Introduction

This document provides EVPN multicast configuration examples.

Prerequisites

The configuration examples were created and verified in a lab environment, and all the devices were started with the factory default configuration. When you are working on a live network, make sure you understand the potential impact of every command on your network.

The following information is provided based on the assumption that you have basic knowledge of EVPN and multicast.

General restrictions and guidelines

On the S12500GAF series switches, only SF interface modules support EVPN multicast.

Example: Configuring Layer 2 EVPN multicast

Network configuration

As shown in Figure 1, configure Layer 2 EVPN multicast as follows:

·     Configure Leaf 1 and Leaf 2 as distributed EVPN gateways. Assign the multicast receivers attached to Leaf 1 and the multicast source attached to Leaf 2 to VXLAN 10.

·     Configure Leaf 1, Leaf 2, and the RR to set up BGP EVPN peer relationships in AS 65000 of the overlay network. Configure the RR to reflect BGP EVPN routes between Leaf 1 and Leaf 2.

·     Configure OSPF on Leaf 1, Leaf 2, and the RR for them to have Layer 3 connectivity on the underlay network.

Figure 1 Network diagram



Analysis

To enable Layer 2 multicast forwarding in the EVPN network, perform the following tasks:

·     Enable IGMP snooping on the leaf devices for them to snoop the IGMP membership reports sent by the multicast receivers.

·     For the leaf devices to create Layer 2 multicast forwarding entries, configure the leaf devices to advertise multicast group join requests through selective multicast Ethernet tag (SMET) routes.

Applicable hardware and software versions

The following matrix shows the hardware and software versions to which this configuration example is applicable:



Hardware	Software version
S12500G-AF	Release 8053P05 and later
S12500CR	Release 8053P05 and later
S10500X-G	Release 7753P05 and later
S7500X-G	Release 7753P05 and later



Restrictions and guidelines

IGMP snooping restrictions and guideline

IGMP snooping configuration in a VSI takes effect only on the member ports in the VSI.

In an EVPN VXLAN network, the IGMP snooping querier in a VSI does not include VLAN tags in IGMP general queries. As a best practice, do not enable the IGMP snooping querier in a VSI if the VSI uses the Ethernet access mode.

The interface where an Ethernet service instance resides must allow the VLANs that the Ethernet service instance matches.

Distributed EVPN gateway restrictions and guideline

When you configure VSI interfaces on distributed EVPN gateways, follow these restrictions and guidelines:

·     Do not assign reserved MAC addresses to VSI interfaces.

·     You must assign the same MAC address to the VSI interfaces with L3 VXLAN IDs associated

·     If you use the mac-address command to modify the MAC address of a L3 VXLAN ID associated VSI interface on a DR system, also modify the MAC address of the other L3 VXLAN ID associated VSI interfaces. These VSI interfaces must use the same MAC address.

·     If a distributed EVPN gateway is connected to an IPv6 site, make sure the VSI interfaces with L3 VXLAN IDs associated use the same link-local address.

·     On different distributed EVPN gateways, the VSI interface of a VXLAN must use the same IP address and MAC address to provide services.

·     The L3 VXLAN ID of a VSI interface cannot be the same as the VXLAN ID specified by using the mapping vni command.

·     As a best practice, do not use ARP flood suppression and local proxy ARP or ND flood suppression and local ND proxy together on distributed EVPN gateways. If both ARP flood suppression and local proxy ARP are enabled on a distributed EVPN gateway, only local proxy ARP takes effect. If both ND flood suppression and local ND proxy are enabled on a distributed EVPN gateway, only local ND proxy takes effect.

Procedures

Configuring Leaf 1

Assigning IP addresses and configuring unicast routing

# Assign IP addresses to loopback interfaces and Ten-GigabitEthernet 3/0/3.

<Sysname> system-view

[Sysname] sysname Leaf1

[Leaf1] interface loopback 0

[Leaf1-LoopBack0] ip address 172.16.0.1 255.255.255.255

[Leaf1-LoopBack0] quit

[Leaf1] interface ten-gigabitethernet 3/0/3

[Leaf1-Ten-GigabitEthernet3/0/3] port link-mode route

[Leaf1-Ten-GigabitEthernet3/0/3] ip address 12.1.1.1 24

[Leaf1-Ten-GigabitEthernet3/0/3] quit

# Configure OSPF for the devices to communicate at Layer 3 over the underlay network.

[Leaf1] router id 172.16.0.1

[Leaf1] ospf

[Leaf1-ospf-1] area 0

[Leaf1-ospf-1-area-0.0.0.0] network 172.16.0.1 0.0.0.0

[Leaf1-ospf-1-area-0.0.0.0] network 12.1.1.1 0.0.0.255

[Leaf1-ospf-1-area-0.0.0.0] quit

[Leaf1-ospf-1] quit

Configuring a VPN instance

# Create VPN instance vpn1 and configure an RD and route targets for it.

[Leaf1] ip vpn-instance vpn1

[Leaf1-vpn-instance-vpn1] route-distinguisher 1:1

[Leaf1-vpn-instance-vpn1] address-family ipv4

[Leaf1-vpn-ipv4-vpn1] vpn-target 2:2 import-extcommunity

[Leaf1-vpn-ipv4-vpn1] vpn-target 2:2 export-extcommunity

[Leaf1-vpn-ipv4-vpn1] quit

[Leaf1-vpn-instance-vpn1] address-family evpn

[Leaf1-vpn-evpn-vpn1] vpn-target 1:1 import-extcommunity

[Leaf1-vpn-evpn-vpn1] vpn-target 1:1 export-extcommunity

[Leaf1-vpn-evpn-vpn1] quit

[Leaf1-vpn-instance-vpn1] quit

Configuring a VSI interface

# Configure VSI interface 1.

[Leaf1] interface vsi-interface 1

[Leaf1-Vsi-interface1] ip binding vpn-instance vpn1

[Leaf1-Vsi-interface1] ip address 10.255.255.254 255.0.0.0

[Leaf1-Vsi-interface1] mac-address 0000-0001-0001

[Leaf1-Vsi-interface1] distributed-gateway local

[Leaf1-Vsi-interface1] quit

Configuring an EVPN instance

# Enable L2VPN.

[Leaf1] l2vpn enable

# Disable remote MAC address learning and remote ARP learning.

[Leaf1] vxlan tunnel mac-learning disable

[Leaf1] vxlan tunnel arp-learning disable

# Create VXLAN 10 on VSI vsi1, and specify VSI interface 1 as the gateway for the VXLAN.

[Leaf1] vsi vsi1

[Leaf1-vsi-vsi1] gateway vsi-interface 1

[Leaf1-vsi-vsi1] statistics enable

[Leaf1-vsi-vsi1] arp suppression enable

[Leaf1-vsi-vsi1] vxlan 10

[Leaf1-vsi-vsi1-vxlan-10] quit

# Configure an EVPN instance using VXLAN encapsulation, and configure an RD and route targets for it.

[Leaf1-vsi-vsi1] evpn encapsulation vxlan

[Leaf1-vsi-vsi1-evpn-vxlan] route-distinguisher auto

[Leaf1-vsi-vsi1-evpn-vxlan] vpn-target auto export-extcommunity

[Leaf1-vsi-vsi1-evpn-vxlan] vpn-target auto import-extcommunity

[Leaf1-vsi-vsi1-evpn-vxlan] quit

[Leaf1-vsi-vsi1] quit

Assigning L3 VXLAN IDs

# Assign a L3 VXLAN ID to VSI interface 2.

[Leaf1] interface vsi-interface 2

[Leaf1-Vsi-interface2] ip binding vpn-instance vpn1

[Leaf1-Vsi-interface2] l3-vni 10000

[Leaf1-Vsi-interface2] quit

Configuring BGP EVPN route advertisement

# Configure Leaf 1 to establish a BGP EVPN peer relationship with the RR.

[Leaf1] bgp 65000

[Leaf1-bgp-default] peer 172.16.10.1 as-number 65000

[Leaf1-bgp-default] peer 172.16.10.1 connect-interface loopback 0

[Leaf1-bgp-default] peer 172.16.10.1 password simple overlay

[Leaf1-bgp-default] address-family l2vpn evpn

[Leaf1-bgp-default-evpn] peer 172.16.10.1 enable

[Leaf1-bgp-default-evpn] quit

[Leaf1-bgp-default] quit

Mapping ACs to the VSI

# On Ten-GigabitEthernet 3/0/1, create Ethernet service instance 1 and map it to VSI vsi1.

[Leaf1] interface ten-gigabitethernet 3/0/1

[Leaf1-Ten-GigabitEthernet3/0/1] port link-mode bridge

[Leaf1-Ten-GigabitEthernet3/0/1] port link-type trunk

[Leaf1-Ten-GigabitEthernet3/0/1] undo port trunk permit vlan 1

[Leaf1-Ten-GigabitEthernet3/0/1] port trunk permit vlan 1000

[Leaf1-Ten-GigabitEthernet3/0/1] service-instance 1

[Leaf1-Ten-GigabitEthernet3/0/1-srv1] encapsulation s-vid 1000

[Leaf1-Ten-GigabitEthernet3/0/1-srv1] statistics enable

[Leaf1-Ten-GigabitEthernet3/0/1-srv1] xconnect vsi vsi1

[Leaf1-Ten-GigabitEthernet3/0/1-srv1] quit

[Leaf1-Ten-GigabitEthernet3/0/1] quit

# On Ten-GigabitEthernet 3/0/2, create Ethernet service instance 1 and map it to VSI vsi1.

[Leaf1] interface ten-gigabitethernet 3/0/2

[Leaf1-Ten-GigabitEthernet3/0/2] port link-mode bridge

[Leaf1-Ten-GigabitEthernet3/0/2] port link-type trunk

[Leaf1-Ten-GigabitEthernet3/0/2] undo port trunk permit vlan 1

[Leaf1-Ten-GigabitEthernet3/0/2] port trunk permit vlan 1001

[Leaf1-Ten-GigabitEthernet3/0/2] service-instance 1

[Leaf1-Ten-GigabitEthernet3/0/2-srv1] encapsulation s-vid 1001

[Leaf1-Ten-GigabitEthernet3/0/2-srv1] statistics enable

[Leaf1-Ten-GigabitEthernet3/0/2-srv1] xconnect vsi vsi1

[Leaf1-Ten-GigabitEthernet3/0/2-srv1] quit

[Leaf1-Ten-GigabitEthernet3/0/2] quit

Configuring IGMP snooping

# Enable IGMP snooping globally.

[Leaf1] igmp-snooping

[Leaf1-igmp-snooping] global-enable

[Leaf1-igmp-snooping] quit

# Configure IGMP snooping for VSI vsi1.

[Leaf1] vsi vsi1

[Leaf1-vsi-vsi1] igmp-snooping enable

[Leaf1-vsi-vsi1] igmp-snooping drop-unknown

[Leaf1-vsi-vsi1] igmp-snooping proxy enable

# Configure Leaf 2 as an IGMP querier.

[Leaf1-vsi-vsi1] igmp-snooping querier

[Leaf1-vsi-vsi1] quit

Configuring Leaf 2

Assigning IP addresses and configuring unicast routing

# Assign IP addresses to loopback interfaces and Ten-GigabitEthernet 3/0/3.

<Sysname> system-view

[Sysname] sysname Leaf2

[Leaf2] interface loopback 0

[Leaf2-LoopBack0] ip address 172.16.0.2 255.255.255.255

[Leaf2-LoopBack0] quit

[Leaf2] interface ten-gigabitethernet 3/0/3

[Leaf2-Ten-GigabitEthernet3/0/3] port link-mode route

[Leaf2-Ten-GigabitEthernet3/0/3] ip address 13.1.1.2 24

[Leaf2-Ten-GigabitEthernet3/0/3] quit

# Configure OSPF for the devices to communicate at Layer 3 over the underlay network.

[Leaf2] router id 172.16.0.2

[Leaf2] ospf

[Leaf2-ospf-1] area 0

[Leaf2-ospf-1-area-0.0.0.0] network 172.16.0.2 0.0.0.0

[Leaf2-ospf-1-area-0.0.0.0] network 13.1.1.2 0.0.0.255

[Leaf2-ospf-1-area-0.0.0.0] quit

[Leaf2-ospf-1] quit

Configuring a VPN instance

# Create VPN instance vpn1 and configure an RD and route targets for it.

[Leaf2] ip vpn-instance vpn1

[Leaf2-vpn-instance-vpn1] route-distinguisher 1:1

[Leaf2-vpn-instance-vpn1] address-family ipv4

[Leaf2-vpn-ipv4-vpn1] vpn-target 2:2 import-extcommunity

[Leaf2-vpn-ipv4-vpn1] vpn-target 2:2 export-extcommunity

[Leaf2-vpn-ipv4-vpn1] quit

[Leaf2-vpn-instance-vpn1] address-family evpn

[Leaf2-vpn-evpn-vpn1] vpn-target 1:1 import-extcommunity

[Leaf2-vpn-evpn-vpn1] vpn-target 1:1 export-extcommunity

[Leaf2-vpn-evpn-vpn1] quit

[Leaf2-vpn-instance-vpn1] quit

Configuring a VSI interface

# Configure VSI interface 1.

[Leaf2] interface vsi-interface 1

[Leaf2-Vsi-interface1] ip binding vpn-instance vpn1

[Leaf2-Vsi-interface1] ip address 10.255.255.254 255.0.0.0

[Leaf2-Vsi-interface1] mac-address 0000-0001-0001

[Leaf2-Vsi-interface1] distributed-gateway local

[Leaf2-Vsi-interface1] quit

Configuring an EVPN instance

# Enable L2VPN.

[Leaf2] l2vpn enable

# Disable remote MAC address learning and remote ARP learning.

[Leaf2] vxlan tunnel mac-learning disable

[Leaf2] vxlan tunnel arp-learning disable

# Create VXLAN 10 on VSI vsi1, and specify VSI interface 1 as the gateway for the VXLAN.

[Leaf2] vsi vsi1

[Leaf2-vsi-vsi1] gateway vsi-interface 1

[Leaf2-vsi-vsi1] statistics enable

[Leaf2-vsi-vsi1] arp suppression enable

[Leaf2-vsi-vsi1] vxlan 10

[Leaf2-vsi-vsi1-vxlan-10] quit

# Configure an EVPN instance using VXLAN encapsulation, and configure an RD and route targets for it.

[Leaf2-vsi-vsi1] evpn encapsulation vxlan

[Leaf2-vsi-vsi1-evpn-vxlan] route-distinguisher auto

[Leaf2-vsi-vsi1-evpn-vxlan] vpn-target auto export-extcommunity

[Leaf2-vsi-vsi1-evpn-vxlan] vpn-target auto import-extcommunity

[Leaf2-vsi-vsi1-evpn-vxlan] quit

[Leaf2-vsi-vsi1] quit

Assigning L3 VXLAN IDs

# Assign a L3 VXLAN ID to VSI interface 2.

[Leaf2] interface vsi-interface 10000

[Leaf2-Vsi-interface10000] ip binding vpn-instance vpn1

[Leaf2-Vsi-interface10000] l3-vni 10000

[Leaf2-Vsi-interface10000] quit

Configuring BGP EVPN route advertisement

# Configure Leaf 2 to establish a BGP EVPN peer relationship with the RR.

[Leaf2] bgp 65000

[Leaf2-bgp-default] peer 172.16.10.1 as-number 65000

[Leaf2-bgp-default] peer 172.16.10.1 connect-interface loopback 0

[Leaf2-bgp-default] peer 172.16.10.1 password simple overlay

[Leaf2-bgp-default] address-family l2vpn evpn

[Leaf2-bgp-default-evpn] peer 172.16.10.1 enable

[Leaf2-bgp-default-evpn] quit

[Leaf2-bgp-default] quit

Mapping ACs to the VSI

# On Ten-GigabitEthernet 3/0/1, create Ethernet service instance 1 and map it to VSI vsi1.

[Leaf2] interface ten-gigabitethernet 3/0/1

[Leaf2-Ten-GigabitEthernet3/0/1] port link-mode bridge

[Leaf2-Ten-GigabitEthernet3/0/1] port link-type trunk

[Leaf2-Ten-GigabitEthernet3/0/1] undo port trunk permit vlan 1

[Leaf2-Ten-GigabitEthernet3/0/1] port trunk permit vlan 1002

[Leaf2-Ten-GigabitEthernet3/0/1] storm-constrain control shutdown

[Leaf2-Ten-GigabitEthernet3/0/1] service-instance 1

[Leaf2-Ten-GigabitEthernet3/0/1-srv1] encapsulation s-vid 1002

[Leaf2-Ten-GigabitEthernet3/0/1-srv1] statistics enable

[Leaf2-Ten-GigabitEthernet3/0/1-srv1] xconnect vsi vsi1

[Leaf2-Ten-GigabitEthernet3/0/1-srv1] quit

[Leaf2-Ten-GigabitEthernet3/0/1] quit

Configuring IGMP snooping

# Enable IGMP snooping globally.

[Leaf1] igmp-snooping

[Leaf1-igmp-snooping] global-enable

[Leaf1-igmp-snooping] quit

# Configure IGMP snooping for VSI vsi1.

[Leaf2] vsi vsi1

[Leaf2-vsi-vsi1] igmp-snooping enable

[Leaf2-vsi-vsi1] igmp-snooping drop-unknown

[Leaf2-vsi-vsi1] igmp-snooping proxy enable

# Configure Leaf 2 as an IGMP querier.

[Leaf2-vsi-vsi1] igmp-snooping querier

[Leaf2-vsi-vsi1] quit

Configuring the RR

Assigning IP addresses and configuring unicast routing

# Assign IP addresses to loopback interfaces, Ten-GigabitEthernet 3/0/1, and Ten-GigabitEthernet 3/0/2.

<Sysname> system-view

[Sysname] sysname RR

[RR] interface loopback 0

[RR-LoopBack0] ip address 172.16.10.1 255.255.255.255

[RR-LoopBack0] quit

[RR] interface ten-gigabitethernet 3/0/1

[RR-Ten-GigabitEthernet3/0/1] port link-mode route

[RR-Ten-GigabitEthernet3/0/1] ip address 12.1.1.3 24

[RR-Ten-GigabitEthernet3/0/1] quit

[RR] interface ten-gigabitethernet 3/0/2

[RR-Ten-GigabitEthernet3/0/2] port link-mode route

[RR-Ten-GigabitEthernet3/0/2] ip address 13.1.1.3 24

[RR-Ten-GigabitEthernet3/0/2] quit

# Configure OSPF for the devices to communicate at Layer 3 over the underlay network.

[RR] router id 172.16.10.1

[RR] ospf

[RR-ospf-1] area 0

[RR-ospf-1-area-0.0.0.0] network 172.16.10.1 0.0.0.0

[RR-ospf-1-area-0.0.0.0] network 12.1.1.3 0.0.0.255

[RR-ospf-1-area-0.0.0.0] network 13.1.1.3 0.0.0.255

[RR-ospf-1-area-0.0.0.0] quit

[RR-ospf-1] quit

Configuring BGP EVPN route advertisement

# Assign Leaf 1 and Leaf 2 to IBGP peer group leaf.

[RR] bgp 65000

[RR-bgp-default] group leaf internal

[RR-bgp-default] peer leaf connect-interface loopback 0

[RR-bgp-default] peer leaf password simple overlay

[RR-bgp-default] peer 172.16.0.1 group leaf

[RR-bgp-default] peer 172.16.0.2 group leaf

# Configure the device as an RR, configure it to establish BGP EVPN peer relationships with IBGP peer group leaf, and disable route target filtering of received BGP EVPN routes.

[RR-bgp-default] address-family l2vpn evpn

[RR-bgp-default-evpn] undo policy vpn-target

[RR-bgp-default-evpn] peer leaf enable

[RR-bgp-default-evpn] peer leaf reflect-client

[RR-bgp-default-evpn] quit

[RR-bgp-default] quit

Verifying the configuration

Verifying routing information

# Verify that the leaf devices and the RR have learned one another's OSPF routes and can communicate at Layer 3 over the underlay network.

[Leaf1] display ip routing-table



Destinations : 16       Routes : 16



Destination/Mask   Proto   Pre Cost        NextHop         Interface

0.0.0.0/32         Direct  0   0           127.0.0.1       InLoop0

12.1.1.0/24        Direct  0   0           12.1.1.1        XGE3/0/3

12.1.1.0/32        Direct  0   0           12.1.1.1        XGE3/0/3

12.1.1.1/32        Direct  0   0           127.0.0.1       InLoop0

12.1.1.255/32      Direct  0   0           12.1.1.1        XGE3/0/3

13.1.1.0/24        O_INTRA 10  2           12.1.1.3        XGE3/0/3

127.0.0.0/8        Direct  0   0           127.0.0.1       InLoop0

127.0.0.0/32       Direct  0   0           127.0.0.1       InLoop0

127.0.0.1/32       Direct  0   0           127.0.0.1       InLoop0

127.255.255.255/32 Direct  0   0           127.0.0.1       InLoop0

172.16.0.1/32      Direct  0   0           127.0.0.1       InLoop0

172.16.0.2/32      O_INTRA 10  2           12.1.1.3        XGE3/0/3

172.16.10.1/32     O_INTRA 10  1           12.1.1.3        XGE3/0/3

224.0.0.0/4        Direct  0   0           0.0.0.0         NULL0

224.0.0.0/24       Direct  0   0           0.0.0.0         NULL0

255.255.255.255/32 Direct  0   0           127.0.0.1       InLoop0

# Verify that the leaf devices and the RR have established BGP EVPN peer relationships with one another.

[Leaf1] display bgp peer l2vpn evpn



 BGP local router ID: 172.16.0.1

 Local AS number: 65000

 Total number of peers: 1                 Peers in established state: 1



  * - Dynamically created peer

  ^ - Peer created through link-local address

  Peer                    AS  MsgRcvd  MsgSent OutQ PrefRcv Up/Down  State



  172.16.10.1          65000       24       27    0       4 00:14:59 Established

Verifying VSI configuration

# Verify that VXLAN tunnels and ACs are correctly mapped to VSI vsi1.

[Leaf1] display l2vpn vsi verbose

VSI Name: Auto_L3VNI10000_2

  VSI Index               : 1

  VSI State               : Down

  MTU                     : 1500

  Bandwidth               : -

  Broadcast Restrain      : 5120 kbps

  Multicast Restrain      : 5120 kbps

  Unknown Unicast Restrain: 5120 kbps

  MAC Learning            : Enabled

  MAC Table Limit         : -

  MAC Learning rate       : Unlimited

  Drop Unknown            : Disabled

  Flooding                : Enabled

  Statistics              : Disabled

  Gateway Interface       : VSI-interface 2

  VXLAN ID                : 10000



VSI Name: vsi1

  VSI Index               : 0

  VSI State               : Up

  MTU                     : 1500

  Bandwidth               : -

  Broadcast Restrain      : 5120 kbps

  Multicast Restrain      : 5120 kbps

  Unknown Unicast Restrain: 5120 kbps

  MAC Learning            : Enabled

  MAC Table Limit         : -

  MAC Learning rate       : Unlimited

  Drop Unknown            : Disabled

  Flooding                : Enabled

  Statistics              : Enabled

  Input Statistics        :

    Octets   :0

    Packets  :0

    Errors   :0

    Discards :0

  Output Statistics       :

    Octets   :0

    Packets  :0

    Errors   :0

    Discards :0

  Gateway Interface       : VSI-interface 1

  VXLAN ID                : 10

  Tunnels:

    Tunnel Name          Link ID    State    Type        Flood proxy

    Tunnel0              0x5000000  UP       Auto        Disabled

  ACs:

    AC                                 Link ID    State       Type

    XGE3/0/1 srv1                      0          Up          Manual

    XGE3/0/2 srv1                      1          Up          Manual

Verifying IGMP snooping and SMET routes

# Verify that IGMP snooping is enabled on a per-VSI basis on the leaf devices.

[Leaf1] display igmp-snooping vsi vsi1

IGMP snooping information: VSI vsi1

 IGMP snooping: Enabled

 Forwarding mode: IP

 Drop-unknown: Enabled

 Version: 2

 Host-aging-time: 260s

 Router-aging-time: 260s

 Max-response-time: 10s

 Last-member-query-interval: 1s

 Querier: Enabled (IP:10.255.255.254, Expires: 00:01:39)

 Querier-election: Disabled

 Query-interval: 125s

 General-query source IP: 10.255.255.254

 Special-query source IP: 10.255.255.254

 Report source IP: 10.255.255.254

 Leave source IP: 10.255.255.254

 Proxy: Enabled

 IPP: -(Link ID: 0xffff)

# Verify that Leaf 1 has a dynamic IGMP snooping group entry for multicast group (0.0.0.0, 225.0.0.1).

[Leaf1] display igmp-snooping group

Total 1 entries.



VSI vsi1: Total 1 entries.

  (0.0.0.0, 225.0.0.1)

    Host ports (1 in total):

      XGE3/0/1 (Link ID 0)                        (00:03:42)

# Verify that Leaf 1 has created an SMET route.

[Leaf1] display evpn route smet

VSI name: vsi1

  Source address :

  Group address  : 225.0.0.1

  Local version  : v2

  ACs   :

    AC                               Link ID    Flags

    XGE3/0/1 srv1                    0          Local

# Verify that Leaf 2 has received the SMET route created by Leaf 1.

[Leaf2] display evpn route smet

VSI name: vsi1

  Source address :

  Group address  : 225.0.0.1

  Local version  : -

  Peers :

    Nexthop          Tunnel name     Link ID    Remote version

    172.16.0.1       Tunnel0         0x5000000  v2

# Verify that Leaf 1 has a dynamic IGMP snooping group entry for multicast group (0.0.0.0, 225.0.0.1).

[Leaf2] display igmp-snooping evpn-group

Total 1 entries.



VSI vsi1: Total 1 entries.

  (0.0.0.0, 225.0.0.1)

    Host ports (1 in total):

      Tun0 (VXLAN ID 10)

Configuration files

·     Leaf 1:

#

 sysname Leaf1

#

ip vpn-instance vpn1

 route-distinguisher 1:1

 #

 address-family ipv4

  vpn-target 2:2 import-extcommunity

  vpn-target 2:2 export-extcommunity

 #

 address-family evpn

  vpn-target 1:1 import-extcommunity

  vpn-target 1:1 export-extcommunity

#

vxlan tunnel mac-learning disable

#

 router id 172.16.0.1

#

ospf 1

 area 0.0.0.0

  network 12.1.1.0 0.0.0.255

  network 172.16.0.1 0.0.0.0

#

igmp-snooping

 global-enable

#

 l2vpn enable

 vxlan tunnel arp-learning disable

#

vsi vsi1

 gateway vsi-interface 1

 statistics enable

 arp suppression enable

 vxlan 10

 evpn encapsulation vxlan

  route-distinguisher auto

  vpn-target auto export-extcommunity

  vpn-target auto import-extcommunity

 igmp-snooping enable

 igmp-snooping drop-unknown

 igmp-snooping querier

 igmp-snooping proxy enable

#

interface Ten-GigabitEthernet3/0/1

 port link-mode bridge

 port link-type trunk

 undo port trunk permit vlan 1

 port trunk permit vlan 1000

#

 service-instance 1

  encapsulation s-vid 1000

  statistics enable

  xconnect vsi vsi1

#

interface Ten-GigabitEthernet3/0/2

 port link-mode bridge

 port link-type trunk

 undo port trunk permit vlan 1

 port trunk permit vlan 1001

#

 service-instance 1

  encapsulation s-vid 1001

  statistics enable

  xconnect vsi vsi1

#

interface LoopBack0

 ip address 172.16.0.1 255.255.255.255

#

interface Ten-GigabitEthernet3/0/3

 port link-mode route

 combo enable copper

 ip address 12.1.1.1 255.255.255.0

#

interface Vsi-interface1

 ip binding vpn-instance vpn1

 ip address 10.255.255.254 255.0.0.0

 mac-address 0000-0001-0001

 distributed-gateway local

#

interface Vsi-interface2

 ip binding vpn-instance vpn1

 l3-vni 10000

#

bgp 65000

 peer 172.16.10.1 as-number 65000

 peer 172.16.10.1 connect-interface LoopBack0

 peer 172.16.10.1 password simple overlay

 #

 address-family l2vpn evpn

  peer 172.16.10.1 enable

#

return

·     Leaf 2:

#

 sysname Leaf2

#

ip vpn-instance vpn1

 route-distinguisher 1:1

 #

 address-family ipv4

  vpn-target 2:2 import-extcommunity

  vpn-target 2:2 export-extcommunity

 #

 address-family evpn

  vpn-target 1:1 import-extcommunity

  vpn-target 1:1 export-extcommunity

#

vxlan tunnel mac-learning disable

#

 router id 172.16.0.2

#

ospf 1

 area 0.0.0.0

  network 13.1.1.0 0.0.0.255

  network 172.16.0.2 0.0.0.0

#

igmp-snooping

 global-enable

#

 l2vpn enable

 vxlan tunnel arp-learning disable

#

vsi vsi1

 gateway vsi-interface 1

 statistics enable

 arp suppression enable

 vxlan 10

 evpn encapsulation vxlan

  route-distinguisher auto

  vpn-target auto export-extcommunity

  vpn-target auto import-extcommunity

 igmp-snooping enable

 igmp-snooping drop-unknown

 igmp-snooping querier

 igmp-snooping proxy enable

#

interface LoopBack0

 ip address 172.16.0.2 255.255.255.255

#

interface Ten-GigabitEthernet3/0/1

 port link-mode bridge

 port link-type trunk

 undo port trunk permit vlan 1

 port trunk permit vlan 1002

 storm-constrain control shutdown

 #

 service-instance 1

  encapsulation s-vid 1002

  statistics enable

  xconnect vsi vsi1

#

interface Ten-GigabitEthernet3/0/3

 port link-mode route

 ip address 13.1.1.1 255.255.255.0

#

interface Vsi-interface1

 ip binding vpn-instance vpn1

 ip address 10.255.255.254 255.0.0.0

 mac-address 0000-0001-0001

#

interface Vsi-interface2

 ip binding vpn-instance vpn1

 l3-vni 10000

#

bgp 65000

 peer 172.16.10.1 as-number 65000

 peer 172.16.10.1 connect-interface LoopBack0

 peer 172.16.10.1 password simple overlay

 #

 address-family l2vpn evpn

  peer 172.16.10.1 enable

#

return

·     RR:

#

 sysname RR

#

 router id 172.16.10.1

#

ospf 1

 area 0.0.0.0

  network 12.1.1.0 0.0.0.255

  network 13.1.1.0 0.0.0.255

  network 172.16.10.1 0.0.0.0

#

interface LoopBack0

 ip address 172.16.10.1 255.255.255.255

#

interface Ten-GigabitEthernet3/0/1

 port link-mode route

 ip address 12.1.1.3 255.255.255.0

#

interface Ten-GigabitEthernet3/0/2

 port link-mode route

 ip address 13.1.1.3 255.255.255.0

#

bgp 65000

 group leaf internal

 peer leaf connect-interface LoopBack0

 peer leaf password simple overlay

 peer 172.16.0.1 group leaf

 peer 172.16.0.2 group leaf

 #

 address-family l2vpn evpn

  undo policy vpn-target

  peer leaf enable

  peer leaf reflect-client

#

return
