LSR ID of Switch D, use RSVP-TE to establish the tunnel, and assign 30000 kbps bandwidth to the tunnel.

[SwitchA-Tunnel2] destination 4.4.4.4

[SwitchA-Tunnel2] mpls te signaling rsvp-te

[SwitchA-Tunnel2] mpls te bandwidth 30000

# Enable route recording for MPLS TE tunnel 2.

[SwitchA-Tunnel2] mpls te record-route

[SwitchA-Tunnel2] quit

7. Configure static routing on Switch A to direct traffic to the MPLS TE tunnels:

# Configure a static route to direct traffic destined for 50.1.1.0/24 to MPLS TE tunnel interface Tunnel 1.

[SwitchA] ip route-static 50.1.1.0 24 tunnel 1 preference 1

# Configure a static route to direct traffic destined for 60.1.1.0/24 to MPLS TE tunnel interface Tunnel 2.

[SwitchA] ip route-static 60.1.1.0 24 tunnel 2 preference 1

Verifying the configuration

# Execute the display interface tunnel brief command on Switch A. The output shows that the two tunnel interfaces are up.

[SwitchA] display interface tunnel brief

Brief information on interfaces in route mode:

Link: ADM - administratively down; Stby - standby

Protocol: (s) - spoofing

Interface Link Protocol Primary IP Description

Tun1 UP UP 7.1.1.1

Tun2 UP UP 8.1.1.1

# Execute the display mpls te tunnel-interface command on Switch A to display detailed information about the MPLS TE tunnels.

[SwitchA] display mpls te tunnel-interface

Tunnel Name : Tunnel 1

Tunnel State : Up (Main CRLSP up, Shared-resource CRLSP down)

Tunnel Attributes :

LSP ID : 27415 Tunnel ID : 1

Admin State : Normal

Ingress LSR ID : 1.1.1.1 Egress LSR ID : 4.4.4.4

Signaling : RSVP-TE Static CRLSP Name : -

Resv Style : SE

Tunnel mode : -

Reverse-LSP name : -

Reverse-LSP LSR ID : - Reverse-LSP Tunnel ID: -

Class Type : CT0 Tunnel Bandwidth : 20000 kbps

Reserved Bandwidth : 20000 kbps

Setup Priority : 7 Holding Priority : 7

Affinity Attr/Mask : 0/0

Explicit Path : -

Backup Explicit Path : -

Metric Type : TE

Record Route : Enabled Record Label : Disabled

FRR Flag : Disabled Bandwidth Protection : Disabled

Backup Bandwidth Flag: Disabled Backup Bandwidth Type: -

Backup Bandwidth : -

Bypass Tunnel : No Auto Created : No

Route Pinning : Disabled

Retry Limit : 3 Retry Interval : 2 sec

Reoptimization : Disabled Reoptimization Freq : -

Backup Type : None Backup LSP ID : -

Auto Bandwidth : Disabled Auto Bandwidth Freq : -

Min Bandwidth : - Max Bandwidth : -

Collected Bandwidth : -

Tunnel Name : Tunnel 2

Tunnel State : Up (Main CRLSP up, Shared-resource CRLSP down)

Tunnel Attributes :

LSP ID : 27302 Tunnel ID : 2

Admin State : Normal

Ingress LSR ID : 1.1.1.1 Egress LSR ID : 4.4.4.4

Signaling : RSVP-TE Static CRLSP Name : -

Resv Style : SE

Tunnel mode : -

Reverse-LSP name : -

Reverse-LSP LSR ID : - Reverse-LSP Tunnel ID: -

Class Type : CT0 Tunnel Bandwidth : 30000 kbps

Reserved Bandwidth : 30000 kbps

Setup Priority : 7 Holding Priority : 7

Affinity Attr/Mask : 0/0

Explicit Path : -

Backup Explicit Path : -

Metric Type : TE

Record Route : Enabled Record Label : Disabled

FRR Flag : Disabled Bandwidth Protection : Disabled

Backup Bandwidth Flag: Disabled Backup Bandwidth Type: -

Backup Bandwidth : -

Bypass Tunnel : No Auto Created : No

Route Pinning : Disabled

Retry Limit : 3 Retry Interval : 2 sec

Reoptimization : Disabled Reoptimization Freq : -

Backup Type : None Backup LSP ID : -

Auto Bandwidth : Disabled Auto Bandwidth Freq : -

Min Bandwidth : - Max Bandwidth : -

Collected Bandwidth : -

# Execute the display ip routing-table command on Switch A. The output shows two static route entries with output interfaces of Tunnel 1 and Tunnel 2.

[SwitchA] display ip routing-table

Destinations : 28 Routes : 29

Destination/Mask Proto Pre Cost NextHop Interface

0.0.0.0/32 Direct 0 0 127.0.0.1 InLoop0

1.1.1.1/32 Direct 0 0 127.0.0.1 InLoop0

2.2.2.2/32 O_INTRA 10 1 10.1.1.2 Vlan10

3.3.3.3/32 O_INTRA 10 1 30.1.1.3 Vlan30

4.4.4.4/32 O_INTRA 10 2 10.1.1.2 Vlan10

30.1.1.3 Vlan30

7.1.1.0/24 Direct 0 0 7.1.1.1 Tun1

7.1.1.0/32 Direct 0 0 7.1.1.1 Tun1

7.1.1.1/32 Direct 0 0 127.0.0.1 InLoop0

7.1.1.255/32 Direct 0 0 7.1.1.1 Tun1

8.1.1.0/24 Direct 0 0 8.1.1.1 Tun2

8.1.1.0/32 Direct 0 0 8.1.1.1 Tun2

8.1.1.1/32 Direct 0 0 127.0.0.1 InLoop0

8.1.1.255/32 Direct 0 0 8.1.1.1 Tun2

10.1.1.0/24 Direct 0 0 10.1.1.1 Vlan10

10.1.1.0/32 Direct 0 0 10.1.1.1 Vlan10

10.1.1.1/32 Direct 0 0 127.0.0.1 InLoop0

10.1.1.255/32 Direct 0 0 10.1.1.1 Vlan10

50.1.1.0/24 Static 1 0 0.0.0.0 Tun1

30.1.1.0/24 Direct 0 0 30.1.1.1 Vlan30

30.1.1.0/32 Direct 0 0 30.1.1.1 Vlan30

30.1.1.1/32 Direct 0 0 127.0.0.1 InLoop0

30.1.1.255/32 Direct 0 0 30.1.1.1 Vlan30

60.1.1.0/24 Static 1 0 0.0.0.0 Tun2

127.0.0.0/8 Direct 0 0 127.0.0.1 InLoop0

127.0.0.0/32 Direct 0 0 127.0.0.1 InLoop0

127.0.0.1/32 Direct 0 0 127.0.0.1 InLoop0

127.255.255.255/32 Direct 0 0 127.0.0.1 InLoop0

255.255.255.255/32 Direct 0 0 127.0.0.1 InLoop0

# Execute the display rsvp lsp verbose command on Switch A to verify the following information:

· Tunnel 1 uses path Switch A—Switch B—Switch D, and has a bandwidth of 20000 kbps.

· Tunnel 2 uses path Switch A—Switch C—Switch D, and has a bandwidth of 30000 kbps.

[SwitchA] display rsvp lsp verbose

Tunnel name: SwitchA_t1

Destination: 4.4.4.4 Source: 1.1.1.1

Tunnel ID: 1 LSP ID: 27415

LSR type: Ingress Direction: Unidirectional

Setup priority: 7 Holding priority: 7

In-Label: - Out-Label: 1146

In-Interface: - Out-Interface: Vlan10

Nexthop: 10.1.1.2 Exclude-any: 0

Include-Any: 0 Include-all: 0

Mean rate (CIR): 20000 kbps Mean burst size (CBS): 1000.00 bytes

Path MTU: 1500 Class type: CT0

RRO number: 6

10.1.1.1/32 Flag: 0x00 (No FRR)

10.1.1.2/32 Flag: 0x00 (No FRR)

2.2.2.2/32 Flag: 0x20 (No FRR/Node-ID)

20.1.1.2/32 Flag: 0x00 (No FRR)

20.1.1.4/32 Flag: 0x00 (No FRR)

4.4.4.4/32 Flag: 0x20 (No FRR/Node-ID)

Fast Reroute protection: None

Tunnel name: SwitchA_t2

Destination: 4.4.4.4 Source: 1.1.1.1

Tunnel ID: 2 LSP ID: 27302

LSR type: Ingress Direction: Unidirectional

Setup priority: 7 Holding priority: 7

In-Label: - Out-Label: 1150

In-Interface: - Out-Interface: Vlan30

Nexthop: 30.1.1.3 Exclude-any: 0

Include-Any: 0 Include-all: 0

Mean rate (CIR): 30000 kbps Mean burst size (CBS): 1000.00 bytes

Path MTU: 1500 Class type: CT0

RRO number: 6

30.1.1.1/32 Flag: 0x00 (No FRR)

30.1.1.3/32 Flag: 0x00 (No FRR)

3.3.3.3/32 Flag: 0x20 (No FRR/Node-ID)

40.1.1.3/32 Flag: 0x00 (No FRR)

40.1.1.4/32 Flag: 0x00 (No FRR)

4.4.4.4/32 Flag: 0x20 (No FRR/Node-ID)

Fast Reroute protection: None

Configuration files

· Switch A:

ospf 1

area 0.0.0.0

network 1.1.1.1 0.0.0.0

network 10.1.1.0 0.0.0.255

network 30.1.1.0 0.0.0.255

mpls te enable

mpls lsr-id 1.1.1.1

vlan 10

vlan 30

vlan 70

vlan 80

mpls te

rsvp

interface LoopBack0

ip address 1.1.1.1 255.255.255.255

interface Vlan-interface10

ip address 10.1.1.1 255.255.255.0

mpls enable

mpls te enable

mpls te max-link-bandwidth 50000

mpls te max-reservable-bandwidth 40000

rsvp enable

interface Vlan-interface30

ip address 30.1.1.1 255.255.255.0

mpls enable

mpls te enable

mpls te max-link-bandwidth 50000

mpls te max-reservable-bandwidth 40000

rsvp enable

interface Vlan-interface70

ip address 70.1.1.1 255.255.255.0

interface Vlan-interface80

ip address 80.1.1.1 255.255.255.0

interface HundredGigE1/0/1

port link-mode bridge

port access vlan 10

interface HundredGigE1/0/2

port link-mode bridge

port access vlan 30

interface HundredGigE1/0/3

port link-mode bridge

port access vlan 70

interface HundredGigE1/0/4

port link-mode bridge

port access vlan 80

interface Tunnel1 mode mpls-te

ip address 7.1.1.1 255.255.255.0

mpls te bandwidth ct0 20000

mpls te record-route

destination 4.4.4.4

interface Tunnel2 mode mpls-te

ip address 8.1.1.1 255.255.255.0

mpls te bandwidth ct0 30000

mpls te record-route

destination 4.4.4.4

ip route-static 50.1.1.0 24 Tunnel1 preference 1

ip route-static 60.1.1.0 24 Tunnel2 preference 1

· Switch B:

ospf 1

area 0.0.0.0

network 2.2.2.2 0.0.0.0

network 10.1.1.0 0.0.0.255

network 20.1.1.0 0.0.0.255

mpls te enable

mpls lsr-id 2.2.2.2

vlan 10

vlan 20

mpls te

rsvp

interface LoopBack0

ip address 2.2.2.2 255.255.255.255

interface Vlan-interface10

ip address 10.1.1.2 255.255.255.0

mpls enable

mpls te enable

mpls te max-link-bandwidth 50000

mpls te max-reservable-bandwidth 40000

rsvp enable

interface Vlan-interface20

ip address 20.1.1.2 255.255.255.0

mpls enable

mpls te enable

mpls te max-link-bandwidth 50000

mpls te max-reservable-bandwidth 40000

rsvp enable

interface HundredGigE1/0/1

port link-mode bridge

port access vlan 10

interface HundredGigE1/0/2

port link-mode bridge

port access vlan 20

· Switch C:

ospf 1

area 0.0.0.0

network 3.3.3.3 0.0.0.0

network 30.1.1.0 0.0.0.255

network 40.1.1.0 0.0.0.255

mpls te enable

mpls lsr-id 3.3.3.3

vlan 30

vlan 40

mpls te

rsvp

interface LoopBack0

ip address 3.3.3.3 255.255.255.0

interface Vlan-interface30

ip address 30.1.1.3 255.255.255.0

mpls enable

mpls te enable

mpls te max-link-bandwidth 50000

mpls te max-reservable-bandwidth 40000

rsvp enable

interface Vlan-interface40

ip address 40.1.1.3 255.255.255.0

mpls enable

mpls te enable

mpls te max-link-bandwidth 50000

mpls te max-reservable-bandwidth 40000

rsvp enable

interface HundredGigE1/0/1

port link-mode bridge

port access vlan 40

interface HundredGigE1/0/2

port link-mode bridge

port access vlan 30

· Switch D:

ospf 1

area 0.0.0.0

network 4.4.4.4 0.0.0.0

network 20.1.1.0 0.0.0.255

network 40.1.1.0 0.0.0.255

mpls te enable

mpls lsr-id 4.4.4.4

vlan 20

vlan 40

vlan 50

vlan 60

mpls te

rsvp

interface LoopBack0

ip address 4.4.4.4 255.255.255.255

interface Vlan-interface20

ip address 20.1.1.4 255.255.255.0

mpls enable

mpls te enable

mpls te max-link-bandwidth 50000

mpls te max-reservable-bandwidth 40000

rsvp enable

interface Vlan-interface40

ip address 40.1.1.4 255.255.255.0

mpls enable

mpls te enable

mpls te max-link-bandwidth 50000

mpls te max-reservable-bandwidth 40000

rsvp enable

interface Vlan-interface50

ip address 50.1.1.4 255.255.255.0

interface Vlan-interface60

ip address 60.1.1.4 255.255.255.0

interface HundredGigE1/0/1

port link-mode bridge

port access vlan 40

interface HundredGigE1/0/2

port link-mode bridge

port access vlan 20

interface HundredGigE1/0/3

port link-mode bridge

port access vlan 50

interface HundredGigE1/0/4

port link-mode bridge

port access vlan 60

Example: Configuring MPLS TE forwarding adjacency

Network configuration

As shown in Figure 2, Device A, Device B, Device C, and Device D run OSPF.

Establish an MPLS TE tunnel from Device B to Device D that uses the path Device B—Device C—Device D, and configure MPLS TE forwarding adjacency for the tunnel.

Before the tunnel is established, traffic from Device A to Device D is forwarded through the direct link Device A—Device D. After the tunnel is established, the traffic is forwarded through the MPLS TE tunnel.

Figure 2 Network diagram

Analysis

· Enable MPLS TE on nodes and interfaces that the MPLS TE tunnels traverse.

· To make forwarding adjacency take effect, you must establish two MPLS TE tunnels in opposite directions between Device B and Device D, and enable forwarding adjacency on both devices.

· For the MPLS TE tunnel to use the path Device B—Device C—Device D, configure the path as the explicit path for the tunnel.

· For traffic from Device A to Device D to be forwarded through the MPLS TE tunnel, make sure the tunnel's metric is less than 15 (metric 25 minus 10). This example uses 12.

Applicable hardware and software versions

The following matrix shows the hardware and software versions to which this configuration example is applicable:

Hardware	Software version
S6805 switch series	Release 6607, Release 6616, Release 6616P01, Release 6635 and later
S6825 switch series	Release 6616, Release 6616P01, Release 6635 and later
S6850 switch series S9850 switch series	Release 6555P01, Release 6607, Release 6616, Release 6616P01, Release 6635 and later
S9820-64H switch	Release 6555P01, Release 6607, Release 6616, Release 6616P01, Release 6635 and later
S9820-8C switch	Not supported

Procedures

1. Configure IP addresses for interfaces, configure basic OSPF, and set OSPF costs. (Details not shown.) For the configuration, see "Configuration files."

2. Enable MPLS TE on each node and interface that the MPLS TE tunnel traverses:

# On Device B, configure an LSR ID, and enable MPLS, MPLS TE, and RSVP-TE.

<DeviceB> system-view

[DeviceB] mpls lsr-id 2.2.2.2

[DeviceB] mpls te

[DeviceB-te] quit

[DeviceB] rsvp

[DeviceB-rsvp] quit

[DeviceB] interface vlan-interface 23

[DeviceB-Vlan-interface23] mpls enable

[DeviceB-Vlan-interface23] mpls te enable

[DeviceB-Vlan-interface23] rsvp enable

[DeviceB-Vlan-interface23] quit

# On Device C, configure an LSR ID, and enable MPLS, MPLS TE, and RSVP-TE.

<DeviceC> system-view

[DeviceC] mpls lsr-id 3.3.3.3

[DeviceC] mpls te

[DeviceC-te] quit

[DeviceC] rsvp

[DeviceC-rsvp] quit

[DeviceC] interface vlan-interface 23

[DeviceC-Vlan-interface23] mpls enable

[DeviceC-Vlan-interface23] mpls te enable

[DeviceC-Vlan-interface23] rsvp enable

[DeviceC-Vlan-interface23] quit

[DeviceC] interface vlan-interface 34

[DeviceC-Vlan-interface34] mpls enable

[DeviceC-Vlan-interface34] mpls te enable

[DeviceC-Vlan-interface34] rsvp enable

[DeviceC-Vlan-interface34] quit

# On Device D, configure an LSR ID, and enable MPLS, MPLS TE, and RSVP-TE.

<DeviceD> system-view

[DeviceD] mpls lsr-id 4.4.4.4

[DeviceD] mpls te

[DeviceD-te] quit

[DeviceD] rsvp

[DeviceD-rsvp] quit

[DeviceD] interface vlan-interface 34

[DeviceD-Vlan-interface34] mpls enable

[DeviceD-Vlan-interface34] mpls te enable

[DeviceD-Vlan-interface34] rsvp enable

[DeviceD-Vlan-interface34] quit

3. Configure OSPF TE to advertise link TE attributes:

# On Device B, enable opaque LSA advertisement and reception, and enable MPLS TE for OSPF area 0. By default, opaque LSA advertisement and reception are enabled.

[DeviceB] ospf

[DeviceB-ospf-1] opaque-capability enable

[DeviceB-ospf-1] area 0

[DeviceB-ospf-1-area-0.0.0.0] mpls te enable

[DeviceB-ospf-1-area-0.0.0.0] quit

[DeviceB-ospf-1] quit

# On Device C, enable opaque LSA advertisement and reception, and enable MPLS TE for OSPF area 0. By default, opaque LSA advertisement and reception are enabled.

[DeviceC] ospf

[DeviceC-ospf-1] opaque-capability enable

[DeviceC-ospf-1] area 0

[DeviceC-ospf-1-area-0.0.0.0] mpls te enable

[DeviceC-ospf-1-area-0.0.0.0] quit

[DeviceC-ospf-1] quit

# On Device D, enable opaque LSA advertisement and reception, and enable MPLS TE for OSPF area 0. By default, opaque LSA advertisement and reception are enabled.

[DeviceD] ospf

[DeviceD-ospf-1] opaque-capability enable

[DeviceD-ospf-1] area 0

[DeviceD-ospf-1-area-0.0.0.0] mpls te enable

[DeviceD-ospf-1-area-0.0.0.0] quit

[DeviceD-ospf-1] quit

4. Configure MPLS TE tunnels:

# On Device B, configure MPLS TE tunnel interface Tunnel 1, and specify the tunnel destination address as the LSR ID of Device D.

[DeviceB] interface tunnel 1 mode mpls-te

[DeviceB-Tunnel1] ip address 9.2.2.2 255.255.255.0

[DeviceB-Tunnel1] destination 4.4.4.4

# Configure MPLS TE to use RSVP-TE to establish the tunnel.

[DeviceB-Tunnel1] mpls te signaling rsvp-te

[DeviceB-Tunnel1] quit

# Configure an explicit path named tun1.

[DeviceB] explicit-path tun1

[DeviceB-explicit-path-tun1] nexthop 23.23.23.3

[DeviceB-explicit-path-tun1] nexthop 34.34.34.4

[DeviceB-explicit-path-tun1]quit

# Specify explicit path tun1 for the tunnel.

[DeviceB] interface tunnel 1

[DeviceB–Tunnel1] mpls te path preference 1 explicit-path tun1

# Enable forwarding adjacency for the tunnel.

[DeviceB-Tunnel1] mpls te igp advertise

# Enable OSPF on tunnel interface Tunnel 1 and set the OSPF cost to 12 for the tunnel interface.

[DeviceB-Tunnel1] ospf 1 area 0

[DeviceB-Tunnel1] ospf cost 12

[DeviceB-Tunnel1] quit

# On Device D, configure MPLS TE tunnel interface Tunnel 1, and specify the tunnel destination address as the LSR ID of Device B.

[DeviceD] interface tunnel 1 mode mpls-te

[DeviceD-Tunnel1] ip address 9.2.2.4 255.255.255.0

[DeviceD-Tunnel1] destination 2.2.2.2

# Configure MPLS TE to use RSVP-TE to establish the tunnel.

[DeviceD-Tunnel1] mpls te signaling rsvp-te

[DeviceD-Tunnel1] quit

# Configure an explicit path named tun1.

[DeviceD] explicit-path tun1

[DeviceD-explicit-path-tun1] nexthop 34.34.34.3

[DeviceD-explicit-path-tun1] nexthop 23.23.23.2

[DeviceD-explicit-path-tun1]quit

# Specify explicit path tun1 for the tunnel.

[DeviceD] interface tunnel 1

[DeviceD–Tunnel1] mpls te path preference 1 explicit-path tun1

# Enable forwarding adjacency for the tunnel.

[DeviceD-Tunnel1] mpls te igp advertise

# Enable OSPF on tunnel interface Tunnel 1 and set the OSPF cost to 12 for the tunnel interface.

[DeviceD-Tunnel1] ospf 1 area 0

[DeviceD-Tunnel1] ospf cost 12

[DeviceD-Tunnel1] quit

Verifying the configuration

# Execute the display interface tunnel brief command on Device B and Device D. This example uses Device B. The output shows that Tunnel 1 is up.

[DeviceB] display interface tunnel brief

Brief information on interfaces in route mode:

Link: ADM - administratively down; Stby - standby

Protocol: (s) - spoofing

Interface Link Protocol Primary IP Description

Tun1 UP UP 9.2.2.2

# Display routing table information on Device A. The output shows that the next hop of the route to Device D is Device B, and the cost is 22 (10 plus 12). The MPLS TE tunnel has been used during IGP route calculation.

[Device A] display ip routing-table

Destinations : 22 Routes : 22

Destination/Mask Proto Pre Cost NextHop Interface

0.0.0.0/32 Direct 0 0 127.0.0.1 InLoop0

1.1.1.1/32 Direct 0 0 127.0.0.1 InLoop0

2.2.2.2/32 O_INTRA 10 10 12.12.12.2 Vlan12

3.3.3.3/32 O_INTRA 10 20 12.12.12.2 Vlan12

4.4.4.4/32 O_INTRA 10 22 12.12.12.2 Vlan12

9.2.2.0/24 O_INTRA 10 22 12.12.12.2 Vlan12

10.1.0.3/32 Direct 0 0 127.0.0.1 InLoop0

12.12.12.0/24 Direct 0 0 12.12.12.1 Vlan12

12.12.12.0/32 Direct 0 0 12.12.12.1 Vlan12

12.12.12.1/32 Direct 0 0 127.0.0.1 InLoop0

12.12.12.255/32 Direct 0 0 12.12.12.1 Vlan12

14.14.14.0/24 Direct 0 0 14.14.14.1 Vlan14

14.14.14.0/32 Direct 0 0 14.14.14.1 Vlan14

14.14.14.1/32 Direct 0 0 127.0.0.1 InLoop0

14.14.14.255/32 Direct 0 0 14.14.14.1 Vlan14

23.23.23.0/24 O_INTRA 10 20 12.12.12.2 Vlan12

34.34.34.0/24 O_INTRA 10 30 12.12.12.2 Vlan12

127.0.0.0/8 Direct 0 0 127.0.0.1 InLoop0

127.0.0.0/32 Direct 0 0 127.0.0.1 InLoop0

127.0.0.1/32 Direct 0 0 127.0.0.1 InLoop0

127.255.255.255/32 Direct 0 0 127.0.0.1 InLoop0

255.255.255.255/32 Direct 0 0 127.0.0.1 InLoop0

Configuration files

· Device A:

ospf 1

area 0.0.0.0

network 1.1.1.1 0.0.0.0

network 12.12.12.0 0.0.0.255

network 14.14.14.0 0.0.0.255

vlan 12

vlan 14

interface LoopBack0

ip address 1.1.1.1 255.255.255.255

interface Vlan-interface12

ip address 12.12.12.1 255.255.255.0

ospf cost 10

interface Vlan-interface14

ip address 14.14.14.1 255.255.255.0

ospf cost 25

interface HundredGigE1/0/1

port link-mode bridge

port access vlan 12

interface HundredGigE1/0/2

port link-mode bridge

port access vlan 14

· Device B:

ospf 1

area 0.0.0.0

network 2.2.2.2 0.0.0.0

network 12.12.12.0 0.0.0.255

network 23.23.23.0 0.0.0.255

mpls te enable

mpls lsr-id 2.2.2.2

vlan 12

vlan 23

mpls te

explicit-path tun1

nexthop index 1 23.23.23.3 include strict

nexthop index 101 34.34.34.4 include strict

rsvp

interface LoopBack0

ip address 2.2.2.2 255.255.255.255

interface Vlan-interface12

ip address 12.12.12.2 255.255.255.0

ospf cost 10

interface Vlan-interface23

ip address 23.23.23.2 255.255.255.0

ospf cost 10

mpls enable

mpls te enable

rsvp enable

interface HundredGigE1/0/1

port link-mode bridge

port access vlan 12

interface HundredGigE1/0/2

port link-mode bridge

port access vlan 23

interface Tunnel1 mode mpls-te

ip address 9.2.2.2 255.255.255.0

ospf cost 12

ospf 1 area 0.0.0.0

mpls te path preference 1 explicit-path tun1

mpls te igp advertise

destination 4.4.4.4

· Device C:

ospf 1

area 0.0.0.0

network 3.3.3.3 0.0.0.0

network 23.23.23.0 0.0.0.255

network 34.34.34.0 0.0.0.255

mpls te enable

mpls lsr-id 3.3.3.3

vlan 23

vlan 34

mpls te

rsvp

interface LoopBack0

ip address 3.3.3.3 255.255.255.255

interface Vlan-interface23

ip address 23.23.23.3 255.255.255.0

ospf cost 10

mpls enable

mpls te enable

rsvp enable

interface Vlan-interface34

ip address 34.34.34.3 255.255.255.0

ospf cost 10

mpls enable

mpls te enable

rsvp enable

interface HundredGigE1/0/1

port link-mode bridge

port access vlan 34

interface HundredGigE1/0/2

port link-mode bridge

port access vlan 23

· Device D:

ospf 1

area 0.0.0.0

network 4.4.4.4 0.0.0.0

network 14.14.14.0 0.0.0.255

network 34.34.34.0 0.0.0.255

mpls te enable

mpls lsr-id 4.4.4.4

vlan 14

vlan 34

mpls te

explicit-path tun1

nexthop index 1 34.34.34.3 include strict

nexthop index 101 23.23.23.2 include strict

rsvp

interface LoopBack0

ip address 4.4.4.4 255.255.255.255

interface Vlan-interface14

ip address 14.14.14.4 255.255.255.0

ospf cost 25

interface Vlan-interface34

ip address 34.34.34.4 255.255.255.0

ospf cost 10

mpls enable

mpls te enable

rsvp enable

interface HundredGigE1/0/1

port link-mode bridge

port access vlan 34

interface HundredGigE1/0/2

port link-mode bridge

port access vlan 14

interface Tunnel1 mode mpls-te

ip address 9.2.2.4 255.255.255.0

ospf cost 12

ospf 1 area 0.0.0.0

mpls te path preference 1 explicit-path tun1

mpls te igp advertise

destination 2.2.2.2

H3C S6805 & S6825 & S6850 & S9850 & S9820 Config Examples-Release 66xx-6W100

Introduction

Prerequisites

Example: Establishing MPLS TE tunnels with RSVP-TE

Network configuration

Analysis

Applicable hardware and software versions

Restrictions and guidelines

Procedures

Verifying the configuration

Configuration files

Example: Configuring MPLS TE forwarding adjacency

Network configuration

Analysis

Applicable hardware and software versions

Procedures

Verifying the configuration

Configuration files

Related documentation

Cloud & AI

InterConnect

Intelligent Computing

Security

SMB Products

Intelligent Terminal Products

Industry Solutions

Product Support Services

Technical Service Solutions

Resource Center

Policy

Online Help

Training & Certification

Become a Partner

Partner Resources

Partner Business Management

Company Information

News & Events

Online Exhibition Center

Contact Us
