H3C Access Controllers
Static Blacklist Configuration Examples





























































































Contents

Introduction· 1

Prerequisites· 1

Example: Configuring the WLAN static blacklist 1

Network configuration· 1

Restrictions and guidelines· 1

Procedures· 1

Configuring the AC· 1

Configuring the switch· 3

Verifying the configuration· 4

Configuration files· 4

Related documentation· 6



Introduction

The following information provides an example for configuring the WLAN static blacklist.

Prerequisites

This document applies to Comware-based access controllers and access points. Procedures and information in the examples might be slightly different depending on the software or hardware version of the access controllers and access points.

The configuration examples in this document were created and verified in a lab environment, and all the devices were started with the factory default configuration. When you are working on a live network, make sure you understand the potential impact of every command on your network.

This document assumes that you have basic knowledge of WLAN static blacklists.

Example: Configuring the WLAN static blacklist

Network configuration

As shown in Figure 1, the switch acts as a DHCP server to assign IP addresses to the AP and the clients, and the AC forwards client traffic. Client 1 is a rogue client. Configure the static blacklist to deny Client 1's access to the WLAN.

Figure 1 Network diagram



Restrictions and guidelines

Use the serial ID labeled on the AP's rear panel to specify an AP.

Procedures

Configuring the AC

1.     Configure AC interfaces:

# Create VLAN 100 and VLAN-interface 100, and assign an IP address to the VLAN interface. The AC will use this IP address to establish a CAPWAP tunnel with the AP.

<AC> system-view

[AC] vlan 100

[AC-vlan100] quit

[AC] interface vlan-interface 100

[AC-Vlan-interface100] ip address 192.1.0.1 16

[AC-Vlan-interface100] quit

# Create VLAN 200 and VLAN-interface 200, and assign an IP address to the VLAN interface. Clients will use this VLAN to access the WLAN.

[AC] vlan 200

[AC-vlan200] quit

[AC] interface vlan-interface 200

[AC-Vlan-interface200] ip address 192.2.0.1 24

[AC-Vlan-interface200] quit

# Configure GigabitEthernet 1/0/1 that connects the AC to the switch as a trunk port, and assign the port to VLANs 1, 100, and 200.

[AC] interface gigabitethernet 1/0/1

[AC-GigabitEthernet1/0/1] port link-type trunk

[AC-GigabitEthernet1/0/1] port trunk permit vlan 1 100 200

[AC-GigabitEthernet1/0/1] quit

2.     Configure wireless services:

# Create service template service and enter its view.

[AC] wlan service-template service

# Configure the SSID as service.

[AC-wlan-st-service] ssid service

# Specify VLAN 200 for clients to access the WLAN defined by the service template.

[AC-wlan-st-service] vlan 200

# Set the AKM mode to PSK and specify plaintext string 12345678 as the preshared key.

[AC-wlan-st-service] akm mode psk

[AC-wlan-st-service] preshared-key pass-phrase simple 12345678

# Specify the cipher suite as CCMP and the security IE as RSN.

[AC-wlan-st-service] cipher-suite ccmp

[AC-wlan-st-service] security-ie rsn

# Configure the AC to forward client data traffic. You can skip this step if the AC is the client traffic forwarder by default.

[AC-wlan-st-service] client forwarding-location ac

# Enable the service template.

[AC-wlan-st-service] service-template enable

[AC-wlan-st-service] quit

3.     Configure the AP:



NOTE: In large-scale networks, configure AP groups instead of single APs as a best practice.



# Create manual AP officeap, and specify the AP model and serial ID.

[AC] wlan ap officeap model WA6320

[AC-wlan-ap-officeap] serial-id 219801A28N819CE0002T

# Create AP group group1, add the AP to the AP group, and specify the AP model.

[AC] wlan ap-group group1

[AC-wlan-ap-group-group1] ap officeap

[AC-wlan-ap-group-group1] ap-model WA6320

# Bind service template service to radio 1.

[AC-wlan-ap-group-group1-ap-model-WA6320] radio 1

[AC-wlan-ap-group-group1-ap-model-WA6320-radio-1] service-template service

# Enable radio 1.

[AC-wlan-ap-group-group1-ap-model-WA6320-radio-1] radio enable

[AC-wlan-ap-group-group1-ap-model-WA6320-radio-1] quit

[AC-wlan-ap-group-group1-ap-model-WA6320] quit

[AC-wlan-ap-group-group1] quit

4.     Add Client 1 to the static blacklist.

[AC] wlan static-blacklist mac-address 0000-000f-1211

Configuring the switch

1.     Configure switch interfaces:

# Create VLAN 100 and VLAN-interface 100, and assign an IP address to the VLAN interface. The switch will use VLAN 100 to forward packets between the AC and the AP.

<Switch> system-view

[Switch] vlan 100

[Switch-vlan100] quit

[Switch] interface vlan-interface 100

[Switch-Vlan-interface100] ip address 192.1.0.2 16

[Switch-Vlan-interface100] quit

# Create VLAN 200 and VLAN-interface 200, and assign an IP address to the VLAN interface. The switch will use VLAN 200 to forward client traffic.

[Switch] vlan 200

[Switch-vlan200] quit

[Switch] interface vlan-interface 200

[Switch-Vlan-interface200] ip address 192.2.0.2 24

[Switch-Vlan-interface200] quit

# Configure GigabitEthernet 1/0/1 that connects the switch to the AC as a trunk port, and assign the port to VLANs 1, 100, and 200.

[Switch] interface gigabitethernet 1/0/1

[Switch-GigabitEthernet1/0/1] port link-type trunk

[Switch-GigabitEthernet1/0/1] port trunk permit vlan 1 100 200

[Switch-GigabitEthernet1/0/1] quit

# Configure GigabitEthernet 1/0/2 that connects the switch to the AP as an access port, and assign the port to VLAN 100.

[Switch] interface gigabitethernet 1/0/2

[Switch-GigabitEthernet1/0/2] port link-type access

[Switch-GigabitEthernet1/0/2] port access vlan 100

# Enable PoE on GigabitEthernet 1/0/2.

[Switch-GigabitEthernet1/0/2] poe enable

[Switch-GigabitEthernet1/0/2] quit

2.     Configure DHCP:

# Enable DHCP.

[Switch] dhcp enable

# Create DHCP address pool 100 to assign an IP address to the AP, and specify subnet 192.1.0.0/16 in the DHCP address pool.

[Switch] dhcp server ip-pool 100

[Switch-dhcp-pool-100] network 192.1.0.0 mask 255.255.0.0

# Specify the gateway address as 192.1.0.1 in the DHCP address pool.

[Switch-dhcp-pool-100] gateway-list 192.1.0.1

[Switch-dhcp-pool-100] quit

# Create DHCP address pool 200 to assign IP addresses to clients, and specify subnet 192.2.0.0/24 in the DHCP address pool.

[Switch] dhcp server ip-pool 200

[Switch-dhcp-pool-200] network 192.2.0.0 mask 255.255.255.0

# Specify the gateway address as 192.2.0.1 and specify the DNS server address in the DHCP address pool. In this example, the gateway also acts as the DNS server.

[Switch-dhcp-pool-200] gateway-list 192.2.0.1

[Switch-dhcp-pool-200] dns-list 192.2.0.1

[Switch-dhcp-pool-200] quit

Verifying the configuration

# Verify that the MAC address of Client 1 is in the static blacklist.

[AC] display wlan blacklist static

Total number of clients: 1

 MAC addresses:

  0000-000f-1211

# Verify that only Client 2 is associated with the AP successfully.

[AC] display wlan client

Total number of clients: 1



MAC address     Username   AP name      RID   IP address      IPv6 address   VLAN

0000-000f-1212  N/A        officeap     1     192.2.0.3       N/A            200

Configuration files

·     AC:

#

vlan 1

#

vlan 100

#

vlan 200

#

wlan service-template service

 ssid service

 vlan 200

akm mode psk

preshared-key pass-phrase simple 12345678

cipher-suite ccmp

security-ie rsn

client forwarding-location ac

service-template enable

#

interface Vlan-interface100

 ip address 192.1.0.1 255.255.0.0

#

interface Vlan-interface200

 ip address 192.2.0.1 255.255.255.0

#

interface GigabitEthernet1/0/1

 port link-type trunk

 port trunk permit vlan 1 100 200

#

wlan ap officeap model WA6320

 serial-id 219801A28N819CE0002T

#

wlan ap-group group1

ap officeap

ap-model WA6320

radio 1

service-template service

radio enable

#

wlan static-blacklist mac-address 0000-000f-1211

#

·     Switch:

#

vlan 1

#

vlan 100

#

vlan 200

#

dhcp server ip-pool 100

 gateway-list 192.1.0.1

 network 192.1.0.0 mask 255.255.0.0

#

dhcp server ip-pool 200

 gateway-list 192.2.0.1

 network 192.2.0.0 mask 255.255.255.0

 dns-list 192.2.0.1

#

interface Vlan-interface100

 ip address 192.1.0.2 255.255.0.0

#

interface Vlan-interface200

 ip address 192.2.0.2 255.255.255.0

#

interface GigabitEthernet1/0/1

 port link-type trunk

 port trunk permit vlan 1 100 200

#

interface GigabitEthernet1/0/2

 port link-type access

 port access permit vlan 100

 poe enable

#

Related documentation

·     WLAN Access Command Reference in H3C Access Controllers Command References

·     WLAN Access Configuration Guide in H3C Access Controllers Configuration Guides
