Configuring uRPF

About uRPF

Unicast Reverse Path Forwarding (uRPF) protects a network against source address spoofing attacks, such as DoS and DDoS attacks.

uRPF application scenario

Attackers send packets with a forged source address to access a system that uses IPv4-based authentication, in the name of authorized users or even the administrator. Even if the attackers or other hosts cannot receive any response packets, the attacks are still disruptive to the attacked target.

Figure 1 Source address spoofing attack

‌

As shown in Figure 1, an attacker on Router A sends the server (Router B) requests with a forged source IP address 2.2.2.1 at a high rate. Router B sends response packets to IP address 2.2.2.1 (Router C). Consequently, both Router B and Router C are attacked. If the administrator disconnects Router C by mistake, the network service is interrupted.

Attackers can also send packets with different forged source addresses or attack multiple servers simultaneously to block connections or even break down the network.

uRPF can prevent these source address spoofing attacks. It checks whether an interface that receives a packet is the output interface of the FIB entry that matches the source address of the packet. If not, uRPF considers it a spoofing attack and discards the packet.

uRPF check modes

uRPF supports strict and loose modes.

Strict uRPF check

To pass strict uRPF check, the source address of a packet and the receiving interface must match the destination address and output interface of a FIB entry. In some scenarios (for example, asymmetrical routing), strict uRPF might discard valid packets.

Strict uRPF is often deployed between a PE and a CE.

Loose uRPF check

To pass loose uRPF check, the source address of a packet must match the destination address of a FIB entry. Loose uRPF can avoid discarding valid packets, but might let go attack packets.

Loose uRPF is often deployed between ISPs, especially in asymmetrical routing.

Network application

As shown in Figure 2, strict uRPF check is configured between an ISP network and a customer network. Loose uRPF check is configured between ISPs.

Figure 2 Network diagram

‌

Restrictions and guidelines: uRPF configuration

Do not use strict uRPF if ECMP routing is available in the network. Service packets that travel along ECMP routes cannot pass the strict uRPF check and will be dropped.

Enabling uRPF globally

Restrictions and guidelines

Global uRPF takes effect on all interfaces of the device.

Procedure

1.     Enter system view.

system-view

2.     Enable uRPF globally.

ip urpf { loose | strict }

By default, uRPF is disabled.

Display and maintenance commands for uRPF

Execute display commands in any view.

‌

Configuring IPv6 uRPF

About IPv6 uRPF

IPv6 Unicast Reverse Path Forwarding (uRPF) protects a network against source address spoofing attacks, such as DoS and DDoS attacks.

IPv6 uRPF application scenario

Attackers send packets with a forged source address to access a system that uses IPv6-based authentication, in the name of authorized users or even the administrator. Even if the attackers or other hosts cannot receive any response packets, the attacks are still disruptive to the attacked target.

Figure 3 Source address spoofing attack

As shown in Figure 3, an attacker on Router A sends the server (Router B) requests with a forged source IPv6 address 2000::1 at a high rate. Router B sends response packets to IPv6 address 2000::1 (Router C). Consequently, both Router B and Router C are attacked. If the administrator disconnects Router C by mistake, the network service is interrupted.

Attackers can also send packets with different forged source addresses or attack multiple servers simultaneously to block connections or even break down the network.

IPv6 uRPF can prevent these source address spoofing attacks. It checks whether an interface that receives a packet is the output interface of the FIB entry that matches the source address of the packet. If not, IPv6 uRPF considers it a spoofing attack and discards the packet.

IPv6 uRPF check modes

IPv6 uRPF supports strict and loose check modes.

Strict IPv6 uRPF check

To pass strict IPv6 uRPF check, the source address of a packet and the receiving interface must match the destination address and output interface of an IPv6 FIB entry. In some scenarios (for example, asymmetrical routing), strict IPv6 uRPF might discard valid packets.

Strict IPv6 uRPF is often deployed between a PE and a CE.

Loose IPv6 uRPF check

To pass loose IPv6 uRPF check, the source address of a packet must match the destination address of an IPv6 FIB entry. Loose IPv6 uRPF can avoid discarding valid packets, but might let go attack packets.

Loose IPv6 uRPF is often deployed between ISPs, especially in asymmetrical routing.

Network application

As shown in Figure 4, strict IPv6 uRPF check is configured between an ISP network and a customer network. Loose IPv6 uRPF check is configured between ISPs.

Figure 4 Network diagram

Restrictions and guidelines: IPv6 uRPF configuration

Do not use strict IPv6 uRPF if ECMP routing is available in the network. Service packets that travel along ECMP routes cannot pass the strict uRPF check and will be dropped.

Enabling IPv6 uRPF globally

Restrictions and guidelines

Global IPv6 uRPF takes effect on all interfaces of the device.

Procedure

1.     Enter system view.

system-view

2.     Enable global IPv6 uRPF.

ipv6 urpf { loose | strict }

By default, IPv6 uRPF is disabled.

Display and maintenance commands for IPv6 uRPF

Execute display commands in any view.

‌
