Upgrading software

About software upgrade

Software upgrade enables you to upgrade a software version, add new features, and fix software bugs. This chapter describes software types and release forms, compares software upgrade methods, and provides the procedures for upgrading software from the CLI.

Software types

The following software types are available:

·     BootWare image—Also called the Boot ROM image. This image contains a basic segment and an extended segment.

¡     The basic segment is the minimum code that bootstraps the system.

¡     The extended segment enables hardware initialization and provides system management menus. When the device cannot start up correctly, you can use the menus to load software and the startup configuration file or manage files.

Typically, the BootWare image is integrated into the Boot image to avoid software compatibility errors.

·     Comware image—Includes the following image subcategories:

¡     Boot image—A .bin file that contains the Linux operating system kernel. It provides process management, memory management, and file system management.

¡     System image—A .bin file that contains the Comware kernel and standard features, including device management, interface management, configuration management, and routing.

¡     Feature image—A .bin file that contains advanced or customized software features. You can purchase feature images as needed.

¡     Patch image—A .bin file that is released for fixing bugs without rebooting the device. A patch image does not add or remove features.

Patch images have the following types:

-     Incremental patch images—A new patch image can cover all, part, or none of the functions provided by an old patch image. A new patch image can coexist with an old patch image on the device only when the former covers none of the functions provided by the latter.

-     Non-incremental patch images—A new non-incremental patch image covers all functions provided by an old non-incremental patch image. Each boot, system, or feature image can have one non-incremental patch image, and these patch images can coexist on the device. The device uninstalls the old non-incremental patch image before installing a new non-incremental patch image.

An incremental patch image and a non-incremental patch image can coexist on the device.

Comware images that have been loaded are called current software images. Comware images specified to load at the next startup are called startup software images.

BootWare image, boot image, and system image are required for the device to operate.

You can install up to 32 .bin files on the device, including one boot image file, one system image file, and up to 30 feature and patch image files.

Software release forms

Software images are released in one of the following forms:

·     Separate .bin files. You must verify compatibility between software images.

·     As a whole in one .ipe package file. The images in an .ipe package file are compatible. The system decompresses the file automatically, loads the .bin images and sets them as startup software images.



NOTE: Software image file names use the model-comware version-image type-release format. This document uses boot.bin and system.bin as boot and system image file names.



Upgrade methods

Upgrade method	Software types	Remarks
Upgrading from the CLI by using the boot loader method	·     BootWare image ·     Comware images (excluding incremental patches)	This method is disruptive. You must reboot the entire device to complete the upgrade.
Performing an ISSU from the CLI	Comware images	This method enables a software upgrade with a minimum amount of downtime. Use this method if possible. For more information about ISSU, see "Performing an ISSU."
Upgrading from the BootWare menu	·     BootWare image ·     Comware images	Use this method when the device cannot start up correctly. To use this method, first connect to the console port and power cycle the device. Then, press Ctrl+B at prompt to access the BootWare menu. For more information about upgrading software from the BootWare menu, see the release notes for the software version.  IMPORTANT: Use this method only when you do not have any other choice.



This chapter covers only upgrading software from the CLI by using the boot loader method.



Restrictions and guidelines: Software upgrade

As a best practice, store the startup images in a fixed storage medium. If you store the startup images in a hot swappable storage medium, do not remove the hot swappable storage medium during the startup process.

A software upgrade will take a long time if CPLD firmware is also updated. For the device to start up correctly, do not power off the device during the software upgrade.

Upgrading device software by using the boot loader method

Software upgrade tasks at a glance

To upgrade software, perform one of the following tasks:

1.     Upgrade the IRF fabric:

a.     (Optional.) Preloading the BootWare image to BootWare

If a BootWare upgrade is required, you can perform this task to shorten the subsequent upgrade time. This task helps reduce upgrade problems caused by unexpected power failure. If you skip this task, the device upgrades the BootWare automatically when it upgrades the startup software images.

b.     Specifying startup images and completing the upgrade

2.     (Optional.) Synchronizing startup images from the master device to subordinate devices

Perform this task when the startup images on subordinate devices are not the same version as those on the master device.

Prerequisites

1.     Use the display version command to verify the current BootWare image version and startup software version.

2.     Use the release notes for the upgrade software version to evaluate the upgrade impact on your network and verify the following items:

¡     Software and hardware compatibility.

¡     Version and size of the upgrade software.

¡     Compatibility of the upgrade software with the current BootWare image and startup software image.



3.     Use the dir command to verify that all IRF member devices have sufficient storage space for the upgrade images. If the storage space is not sufficient on any member device, delete unused files by using the delete command. For more information, see "Managing file systems."

4.     Use FTP or TFTP to transfer the upgrade image file to the root directory of a file system. For more information about FTP and TFTP, see "Configuring FTP" or "Configuring TFTP." For more information about file systems, see "Managing file systems."

Preloading the BootWare image to BootWare



1.     Enter system view.

system-view

2.     Load the upgrade BootWare image to the Normal area of BootWare.

bootrom update file file slot slot-number-list ]

Specify the downloaded software image file for the file argument.



The new BootWare image takes effect at a reboot.

Specifying startup images and completing the upgrade

Perform the following steps in user view:

1.     Specify main or backup startup images for all member devices.

¡     Use an .ipe file:

boot-loader file ipe-filename [ patch filename&<1-16> ] { all | slot slot-number } { backup | main }

¡     Use .bin files:

boot-loader file boot filename system filename [ feature filename&<1-30> ] [ patch filename&<1-16> ] { all | slot slot-number } { backup | main }

As a best practice in a multichassis IRF fabric, specify the all keyword for the command. If you use the slot slot-number option to upgrade member devices one by one, version inconsistencies occur among the member devices during the upgrade.

2.     Save the running configuration.

save

This step ensures that any configuration you have made can survive a reboot.

3.     Reboot the IRF fabric.

reboot

4.     (Optional.) Verify the device is running the correct software version after upgrade.

display version

Synchronizing startup images from the master device to subordinate devices

About this task

Perform this task when the startup images on subordinate devices are not the same version as those on the master device.

This task synchronizes startup images that are running on the master device to subordinate devices. If any of the startup images does not exist or is invalid, the synchronization fails.

The startup images synchronized to subordinate devices are set as main startup images, regardless of whether the source startup images are main or backup.

Restrictions and guidelines

If an ISSU or patch installation has been performed on the master device, use the install commit command to update the set of main startup images on the master device before software synchronization. This command ensures startup image consistency between the master and subordinate devices.

Procedure

Perform the following steps in user view:

1.     Synchronize startup images from the master to subordinate devices.

boot-loader update { all | slot slot-number }

2.     Reboot the subordinate devices.

reboot slot slot-number [ force ]

Display and maintenance commands for software image settings

Execute display commands in any view and execute reset commands in user view.



Task	Command
Display current software images and startup software images.	display boot-loader [ slot slot-number

‌



Software upgrade examples

Example: Upgrading device software

Network configuration

As shown in Figure 1, use the file startup-a2105.ipe to upgrade software images for the IRF fabric.

Figure 1 Network diagram



Procedure

# Configure IP addresses and routes. Make sure the device and the TFTP server can reach each other. (Details not shown.)

# Configure TFTP settings on both the device and the TFTP server. (Details not shown.)

# Display information about the current software images.

<Sysname> display version

# Back up the current software images.

<Sysname> copy boot.bin boot_backup.bin

<Sysname> copy system.bin system_backup.bin

# Specify boot_backup.bin and system_backup.bin as the backup startup image files for all IRF member devices.

<Sysname> boot-loader file boot flash:/boot_backup.bin system flash:/system_backup.bin slot 1 backup

<Sysname> boot-loader file boot flash:/boot_backup.bin system flash:/system_backup.bin slot 2 backup

# Use TFTP to download the startup-a2105.ipe image file from the TFTP server to the root directory of the flash memory on the master device.

<Sysname> tftp 2.2.2.2 get startup-a2105.ipe

# Specify startup-a2105.ipe as the main startup image file for all IRF member devices.

<Sysname> boot-loader file flash:/startup-a2105.ipe slot 1 main

<Sysname> boot-loader file flash:/startup-a2105.ipe slot 2 main

# Verify the startup image settings.

<Sysname> display boot-loader

# Reboot the IRF fabric to complete the upgrade.

<Sysname> reboot

# Verify that the IRF fabric is running the correct software.

<Sysname> display version
