Introduction
This document provides software patching examples that use ISSU install commands.
Prerequisites
The configuration examples in this document were created and verified in a lab environment, and all the devices were started with the factory default configuration. When you are working on a live network, make sure you understand the potential impact of every command on your network.
This document assumes that you have basic knowledge of ISSU that uses install commands.
Example: Patching software
Network configuration
As shown in Figure 1, the switch and the TFTP server can reach each other. The switch is running CMW910-SYSTEM-R1116, and it is not been patched before.
Use the patch image file CMW910-SYSTEM-R1116H04.bin to fix bugs without rebooting the switch.
Applicable hardware and software versions
The following matrix shows the hardware and software versions to which this configuration example is applicable:
|
Hardware |
Software version |
|
S6550X-HI switch series |
Release 1116 and later, Release 1213P51 and later |
|
S6880 switch series |
Release 1116 and later, Release 1213P51 and later |
|
S9820-8M switch |
Release 1116 and later, Release 1213P51 and later |
|
S9855 switch series |
Release 9126 and later |
|
S9825 switch series |
Release 9126 and later |
|
S5580X-HI switch series |
Not supported |
|
S5580X-EI switch series |
Not supported |
|
S5580S-EI switch series |
Not supported |
Restrictions and guidelines
The patch image version must match the device model and Comware version. For example, to fix bugs in CMW910-SYSTEM-R1116.bin, you must use CMW910-SYSTEM-R1116H04.bin.
Procedures
# Download the patch image file CMW910-SYSTEM-R1116H04.bin from the TFTP server to the root directory of the flash memory on the master.
<Sysname> tftp 2.2.2.2 get CMW910-SYSTEM-R1116H04.bin
Press CTRL+C to abort.
% Total % Received % Xferd Average Speed Time Time Time Current
Dload Upload Total Spent Left Speed
100 25.2M 0 25.2M 0 0 210k 0 --:--:-- 0:02:02 --:--:-- 209k
# Activate the patch image on the switch.
<Sysname> install activate patch flash:/CMW910-SYSTEM-R1116H04.bin slot 1
This operation maybe take several minutes, please wait.............Done.
The patch image takes effect immediately after it is activated.
# For the patch image to take effect after a reboot, commit the software change.
<Sysname> install commit
Verifying the configuration
# Verify that the patch image has been activated successfully.
<Sysname> display install active
Active packages on slot 1:
flash:/CMW910-BOOT-R1116.bin
flash:/CMW910-SYSTEM-R1116.bin
flash:/CMW910-SYSTEM-R1116H04.bin
# Verify that the patch image file has been added to the main startup software image list so the images can take effect after a reboot.
<Sysname> display install committed
Committed packages on slot 1:
flash:/CMW910-BOOT-R1116.bin
flash:/CMW910-SYSTEM-R1116.bin
flash:/CMW910-SYSTEM-R1116H04.bin
Configuration files
The system does not save the commands used in the configuration procedures to a configuration file.
