Configuring cloud connections

About cloud connections

A cloud connection is a management tunnel established between a local device and the cloud server. It enables you to manage the local device from the cloud server without accessing the network where the device resides.

Multiple subconnections

After a local device establishes a connection with the cloud server, service modules on the local device can establish multiple subconnections with the microservices on the cloud server. These subconnections are independent from each other and provide separate communication channels for different services. This mechanism avoids interference among different services.

Cloud connection establishment

As shown in Figure 1, the cloud connection between the device and the cloud server is established as follows:

1.     The device sends an authentication request to the cloud server.

2.     The cloud server sends an authentication success packet to the device.

The device passes the authentication only if the serial number of the device has been added to the cloud server. If the authentication fails, the cloud server sends an authentication failure packet to the device.

3.     The device sends a registration request to the cloud server.

4.     The cloud server sends a registration response to the device.

The registration response contains the uniform resource locator (URL) used to establish a cloud connection.

5.     The device uses the URL to send a handshake request (changing the protocol from HTTP to WebSocket) to the cloud server.

6.     The cloud server sends a handshake response to the device to finish establishing the cloud connection.

7.     After the cloud connection is established, the device automatically obtains the subconnection URLs and establishes subconnections with the cloud server based on the service needs.



Figure 1 Establishing a cloud connection

‌

Restrictions: Hardware compatibility with cloud connections

F1000 series	Model	Cloud connection compatibility
F1000-X-G5 series	F1000-A-G5, F1000-C-G5, F1000-C-G5-LI, F1000-E-G5, F1000-H-G5, F1000-S-G5	No
F1000-X-G3 series	F1000-A-G3, F1000-C-G3, F1000-E-G3, F1000-S-G3	No
F1000-X-G2 series	F1000-A-G2, F1000-C-G2, F1000-E-G2, F1000-S-G2	No
F1000-9X0-AI series	F1000-9390-AI, F1000-9385-AI, F1000-9380-AI, F1000-9370-AI, F1000-9360-AI, F1000-9350-AI, F1000-9330-AI, F1000-9320-AI, F1000-990-AI, F1000-980-AI, F1000-970-AI, F1000-960-AI, F1000-950-AI, F1000-930-AI, F1000-920-AI , F1000-910-AI, F1000-905-AI	No
F1000-C83X0 series	F1000-C8395, F1000-C8390, F1000-C8385, F1000-C8380, F1000-C8370, F1000-C8360, F1000-C8350, F1000-C8330	Yes
F1000-C81X0 series	F1000-C8180, F1000-C8170, F1000-C8160, F1000-C8150, F1000-C8130, F1000-C8120, F1000-C8110	Yes
F1000-7X0-HI series	F1000-770-HI, F1000-750-HI, F1000-740-HI, F1000-730-HI, F1000-720-HI, F1000-710-HI	No
F1000-C-X series	F1000-C-EI, F1000-C-HI, F1000-C-XI, F1000-E-XI	No
F1000-V series	F1000-E-VG, F1000-S-VG	No
SecBlade IV	LSPM6FWD8, LSQM2FWDSC8	No

‌

F100 series	Model	Cloud connection compatibility
F100-X-G5 series	F100-A-G5, F100-C-G5, F100-E-G5, F100-M-G5, F100-S-G5	No
F100-X-G3 series	F100-A-G3, F100-C-G3, F100-E-G3, F100-M-G3, F100-S-G3	No
F100-X-G2 series	F100-A-G2, F100-C-G2, F100-E-G2, F100-M-G2, F100-S-G2	No
F100-WiNet series	F100-A80-WiNet, F100-C80-WiNet, F100-C60-WiNet, F100-C50-WiNet, F100-S80-WiNet, F100-A81-WiNet, F100-A91-WiNet	No
F100-C-A series	F100-C-A6, F100-C-A5, F100-C-A3, F100-C-A6-WL, F100-C-A5-W, F100-C-A3-W	No
F100-X-XI series	F100-A-EI, F100-A-HI, F100-A-SI, F100-C-EI, F100-C-HI, F100-C-XI, F100-E-EI, F100-S-HI, F100-S-XI	No

‌

Configuring the cloud server

For a successful cloud connection establishment, add the serial number of the device to be managed to the cloud server.

Configuring the local device

About this task

You can specify a cloud server by its domain name and log in to the server through the domain name on a remote PC to manage the local device.

If the local device does not receive a response from the cloud server within three keepalive intervals, the device sends a registration request to re-establish the cloud connection.

To prevent NAT entry aging, the local device sends ping packets to the cloud server periodically.

Restrictions and guidelines

You can specify one primary server by using the cloud-management server domain command and a maximum of eight backup servers by repeating the cloud-management backup-server domain command.

When establishing a cloud connection, the device connects to one of the primary and backup servers according to the sequence in which they are specified. The first specified server has the highest priority. When the connected server fails, the device switches to another server and does not switch back to the original server even if the original server recovers. To view the connected server, execute the display cloud-management state command.

Reduce the ping interval value if the network condition is poor or the NAT entry aging time is short. When you use the ADWAN server for cloud connections, you must set the password for establishing cloud connections to the ADWAN server.

Prerequisites

Before configuring this feature, make sure a DNS server is configured to translate domain names.

Procedure

1.     Enter system view.

system-view

2.     Specify the primary cloud server by its domain name.

cloud-management server domain domain-name [ vpn-instance vpn-instance-name ] [ source-ip ipv4-address ]

By default, the cloud server uses domain name ops.seccloud.h3c.com.

3.     (Optional.) Specify a backup cloud server by its domain name.

cloud-management backup-server domain domain-name [ vpn-instance vpn-instance-name ] [ source-ip ipv4-address ]

By default, no backup cloud server is specified.

4.     (Optional.) Set the keepalive interval.

cloud-management keepalive interval

By default, the keepalive interval is 180 seconds.

5.     (Optional.) Set the ping interval.

cloud-management ping interval

By default, the ping interval is 60 seconds.

6.     (Optional.) Specify the TCP port number used to establish cloud connections.

cloud-management server port port-number

By default, TCP port number 19443 is used to establish cloud connections.

7.     (Optional.) Set the password for establishing cloud connections to the ADWAN server.

cloud-management server password { cipher | simple } string

By default, no password is set for establishing cloud connections to the ADWAN server.

Unbinding the device from the cloud server

About this task

A device can be registered on the cloud server by only one user.

To register a device that has been registered by another user, you need to take the following steps:

1.     Obtain a verification code for device unbinding from the cloud server.

2.     Execute the command on the device for sending the verification code to the cloud server.

3.     Register the device on the cloud server.

Procedure

1.     Enter system view.

system-view

2.     Send the verification code for device unbinding to the cloud server.

cloud-management unbinding-code code

Display and maintenance commands for cloud connections

Execute display commands in any view.



Task	Command
Display cloud connection state information.	display cloud-management state

‌

Cloud connection configuration examples

Example: Configuring a cloud connection

Network configuration

As shown in Figure 2, configure the device to establish a cloud connection with the cloud O&M platform.

Figure 2 Network diagram

‌

Procedure

1.     Configure IP addresses for interfaces, routes, security domains, and security policies. (Details not shown.)

2.     Log in to the cloud O&M platform to add the serial number of the device to the platform. (Details not shown.)

3.     Configure the domain name of the cloud O&M platform as ops.seccloud.h3c.com on the device.

<Device> system-view

[Device] cloud-management server domain ops.seccloud.h3c.com



	NOTE: Make sure a DNS server is configured to translate the domain name of the cloud O&M platform.

‌

Verifying the configuration

# Verify that the device and the cloud O&M platform have established a cloud connection.

[Device] display cloud-management state

Cloud connection state                      : Established

Device state                                : Request_success

Cloud server address                        : 10.1.1.1

Cloud server domain name                    : ops.seccloud.h3c.com

Cloud connection mode                       : Https

Cloud server port                           : 19443

Connected at                                : Wed Jan 27 14:18:40 2018

Duration                                    : 00d 00h 02m 01s

Process state                               : Message received

Failure reason                              : N/A

Last down reason                            : socket connection error (Details:N/A)

Last down at                                : Wed Jan 27 13:18:40 2018

Last report failure reason                  : N/A

Last report failure at                      : N/A

Dropped packets after reaching buffer limit : 0

Total dropped packets                       : 1

Last report incomplete reason               : N/A

Last report incomplete at                   : N/A

Buffer full count                           : 0
