Managing the device



About device management

This chapter describes how to configure basic device parameters and manage the device.

Restrictions: Command and hardware compatibility

The WX1800H series, WX2500H series, MAK series, and WX3000H series access controllers do not support parameters or commands that are available only in IRF mode.

Device management tasks at a glance

All device management tasks are optional. You can perform any of the tasks in any order.

·     Configuring basic parameters

¡     Configuring the device name

¡     Configuring the system time

¡     Enabling displaying the copyright statement

¡     Configuring banners

·     Configuring security parameters

¡     Disabling password recovery capability

·     Adjusting device capacities

¡     Setting the port status detection timer

·     Monitoring the device

¡     Monitoring CPU usage

¡     Setting memory alarm thresholds

¡     Setting the temperature alarm thresholds

·     Managing resources

¡     Verifying and diagnosing transceiver modules

·     Maintaining the device

¡     Scheduling a task

¡     Rebooting the device

¡     Restoring the factory-default configuration

Configuring the device name

About this task

A device name (also called hostname) identifies a device in a network and is used in CLI view prompts. For example, if the device name is Sysname, the user view prompt is <Sysname>.

Procedure

1.     Enter system view.

system-view

2.     Configure the device name.

sysname sysname

By default, the device name is H3C.

Configuring the system time

About the system time

Correct system time is essential to network management and communication. Configure the system time correctly before you run the device on the network.

The device can use one of the following methods to obtain the system time:

·     Uses the locally set system time, and then uses the clock signals generated by its built-in crystal oscillator to maintain the system time.

·     Periodically obtains the UTC time from an NTP source, and uses the UTC time, time zone, and daylight saving time to calculate the system time. For more information about NTP, see System Management Configuration Guide.

The system time calculated by using the UTC time from a time source is more precise.

Restrictions and guidelines for configuring the system time

After you execute the clock protocol none command, the clock datetime command determines the system time, whether or not the time zone or daylight saving time has been configured.

If you configure or change the time zone or daylight saving time after the device obtains the system time, the device recalculates the system time. To view the system time, use the display clock command.

System time configuration tasks at a glance

To configure the system time, perform the following tasks:

1.     Configuring the system time

Choose one of the following tasks:

¡     Setting the system time at the CLI

¡     Obtaining the UTC time through a time protocol

2.     (Optional.) Setting the time zone

Make sure each network device uses the time zone of the place where the device resides.

3.     (Optional.) Setting the daylight saving time

Make sure each network device uses the daylight saving time parameters of the place where the device resides.

Setting the system time at the CLI

1.     Enter system view.

system-view

2.     Configure the device to use the local system time.

clock protocol none

By default, the device uses the NTP time source.

If you execute the clock protocol command multiple times, the most recent configuration takes effect.

3.     Return to user view.

quit

4.     Set the local system time.

clock datetime time date

By default, the system time is UTC time 00:00:00 01/01/2011.



‌

Obtaining the UTC time through a time protocol

1.     Enter system view.

system-view

2.     Specify the system time source.

clock protocol ntp

By default, the device uses the NTP time source.

If you execute the clock protocol command multiple times, the most recent configuration takes effect.

3.     Configure time protocol parameters.

For more information about NTP configuration, see System Management Configuration Guide.

Setting the time zone

1.     Enter system view.

system-view

2.     Set the time zone.

clock timezone zone-name { add | minus } zone-offset

By default, the system uses the UTC time zone.

Setting the daylight saving time

1.     Enter system view.

system-view

2.     Set the daylight saving time.

clock summer-time name start-time start-date end-time end-date add-time

By default, the daylight saving time is not set.

Enabling displaying the copyright statement

About this task

This feature enables the device to display the copyright statement in the following situations:

·     When a Telnet or SSH user logs in.

·     When a console user quits user view. This is because the device automatically tries to restart the user session.

If you disable displaying the copyright statement, the device does not display the copyright statement in any situations.

Procedure

1.     Enter system view.

system-view

2.     Enable displaying the copyright statement.

copyright-info enable

By default, displaying the copyright statement is enabled.

Configuring banners

About this task

Banners are messages that the system displays when a user logs in.

The system supports the following banners:

·     Legal banner—Appears after the copyright statement. To continue login, the user must enter Y or press Enter. To quit the process, the user must enter N. Y and N are case insensitive.

·     Message of the Day (MOTD) banner—Appears after the legal banner and before the login banner.

·     Login banner—Appears only when password or scheme authentication is configured.

·     Shell banner—Appears before the user enters user view.

The system displays the banners in the following order: legal banner, MOTD banner, login banner, and shell banner.

Banner input methods

You can configure a banner by using one of the following methods:

·     Input the entire command line in a single line.

The banner cannot contain carriage returns. The entire command line, including the command keywords, the banner, and the delimiters, can have a maximum of 511 characters. The delimiters for the banner can be any printable character but must be the same. You cannot press Enter before you input the end delimiter.

For example, you can configure the shell banner "Have a nice day." as follows:

<System> system-view

[System] header shell %Have a nice day.%

·     Input the command line in multiple lines.

The banner can contain carriage returns. A carriage return is counted as two characters.

To input a banner configuration command line in multiple lines, use one of the following methods:

¡     Press Enter after the final command keyword, type the banner, and end the final line with the delimiter character %. The banner plus the delimiter can have a maximum of 1999 characters.

For example, you can configure the banner "Have a nice day." as follows:

<System> system-view

[System] header shell

Please input banner content, and quit with the character '%'.

Have a nice day.%

¡     After you type the final command keyword, type any printable character as the start delimiter for the banner and press Enter. Then, type the banner and end the final line with the same delimiter. The banner plus the end delimiter can have a maximum of 1999 characters.

For example, you can configure the banner "Have a nice day." as follows:

<System> system-view

[System] header shell A

Please input banner content, and quit with the character 'A'.

Have a nice day.A

¡     After you type the final command keyword, type the start delimiter and part of the banner. Make sure the final character of the final string is different from the start delimiter. Then, press Enter, type the rest of the banner, and end the final line with the same delimiter. The banner plus the start and end delimiters can have a maximum of 2002 characters.

For example, you can configure the banner "Have a nice day." as follows:

<System> system-view

[System] header shell AHave a nice day.

Please input banner content, and quit with the character 'A'.

A

Procedure

1.     Enter system view.

system-view

2.     Configure the legal banner.

header legal text

3.     Configure the MOTD banner.

header motd text

4.     Configure the login banner.

header login text

5.     Configure the shell banner.

header shell text

Disabling password recovery capability

About this task

Password recovery capability controls console user access to the device configuration and SDRAM from BootWare menus. For more information about BootWare menus, see the release notes.

If password recovery capability is enabled, a console user can access the device configuration without authentication to configure a new password.

If password recovery capability is disabled, console users must restore the factory-default configuration before they can configure new passwords. Restoring the factory-default configuration deletes the next-startup configuration files.

To enhance system security, disable password recovery capability.

Procedure

1.     Enter system view.

system-view

2.     Disable password recovery capability.

undo password-recovery enable

By default, password recovery capability is enabled.

Setting the port status detection timer

About this task

The device starts a port status detection timer when a port is shut down by a protocol. Once the timer expires, the device brings up the port so the port status reflects the port's physical status.

Procedure

1.     Enter system view.

system-view

2.     Set the port status detection timer.

shutdown-interval time

The default setting is 30 seconds.

Monitoring CPU usage

About this task

To monitor CPU usage, the device performs the following operations:

·     Samples CPU usage at 1-minute intervals and compares the samples with the CPU usage threshold and the CPU usage recovery threshold.

¡     If a sample is greater than or equal to the CPU usage threshold, the device determines the CPU usage is high and sends traps to affected service modules and processes.

¡     If a sample decreases to or below the CPU usage recovery threshold, the device determines the CPU usage has recovered and sends traps to affected service modules and processes.

·     Samples and saves CPU usage at a configurable interval if CPU usage tracking is enabled. You can use the display cpu-usage history command to display the historical CPU usage statistics in a coordinate system.

Figure 1 CPU alarms and alarm-removed notifications

‌

Procedure

1.     Enter system view.

system-view

2.     Set the CPU usage alarm thresholds.

In standalone mode:

monitor cpu-usage threshold severe-threshold

In IRF mode:

monitor cpu-usage threshold severe-threshold [ slot slot-number ]

By default, the CPU usage alarm threshold is 99%.





3.     Set the sampling interval for CPU usage tracking.

In standalone mode:

monitor cpu-usage interval interval

In IRF mode:

monitor cpu-usage interval interval [ slot slot-number ]

By default, the sampling interval for CPU usage tracking is 1 minute.

4.     Enable CPU usage tracking.

In standalone mode:

monitor cpu-usage enable

In IRF mode:

monitor cpu-usage enable [ slot slot-number ]

By default, CPU usage tracking is enabled.

Setting memory alarm thresholds

About this task

To ensure correct operation and improve memory efficiency, the system monitors the amount of free memory space in real time. If the amount of free memory space reaches the minor, severe, or critical alarm threshold, the system issues an alarm to affected service modules and processes.

As shown in Table 1 and Figure 2, the system supports the following free-memory thresholds:

·     Normal state threshold.

·     Minor alarm threshold.

·     Severe alarm threshold.

·     Critical alarm threshold.

Table 1 Memory alarm notifications and memory alarm-removed notifications

‌

Figure 2 Memory alarm notifications and alarm-removed notifications



‌

Procedure

1.     Enter system view.

system-view

2.     Set the memory usage threshold.

In standalone mode:

memory-threshold usage memory-threshold

In IRF mode:

memory-threshold [ slot slot-number ] usage memory-threshold

By default, the memory usage threshold is 100%.

3.     Set the free-memory thresholds.

In standalone mode:

memory-threshold  minor minor-value severe severe-value critical critical-value normal normal-value

In IRF mode:

memory-threshold [ slot slot-number ] minor minor-value severe severe-value critical critical-value normal normal-value

The default settings vary by device model. To view the default settings, use the undo memory-threshold command to restore the default settings and then execute the display memory-threshold command.

Setting the temperature alarm thresholds

About this task

The device monitors its temperature based on the following thresholds:

·     Low-temperature threshold.

·     High-temperature warning threshold.

·     High-temperature alarming threshold.

When the device temperature drops below the low-temperature threshold or reaches the high-temperature warning or alarming threshold, the device performs the following operations:

·     Sends log messages and traps.

·     Sets LEDs on the device panel.

Procedure

1.     Enter system view.

system-view

2.     Configure the temperature alarm thresholds.

In standalone mode:

temperature-limit { hotspot | inflow } sensor-number lowlimit warninglimit [ alarmlimit ]

In IRF mode:

temperature-limit slot slot-number { hotspot | inflow } sensor-number lowlimit warninglimit [ alarmlimit ]

The defaults vary by temperature sensor model. To view the defaults, execute the undo temperature-limit and display environment commands in turn.

The high-temperature alarming threshold must be higher than the high-temperature warning threshold, and the high-temperature warning threshold must be higher than the low-temperature threshold.

Verifying and diagnosing transceiver modules

Hardware compatibility with transceiver module verification and diagnosis

‌

‌

Verifying transceiver modules

About this task

You can use one of the following methods to verify the genuineness of a transceiver module:

·     Display the key parameters of a transceiver module, including its transceiver type, connector type, central wavelength of the transmit laser, transfer distance, and vendor name.

·     Display its electronic label. The electronic label is a profile of the transceiver module and contains the permanent configuration, including the serial number, manufacturing date, and vendor name. The data was written to the transceiver module or the device's storage component during debugging or testing of the transceiver module or device.

The device regularly checks transceiver modules for their vendor names. If a transceiver module does not have a vendor name or the vendor name is not H3C, the device repeatedly outputs traps and log messages. For information about logging rules, see information center in System Management Configuration Guide.

Procedure

To verify transceiver modules, execute the following commands in any view:

·     Display the key parameters of transceiver modules.

display transceiver interface [ interface-type interface-number ]

·     Display the electrical label information of transceiver modules.

display transceiver manuinfo interface [ interface-type interface-number ]

Diagnosing transceiver modules

About this task

The device provides the alarm and digital diagnosis functions for transceiver modules. When a transceiver module fails or is not operating correctly, you can perform the following tasks:

·     Check the alarms that exist on the transceiver module to identify the fault source.

·     Examine the key parameters monitored by the digital diagnosis function, including the temperature, voltage, laser bias current, TX power, and RX power.

Procedure

To diagnose transceiver modules, execute the following commands in any view:

·     Display transceiver alarms.

display transceiver alarm interface [ interface-type interface-number ]

·     Display the current values of the digital diagnosis parameters on transceiver modules.

display transceiver diagnosis interface [ interface-type interface-number ]

Enabling alarm upon detection of a third-party transceiver module

About this task

Upon installation of a transceiver module, the system reads vendor information from it to determine whether it is a third-party transceiver module. If it is a third-party module, the device sends a notification and a log message to notify the user of replacing it with an H3C transceiver module. You can use display transceiver manuinfo to obtain vendor information for a transceiver module.

Procedure

1.     Enter system view.

system-view

2.     Enable alarm upon detection of a third-party transceiver module.

transceiver third-party alarm enable

By default, alarm is enabled upon detection of a third-party transceiver module.

Scheduling a task

About task scheduling

You can schedule the device to automatically execute a command or a set of commands without administrative interference.

You can configure a periodic schedule or a non-periodic schedule. A non-periodic schedule is not saved to the configuration file and is lost when the device reboots. A periodic schedule is saved to the startup configuration file and is automatically executed periodically.

Restrictions and guidelines

·     To assign a command (command A) to a job, you must first assign the job the command or commands for entering the view of command A.

·     Make sure all commands in a schedule are compliant to the command syntax. The system does not check the syntax when you assign a command to a job.

·     A schedule cannot contain any one of these commands: telnet, ftp, ssh2, and monitor process.

·     A schedule does not support user interaction. If a command requires a yes or no answer, the system always assumes that a Y or Yes is entered. If a command requires a character string input, the system assumes that either the default character string (if any) or a null string is entered.

·     A schedule is executed in the background, and no output (except for logs, traps, and debug information) is displayed for the schedule.

Procedure

1.     Enter system view.

system-view

2.     Create a job.

scheduler job job-name

3.     Assign a command to the job.

command id command

By default, no command is assigned to a job.

You can assign multiple commands to a job. A command with a smaller ID is executed first.

4.     Exit to system view.

quit

5.     Create a schedule.

scheduler schedule schedule-name

6.     Assign a job to the schedule.

job job-name

By default, no job is assigned to a schedule.

You can assign multiple jobs to a schedule. The jobs will be executed concurrently.

7.     Assign user roles to the schedule.

user-role role-name

By default, a schedule has the user role of the schedule creator.

You can assign a maximum of 64 user roles to a schedule. A command in a schedule can be executed if it is permitted by one or more user roles of the schedule.

8.     Specify the execution time for the schedule.

Choose one option as needed:

¡     Execute the schedule at specific points of time.

time at time date

time once at time [ month-date month-day | week-day week-day&<1-7> ]

¡     Execute the schedule after a period of time.

time once delay time

¡     Execute the schedule at the specified time on every specified day in a month or week.

time repeating at time [ month-date [ month-day | last ] | week-day week-day&<1-7> ]

¡     Execute the schedule periodically from the specified time on.

time repeating [ at time [date ] ] interval interval

By default, no execution time is specified for a schedule.

The time commands overwrite each other. The most recently executed command takes effect.

Example: Scheduling a task

Network configuration

As shown in Figure 3, the client needs to access the AC. The AP is connected to the AC through the switch. The AC acts as the DHCP server to assign IP addresses to the AP and client.

To save energy, configure the AC to perform the following operations:

·     Enable the interface connected to the AP (Radio 1) at 8:00 a.m. every day.

·     Disable the interface connected to the AP (Radio 1) at 20:00 every day.

Figure 3 Network diagram

‌

Procedure

# Configure wireless access on the AC. For more information, see WLAN access configuration in WLAN Access Configuration Guide.

# Enter system view.

<AC> system-view

# Configure a job for disabling the interface.

[AC] scheduler job radio_disable

[AC-job-radio_disable] command 1 system-view

[AC-job-radio_disable] command 2 wlan ap ap1 model WA6320

[AC-job-radio_disable] command 3 radio 1

[AC-job-radio_disable] command 4 radio disable

[AC-job-radio_disable] quit

# Configure a periodic schedule for disabling the interface at 20:00 every day.

[AC] scheduler schedule stop_radio

[AC-schedule-stop_radio] job radio_disable

[AC-schedule-stop_radio] time repeating at 20:00

[AC-schedule-stop_radio] quit

# Configure a job for enabling the interface.

[AC] scheduler job radio_enable

[AC-job-radio_enable] command 1 system-view

[AC-job-radio_enable] command 2 wlan ap ap1 model WA6320

[AC-job-radio_enable] command 3 radio 1

[AC-job-radio_enable] command 4 radio enable

[AC-job-radio_enable] quit

# Configure a periodic schedule for enabling the interface at 8:00 a.m. every day.

[AC] scheduler schedule start_radio

[AC-schedule-start_radio] job radio_enable

[AC-schedule-start_radio] time repeating at 8:00

[AC-schedule-start_radio] quit

Verifying the configuration

# On the AC, display detailed information about AP1. Verify that the value of the Admin State field is UP between 8:00 and 20:00 and is DOWN at any other time.

[AC] display wlan ap name ap1 verbose

AP name                       : ap1

AP ID                         : 1

AP group name                 : default-group

State                         : Run

Backup Type                   : NULL

Online time                   : 0 days 2 hours 18 minutes 10 seconds

System up time                : 0 days 2 hours 19 minutes 11 seconds

Model                         : WA6320

Region code                   : CN

Region code lock              : Disable

Serial ID                     : 210235A1BSC123000050

MAC address                   : 586a-b1fb-e2c0

IP address                    : 100.1.0.1

H/W version                   : Ver.C

S/W version                   : V700R001B64D003

Boot version                  : 7.01

Description                   : Not configured

Priority                      : 4

Echo interval                 : 10 seconds

Statistics report interval    : 50 seconds

Jumbo frame value             : 1500

MAC type                      : Local MAC & Split MAC

Tunnel mode                   : Local Bridging & 802.3 Frame & Native Frame

Discovery type                : Unknown

Retransmission count          : 3

Retransmission interval       : 5 seconds

Firmware upgrade              : Enabled

Sent control packets          : 3159

Received control packets      : 3159

Connection count              : 1

Backup Ipv4                   : Not configured

Backup Ipv6                   : Not configured

Tunnel encryption             : Disabled

LED mode                      : Normal

Radio 1:

    Basic BSSID               : 586a-b1fb-e2c0

    Admin state               : Up

    Radio type                : 802.11ax

    Antenna type              : internal

    Client dot11ac-only       : Disabled

    Client dot11n-only        : Disabled

    Channel band-width        : 20/40/80MHz

    Operating bandwidth       : 20/40/80MHz

    Secondary channel mode    : SCA

    Short GI for 20MHz        : Supported

    Short GI for 40MHz        : Supported

    Short GI for 80MHz        : Supported

    Short GI for 160MHz       : Not supported

    MIMO                      : Not Config

    Green-Energy-Management   : Disabled

    A-MSDU                    : Enabled

    A-MPDU                    : Enabled

    LDPC                      : Not Supported

    STBC                      : Supported

    Operational VHT-MCS Set:

        Mandatory             : Not configured

        Supported             : NSS1 0,1,2,3,4,5,6,7,8,9

                                NSS2 0,1,2,3,4,5,6,7,8,9

        Multicast             : Not configured

    Operational HT MCS Set:

        Mandatory             : Not configured

        Supported             : 0, 1, 2, 3, 4, 5, 6, 7, 8, 9,

                                10, 11, 12, 13, 14, 15

        Multicast             : Not configured

    Channel                   : 149

    Max power                 : 20 dBm

    Operational rate:

        Mandatory             : 6, 12, 24 Mbps

        Multicast             : Auto

        Supported             : 9, 18, 36, 48, 54 Mbps

        Disabled              : Not configured

    Distance                  : 1 km

    ANI                       : Enabled

    Fragmentation threshold   : 2346 bytes

    Beacon interval           : 100 TU

    Protection threshold      : 2346 bytes

    Long retry threshold      : 4

    Short retry threshold     : 7

    Maximum rx duration       : 2000 ms

    Noise floor               : -102 dBm

Rebooting the device

About device reboot

The following device reboot methods are available:

·     Schedule a reboot at the CLI, so the device automatically reboots at the specified time or after the specified period of time.

·     Immediately reboot the device at the CLI.

During the reboot process, the device performs the following operations:

a.     Resets all of its chips.

b.     Uses the BootWare to verify the startup software package, decompress the package, and load the images.

c.     Initializes the system.

·     Power off and then power on the device. This method might cause data loss, and is the least-preferred method.

Using the CLI, you can reboot the device from a remote host.

Restrictions and guidelines for device reboot

A device reboot might result in a service outage.

For data security, the device does not reboot while it is performing file operations.

Rebooting devices immediately at the CLI

Prerequisites

Perform the following steps in any view:

1.     Verify that the next-startup configuration file is correctly specified.

display startup

For more information about the display startup command, see Fundamentals Command Reference.

2.     Verify that the startup image files are correctly specified.

display boot-loader

If one main startup image file is damaged or does not exist, you must specify another main startup image file before rebooting the device.

For more information about the display boot-loader command, see Fundamentals Command Reference.

3.     Save the running configuration to the next-startup configuration file.

save

To avoid configuration loss, save the running configuration before a reboot.

For more information about the save command, see Fundamentals Command Reference.

Procedure

To reboot the device immediately at the CLI, execute one of the following commands in user view:

In standalone mode:

reboot [ force ]

In IRF mode:

reboot [ slot slot-number ] [ force ]



‌

Scheduling a device reboot

Restrictions and guidelines

(In IRF mode.) The automatic reboot configuration takes effect on all member devices. It will be canceled if a master/subordinate switchover occurs.

The device supports only one device reboot schedule. If you execute the scheduler reboot command multiple times, the most recent configuration takes effect.

Procedure

To schedule a reboot, execute one of the following commands in user view:

·     scheduler reboot at time [ date ]

·     scheduler reboot delay time

By default, no device reboot time is specified.



‌

Restoring the factory-default configuration

About this task

If you want to use the device in a different scenario or you cannot troubleshoot the device by using other methods, use this task to restore the factory-default configuration.

This task does not delete the following items:

·     .bin files and license files.

·     Directory apimge on the WX1800H series, WX2500H series, MAK series, and WX3000H series.

Restrictions and guidelines

This feature is disruptive.

Procedure

1.     Execute the following command in user view to restore the factory-default configuration for the device:

restore factory-default



‌

2.     Reboot the device.

reboot

When the command prompts you to choose whether to save the running configuration, enter N. If you choose to save the running configuration, the device loads the saved configuration at startup.

Display and maintenance commands for device management configuration

‌

‌



Execute display commands in any view. Execute the reset scheduler logfile command in user view. Execute the reset version-update-record command in system view.



‌
