05-Static CRLSP configuration
Title Size Download
05-Static CRLSP configuration 85.24 KB

Configuring a static CRLSP

About static CRLSP

A static Constraint-based Routed Label Switched Path (CRLSP) is established by manually specifying CRLSP setup information on the ingress, transit, and egress nodes of the forwarding path. The CRLSP setup information includes the incoming label, outgoing label, and required bandwidth. If the device does not have enough bandwidth resources required by a CRLSP, the CRLSP cannot be established.

Static CRLSPs consume fewer resources, but they cannot automatically adapt to network topology changes. Therefore, static CRLSPs are suitable for small and stable networks with simple topologies.

Restrictions and guidelines: Static CRLSP configuration

The device does not support static CRLSP when it is operating in enhanced Layer 2 mode (set by the system-working-mode bridgee command).

The outgoing label specified on an LSR must be the same as the incoming label specified on the directly connected downstream LSR.

Static CRLSPs are special static LSPs. They use the same label space as static LSPs. On a device, a static CRLSP and a static LSP cannot use the same incoming label. In addition, a static PW and a static LSP (or a static CRLSP) cannot use the same incoming label.

A static CRLSP can forward MPLS TE traffic only after you create an MPLS TE tunnel interface on the ingress node and specify the static CRLSP for the tunnel interface. For more information about MPLS TE, see "Configuring MPLS TE."

Prerequisites for static CRLSP configuration

Before you configure a static CRLSP, perform the following tasks:

1.     Identify the ingress node, transit nodes, and egress node of the CRLSP.

2.     Enable MPLS on all interfaces that participate in MPLS forwarding. For more information, see "Configuring basic MPLS."

3.     Enable MPLS TE for each node and interface that the CRLSP traverses. For more information, see "Configuring MPLS TE."

Configuring the ingress node of a static CRLSP

About the ingress node of a static CRLSP

The ingress node performs the following operations to forward MPLS TE traffic:

1.     Adds the outgoing label of the static CRLSP to each packet.

2.     Forwards the packet to the next hop or out of the outgoing interface.

On the ingress node, you must specify the outgoing label, the next hop or the outgoing interface, and the required bandwidth.

Restrictions and guidelines

Do not configure the next hop address as a local public IP address when configuring the ingress node.

Procedure

1.     Enter system view.

system-view

2.     Configure the ingress node of a static CRLSP.

static-cr-lsp ingress lsp-name { nexthop ip-address | outgoing-interface interface-type interface-number } out-label out-label-value [ bandwidth [ ct0 | ct1 | ct2 | ct3 ] bandwidth-value ]

Configuring a transit node of a static CRLSP

About transit nodes of a static CRLSP

A transit node swaps the label carried in a received packet with a label, and forwards the packet to the next hop or out of the outgoing interface.

On a transit node, you must specify the incoming label, the outgoing label, the next hop or the outgoing interface, and the required bandwidth.

Restrictions and guidelines

Do not configure the next hop address as a local public IP address when configuring a transit node.

Procedure

1.     Enter system view.

system-view

2.     Configure a transit node of a static CRLSP.

static-cr-lsp transit lsp-name in-label in-label-value { nexthop ip-address | outgoing-interface interface-type interface-number } out-label out-label-value [ bandwidth [ ct0 | ct1 | ct2 | ct3 ] bandwidth-value ]

Configuring the egress node of a static CRLSP

About the egress node of a static CRLSP

If PHP is not configured, the egress node processes a received packet as follows:

1.     Pops the incoming label of a packet.

2.     Performs label forwarding according to the inner label of the packet or performs IP forwarding.

Therefore, you must perform this task to specify the incoming label on the egress node.

You do not need to perform this task if PHP is configured. To configure PHP for a static CRLSP, set the outgoing label to 0 or 3 on the penultimate hop of the static CRLSP.

Procedure

1.     Enter system view.

system-view

2.     Configure the egress node of a static CRLSP.

static-cr-lsp egress lsp-name in-label in-label-value

Display and maintenance commands for static CRLSPs

Execute display commands in any view.



Task

Command

Display static CRLSP information.

display mpls static-cr-lsp [ lsp-name lsp-name ] [ verbose ]



Static CRLSP configuration examples

Example: Configuring a static CRLSP

Network configuration

Switch A, Switch B, and Switch C run IS-IS.

Establish an MPLS TE tunnel over a static CRLSP from Switch A to Switch C to transmit data between the two IP networks. The required bandwidth for the tunnel is 2000 kbps.

The maximum bandwidth for MPLS TE traffic is 10000 kbps, and the maximum reservable bandwidth is 5000 kbps.

Figure 1 Network diagram



Procedure

IMPORTANT

IMPORTANT:

By default, interfaces on the device are disabled (in ADM or Administratively Down state). To have an interface operate, you must use the undo shutdown command to enable that interface.

1.     Configure IP addresses and masks for interfaces. (Details not shown.)

2.     Configure IS-IS to advertise interface addresses, including the loopback interface address:

# Configure Switch A.

<SwitchA> system-view

[SwitchA] isis 1

[SwitchA-isis-1] network-entity 00.0005.0000.0000.0001.00

[SwitchA-isis-1] quit

[SwitchA] interface vlan-interface 1

[SwitchA-Vlan-interface1] isis enable 1

[SwitchA-Vlan-interface1] quit

[SwitchA] interface loopback 0

[SwitchA-LoopBack0] isis enable 1

[SwitchA-LoopBack0] quit

# Configure Switch B.

<SwitchB> system-view

[SwitchB] isis 1

[SwitchB-isis-1] network-entity 00.0005.0000.0000.0002.00

[SwitchB-isis-1] quit

[SwitchB] interface vlan-interface 1

[SwitchB-Vlan-interface1] isis enable 1

[SwitchB-Vlan-interface1] quit

[SwitchB] interface vlan-interface 2

[SwitchB-Vlan-interface2] isis enable 1

[SwitchB-Vlan-interface2] quit

[SwitchB] interface loopback 0

[SwitchB-LoopBack0] isis enable 1

[SwitchB-LoopBack0] quit

# Configure Switch C.

<SwitchC> system-view

[SwitchC] isis 1

[SwitchC-isis-1] network-entity 00.0005.0000.0000.0003.00

[SwitchC-isis-1] quit

[SwitchC] interface vlan-interface 2

[SwitchC-Vlan-interface2] isis enable 1

[SwitchC-Vlan-interface2] quit

[SwitchC] interface loopback 0

[SwitchC-LoopBack0] isis enable 1

[SwitchC-LoopBack0] quit

# Execute the display ip routing-table command on each switch to verify that the switches have learned the routes to one another, including the routes to the loopback interfaces. (Details not shown.)

3.     Configure an LSR ID, and enable MPLS and MPLS TE:

# Configure Switch A.

[SwitchA] mpls lsr-id 1.1.1.1

[SwitchA] mpls te

[SwitchA-te] quit

[SwitchA] interface vlan-interface 1

[SwitchA-Vlan-interface1] mpls enable

[SwitchA-Vlan-interface1] mpls te enable

[SwitchA-Vlan-interface1] quit

# Configure Switch B.

[SwitchB] mpls lsr-id 2.2.2.2

[SwitchB] mpls te

[SwitchB-te] quit

[SwitchB] interface vlan-interface 1

[SwitchB-Vlan-interface1] mpls enable

[SwitchB-Vlan-interface1] mpls te enable

[SwitchB-Vlan-interface1] quit

[SwitchB] interface vlan-interface 2

[SwitchB-Vlan-interface2] mpls enable

[SwitchB-Vlan-interface2] mpls te enable

[SwitchB-Vlan-interface2] quit

# Configure Switch C.

[SwitchC] mpls lsr-id 3.3.3.3

[SwitchC] mpls te

[SwitchC-te] quit

[SwitchC] interface vlan-interface 2

[SwitchC-Vlan-interface2] mpls enable

[SwitchC-Vlan-interface2] mpls te enable

[SwitchC-Vlan-interface2] quit

4.     Configure MPLS TE attributes:

# On Switch A, set the maximum bandwidth and the maximum reservable bandwidth.

[SwitchA] interface vlan-interface 1

[SwitchA-Vlan-interface1] mpls te max-link-bandwidth 10000

[SwitchA-Vlan-interface1] mpls te max-reservable-bandwidth 5000

[SwitchA-Vlan-interface1] quit

# On Switch B, set the maximum bandwidth and the maximum reservable bandwidth.

[SwitchB] interface vlan-interface 1

[SwitchB-Vlan-interface1] mpls te max-link-bandwidth 10000

[SwitchB-Vlan-interface1] mpls te max-reservable-bandwidth 5000

[SwitchB-Vlan-interface1] quit

[SwitchB] interface vlan-interface 2

[SwitchB-Vlan-interface2] mpls te max-link-bandwidth 10000

[SwitchB-Vlan-interface2] mpls te max-reservable-bandwidth 5000

[SwitchB-Vlan-interface2] quit

# On Switch C, set the maximum bandwidth and the maximum reservable bandwidth.

[SwitchC] interface vlan-interface 2

[SwitchC-Vlan-interface2] mpls te max-link-bandwidth 10000

[SwitchC-Vlan-interface2] mpls te max-reservable-bandwidth 5000

[SwitchC-Vlan-interface2] quit

5.     Configure an MPLS TE tunnel on Switch A:

# Configure MPLS TE tunnel interface Tunnel 0.

[SwitchA] interface tunnel 0 mode mpls-te

[SwitchA-Tunnel0] ip address 6.1.1.1 255.255.255.0

# Specify the tunnel destination address as the LSR ID of Switch C.

[SwitchA-Tunnel0] destination 3.3.3.3

# Configure MPLS TE to use a static CRLSP to establish the tunnel.

[SwitchA-Tunnel0] mpls te signaling static

[SwitchA-Tunnel0] quit

6.     Create a static CRLSP:

# Configure Switch A as the ingress node of the static CRLSP, and specify the next hop address as 2.1.1.2, outgoing label as 20, and required bandwidth as 2000 kbps.

[SwitchA] static-cr-lsp ingress static-cr-lsp-1 nexthop 2.1.1.2 out-label 20 bandwidth 2000

# On Switch A, configure tunnel 0 to use the static CRLSP static-cr-lsp-1.

[SwitchA] interface tunnel 0

[SwitchA-Tunnel0] mpls te static-cr-lsp static-cr-lsp-1

[SwitchA-Tunnel0] quit

# Configure Switch B as the transit node of the static CRLSP, and specify the incoming label as 20, next hop address as 3.2.1.2, outgoing label as 30, and required bandwidth as 2000 kbps.

[SwitchB] static-cr-lsp transit static-cr-lsp-1 in-label 20 nexthop 3.2.1.2 out-label 30 bandwidth 2000

# Configure Switch C as the egress node of the static CRLSP, and specify the incoming label as 30.

[SwitchC] static-cr-lsp egress static-cr-lsp-1 in-label 30

7.     Configure a static route on Switch A to direct traffic destined for subnet 100.1.2.0/24 to MPLS TE tunnel 0.

[SwitchA] ip route-static 100.1.2.0 24 tunnel 0 preference 1

Verifying the configuration

# Verify that the tunnel interface is up on Switch A.

[SwitchA] display interface tunnel

Tunnel0

Current state: UP

Line protocol state: UP

Description: Tunnel0 Interface

Bandwidth: 64kbps

Maximum transmission unit: 1496

Internet address: 6.1.1.1/24 (primary)

Tunnel source unknown, destination 3.3.3.3

Tunnel TTL 255

Tunnel protocol/transport CR_LSP

Last clearing of counters: Never

Last 300 seconds input rate: 0 bytes/sec, 0 bits/sec, 0 packets/sec

Last 300 seconds output rate: 0 bytes/sec, 0 bits/sec, 0 packets/sec

Input: 0 packets, 0 bytes, 0 drops

Output: 0 packets, 0 bytes, 0 drops

# Display detailed information about the MPLS TE tunnel on Switch A.

[SwitchA] display mpls te tunnel-interface

Tunnel Name            : Tunnel 0

Tunnel State           : Up (Main CRLSP up)

Tunnel Attributes      :

  LSP ID               : 1               Tunnel ID            : 0

  Admin State          : Normal

  Ingress LSR ID       : 1.1.1.1         Egress LSR ID        : 3.3.3.3

  Signaling            : Static          Static CRLSP Name    : static-cr-lsp-1

  Resv Style           : -

  Tunnel mode          : -

  Reverse-LSP name     : -

  Reverse-LSP LSR ID   : -               Reverse-LSP Tunnel ID: -

  Class Type           : -               Tunnel Bandwidth     : -

  Reserved Bandwidth   : -

  Setup Priority       : 0               Holding Priority     : 0

  Affinity Attr/Mask   : -/-

  Explicit Path        : -

  Backup Explicit Path : -

  Metric Type          : TE

  Record Route         : -               Record Label         : -

  FRR Flag             : -               Backup Bandwidth Flag: -

  Backup Bandwidth Type: -               Backup Bandwidth     : -

  Route Pinning        : -

  Retry Limit          : 3               Retry Interval       : 2 sec

  Reoptimization       : -               Reoptimization Freq  : -

  Backup Type          : -               Backup LSP ID        : -

  Auto Bandwidth       : -               Auto Bandwidth Freq  : -

  Min Bandwidth        : -               Max Bandwidth        : -

  Collected Bandwidth  : -

# Display static CRLSP information on each switch.

[SwitchA] display mpls lsp

FEC                         Proto    In/Out Label    Interface/Out NHLFE

1.1.1.1/0/1                 StaticCR -/20            Vlan1

2.1.1.2                     Local    -/-             Vlan1

[SwitchB] display mpls lsp

FEC                         Proto    In/Out Label    Interface/Out NHLFE

-                           StaticCR 20/30           Vlan2

3.2.1.2                     Local    -/-             Vlan2

[SwitchC] display mpls lsp

FEC                         Proto    In/Out Label    Interface/Out NHLFE

-                           StaticCR 30/-            -

[SwitchA] display mpls static-cr-lsp

Name            LSR Type    In/Out Label   Out Interface        State

static-cr-lsp-1 Ingress     Null/20        Vlan1                Up

[SwitchB] display mpls static-cr-lsp

Name            LSR Type    In/Out Label   Out Interface        State

static-cr-lsp-1 Transit     20/30          Vlan2                Up

[SwitchC] display mpls static-cr-lsp

Name            LSR Type    In/Out Label   Out Interface        State

static-cr-lsp1  Egress      30/Null        -                    Up

# Verify that Switch A has a static route entry with interface Tunnel 0 as the output interface.

[SwitchA] display ip routing-table



Destinations : 12        Routes : 12



Destination/Mask   Proto   Pre Cost        NextHop         Interface

0.0.0.0/32         Direct  0   0           127.0.0.1       InLoop0

1.1.1.1/32         Direct  0   0           127.0.0.1       InLoop0

2.1.1.0/24         Direct  0   0           2.1.1.1         Vlan1

2.1.1.0/32         Direct  0   0           2.1.1.1         Vlan1

2.1.1.1/32         Direct  0   0           127.0.0.1       InLoop0

2.1.1.255/32       Direct  0   0           2.1.1.1         Vlan1

2.2.2.2/32         IS_L1   15  10          2.1.1.2         Vlan1

100.1.2.0/24       Static  1   0           0.0.0.0         Tun0

3.3.3.3/32         IS_L1   15  20          2.1.1.2         Vlan1

6.1.1.0/24         Direct  0   0           6.1.1.1         Tun0

6.1.1.0/32         Direct  0   0           6.1.1.1         Tun0

6.1.1.1/32         Direct  0   0           127.0.0.1       InLoop0

6.1.1.255/32       Direct  0   0           6.1.1.1         Tun0



  • Cloud & AI
  • InterConnect
  • Intelligent Computing
  • Security
  • SMB Products
  • Intelligent Terminal Products
  • Product Support Services
  • Technical Service Solutions
All Services
  • Resource Center
  • Policy
  • Online Help
All Support
  • Become a Partner
  • Partner Resources
  • Partner Business Management
All Partners
  • Profile
  • News & Events
  • Online Exhibition Center
  • Contact Us
All About Us
新华三官网
