Campus border gateway configuration summary

On the egress of a large-scaled campus, the routers  are directly connected to firewalls, and the firewalls are connected to the external network and data center. The firewalls provide security filtering for incoming and outgoing service traffic of the campus and assure network security. Within the campus, a user connects to the internal network through a wireless device, and the wireless device connects to the routers through devices on the access layer and core layer.

Prerequisites

The configuration examples were created and verified in a lab environment, and all the devices were started with the factory default configuration. When you are working on a live network, make sure you understand the potential impact of every command on your network.

This document assumes that you have basic knowledge of Open Shortest Path First (OSPF), Bidirectional Forwarding Detection (BFD), Virtual Router Redundancy Protocol (VRRP), Quality of Service (QoS), and Dynamic Host Configuration Protocol (DHCP).

Campus border gateway configuration example

Network configuration

This example describes how to configure the routers in the campus border gateway configuration scenario. Configure the network as follows:

·     Users in the campus use private IP addresses. The user IP addresses are managed and allocated by the DHCP server. The routers act as the DHCP relay agents.

·     Divide users into VIP users and non-VIP users, and configure different number of endpoints that can be accessed and different upper bandwidth limits for VIP users and non-VIP users. To meet this requirement, configure QoS on the routers.

·     To ensure network availability, deploy BFD on each device. Deploy VRRP groups that collaborate with BFD on the two routers, so that the gateway devices can automatically negotiate the master and backup roles to ensure that the routes are not interrupted.

As shown in Figure 1, routers Router A and Router B are gateway devices.

Figure 1 Campus border gateway configuration example



Analysis

·     Configure IP addresses for interfaces on the routers, firewalls, and switches.

·     Configure OSPF for interfaces on the routers, firewalls, and switches.

·     Configure BFD for OSPF on the routers, firewalls, and switches to ensure network availability.

·     Configure VRRP to collaborate with BFD on the routers to improve device availability.

·     Configure QoS and deploy traffic policies on the routers.

·     Configure the DHCP relay agent, and allocate and manage IP addresses on the routers.

Procedure

Configuring OSPF

Configuring basic OSPF functions

# Configure IP addresses for interfaces. (Details not shown.)

# Configure Router A.

<RouterA> system-view

[RouterA] router id 1.1.1.1

[RouterA] ospf

[RouterA-ospf-1] area 0

[RouterA-ospf-1-area-0.0.0.0] network 10.1.1.0 0.0.0.255

[RouterA-ospf-1-area-0.0.0.0] network 10.1.2.0 0.0.0.255

[RouterA-ospf-1-area-0.0.0.0] network 192.168.1.0 0.0.0.255

[RouterA-ospf-1-area-0.0.0.0] network 172.16.0.0 0.0.0.255

[RouterA-ospf-1-area-0.0.0.0] network 172.17.0.0 0.0.0.255

[RouterA-ospf-1-area-0.0.0.0] quit

# Configure Router B.

<RouterB> system-view

[RouterB] router id 2.2.2.2

[RouterB] ospf

[RouterB-ospf-1] area 0

[RouterB-ospf-1-area-0.0.0.0] network 10.1.1.0 0.0.0.255

[RouterB-ospf-1-area-0.0.0.0] network 10.1.2.0 0.0.0.255

[RouterB-ospf-1-area-0.0.0.0] network 192.168.1.0 0.0.0.255

[RouterB-ospf-1-area-0.0.0.0] network 172.16.0.0 0.0.0.255

[RouterB-ospf-1-area-0.0.0.0] network 172.17.0.0 0.0.0.255

[RouterB-ospf-1-area-0.0.0.0] quit

Configuring the network type and route costs on interfaces of the routers

# Configure Router A.

<RouterA> system-view

[RouterA] interface Ten-GigabitEthernet 3/1/1

[RouterA-Ten-GigabitEthernet3/1/1] ospf cost 10

[RouterA-Ten-GigabitEthernet3/1/1] ospf network-type p2p

[RouterA-Ten-GigabitEthernet3/1/1] quit

[RouterA] interface Ten-GigabitEthernet 3/1/2

[RouterA-Ten-GigabitEthernet3/1/2] ospf cost 2000

[RouterA-Ten-GigabitEthernet3/1/2] ospf network-type p2p

[RouterA-Ten-GigabitEthernet3/1/2] quit

[RouterA] interface Ten-GigabitEthernet 3/1/3

[RouterA-Ten-GigabitEthernet3/1/3] ospf cost 2000

[RouterA-Ten-GigabitEthernet3/1/3] ospf network-type p2p

[RouterA-Ten-GigabitEthernet3/1/3] quit

[RouterA] interface Ten-GigabitEthernet 3/1/4.1

[RouterA-Ten-GigabitEthernet3/1/4.1] ospf cost 2000

[RouterA-Ten-GigabitEthernet3/1/4.1] quit

[RouterA] interface Ten-GigabitEthernet 3/1/4.2

[RouterA-Ten-GigabitEthernet3/1/4.2] ospf cost 2000

[RouterA-Ten-GigabitEthernet3/1/4.2] quit

# Configure Router B.

<RouterB> system-view

[RouterB] interface Ten-GigabitEthernet 3/1/1

[RouterB-Ten-GigabitEthernet3/1/1] ospf cost 10

[RouterB-Ten-GigabitEthernet3/1/1] ospf network-type p2p

[RouterB-Ten-GigabitEthernet3/1/1] quit

[RouterB] interface Ten-GigabitEthernet 3/1/2

[RouterB-Ten-GigabitEthernet3/1/2] ospf cost 2000

[RouterB-Ten-GigabitEthernet3/1/2] ospf network-type p2p

[RouterB-Ten-GigabitEthernet3/1/2] quit

[RouterB] interface Ten-GigabitEthernet 3/1/3

[RouterB-Ten-GigabitEthernet3/1/3] ospf cost 2000

[RouterB-Ten-GigabitEthernet3/1/3] ospf network-type p2p

[RouterB-Ten-GigabitEthernet3/1/3] quit

[RouterB] interface Ten-GigabitEthernet 3/1/4.1

[RouterB-Ten-GigabitEthernet3/1/4.1] ospf cost 2000

[RouterB-Ten-GigabitEthernet3/1/4.1] quit

[RouterB] interface Ten-GigabitEthernet 3/1/4.2

[RouterB-Ten-GigabitEthernet3/1/4.2] ospf cost 2000

[RouterB-Ten-GigabitEthernet3/1/4.2] quit

Configuring BFD

Enabling BFD and configuring BFD parameters on Router A

[RouterA] bfd session init-mode active

[RouterA] interface Ten-GigabitEthernet 3/1/1

[RouterA-Ten-GigabitEthernet3/1/1] ospf bfd enable

[RouterA-Ten-GigabitEthernet3/1/1] bfd min-transmit-interval 100

[RouterA-Ten-GigabitEthernet3/1/1] bfd min-receive-interval 100

[RouterA-Ten-GigabitEthernet3/1/1] bfd detect-multiplier 3

[RouterA-Ten-GigabitEthernet3/1/1] quit

[RouterA] interface Ten-GigabitEthernet 3/1/2

[RouterA-Ten-GigabitEthernet3/1/2] ospf bfd enable

[RouterA-Ten-GigabitEthernet3/1/2] bfd min-transmit-interval 100

[RouterA-Ten-GigabitEthernet3/1/2] bfd min-receive-interval 100

[RouterA-Ten-GigabitEthernet3/1/2] bfd detect-multiplier 3

[RouterA-Ten-GigabitEthernet3/1/2] quit

[RouterA] interface Ten-GigabitEthernet 3/1/3

[RouterA-Ten-GigabitEthernet3/1/3] ospf bfd enable

[RouterA-Ten-GigabitEthernet3/1/3] bfd min-transmit-interval 100

[RouterA-Ten-GigabitEthernet3/1/3] bfd min-receive-interval 100

[RouterA-Ten-GigabitEthernet3/1/3] bfd detect-multiplier 3

[RouterA-Ten-GigabitEthernet3/1/3] quit

Enabling BFD and configuring BFD parameters on Router B

[RouterB] bfd session init-mode active

[RouterB] interface Ten-GigabitEthernet 3/1/1

[RouterB-Ten-GigabitEthernet3/1/1] ospf bfd enable

[RouterB-Ten-GigabitEthernet3/1/1] bfd min-transmit-interval 100

[RouterB-Ten-GigabitEthernet3/1/1] bfd min-receive-interval 100

[RouterB-Ten-GigabitEthernet3/1/1] bfd detect-multiplier 3

[RouterB-Ten-GigabitEthernet3/1/1] quit

[RouterB] interface Ten-GigabitEthernet 3/1/2

[RouterB-Ten-GigabitEthernet3/1/2] ospf bfd enable

[RouterB-Ten-GigabitEthernet3/1/2] bfd min-transmit-interval 100

[RouterB-Ten-GigabitEthernet3/1/2] bfd min-receive-interval 100

[RouterB-Ten-GigabitEthernet3/1/2] bfd detect-multiplier 3

[RouterB-Ten-GigabitEthernet3/1/2] quit

[RouterB] interface Ten-GigabitEthernet 3/1/3

[RouterB-Ten-GigabitEthernet3/1/3] ospf bfd enable

[RouterB-Ten-GigabitEthernet3/1/3] bfd min-transmit-interval 100

[RouterB-Ten-GigabitEthernet3/1/3] bfd min-receive-interval 100

[RouterB-Ten-GigabitEthernet3/1/3] bfd detect-multiplier 3

[RouterB-Ten-GigabitEthernet3/1/3] quit

Configuring VRRP

Configuring Router A

# Assign IP addresses to interfaces.

<RouterA> system-view

[RouterA] interface Ten-GigabitEthernet 3/1/4.1

[RouterA-Ten-GigabitEthernet3/1/4.1] ip address 172.16.0.9 255.255.255.0

[RouterA-Ten-GigabitEthernet3/1/4.1] quit

[RouterA] interface Ten-GigabitEthernet 3/1/4.2

[RouterA-Ten-GigabitEthernet3/1/4.2] ip address 172.17.0.9 255.255.255.0

[RouterA-Ten-GigabitEthernet3/1/4.2] quit

# Create VRRP group 1 and set its virtual IP address to 172.16.0.11.

<RouterA> system-view

[RouterA] interface Ten-GigabitEthernet 3/1/4.1

[RouterA-Ten-GigabitEthernet3/1/4.1] vrrp vrid 1 virtual-ip 172.16.0.11

# Set the priority of Router A to 110 in VRRP group 1, which is higher than the priority of Router B (100) in VRRP group 1. Therefore, Router A acts as the master device in VRRP group 1 to forward traffic.

[RouterA-Ten-GigabitEthernet3/1/4.1] vrrp vrid 1 priority 110

# Create VRRP group 2 and set its virtual IP address to 172.17.0.11.

<RouterA> system-view

[RouterA] interface Ten-GigabitEthernet 3/1/4.2

[RouterA-Ten-GigabitEthernet3/1/4.2] vrrp vrid 2 virtual-ip 172.17.0.11

Configuring Router B

# Assign IP addresses to interfaces.

<RouterB> system-view

[RouterB] interface Ten-GigabitEthernet 3/1/4.1

[RouterB-Ten-GigabitEthernet3/1/4.1] ip address 172.16.0.10 255.255.255.0

[RouterB-Ten-GigabitEthernet3/1/4.1] quit

[RouterB] interface Ten-GigabitEthernet 3/1/4.2

[RouterB-Ten-GigabitEthernet3/1/4.2] ip address 172.17.0.10 255.255.255.0

[RouterB-Ten-GigabitEthernet3/1/4.2] quit

# Create VRRP group 1 and set its virtual IP address to 172.16.0.11.

<RouterB> system-view

[RouterB] interface Ten-GigabitEthernet 3/1/4.1

[RouterB-Ten-GigabitEthernet3/1/4.1] vrrp vrid 1 virtual-ip 172.16.0.11

[RouterB-Ten-GigabitEthernet3/1/4.1] quit

# Create VRRP group 2 and set its virtual IP address to 172.17.0.11.

<RouterB> system-view

[RouterB] interface Ten-GigabitEthernet 3/1/4.2

[RouterB-Ten-GigabitEthernet3/1/4.2] vrrp vrid 2 virtual-ip 172.17.0.11

# Set the priority of Router B to 110 in VRRP group 2, which is higher than the priority of Router A (100) in VRRP group 2. Therefore, Router B acts as the master device in VRRP group 2 to forward traffic.

[RouterB-Ten-GigabitEthernet3/1/4.2] vrrp vrid 2 priority 110

Configuring QoS

Configuring ACLs on Router A

# Configure an ACL to match IP addresses of VIP users.

<RouterA> system-view

[RouterA] acl basic 2001

[RouterA-acl-ipv4-basic-2001] rule 1 permit source 172.16.0.0 0.0.255.255

[RouterA-acl-ipv4-basic-2001] quit

# Configure an ACL to match IP addresses of non-VIP users.

[RouterA] acl basic 2002

[RouterA-acl-ipv4-basic-2002] rule 1 permit source 172.17.0.0 0.0.255.255

[RouterA-acl-ipv4-basic-2002] quit

Configuring ACLs on Router B

# Configure an ACL to match IP addresses of VIP users.

<RouterB> system-view

[RouterB] acl basic 2001

[RouterB-acl-ipv4-basic-2001] rule 1 permit source 172.16.0.0 0.0.255.255

[RouterB-acl-ipv4-basic-2001] quit

# Configure an ACL to match IP addresses of non-VIP users.

[RouterB] acl basic 2002

[RouterB-acl-ipv4-basic-2002] rule 1 permit source 172.17.0.0 0.0.255.255

[RouterB-acl-ipv4-basic-2002] quit

Configuring traffic classes, traffic behaviors, and QoS policies on Router A

[RouterA] traffic classifier VIP

[RouterA-classifier-VIP] if-match acl 2001

[RouterA-classifier-VIP] quit

[RouterA] traffic classifier SIP

[RouterA-classifier-SIP] if-match acl 2002

[RouterA-classifier-SIP] quit

[RouterA] traffic behavior VIP

[RouterA-behavior-VIP] remark ip-precedence 5

[RouterA-behavior-VIP] quit

[RouterA] traffic behavior SIP

[RouterA-behavior-SIP] remark ip-precedence 4

[RouterA-behavior-SIP] quit

[RouterA] qos policy VIP

[RouterA-qospolicy-VIP] classifier VIP behavior VIP

[RouterA-qospolicy-VIP] quit

[RouterA] qos policy SIP

[RouterA-qospolicy-SIP] classifier SIP behavior SIP

[RouterA-qospolicy-SIP] quit

Configuring traffic classes, traffic behaviors, and QoS policies on Router B

[RouterB] traffic classifier VIP

[RouterB-classifier-VIP] if-match acl 2001

[RouterB-classifier-VIP] quit

[RouterB] traffic classifier SIP

[RouterB-classifier-SIP] if-match acl 2002

[RouterB-classifier-SIP] quit

[RouterB] traffic behavior VIP

[RouterB-behavior-VIP] remark ip-precedence 5

[RouterB-behavior-VIP] quit

[RouterB] traffic behavior SIP

[RouterB-behavior-SIP] remark ip-precedence 4

[RouterB-behavior-SIP] quit

[RouterB] qos policy VIP

[RouterB-qospolicy-VIP] classifier VIP behavior VIP

[RouterB-qospolicy-VIP] quit

[RouterB] qos policy SIP

[RouterB-qospolicy-SIP] classifier SIP behavior SIP

[RouterB-qospolicy-SIP] quit

Applying QoS policies in sharing mode to the subinterfaces connecting to service traffic on Router A

<RouterA> system-view

[RouterA] interface Ten-GigabitEthernet 3/1/4.1

[RouterA-Ten-GigabitEthernet3/1/4.1] qos apply policy VIP inbound share-mode

[RouterA-Ten-GigabitEthernet3/1/4.1] quit

[RouterA] interface Ten-GigabitEthernet 3/1/4.2

[RouterA-Ten-GigabitEthernet3/1/4.2] qos apply policy SIP inbound share-mode

[RouterA-Ten-GigabitEthernet3/1/4.2] quit

Applying QoS policies in sharing mode to the subinterfaces connecting to service traffic on Router B

<RouterB> system-view

[RouterB] interface Ten-GigabitEthernet 3/1/4.1

[RouterB-Ten-GigabitEthernet3/1/4.1] qos apply policy VIP inbound share-mode

[RouterB-Ten-GigabitEthernet3/1/4.1] quit

[RouterB] interface Ten-GigabitEthernet 3/1/4.2

[RouterB-Ten-GigabitEthernet3/1/4.2] qos apply policy SIP inbound share-mode

[RouterB-Ten-GigabitEthernet3/1/4.2] quit

Configuring user access

Configuring Router A

<RouterA> system-view

[RouterA] dhcp enable

[RouterA] interface Ten-GigabitEthernet 3/1/4.1

[RouterA-Ten-GigabitEthernet3/1/4.1] dhcp select relay

[RouterA-Ten-GigabitEthernet3/1/4.1] dhcp relay server-address 192.168.1.5

[RouterA-Ten-GigabitEthernet3/1/4.1] quit

[RouterA] interface Ten-GigabitEthernet 3/1/4.2

[RouterA-Ten-GigabitEthernet3/1/4.2] dhcp select relay

[RouterA-Ten-GigabitEthernet3/1/4.2] dhcp relay server-address 192.168.1.5

[RouterA-Ten-GigabitEthernet3/1/4.2] quit

Configuring Router B

<RouterB> system-view

[RouterB] dhcp enable

[RouterB] interface Ten-GigabitEthernet 3/1/4.1

[RouterB-Ten-GigabitEthernet3/1/4.1] dhcp select relay

[RouterB-Ten-GigabitEthernet3/1/4.1] dhcp relay server-address 192.168.1.5

[RouterB-Ten-GigabitEthernet3/1/4.1] quit

[RouterB] interface Ten-GigabitEthernet 3/1/4.2

[RouterB-Ten-GigabitEthernet3/1/4.2] dhcp select relay

[RouterB-Ten-GigabitEthernet3/1/4.2] dhcp relay server-address 192.168.1.5

[RouterB-Ten-GigabitEthernet3/1/4.2] quit

Verifying the configuration

# Display OSPF route information on Router A.

<RouterA> display ospf routing



         OSPF Process 1 with Router ID 1.1.1.1

                  Routing Table



                Topology base (MTID 0)



 Routing for network

 Destination        Cost     Type    NextHop         AdvRouter       Area

 10.1.2.0/24        2000     Stub    0.0.0.0         1.1.1.1         0.0.0.0

 10.1.1.0/24        10       Stub    0.0.0.0         1.1.1.1         0.0.0.0

 192.168.1.0/24     2000     Stub    0.0.0.0         1.1.1.1         0.0.0.0



 Total nets: 3

 Intra area: 3  Inter area: 0  ASE: 0  NSSA: 0

# Display OSPF route information on Router B.

<RouterB> display ospf routing



         OSPF Process 1 with Router ID 2.2.2.2

                  Routing Table



                Topology base (MTID 0)



 Routing for network

 Destination        Cost     Type    NextHop         AdvRouter       Area

 10.1.2.0/24        2010     Stub    10.1.1.1        1.1.1.1         0.0.0.0

 10.1.1.0/24        10       Stub    0.0.0.0         2.2.2.2         0.0.0.0

 192.168.1.0/24     2000     Stub    0.0.0.0         2.2.2.2         0.0.0.0



 Total nets: 3

 Intra area: 3  Inter area: 0  ASE: 0  NSSA: 0

# Display BFD session information on Router A.

<RouterA> display bfd session

 Total sessions: 1        Up sessions: 1        Init mode: Active



 IPv4 session working in control packet mode:



 LD/RD           SourceAddr      DestAddr        State   Holdtime    Interface

 33793/33793     10.1.1.1        10.1.1.2        Up      294ms       XGE3/1/1

# Display BFD session information on Router B.

<RouterB> display bfd session

 Total sessions: 1        Up sessions: 1        Init mode: Active



 IPv4 session working in control packet mode:



 LD/RD           SourceAddr      DestAddr        State   Holdtime    Interface

 33793/33793     10.1.1.2        10.1.1.1        Up      267ms       XGE3/1/1

# Display VRRP group state information on Router A.

<RouterA> display vrrp

IPv4 virtual router information:

 Running mode : Standard

 Total number of virtual routers : 2

 Interface          VRID  State       Running Adver     Auth    Virtual

                                      pri     timer(cs) type    IP

 ---------------------------------------------------------------------

 XGE3/1/4.1         1     Master      110     100       None    172.16.0.11

 XGE3/1/4.2         2     Backup      100     100       None    172.17.0.11

# Display VRRP group state information on Router B.

<RouterB> display vrrp

IPv4 virtual router information:

 Running mode : Standard

 Total number of virtual routers : 2

 Interface          VRID  State       Running Adver     Auth    Virtual

                                      pri     timer(cs) type    IP

 ---------------------------------------------------------------------

 XGE3/1/4.1         1     Backup      100     100       None    172.16.0.11

 XGE3/1/4.2         2     Master      110     100       None    172.17.0.11

Configuration files

·     Router A:

#

 router id 1.1.1.1

#

ospf 1

 area 0.0.0.0

  network 10.1.1.0 0.0.0.255

  network 10.1.2.0 0.0.0.255

  network 172.16.0.0 0.0.0.255

  network 172.17.0.0 0.0.0.255

  network 192.168.1.0 0.0.0.255

#

 dhcp enable

#

traffic classifier SIP operator and

 if-match acl 2002

#

traffic classifier VIP operator and

 if-match acl 2001

#

traffic behavior SIP

 remark ip-precedence 4

#

traffic behavior VIP

 remark ip-precedence 5

#

qos policy SIP

 classifier SIP behavior SIP

#

qos policy VIP

 classifier VIP behavior VIP

#

interface LoopBack0

 ip address 1.1.1.1 255.255.255.0

#

interface Ten-GigabitEthernet3/1/1

 ip address 10.1.1.1 255.255.255.0

 ospf cost 10

 ospf network-type p2p

 ospf bfd enable

 bfd min-transmit-interval 100

 bfd min-receive-interval 100

 bfd detect-multiplier 3

#

interface Ten-GigabitEthernet3/1/2

 ip address 10.1.2.1 255.255.255.0

 ospf cost 2000

 ospf network-type p2p

 ospf bfd enable

 bfd min-transmit-interval 100

 bfd min-receive-interval 100

 bfd detect-multiplier 3

#

interface Ten-GigabitEthernet3/1/3

 ip address 192.168.1.1 255.255.255.0

 ospf cost 2000

 ospf network-type p2p

 ospf bfd enable

 bfd min-transmit-interval 100

 bfd min-receive-interval 100

 bfd detect-multiplier 3

#

interface Ten-GigabitEthernet3/1/4.1

 ip address 172.16.0.9 255.255.255.0

 ospf cost 2000

 vrrp vrid 1 virtual-ip 172.16.0.11

 vrrp vrid 1 priority 110

 qos apply policy SIP inbound share-mode

 dhcp select relay

 dhcp relay server-address 192.168.1.5

#

interface Ten-GigabitEthernet3/1/4.2

 ip address 172.17.0.9 255.255.255.0

 ospf cost 2000

 vrrp vrid 2 virtual-ip 172.17.0.11

 qos apply policy VIP inbound share-mode

 dhcp select relay

 dhcp relay server-address 192.168.1.5

#

acl basic 2001

 rule 1 permit source 172.16.0.0 0.0.255.255

#

acl basic 2002

 rule 1 permit source 172.17.0.0 0.0.255.255

·     Router B:

#

ospf 1

 area 0.0.0.0

  network 10.1.1.0 0.0.0.255

  network 10.1.2.0 0.0.0.255

  network 172.16.0.0 0.0.0.255

  network 172.17.0.0 0.0.0.255

  network 192.168.1.0 0.0.0.255

#

 dhcp enable

#

traffic classifier SIP operator and

 if-match acl 2002

#

traffic classifier VIP operator and

 if-match acl 2001

#

traffic behavior SIP

 remark ip-precedence 4

#

traffic behavior VIP

 remark ip-precedence 5

#

qos policy SIP

 classifier SIP behavior SIP

#

qos policy VIP

 classifier VIP behavior VIP

#

interface LoopBack0

 ip address 2.2.2.2 255.255.255.0

#

interface Ten-GigabitEthernet3/1/1

 ip address 10.1.1.2 255.255.255.0

 ospf cost 10

 ospf network-type p2p

 ospf bfd enable

 bfd min-transmit-interval 100

 bfd min-receive-interval 100

 bfd detect-multiplier 3

#

interface Ten-GigabitEthernet3/1/2

 ip address 10.2.1.1 255.255.255.0

 ospf cost 2000

 ospf network-type p2p

 ospf bfd enable

 bfd min-transmit-interval 100

 bfd min-receive-interval 100

 bfd detect-multiplier 3

#

interface Ten-GigabitEthernet3/1/3

 ip address 192.168.1.2 255.255.255.0

 ospf cost 2000

 ospf network-type p2p

 ospf bfd enable

 bfd min-transmit-interval 100

 bfd min-receive-interval 100

 bfd detect-multiplier 3

#

interface Ten-GigabitEthernet3/1/4.1

 ip address 172.16.0.10 255.255.255.0

 ospf cost 2000

 vrrp vrid 1 virtual-ip 172.16.0.11

 qos apply policy SIP inbound share-mode

 dhcp select relay

 dhcp relay server-address 192.168.1.5

#

interface Ten-GigabitEthernet3/1/4.2

 ip address 172.17.0.10 255.255.255.0

 ospf cost 2000

 vrrp vrid 2 virtual-ip 172.17.0.11

 vrrp vrid 2 priority 110

 qos apply policy VIP inbound share-mode

 dhcp select relay

 dhcp relay server-address 192.168.1.5

#

acl basic 2001

 rule 1 permit source 172.16.0.0 0.0.255.255

#

acl basic 2002

 rule 1 permit source 172.17.0.0 0.0.255.255

Related documentation

·     H3C SR8800-F Router OSPF Service Configuration Guide-R8385P09

·     H3C SR8800-F Router OSPF Service Command Reference-R8385P09

·     H3C SR8800-F Router BFD Service Configuration Guide-R8385P09

·     H3C SR8800-F Router BFD Service Command Reference-R8385P09

·     H3C SR8800-F Router VRRP Service Configuration Guide-R8385P09

·     H3C SR8800-F Router VRRP Service Command Reference-R8385P09

·     H3C SR8800-F Router ACL Service Configuration Guide-R8385P09

·     H3C SR8800-F Router ACL Service Command Reference-R8385P09

·     H3C SR8800-F Router QoS Service Configuration Guide-R8385P09

·     H3C SR8800-F Router QoS Service Command Reference-R8385P09

·     H3C SR8800-F Router DHCP Service Configuration Guide-R8385P09

·     H3C SR8800-F Router DHCP Service Command Reference-R8385P09

·
