With the automatic configuration feature, the device can automatically obtain a set of configuration settings at startup. This feature simplifies network configuration and maintenance.

Automatic configuration can be implemented by using the implementation methods in Table 1.

Table 1 Automatic configuration implementation methods

Implementation method	Configuration file location	Application scenarios
Server-based automatic configuration	File server	A number of geographically distributed devices need to be configured.

‌

Using server-based automatic configuration

About server-based automatic configuration

With server-based automatic configuration, a device without a configuration file can run the DHCP client to obtain a configuration file from a file server at startup.

You can deploy server-based automatic configuration on both IPv4 and IPv6 networks by using the same method. This chapter describes the tasks for deploying server-based automatic configuration on an IPv4 network.

Typical server-based automatic configuration network

As shown in Figure 1, a typical server-based automatic configuration network consists of the following servers:

· DHCP server—Allocates an IP address to the device that performs server-based automatic configuration and notifies the device of the method to obtain the configuration file or script file for automatic configuration.

· File server—TFTP, HTTP, SFTP, or FTP server. The file server stores the configuration file or script file for automatic configuration.

· (Optional.) DNS server—Obtains the configuration file name or the IP address of the file server for the device.

Figure 1 Server-based automatic configuration network diagram

‌

Host name file

A host name file stores mappings between host IP addresses and host names. To configure a host name file:

1. Create a host name file. The file name must be network.cfg.

2. Add each mapping entry in the ip host host-name ip-address format on a separate line. For example:

ip host host1 101.101.101.101

ip host host2 101.101.101.102

ip host client1 101.101.101.103

ip host client2 101.101.101.104

IMPORTANT:

The host name for a device must be the same as the name of the configuration file configured for the device. For example, the name of the configuration file for the device at 101.101.101.101 is host1.cfg.

‌

Selecting the interface used for automatic configuration

The device uses the following steps to select the interface for automatic configuration:

1. Identifies the status of the management Ethernet interface at Layer 2. If the management Ethernet interface is up, the device uses that interface.

2. Identifies the status of Layer 2 Ethernet interfaces. If one or more Layer 2 Ethernet interfaces are in up state, the device uses the VLAN interface of the default VLAN.

3. Sorts all Layer 3 Ethernet interfaces in up state first in lexicographical order of interface types and then in ascending order of interface numbers. Uses the interface with the smallest interface number among the interfaces of the first interface type.

4. If no Layer 3 Ethernet interfaces are in up state, the device waits 30 seconds and goes to step 1 to try again.

For fast automatic device configuration, connect only the management Ethernet interface on each device to the network.

Operating mechanism

The process for server-based automatic configuration for a device is as follows:

1. The device selects the interface used to obtain the configuration file or script file for automatic configuration and sends an IP request message to the DHCP server. For more information about the interface selection order, see "Selecting the interface used for automatic configuration."

2. After the DHCP server receives the IP request message, it sends a reply message to the device. If the device does not receive any reply message within the timeout period of the request message, it selects the next interface according to the interface selection order and sends the IP request message again.

3. The device parses the reply message.

¡ Obtains the IP address included in the reply message and uses it as the IP address for the selected interface to connect to the DHCP server. If the interface already has an IP address assigned, the device replaces the original IP address with the one included in the reply message. Once the automatic configuration process is complete, the device restores the original IP address to the interface.

¡ Obtains the protocol information (HTTP, TFTP, SFTP, or FTP), configuration file name information, and file server address included in the reply message.

4. If no configuration file name is obtained or the obtained configuration file name does not meet the requirements, the device uses file network.cfg on the file server. If file network.cfg does not exist, the device uses file device.cfg on the file server. If file device.cfg does not exist, the device fails to obtain the configuration file or script file. In this case, the process returns to step 1.

5. The device resolves the domain name of the file server. If the file server address included in the reply message is a domain name rather than an IP address, the device uses the DNS server to resolve the domain name to an IP address.

6. The device downloads the configuration file or script file used for automatic configuration from the file server based on the obtained protocol, file server address, and configuration file name.

7. The device deploys the configuration in the configuration file or executes the script file.

8. The device automatically deletes the configuration file or script file.

Server-based automatic configuration tasks at a glance

To configure server-based automatic configuration, perform the following tasks:

1. Prepare the files for automatic configuration:

¡ Preparing configuration files

¡ Preparing script files

2. Configuring the file server

3. Configuring the DHCP server

4. (Optional.) Configuring the DNS server

5. (Optional.) Configuring the gateway

6. Starting and completing automatic configuration

7. (Optional.) Stopping automatic configuration

Preparing configuration files

Configuration file types

The device supports the configuration file types listed in Table 2.

Table 2 Configuration file types

Configuration file type	Application objects	File name requirements	Supported file server types
Dedicated configuration file	Devices that require different settings	File name.cfg For simple file name identification, use configuration file names that do not contain spaces.	· HTTP server · TFTP server · SFTP server · FTP server
Common configuration file	Devices that share all or some settings	File name.cfg For simple file name identification, use configuration file names that do not contain spaces.	· HTTP server · TFTP server · SFTP server · FTP server
Default configuration file	All devices. The file contains only common configurations that devices use to start up.	device.cfg	TFTP server

‌

Identifying requirements for and preparing configuration files

1. Identify the requirements of the devices for configuration files.

2. For devices that require different configurations, prepare a configuration file for each of them and save the files to the file server.

3. For devices that share all or some configurations, save the common configurations to a .cfg file on the file server.

4. If a TFTP file server is used, you can save the common configurations that devices use to start up to the device.cfg file on the server. The file is assigned to a device only when the device does not have any other configuration file to use.

Preparing a host name file on the file server

If the DHCP server does not assign configuration file names, you can configure a host name file on the file server. The host name file contains the host name-IP address mappings of the devices to be automatically configured. As the host name for a device is the same as the name of the configuration file configured for the device, the device can obtain the configuration file configured for it.

Preparing script files

About this task

Script files can be used for automatic software upgrade and automatic configuration.

The devices support Python scripts (.py files) and Tcl scripts (.tcl files). For more information about Python and Tcl scripts, see "Using Python" and "Using Tcl."

The devices support dedicated script files and common dedicated script files. They do not support using a default script file. For information about dedicated script files and common dedicated script files, see Table 2.

When script files are used, you cannot use a host name file to provide the host name-IP address mappings for devices.

Restrictions and guidelines

To use a Tcl script, make sure all commands in the script are supported and correctly configured. Any error in a command causes the automatic configuration process to quit.

When you use a Python script to automatically configure a device, make sure the script file does not contain command line errors (such as spelling mistakes, incorrect views, and unsupported commands for the device). If the script file contains command line errors, the current round of automatic configuration will fail and the device will proceed to the next round of automatic configuration.

When you use a Python script to automatically configure a device, the device is in the startup phase and the device is unstable. Therefore, do not use the Stable value in the display system stable state command output as the judgment condition in the Python script.

Procedure

· For devices that share all or some configurations, create a script file that contains the common configurations.

· For the other devices, create a separate script file for each of them.

Configuring the file server

For devices to obtain configuration information from an HTTP, TFTP, SFTP, or FTP server, start HTTP, TFTP, SFTP, or FTP service on the file server, respectively.

Configuring the DHCP server

About this task

The DHCP server assigns the following items to devices that need to be automatically configured:

· IP addresses.

· Paths of the configuration or script files.

Restrictions and guidelines

When you configure the DHCP server, follow these guidelines:

· For devices for which you have prepared different configuration files, perform the following tasks for each of the devices on the DHCP server:

¡ Create a DHCP address pool.

¡ Configure a static address binding.

¡ Specify a configuration file or script file.

Because an address pool can use only one configuration file, you can specify only one static address binding for an address pool.

· For devices for which you have prepared the same configuration file, use either of the following methods:

¡ Method 1:

- Create a DHCP address pool for the devices.

- Configure a static address binding for each of the devices in the address pool.

- Specify the configuration file for the devices.

¡ Method 2:

- Create a DHCP address pool for the devices.

- Specify the subnet for dynamic allocation.

- Specify the TFTP server.

- Specify the configuration file for the devices.

· If all devices on a subnet share the same configuration file or script file, perform the following tasks on the DHCP server:

¡ Configure dynamic address allocation.

¡ Specify the configuration file or script file for the devices.

The configuration file can contain only the common settings for the devices. You can provide a method for the device administrators to change the configurations after their devices start up.

When you specify a startup configuration file on a remote server for a DHCP client, follow these restrictions and guidelines:

· If a TFTP server is used, you must specify the file name. If the file name contains special characters, you must transcode the special characters according to the RFC specification.

· If an HTTP server is used, you must specify the URL of the file in the format of http://HTTP-server-IP-address:port-number/path/file-name. If the path or file name in the URL contains special characters, you must transcode the special characters according to the RFC specification. If you do not specify a port number, the default port number applies.

· If an FTP server is used, you must specify the URL of the file in the format of ftp://username:password@FTP-server-IP-address:port-number/path/file-name. If the username, password, path, or file name in the URL contains special characters, you must transcode the special characters according to the RFC specification. If you do not specify a port number, the default port number applies. If you do not specify a path, the root directory of the server applies.

· If an SFTP server is used, you must specify the URL of the file in the format of sftp://username:password@SFTP-server-IP-address:port-number/path/file-name. If the username, password, path, or file name in the URL contains special characters, you must transcode the special characters according to the RFC specification. If you do not specify a port number, the default port number applies. If you do not specify a path, the root directory of the server applies.

Configuring the DHCP server when an HTTP file server is used

1. Enter system view.

system-view

2. Enable DHCP.

dhcp enable

By default, DHCP is disabled.

3. Create a DHCP address pool and enter its view.

dhcp server ip-pool pool-name

4. Configure the address pool.

Choose the options to configure as needed:

¡ Specify the primary subnet for the address pool.

network network-address [ mask-length | mask mask ]

By default, no primary subnet is specified.

¡ Configure a static binding.

static-bind ip-address ip-address [ mask-length | mask mask ] { client-identifier client-identifier | hardware-address hardware-address [ ethernet | token-ring ] }

By default, no static binding is configured.

You can configure multiple static bindings. However, one IP address can be bound to only one client. To change the binding for a DHCP client, you must remove the binding and reconfigure a binding.

5. Specify the URL of the configuration or script file in HTTP format.

bootfile-name url

By default, no configuration or script file URL is specified in HTTP format.

Configuring the DHCP server when a TFTP file server is used

1. Enter system view.

system-view

2. Enable DHCP.

dhcp enable

By default, DHCP is disabled.

3. Create a DHCP address pool and enter its view.

dhcp server ip-pool pool-name

4. Configure the address pool.

Choose the options to configure as needed:

¡ Specify the primary subnet for the address pool.

network network-address [ mask-length | mask mask ]

By default, no primary subnet is specified.

¡ Configure a static binding.

static-bind ip-address ip-address [ mask-length | mask mask ] { client-identifier client-identifier | hardware-address hardware-address [ ethernet | token-ring ] }

By default, no static binding is configured.

You can configure multiple static bindings. However, one IP address can be bound to only one client. To change the binding for a DHCP client, you must remove the binding and reconfigure a binding.

5. Specify a TFTP server.

Choose one option as needed:

¡ Specify the IP address of the TFTP server.

tftp-server ip-address ip-address

By default, no TFTP server IP address is specified.

¡ Specify the name of the TFTP server.

tftp-server domain-name domain-name

By default, no TFTP server name is specified.

If you specify a TFTP server by its name, a DNS server is required on the network.

6. Specify the name of the configuration or script file.

bootfile-name bootfile-name

By default, no configuration or script file name is specified.

Configuring the DHCP server when an SFTP file server is used

1. Enter system view.

system-view

2. Enable DHCP.

dhcp enable

By default, DHCP is disabled.

3. Create a DHCP address pool and enter its view.

dhcp server ip-pool pool-name

4. Configure the address pool.

Choose the options to configure as needed:

¡ Specify the primary subnet for the address pool.

network network-address [ mask-length | mask mask ]

By default, no primary subnet is specified.

¡ Configure a static binding.

static-bind ip-address ip-address [ mask-length | mask mask ] { client-identifier client-identifier | hardware-address hardware-address [ ethernet | token-ring ] }

By default, no static binding is configured.

You can configure multiple static bindings. However, one IP address can be bound to only one client. To change the binding for a DHCP client, you must remove the binding and reconfigure a binding.

5. Specify the URL of the configuration or script file in SFTP format.

bootfile-name url

By default, no configuration or script file URL in SFTP format is specified.

Configuring the DHCP server when an FTP file server is used

1. Enter system view.

system-view

2. Enable DHCP.

dhcp enable

By default, DHCP is disabled.

3. Create a DHCP address pool and enter its view.

dhcp server ip-pool pool-name

4. Configure the address pool.

Choose the options to configure as needed:

¡ Specify the primary subnet for the address pool.

network network-address [ mask-length | mask mask ]

By default, no primary subnet is specified.

¡ Configure a static binding.

static-bind ip-address ip-address [ mask-length | mask mask ] { client-identifier client-identifier | hardware-address hardware-address [ ethernet | token-ring ] }

By default, no static binding is configured.

You can configure multiple static bindings. However, one IP address can be bound to only one client. To change the binding for a DHCP client, you must remove the binding and reconfigure a binding.

5. Specify the URL of the configuration or script file in FTP format.

bootfile-name url

By default, no configuration or script file URL in FTP format is specified.

Configuring the DNS server

A DNS server is required in the following situations:

· Obtaining the names of configuration files for automatic configuration when the TFTP server does not have a host name file—In this situation, the devices that perform server-based automatic configuration use the DNS server to resolve their IP addresses to their host names. Then, each device can use its host name to obtain the configuration file that has the same name as its host name from the TFTP server.

· Obtaining the IP address of a file server—If the devices obtain the domain name of the file server from DHCP reply messages, they can use the domain name to obtain the IP address of the file server through the DNS server.

For more information about DNS servers, see DNS configuration in Layer 3—IP Services Configuration Guide.

Configuring the gateway

If the devices to be automatically configured and the servers for automatic configuration reside in different network segments, you must perform the following tasks:

· Deploy a gateway and make sure the devices can communicate with the servers.

· Configure the DHCP relay agent feature on the gateway.

· Configure the UDP helper feature on the gateway.

This task is required if devices send requests to a TFTP server by using broadcast packets. A device uses broadcast packets to send requests to a TFTP server in the following situations:

¡ The DHCP reply does not contain the IP address or domain name of the TFTP server.

¡ The IP address or domain name of the TFTP server is invalid.

The UDP helper transforms a broadcast packet into a unicast packet and forwards the unicast packet to the file server. For more information about UDP helper, see Layer 3—IP Services Configuration Guide.

Starting and completing automatic configuration

1. Power on the devices to be automatically configured.

2. The devices enter the automatic configuration process. After a device obtains a configuration file and executes the file successfully, the automatic configuration process ends.

3. Save the running configuration.

save

As a best practice, save the running configuration on each device after the configuration file is executed successfully on the device.

For more information about the save command, see configuration file management commands in Fundamentals Command Reference.

Stopping automatic configuration

If a device cannot obtain a configuration file for automatic configuration, the current automatic configuration attempt fails, and the device continues attempting automatic configuration. You can wait until the device automatically ends the automatic configuration process after it has made the maximum number of attempts. Alternatively, you can manually stop the automatic configuration process by using shortcut keys Ctrl+C or Ctrl+D based on the prompt information. After the automatic configuration process fails and ends, the device starts up with initial settings.

Server-based automatic configuration examples

Example: Using a TFTP server for automatic configuration

Network configuration

As shown in Figure 2, two departments of a company are connected to the network through gateways (Switch B and Switch C). Access devices Switch D, Switch E, Switch F, and Switch G do not have a configuration file.

Configure the servers and gateways so the access devices can obtain a configuration file to complete the following configuration tasks:

· Enable administrators of access devices to Telnet to and manage their respective access devices.

· Require administrators to enter their respective usernames and passwords at login.

Figure 2 Network diagram

‌

Procedure

1. Configure the DHCP server:

# Create a VLAN interface and assign an IP address to the interface.

<SwitchA> system-view

[SwitchA] vlan 2

[SwitchA-vlan2] port twenty-fivegige 1/0/1

[SwitchA-vlan2] quit

[SwitchA] interface vlan-interface 2

[SwitchA-Vlan-interface2] ip address 192.168.1.42 24

[SwitchA-Vlan-interface2] quit

# Enable DHCP.

[SwitchA] dhcp enable

# Enable the DHCP server on VLAN-interface 2.

[SwitchA] interface vlan-interface 2

[SwitchA-Vlan-interface2] dhcp select server

[SwitchA-Vlan-interface2] quit

# Configure address pool market to assign IP addresses on the 192.168.2.0/24 subnet to clients in the Marketing department. Specify the TFTP server, gateway, and configuration file name for the clients.

[SwitchA] dhcp server ip-pool market

[SwitchA-dhcp-pool-market] network 192.168.2.0 24

[SwitchA-dhcp-pool-market] tftp-server ip-address 192.168.1.40

[SwitchA-dhcp-pool-market] gateway-list 192.168.2.1

[SwitchA-dhcp-pool-market] bootfile-name market.cfg

[SwitchA-dhcp-pool-market] quit

# Configure address pool rd to assign IP addresses on the 192.168.3.0/24 subnet to clients in the R&D department. Specify the TFTP server, gateway, and configuration file name for the clients.

[SwitchA] dhcp server ip-pool rd

[SwitchA-dhcp-pool-rd] network 192.168.3.0 24

[SwitchA-dhcp-pool-rd] tftp-server ip-address 192.168.1.40

[SwitchA-dhcp-pool-rd] gateway-list 192.168.3.1

[SwitchA-dhcp-pool-rd] bootfile-name rd.cfg

[SwitchA-dhcp-pool-rd] quit

# Configure static routes to the DHCP relay agents.

[SwitchA] ip route-static 192.168.2.0 24 192.168.1.41

[SwitchA] ip route-static 192.168.3.0 24 192.168.1.43

[SwitchA] quit

2. Configure the gateway Switch B:

# Create VLAN interfaces and assign IP addresses to the interfaces.

<SwitchB> system-view

[SwitchB] vlan 2

[SwitchB-vlan2] port twenty-fivegige 1/0/3

[SwitchB-vlan2] quit

[SwitchB] interface vlan-interface 2

[SwitchB-Vlan-interface2] ip address 192.168.1.41 24

[SwitchB-Vlan-interface2] quit

[SwitchB] vlan 3

[SwitchB-vlan3] port twenty-fivegige 1/0/1

[SwitchB-vlan3] port twenty-fivegige 1/0/2

[SwitchB-vlan3] quit

[SwitchB] interface vlan-interface 3

[SwitchB-Vlan-interface3] ip address 192.168.2.1 24

[SwitchB-Vlan-interface3] quit

# Enable DHCP.

[SwitchB] dhcp enable

# Enable the DHCP relay agent on VLAN-interface 3.

[SwitchB] interface vlan-interface 3

[SwitchB-Vlan-interface3] dhcp select relay

# Specify the DHCP server address.

[SwitchB-Vlan-interface3] dhcp relay server-address 192.168.1.42

3. Configure the gateway Switch C:

# Create VLAN interfaces and assign IP addresses to the interfaces.

<SwitchC> system-view

[SwitchC] vlan 2

[SwitchC-vlan2] port twenty-fivegige 1/0/3

[SwitchC-vlan2] quit

[SwitchC] interface vlan-interface 2

[SwitchC-Vlan-interface2] ip address 192.168.1.43 24

[SwitchC-Vlan-interface2] quit

[SwitchC] vlan 3

[SwitchC-vlan3] port twenty-fivegige 1/0/1

[SwitchC-vlan3] port twenty-fivegige 1/0/2

[SwitchC-vlan3] quit

[SwitchC] interface vlan-interface 3

[SwitchC-Vlan-interface3] ip address 192.168.3.1 24

[SwitchC-Vlan-interface3] quit

# Enable DHCP.

[SwitchC] dhcp enable

# Enable the DHCP relay agent on VLAN-interface 3.

[SwitchC] interface vlan-interface 3

[SwitchC-Vlan-interface3] dhcp select relay

# Specify the DHCP server address.

[SwitchC-Vlan-interface3] dhcp relay server-address 192.168.1.42

4. Configure the TFTP server:

# On the TFTP server, create a configuration file named market.cfg.

sysname Market

telnet server enable

vlan 3

local-user market

password simple build22345

service-type telnet

quit

interface Vlan-interface3

ip address dhcp-alloc

quit

interface twenty-fivegige 1/0/1

port access vlan 3

quit

user-interface vty 0 63

authentication-mode scheme

user-role network-admin

return

# On the TFTP server, create a configuration file named rd.cfg.

sysname RD

telnet server enable

vlan 3

local-user rd

password simple create22345

service-type telnet

quit

interface Vlan-interface3

ip address dhcp-alloc

quit

interface twenty-fivegige 1/0/1

port access vlan 3

quit

user-interface vty 0 63

authentication-mode scheme

user-role network-admin

return

# Start TFTP service software, and specify the folder where the two configuration files reside as the working directory. (Details not shown.)

# Verify that the TFTP server and DHCP relay agents can reach each other. (Details not shown.)

Verifying the configuration

1. Power on Switch D, Switch E, Switch F, and Switch G.

2. After the access devices start up, display assigned IP addresses on Switch A.

<SwitchA> display dhcp server ip-in-use

IP address Client-identifier/ Lease expiration Type

Hardware address

192.168.2.2 3030-3066-2e65-3233- May 6 05:21:25 2013 Auto(C)

642e-3561-6633-2d56-

6c61-6e2d-696e-7465-

7266-6163-6533

192.168.2.3 3030-3066-2e65-3230- May 6 05:22:50 2013 Auto(C)

302e-3232-3033-2d56-

6c61-6e2d-696e-7465-

7266-6163-6533

192.168.3.2 3030-6530-2e66-6330- May 6 05:23:15 2013 Auto(C)

302e-3335-3131-2d56-

6c61-6e2d-696e-7465-

7266-6163-6531

192.168.3.3 3030-6530-2e66-6330- May 6 05:24:10 2013 Auto(C)

302e-3335-3135-2d56-

6c61-6e2d-696e-7465-

7266-6163-6532

3. Telnet to 192.168.2.2 from Switch A.

<SwitchA> telnet 192.168.2.2

4. Enter username market and password build22345 as prompted. (Details not shown.)

You are logged in to Switch D or Switch E.

Example: Using an HTTP server and Tcl scripts for automatic configuration

Network configuration

As shown in Figure 3, Switch A does not have a configuration file.

Configure the servers so Switch A can obtain a Tcl script to complete the following configuration tasks:

· Enable the administrator to Telnet to Switch A to manage Switch A.

· Require the administrator to enter the correct username and password at login.

Figure 3 Network diagram

‌

Procedure

1. Configure the DHCP server:

# Enable DHCP.

<DeviceA> system-view

[DeviceA] dhcp enable

# Configure address pool 1 to assign IP addresses on the 192.168.1.0/24 subnet to clients.

[DeviceA] dhcp server ip-pool 1

[DeviceA-dhcp-pool-1] network 192.168.1.0 24

# Specify the URL of the script file for the clients.

[DeviceA-dhcp-pool-1] bootfile-name http://192.168.1.40/device.tcl

2. Configure the HTTP server:

# Create a configuration file named device.tcl on the HTTP server.

system-view

telnet server enable

local-user user

password simple hello22345

service-type telnet

quit

user-interface vty 0 63

authentication-mode scheme

user-role network-admin

quit

interface twenty-fivegige 1/0/1

port link-mode route

ip address dhcp-alloc

return

# Start HTTP service software and enable HTTP service. (Details not shown.)

Verifying the configuration

1. Power on Switch A.

2. After Switch A starts up, display assigned IP addresses on Device A.

<DeviceA> display dhcp server ip-in-use

IP address Client identifier/ Lease expiration Type

Hardware address

192.168.1.2 0030-3030-632e-3239- Dec 12 17:41:15 2013 Auto(C)

3035-2e36-3736-622d-

4574-6830-2f30-2f32

3. Telnet to 192.168.1.2 from Device A.

<DeviceA> telnet 192.168.1.2

4. Enter username user and password hello22345 as prompted. (Details not shown.)

You are logged in to Switch A.

Example: Using an HTTP server and Python scripts for automatic configuration

Network configuration

As shown in Figure 4, Switch A does not have a configuration file.

Configure the servers so Switch A can obtain a Python script to complete the following configuration tasks:

· Enable the administrator to Telnet to Switch A to manage Switch A.

· Require the administrator to enter the correct username and password at login.

Figure 4 Network diagram

‌

Procedure

1. Configure the DHCP server:

# Enable DHCP.

<DeviceA> system-view

[DeviceA] dhcp enable

# Configure address pool 1 to assign IP addresses on the 192.168.1.0/24 subnet to clients.

[DeviceA] dhcp server ip-pool 1

[DeviceA-dhcp-pool-1] network 192.168.1.0 24

# Specify the URL of the script file for the clients.

[DeviceA-dhcp-pool-1] bootfile-name http://192.168.1.40/device.py

2. Configure the HTTP server:

# Create a configuration file named device.py on the HTTP server.

#!usr/bin/python

import plathformtools

plathformtools.CLI(‘system-view ;telnet server enable ;local-user user ;password simple hello22345 ;service-type telnet ;quit ;user-interface vty 0 63 ;authentication-mode scheme ;user-role network-admin ;quit ;interface twenty-fivegige 1/0/1 ;port link-mode route ;ip address dhcp-alloc ;return’)

# Start HTTP service software and enable HTTP service. (Details not shown.)

Verifying the configuration

1. Power on Switch A.

2. After Switch A starts up, display assigned IP addresses on Device A.

<DeviceA> display dhcp server ip-in-use

IP address Client identifier/ Lease expiration Type

Hardware address

192.168.1.2 0030-3030-632e-3239- Dec 12 17:41:15 2013 Auto(C)

3035-2e36-3736-622d-

4574-6830-2f30-2f32

3. Telnet to 192.168.1.2 from Device A.

<DeviceA> telnet 192.168.1.2

4. Enter username user and password hello22345 as prompted. (Details not shown.)

You are logged in to Switch A.

Example: Using an SFTP server for automatic configuration

Network configuration

As shown in Figure 5, Switch A automatically obtains and executes a configuration file from the SFTP server after it starts up in order to meet the following requirements:

· The network administrator can log in to and control the switch through Telnet.

· Authentication is required for switch login to enhance security.

Figure 5 Network diagram

‌

Procedure

1. Configure the DHCP server:

# Enable DHCP, create DHCP address pool 1, and specify primary subnet 192.168.1.0/24 for dynamic allocation in the address pool.

<DeviceA> system-view

[DeviceA] dhcp enable

[DeviceA] dhcp server ip-pool 1

[DeviceA-dhcp-pool-1] network 192.168.1.0 24

# Specify the URL of the configuration file. The username and password must be the same as those on the SFTP server.

[DeviceA-dhcp-pool-1] bootfile-name sftp://user%dd:[email protected]:22/device.cfg

2. Configure the SFTP server to ensure that Switch A can successfully download configuration file device.cfg from the SFTP server:

# Create configuration file device.cfg on the SFTP server. The file contents are as follows:

telnet server enable

local-user user

password simple hello12345

service-type telnet

quit

user-interface vty 0 63

authentication-mode scheme

user-role network-admin

quit

interface twenty-fivegige 1/0/1

port link-mode route

ip address dhcp-alloc

return

# Start the SFTP management software and enable the SFTP service. (Details not shown.)

Verifying the configuration

# Start up Switch A without a startup configuration file. After the switch starts up successfully, display binding information about assigned IP addresses on Device A.

<DeviceA> display dhcp server ip-in-use

IP address Client identifier/ Lease expiration Type

Hardware address

192.168.1.2 0030-3030-632e-3239- Dec 12 17:41:15 2013 Auto(C)

3035-2e36-3736-622d-

4574-6830-2f30-2f32

# On Device A, Telnet to Switch A.

<SwitchA> telnet 192.168.1.2

# Enter username user and password hello12345. Verify that you can Telnet to Switch A from Device A.

Example: Using an FTP server for automatic configuration

Network configuration

As shown in Figure 6, Switch A automatically obtains and executes a configuration file from the FTP server after it starts up in order to meet the following requirements:

· The network administrator can log in to and control the switch through Telnet.

· Authentication is required for switch login to enhance security.

Figure 6 Network diagram

‌

Procedure

1. Configure the DHCP server:

# Enable DHCP, create DHCP address pool 1, and specify primary subnet 192.168.1.0/24 for dynamic allocation in the address pool.

<DeviceA> system-view

[DeviceA] dhcp enable

[DeviceA] dhcp server ip-pool 1

[DeviceA-dhcp-pool-1] network 192.168.1.0 24

# Specify the URL of the configuration file. The username and password must be the same as those on the FTP server.

[DeviceA-dhcp-pool-1] bootfile-name ftp://user:[email protected]:22/device.cfg

2. Configure the FTP server to ensure that Switch A can successfully download configuration file device.cfg from the FTP server:

# Create configuration file device.cfg on the FTP server. The file contents are as follows:

telnet server enable

local-user user

password simple hello12345

service-type telnet

quit

user-interface vty 0 63

authentication-mode scheme

user-role network-admin

quit

interface twenty-fivegige 1/0/1

port link-mode route

ip address dhcp-alloc

return

# Start the FTP management software and enable the FTP service. (Details not shown.)

Verifying the configuration

# Start up Switch A without a startup configuration file. After the switch starts up successfully, display binding information about assigned IP addresses on Device A.

<DeviceA> display dhcp server ip-in-use

IP address Client identifier/ Lease expiration Type

Hardware address

192.168.1.2 0030-3030-632e-3239- Dec 12 17:41:15 2013 Auto(C)

3035-2e36-3736-622d-

4574-6830-2f30-2f32

# On Device A, Telnet to Switch A.

<SwitchA> telnet 192.168.1.2

# Enter username user and password hello12345. Verify that you can Telnet to Switch A from Device A.

Example: Setting up an IRF fabric

Network configuration

As shown in Figure 7, Switch A and Switch B do not have a configuration file.

Configure the servers so the switches can obtain a Python script to complete their respective configurations and form an IRF fabric.

Figure 7 Network diagram

‌

Procedure

1. Assign IP addresses to the interfaces. Make sure the devices can reach each other. (Details not shown.)

2. Configure the following files on the HTTP server:

File	Content	Remarks
.cfg configuration file	Commands required for IRF setup.	You can create a configuration file by copying and modifying the configuration file of an existing IRF fabric.
sn.txt	Serial numbers of the member switches.	Each SN uniquely identifies a switch. These SNs will be used for assigning a unique IRF member ID to each member switch.
(Optional.) .ipe or .bin software image file	Software images.	If the member switches are running different software versions, you must prepare the software image file used for software upgrade.
.py Python script file	Python commands that complete the following tasks: a (Optional.) Verify that the flash memory has sufficient space for the files to be downloaded. b Download the configuration file and sn.txt. c (Optional.) Download the software image file and specify it as the main startup image file. d Resolve sn.txt and assign a unique IRF member ID to each SN. e Specify the configuration file as the main next-startup configuration file. f Reboot the member switches.	For more information about Python script configuration, see "Using Python."

‌

The specific content of the Python script is as follows (there are simple comments in the Python script, delete the comments when you use the script):

#!usr/bin/python

import comware

from time import strftime,gmtime,sleep

import signal

import os

import string

import commands

import hashlib

#python_config_file_mode

#'python_static'

#python_serial_number

#U can use 2 modes to obtain the config file

#- 'python_static'

#- 'python_serial_number'

python_config_file_mode = "python_serial_number"

# Configure the minimum remaining space required in the device flash for this software upgrade, with the unit in KB.

#Required space to copy config kickstart and system image in KB

required_space = 500000

# Configure the relevant parameters of the HTTP server: username, password, HTTP server IP address, VPN instance name, login timeout.

#transfer information

username = ""

password = ""

hostname = "192.168.1.40"

protocol = "http"

vrf = ""

config_timeout = 120

irf_timeout = 120

image_timeout = 2100

#HTTP server download path

#Server File Path

server_path = ""

# When you download it to the local device, store it in the root directory of the flash.

#Loacl File path

local_path = "flash:/"

# Name of the configuration file after being downloaded to the device.

#Local config name

config_local_name = "startup.cfg"

# Configuration file name on the HTTP server

#Server config name

config_server_name = "startup.cfg"

# Bootup software package downloaded to the local disk

#Local boot name

boot_local_name = "xxxx.ipe"

# Bootup software package on the HTTP server

#Server boot name

boot_server_name = "xxxx.ipe"

# Name of the SN file downloaded to the local disk

#Local irf name

irf_local_name = "sn.txt"

# SN file name on the HTTP server

#Server irf name

irf_server_name = "sn.txt"

# Upgrade log file name recorded on the device

python_log_name = ""

# Log upgrade method recorded on the device

#Write Log File

def write2Log(info):

global python_log_name, local_path

if python_log_name == "":

try:

python_log_name = "%s%s_python_%s_script.log" %(local_path, strftime("%Y%m%d%H%M%S", gmtime()), os.getpid())

except Exception as inst:

print inst

fd = open(python_log_name, "a")

fd.write(info)

fd.flush()

fd.close()

# Obtain the device chassis number and slot number, and then calculate the local storage path of the file by using the chassis number, slot number, and the local_path variable.

# get path according to the Chassis and Slot

def getPath(chassisID, slotID):

global local_path

path = ""

obj = comware.get_self_slot()

if (obj[0] == chassisID) and (obj[1] == slotID):

return local_path

if chassisID != -1:

path = "chassis%d#" % chassisID

if slotID != -1:

path = "%sslot%d#%s" %(path, slotID, local_path)

return path

# Delete the file downloaded to the local disk

#Remove File

def removeFile(filename):

try:

os.remove(filename)

except os.error:

pass

# Calculate the number of files to be deleted from the device.

#Cleanup one device temp files

def cleanDeviceFiles(str, oDevNode):

global config_local_name, boot_local_name, irf_local_name

sFilePath = getPath(oDevNode[0], oDevNode[1])

if str == "error":

removeFile("%s%s" %(sFilePath, config_local_name))

removeFile("%s%s" %(sFilePath, boot_local_name))

removeFile("%s%s" %(sFilePath, irf_local_name))

removeFile("%s%s.md5" %(sFilePath, config_local_name))

removeFile("%s%s.md5" %(sFilePath, boot_local_name))

removeFile("%s%s.md5" %(sFilePath, irf_local_name))

write2Log("\ndelete %s all files\n" %sFilePath)

print "\ndelete %s all files" %sFilePath

#Cleanup files

def cleanupFiles(str):

aSlotRange = []

if ("get_standby_slot" in dir(comware)):

aSlotRange = aSlotRange + comware.get_standby_slot()

aSlotRange.append(comware.get_self_slot())

i = 0

while i < len(aSlotRange):

if(aSlotRange[i] != None):

cleanDeviceFiles(str, aSlotRange[i])

i = i + 1

# Calculate the remaining flash space.

#Verify if free space is available to download config, boot-loader image

def verifyfreespace(path):

global required_space

try:

s = os.statvfs(path)

freespace = (s.f_bavail * s.f_frsize) /1024

write2Log("\nthe %s free space is %s" %(path, freespace))

print "\n####the %s free space is %s####" %(path, freespace)

if required_space > freespace:

write2Log("\nthe %s space is not enough" % path)

print "\n####the %s space is not enough####" % path

return False

except Exception as inst:

write2Log("\nverify %s free space exception: %s" % (path, inst))

print "\n####verify %s free space exception: %s####" % (path, inst)

return False

return True

# Verify whether the remaining space on the device is sufficient.

#verify device freespace

def verifyDeviceFree(obj):

path = getPath(obj[0], obj[1])

if True != verifyfreespace(path):

return False

return True

#check all mpu free space

def verifyAllFreeSpace():

aSlotRange = []

if ("get_standby_slot" in dir(comware)):

aSlotRange = aSlotRange + comware.get_standby_slot()

aSlotRange.append(comware.get_self_slot())

bAllEnough = True

i = 0

while i < len(aSlotRange):

if(aSlotRange[i] != None) and (True != verifyDeviceFree(aSlotRange[i])):

bAllEnough = False

i = i + 1

return bAllEnough

def doExit(str):

if str == "success":

write2Log("\nThe script is running success!")

print "\n#### The script is running success! ####"

cleanupFiles("success")

comd = "reboot force"

comware.CLI(comd, False)

exit(0)

if str == "error":

write2Log("\nThe script is running failed!")

print "\n#### The script is running failed! ####"

cleanupFiles("error")

exit(1)

else:

exit(0)

# Obtain the chassis number and slot number during software upgrade.

#get Chassis and Slot

def getChassisSlot(style):

if style == "master":

obj = comware.get_self_slot()

if len(obj) <= 0:

write2Log("\nget %s chassis and slot failed" % style)

print "\n####get %s chassis and slot failed####" % style

return None

return obj

# Obtain the error information returned during software package startup.

#signal terminal handler function

def sig_handler_no_exit(signum, function):

write2Log("\nSIGTERM Handler while configuring boot-loader variables")

print "\n####SIGTERM Handler while configuring boot-loader variables####"

# Error information returned during software upgrade.

#signal terminal handler

def sigterm_handler(signum, function):

write2Log("\nSIGTERM Handler")

print "\n####SIGTERM Handler####"

cleanupFiles("error")

doExit("error")

# Download file from the HTTP server.

#transfer file

def doCopyFile(src = "", des = "", login_timeout = 10):

global username, password, hostname, protocol, vrf

print "INFO: Starting Copy of %s" % src

try:

removeFile(des)

obj = comware.Transfer(protocol, hostname, src, des, vrf, login_timeout, username, password)

if obj.get_error() != None:

write2Log("\ncopy %s failed: %s" % (src, obj.get_error()))

print "\n####copy %s failed: %s####" % (src, obj.get_error())

return False

except Exception as inst:

write2Log("\ncopy %s exception: %s" % (src, inst))

print "\n####copy %s exception: %s####" % (src, inst)

return False

write2Log("\ncopy file %s to %s success" % (src, des))

print "INFO: Completed Copy of %s" % src

return True

#Get MD5SUM from md5ConfigFile

def getMD5SumGiven(keyword, filename):

try:

file = open(filename, "r")

line = file.readline()

while "" != line:

if not string.find(line, keyword, 0, len(keyword)):

line = line.split("=")

line = line[1]

line = line.strip()

file.close()

return line

line = file.readline()

file.close()

except Exception as inst:

write2Log("\nget %s md5 exception: %s" % (filename, inst))

print "\n####get %s md5 exception: %s####" % (filename, inst)

return ""

#verify MD5SUM of the file

def verifyMD5sumofFile(md5sumgiven, filename):

if md5sumgiven == "":

write2Log("\nverify %s md5 error: the %s md5 file is error" %(filename, filename))

print "\n####verify %s md5 error: the %s md5 file is error####" %(filename, filename)

return False

try:

m = hashlib.md5()

f = open(filename, 'rb')

buffer = 8192

while 1:

chunk = f.read(buffer)

if not chunk:

break

m.update(chunk)

f.close()

md5calculated = m.hexdigest()

except Exception as inst:

write2Log("\nverify %s md5 exception: %s" % (filename, inst))

print "\n####verify %s md5 exception: %s####" % (filename, inst)

return False

if md5sumgiven == md5calculated:

return True

write2Log("\nverify %s md5 error: md5sumgiven is %s filemd5 is %s" %(filename, md5sumgiven, md5calculated))

print "\n####verify %s md5 error: md5sumgiven is %s filemd5 is %s####" %(filename, md5sumgiven, md5calculated)

return False

#Check MD5 file

def checkFile(src, dest):

src = "%s.md5" % src

destmd5 = "%s.md5" % dest

bFlag = doCopyFile(src, destmd5, 120)

if (True == bFlag) and (True == verifyMD5sumofFile(getMD5SumGiven("md5sum", destmd5), dest)):

write2Log("\ncheckFile success: %s" % destmd5)

print "\n####checkFile success: %s####" % destmd5

return True

elif (True != bFlag):

write2Log("\n%s is not exist! Don't verify the MD5 file!" % destmd5)

print "INFO: %s is not exist! Don't verify the MD5 file!" % destmd5

return True

return False

#Get config file according to the mode

def getCfgFileName():

global config_server_name

if (python_config_file_mode == "python_serial_number") and (os.environ.has_key('DEV_SERIAL')):

config_server_name = "%s.cfg" % os.environ['DEV_SERIAL']

return config_server_name

else:

return config_server_name

#copy file to all standby slot

def syncFileToStandby(sSrcFile, sFileName):

try:

aSlotRange = []

if ("get_standby_slot" in dir(comware)):

aSlotRange = aSlotRange + comware.get_standby_slot()

i = 0

while i < len(aSlotRange):

if(aSlotRange[i] != None):

sDestFile = "%s%s" %(getPath(aSlotRange[i][0], aSlotRange[i][1]), sFileName)

removeFile(sDestFile)

open(sDestFile,"wb").write(open(sSrcFile,"rb").read())

write2Log("\nsync file to standby %s" % (sDestFile))

print "\n####sync file to standby %s####" % (sDestFile)

i = i + 1

except Exception as inst:

write2Log("\nsync file to standby %s exception: %s" % (sSrcFile, inst))

print "\n####sync file to standby %s exception: %s####" % (sSrcFile, inst)

# Based on the global variables defined at the beginning of the script, download the startup software package, configuration file, and SN file.

#Procedure to copy config file using global information

def copyAndCheckFile(src, dest, timeout):

global server_path, local_path

srcTmp = "%s%s" % (server_path, src)

sDestFile = "%s%s" % (local_path, dest)

if (True == doCopyFile(srcTmp, sDestFile, timeout)) and (True == checkFile(srcTmp, sDestFile)):

syncFileToStandby(sDestFile, dest)

return True

else:

srcTmp = "%sdefault_%s" %(server_path, src)

if (True == doCopyFile(srcTmp, sDestFile, timeout)) and (True == checkFile(srcTmp, sDestFile)):

syncFileToStandby(dest)

return True

return False

# split the Chassis and Slot

def splitChassisSlot(chassisID, slotID):

chassis_slot = ""

if chassisID != -1:

chassis_slot = " chassis %d" % chassisID

if slotID != -1:

chassis_slot = "%s slot %d" %(chassis_slot, slotID)

return chassis_slot

# Download startup software package from the HTTP server.

def copyBootImage():

global image_timeout, local_path, boot_server_name, boot_local_name

src = "%s" % boot_server_name

return copyAndCheckFile(src, boot_local_name, image_timeout)

# Download configuration file from the HTTP server.

def copyCfgFile():

global config_timeout, local_path, config_local_name

src = "%s" % getCfgFileName()

return copyAndCheckFile(src, config_local_name, config_timeout)

# Download the sn.txt file from the HTTP server.

def copyIrfStack():

global irf_timeout, local_path, irf_local_name, irf_server_name

src = "%s" % irf_server_name

return copyAndCheckFile(src, irf_local_name, config_timeout)

# Execute the boot-loader command to specify the next-bootup main configuration file.

# Procedure to Install Boot Image

def installBoot(chassis_slot, sFile, style):

result = None

write2Log("\ninstall%s%s begin" %(chassis_slot, style))

print "INFO: Install%s%s Start, Please Wait..." %(chassis_slot, style)

comd = "boot-loader file %s%s%s" % (sFile, chassis_slot, style)

try:

result = comware.CLI(comd, False)

if result == None:

write2Log("\nboot-loader file %s%s%s failed" % (sFile, chassis_slot, style))

print "\n####boot-loader file %s%s%s failed####" % (sFile, chassis_slot, style)

return False

except Exception as inst:

write2Log("\nboot-loader %s exception: %s" % (sFile, inst))

print "\n####boot-loader %s exception: %s####" % (sFile, inst)

return False

return True

#Procedure to install boot image

def installBootImage():

global boot_local_name

aSlotRange = [comware.get_self_slot()]

if ("get_standby_slot" in dir(comware)):

aSlotRange = aSlotRange + comware.get_standby_slot()

bInstallOk = True

i = 0

while i < len(aSlotRange):

sFile = "%s%s" %(getPath(aSlotRange[0][0], aSlotRange[0][1]), boot_local_name)

if False == installBoot(splitChassisSlot(aSlotRange[i][0], aSlotRange[i][1]), sFile, " main"):

bInstallOk = False

i = i + 1

return bInstallOk

# Execute the startup saved-configuration command to specify the next-bootup configuration file.

def startupCfg():

global local_path, config_local_name

result = None

dest = "%s%s" %(local_path, config_local_name)

write2Log("\nstartup saved-configuration %s begin" %dest)

print "INFO: Startup Saved-configuration Start"

comd = "startup saved-configuration %s main" % dest

try:

result = comware.CLI(comd, False)

if result == None:

write2Log("\nstartup saved-configuration %s failed" % dest)

print "\n####startup saved-configuration %s failed####" % dest

return False

except Exception as inst:

write2Log("\nstartup %s exception: %s" % (dest, inst))

print "\n####startup %s exception: %s####" % (dest, inst)

return False

write2Log("\nstartup saved-configuration %s success" % dest)

print "INFO: Completed Startup Saved-configuration"

return True

def getIrfCfg(line, num):

line = line.split()

number = None

if 3 == len(line):

number = line[num]

else :

number = None

return number

def getMemberID():

aMemId = comware.get_self_slot()

memId = None

if aMemId[0] == -1 :

memId = aMemId[1]

else :

memId = aMemId[0]

return memId

def getNewMemberID():

global irf_local_name, local_path, env

filename = "%s%s" %(local_path, irf_local_name)

serNum = os.environ['DEV_SERIAL']

print "\n####Test Chassis SN or Slot SN %s" % serNum

reNum = None

try:

file = open(filename, "r")

line = file.readline()

while "" != line:

if (serNum == getIrfCfg(line, 0)):

file.close()

reNum = getIrfCfg(line, 2)

return reNum

line = file.readline()

file.close()

except Exception as inst:

write2Log("\nget renumberID exception: %s" % inst)

print "\n####get renumberID exception: %s####" % inst

write2Log("\nget %s renumberID failed" % filename)

print "\n#### get %s renumberID failed ####" % filename

return reNum

# Check whether the device is in an IRF fabric.

def isIrfDevice():

try:

result = comware.CLI("display irf", False)

if result == None:

return False

except Exception as inst:

return False

return True

# Parse the sn.txt file and use renumber to edit the IRF member ID of the device.

def getIrfComd():

comd = None

newMemberID = getNewMemberID()

aMemId = comware.get_self_slot()

if None == newMemberID:

return None

if False == isIrfDevice():

comd = "system-view ; irf member %s ; chassis convert mode irf" % newMemberID

else:

comd = "system-view ; irf member %s renumber %s" % (getMemberID(), newMemberID)

return comd

def stackIrfCfg():

global env

if (not os.environ.has_key('DEV_SERIAL')):

write2Log("\nenviron variable 'DEV_SERIAL' is not found!")

print "\n####environ variable 'DEV_SERIAL' is not found!####"

return False

comd = getIrfComd()

if None == comd:

return False

result = None

write2Log("\nstartup stack irf begin")

print "INFO: Startup stack irf Start"

try:

result = comware.CLI(comd, False)

if result == None:

write2Log("\nstartup stack irf failed: %s" % comd)

print "\n####startup stack irf failed: %s####" %comd

return False

except Exception as inst:

write2Log("\nstartup stack irf exception: %s command: %s" % (inst, comd))

print "\n####startup stack irf exception: %s command: %s####" % (inst, comd)

return False

write2Log("\nstartup stack irf success")

print "INFO: Completed Startup Stack Irf"

return True

#check if all standby slots are ready

def ifAllStandbyReady():

if (("get_slot_range" in dir(comware)) == False):

return True

aSlotRange = comware.get_slot_range()

bAllReady = True

for i in range(aSlotRange["MinSlot"], aSlotRange["MaxSlot"]):

oSlotInfo = comware.get_slot_info(i)

if (oSlotInfo != None) and (oSlotInfo["Role"] == "Standby") and (oSlotInfo["Status"] == "Fail"):

bAllReady = False

write2Log("\nSlot %s is not ready!" %i)

print "\n####Slot %s is not ready!####" %i

return bAllReady

#if have any standby slot was not ready sleep for waiting

def waitStandbyReady():

while ifAllStandbyReady() == False:

sleep(10)

#python main

#when download file user can stop script

waitStandbyReady()

signal.signal(signal.SIGTERM, sigterm_handler)

if (True == verifyAllFreeSpace()) and (True == copyBootImage()) and (True == copyCfgFile()) and (True == copyIrfStack()):

#after download file user can not stop script

signal.signal(signal.SIGTERM, sig_handler_no_exit)

if (True == installBootImage()) and (True == startupCfg()) and (True == stackIrfCfg()):

doExit("success")

doExit("error")

3. Configure Device A as the DHCP server:

# Enable DHCP.

<DeviceA> system-view

[DeviceA] dhcp enable

# Configure address pool 1 to assign IP addresses on the 192.168.1.0/24 subnet to clients.

[DeviceA] dhcp server ip-pool 1

[DeviceA-dhcp-pool-1] network 192.168.1.0 24

# Specify the URL of the script file for the clients.

[DeviceA-dhcp-pool-1] bootfile-name http://192.168.1.40/device.py

[DeviceA-dhcp-pool-1] quit

# Enable the DHCP server on Twenty-FiveGigE 1/0/1.

[DeviceA] interface twenty-fivegige 1/0/1

[DeviceA-Twenty-FiveGigE1/0/1] dhcp select server

[DeviceA-Twenty-FiveGigE1/0/1] quit

4. Power on Switch A and Switch B.

Switch A and Switch B will obtain the Python script file from the DHCP server and execute the script. After completing the IRF configuration, Switch A and Switch B reboot.

5. After Switch A and Switch B start up again, use a cable to connect Switch A and Switch B through their IRF physical ports.

Switch A and Switch B will elect a master member. The subordinate member will reboot to join the IRF fabric.

Verifying the configuration

# On Switch A, display IRF member devices. You can also use the display irf command on Switch B to display IRF member devices.

<Switch A> display irf

MemberID Slot Role Priority CPU-Mac Description

1 1 Standby 1 00e0-fc0f-8c02 ---

*+2 1 Master 30 00e0-fc0f-8c14 ---

--------------------------------------------------

* indicates the device is the master.

+ indicates the device through which the user logs in.

The Bridge MAC of the IRF is: 000c-1000-1111

Auto upgrade : yes

Mac persistent : always

Domain ID : 0

Auto merge : yes

The output shows that the switches have formed an IRF fabric.

01-Fundamentals Configuration Guide

Configuration file types

Identifying requirements for and preparing configuration files

Preparing a host name file on the file server

About this task

Restrictions and guidelines

Procedure

About this task

Restrictions and guidelines

Configuring the DHCP server when an HTTP file server is used

Configuring the DHCP server when a TFTP file server is used

Configuring the DHCP server when an SFTP file server is used

Configuring the DHCP server when an FTP file server is used

Network configuration

Procedure

Verifying the configuration

Example: Using an HTTP server and Tcl scripts for automatic configuration

Network configuration

Procedure

Verifying the configuration

Example: Using an HTTP server and Python scripts for automatic configuration

Network configuration

Procedure

Verifying the configuration

Network configuration

Procedure

Verifying the configuration

Example: Using an FTP server for automatic configuration

Network configuration

Procedure

Verifying the configuration

Example: Setting up an IRF fabric

Network configuration

Procedure

Verifying the configuration

Intelligent Terminal Products

Product Support Services

Technical Service Solutions

Resource Center

Policy

Online Help

Become a Partner

Partner Policy & Program

Global Learning

Partner Sales Resources

Service Business

News & Events

Contact Us
