H3C Wi-Fi 6 Access Points

Operating Mode Switching Guide































































Document version: 6W100-20210810



Copyright © 2021 New H3C Technologies Co., Ltd. All rights reserved

No part of this manual may be reproduced or transmitted in any form or by any means without prior written consent of New H3C Technologies Co., Ltd.

Except for the trademarks of New H3C Technologies Co., Ltd., any trademarks that may be mentioned in this document are the property of their respective owners.

The information in this document is subject to change without notice.



About AP operating modes

Introduction

Wi-Fi 6 APs can operate in fit, cloud, or anchor AC mode. The images for all the operating modes packaged in one .ipe file. You can switch the operating mode for an AP without the need to obtain the image file for each operating mode.

The following are the supported operating modes:

·     Fit—The AP is managed and controlled by an AC.

·     Cloud—The AP can be managed from Cloudnet or from its Web interface.

·     Anchor AC—The AP acts an AC to manage fit APs.

Operating mode switching methods

Operating mode switching procedure

1.     Determine the target operating mode of the AP.

2.     Determine the current operating mode of the AP.

3.     Select the operating mode switching method and complete networking.

4.     Perform an operating mode switching.

Determining the current operating mode of the AP

From the CLI of the AP

# Log in to the AP from the console port, and then execute the display wlan device role command in any view.

<AP> display wlan device role

Current device role: Cloud AP

Table 1 Command output

Field

Description

Current device role

·     Anchor AC—AC in an AC hierarchy network.

·     FIT AP.

·     Cloud AP.



From the BootWare menu of the AP

Press Ctrl + B when “Press Ctrl+B to access EXTENDED-BOOTWARE MENU...” is displayed during the power-on and restart process of the AP.

==========================<EXTENDED-BOOTWARE MENU>======================

|<1> Boot System                                                        |

|<2> Enter Serial SubMenu                                               |

|<3> Enter Ethernet SubMenu                                             |

|<4> File Control                                                       |

|<5> Restore to Factory Default Configuration                           |

|<6> Skip Current System Configuration                                  |

|<7> BootWare Operation Menu                                            |

|<8> Skip Authentication for Console Login                              |

|<9> Storage Device Operation                                           |

|<0> Reboot                                                             |

=======================================================================

Ctrl+Z: Access EXTENDED ASSISTANT MENU

Ctrl+F: Format File System

Ctrl+C: Display Copyright

Ctrl+Y: Change AP Mode

Enter your choice(0-9):

# Press Ctrl + Y at the main menu.

Please select the new mode

Current mode is Cloud Mode

=======================================================================

|NO.  Mode                                                             |

|1    Fit Mode                                                         |

|2    Anchor-AC   (Virtual AC Mode)                                    |

|3    Cloud Mode                                                       |

|0    Exit                                                             |

=======================================================================

From the CLI of the AC

Use this method if the AP is managed by an AC. This mode is applicable to APs operating in fit or cloud mode.

# Execute the display wlan ap verbose command in any view from the CLI of the AC and check the AP type field for the operating mode of the AP.

<AC> display wlan ap name ap1 verbose

AP name                       : ap1

AP ID                         : 1

AP group name                 : default-group

State                         : Run

Backup type                   : Master

Omitted

AP type                       : Normal AP

Radio 1:

    BSSID                     : N/A

    State                     : Down

    Type                      : 802.11ax

    Antenna type              : internal

Omitted

Table 2 Command output

Field

Description

AP type

·     Normal AP—Fit AP in an AC + fit AP network.

·     Cloud AP.

·     Unknown—Unknown AP type. This field is displayed before the AP comes online from the AC.



Pressing the Reset button

Use this method if you cannot log in to the AP from the console port. Press the Reset button for 20 to 30 seconds, and then determine the operating mode of the AP by observing the status LED or power LED on the AP.

Table 3 Determining the operating mode by LEDs

LED

Status

Description

Yellow

Flashes once every two seconds

Fit mode

Flashes twice every one second

Anchor AC mode

Flashes four times every one second

Cloud mode



By checking the default wireless service

Use this method to identify whether an AP is operating in cloud mode. An AP operating in cloud mode provides a wireless service with an SSID of H3C_xxxxxx, where xxxxxx is the last six digits of the AP’s MAC address. After the AP is powered on, you can use a client to search for this network. If this network is available, the AP is operating in cloud mode.

Operating mode switching methods

The operating mode switching methods vary depending on the operating mode of an AP.

Table 4 Operating mode switching methods

Current operating mode

Available operating modes

Operating mode switching method

FIT

Cloud

Switching the operating mode from the Cloudnet platform

Switching the operating mode for an AP from the CLI of the AC

Switching the operating mode for an AP from the CLI of the AP

Switching the operating mode from the BootWare menu of an AP

Pressing the Reset button to switch the operating mode

Anchor-AC

Switching the operating mode for an AP from the CLI of the AP

Switching the operating mode from the BootWare menu of an AP

Cloud

FIT

Switching the operating mode for an AP from the CLI of the AC

Switching the operating mode for an AP from the CLI of the AP

Switching the operating mode from the BootWare menu of an AP

Anchor AC

Switching the operating mode for an AP from the CLI of the AP

Switching the operating mode from the BootWare menu of an AP

Anchor AC

FIT

Switching the operating mode for an AP from the CLI of the AP

Switching the operating mode from the BootWare menu of an AP

Cloud

Switching the operating mode for an AP from the CLI of the AP

Switching the operating mode from the BootWare menu of an AP




Switching the operating mode for an AP

General restrictions and guidelines

·     APs with a version of R2442 or E2442 or a higher version support mode switching. Before mode switching, please upgrade your AP to R2442 or a higher version.

·     For operating mode switching to take effect on an AP, you must restart the AP.

·     For the first operating mode switching, the AP starts with the factory default setting if you have not used the save command to save the configuration. If you have saved the configuration, the AP starts with the saved configuration.

·     For the operating mode of an AP, see the release notes.

·     An AP operating in anchor AC mode will switch to fit mode and associate with an AC if it does not have persistent mode configured and discovers another AC in the network.

Switching the operating mode from the Cloudnet platform

This method enables you switch the operating mode for an AP only from fit to cloud.

Restrictions and guidelines

Both APs operating in cloud mode and fit mode can come online from the Cloudnet platform. You can manage APs operating in cloud mode from the Cloudnet platform. You cannot manage fit APs from the Cloudnet platform, but you can switch the operating mode and upgrade the software for an AP operating in fit mode from the Cloudnet platform.

Prerequisites

·     The AP will search for an AC and Cloudnet platform after startup. The AP can come online from the Cloudnet platform it has not registered to an AC. If it has registered to an AC, it will come online from the AC. Make sure the AP is not registered to an AC.

·     Register the AP to the Cloudnet platform by its model and serial number.

·     Connect the AP to the network and enable it to obtain an IP address through DHCP. Make sure the obtained IP address and public network are reachable to each other.

·     Make sure the DNS server can translate the Cloudnet server address correctly.

Figure 1 Network diagram



Procedure

Logging in to the Cloudnet platform

Connect the AP to the Internet, enter cloudnet.h3c.com in the browser bar, and then enter the username and password for logging in to the Cloudnet platform.

Scan the QR code on the login page to download the Cloudnet app. The procedure for logging in to the Cloudnet platform from the Web interface and from the Cloudnet app is the same. The following uses login from the Web interface as an example.

Adding a device

1.     On the top navigation bar, click Network.

2.     From the left navigation pane, select Network > Devices.

3.     Select a branch and a site from the top of the work pane.

4.     Click Add. Select a site, and enter the device name and serial number.

Figure 2 Adding a device



5.     Start the AP. If the AP cannot discover an AC, it will switch to cloud mode when it connects to the Cloudnet platform for the first time.

6.     For the AP to switch to fit mode again, perform the following tasks to manually enable operating mode switching:

a.     On the top navigation bar, click Network.

b.     From the left navigation pane, select Settings > Cloud APs > Oasis Mode.

c.     Click the toggle button in the Oasis Mode column for an AP.

Figure 3 Manually switching the operating mode for an AP



7.     Wait for the AP to restart. The AP will switch to cloud mode after restart, and information about the AP will not be displayed in the operating mode switching list.

8.     To display the switching result, click Network on the top navigation bar, and then select Network > Sites from the left navigation pane. Select the site to which the AP belongs. If the AP is online, the mode switching is successful.

Figure 4 Displaying the operating mode switching result



Switching the operating mode for an AP from the CLI of the AC

This method enables you to switch the operating mode of an AP from fit to cloud or from cloud to fit.

Restrictions and guidelines

·     Both APs operating in cloud mode and fit mode can come online from the AC. You can manage APs operating in fit mode from the AC. You cannot manage APs operating in cloud mode from the AC, but you can switch the operating mode and upgrade the software for an AP operating in cloud mode from the AC.

·     If the AP is operating in fit mode, the ap-mode fit command does not take effect.

·     If the AP has gone offline after you execute the ap-mode fit command, you must save the configuration on the AC. After the AP comes online again, the AP will automatically restart and switch to fit mode.

Prerequisites

Configure the AP to come online from the AC, and access the CLI of the AC through the configuration console.

Figure 5 Network diagram



Procedure

Switching the operating mode from fit to cloud

# Execute the wlan mode-switch ap cloud command in system view of the AC.

<AC> system-view

[AC] wlan mode-switch ap ap1 cloud

# Enter Y when the following prompt is displayed:

The operation will change the working mode to cloud.Continue? [Y/N]:

# Return to user view, and then execute the reset wlan ap command to restart the AP for the mode switching to take effect.

[AC] quit

<AC> reset wlan ap name ap1

# Enter Y when the following prompt is displayed and wait several minutes for the AP to come online in cloud mode.

Resetting the APs will terminate the CAPWAP tunnels with the AC. Continue? [Y/N]:

Switching the operating mode from cloud to fit

# Execute the ap-mode command in AP view of the AC.

<AC> system-view

[AC] wlan ap ap1

[AC-wlan-ap-ap1] ap-mode fit

# Enter Y when the following prompt is displayed and wait several minutes for the AP to come online in fit mode.

Changing the working mode will reboot the AP. For the operation to succeed, make sure the corresponding AP image exists on the AC or AP. Continue? [Y/N]:

Switching the operating mode for an AP from the CLI of the AP

You can switch the an AP to any one of the three operating modes from the CLI of the AP.

Restrictions and guidelines

·     In probe view, the ap-mode supports keywords fit, cloud, and Anchor-AC. You cannot use a question mark (?) to display help information for a command or use the Tab key to complete a command.

·     If the new operating mode is the same as the current operating mode, the command does not take effect and not output is displayed.

·     You cannot log in to an AP in fit mode through Telnet after the AP associates with an AC.

Perquisites

This section uses cloud-to-fit switching as an example. Before mode switching, connect your PC to the console port of an AP by using a console cable or log in to an AP through Telnet.

Figure 6 Network diagram



Procedure

# Execute the ap-mode command in probe view of the AP.

<AP> system-view

[AP] probe

[AP-probe] ap-mode fit

# Enter Y when the following prompt is displayed and wait several minutes for the AP to come online in cloud mode.

Changing working mode will reboot system. Continue? [Y/N]:

Switching the operating mode from the BootWare menu of an AP

You can switch the an AP to any one of the three operating modes from the BootWare menu of the AP.

Prerequisites

This section uses cloud-to-fit switching as an example. Before mode switching, connect your PC to the console port of an AP by using a console cable.

Figure 7 Network diagram



You cannot log in to an AP in fit mode from the console port after the AP associates with an AC.

Procedure

# Execute the reboot command to restart the AP. The following output will be displayed.

<AP>reboot

Start to check configuration with next startup configuration file, please wait..

.......DONE!

This command will reboot the device. Continue? [Y/N]:y

Now rebooting, please wait...

%Apr 11 23:36:57:760 2021 H3C DEV/5/SYSTEM_REBOOT: System is rebooting now.



System is starting...

Press Ctrl+D to access BASIC-BOOTWARE MENU...

Booting Normal Extended BootWare

The Extended BootWare is self-decompressing..................Done.



***********************************************************************

*                                                                     *

*                   H3C WA6636 BootWare, Version 7.12                 *

*                                                                     *

***********************************************************************

Copyright (c) 2004-2021 New H3C Technologies Co., Ltd.



Compiled Date       : Jan 28 2021

CPU L1 Cache        : 32KB

CPU L2 Cache        : 256KB

CPU Clock Speed     : 2200MHz

Memory Type         : DDR3 SDRAM

Memory Size         : 1024MB

Memory Speed        : 933MHz

Flash Size          : 256MB

PCB Version         : Ver.A



BootWare Validating...

Press Ctrl+B to access EXTENDED-BOOTWARE MENU...

# Press Ctrl + B when “Press Ctrl+B to access EXTENDED-BOOTWARE MENU...” is displayed.

Password recovery capability is enabled.

Note: The current operating device is flash

Enter < Storage Device Operation > to select device.



==========================<EXTENDED-BOOTWARE MENU>======================

|<1> Boot System                                                        |

|<2> Enter Serial SubMenu                                               |

|<3> Enter Ethernet SubMenu                                             |

|<4> File Control                                                       |

|<5> Restore to Factory Default Configuration                           |

|<6> Skip Current System Configuration                                  |

|<7> BootWare Operation Menu                                            |

|<8> Skip Authentication for Console Login                              |

|<9> Storage Device Operation                                           |

|<0> Reboot                                                             |

=======================================================================

Ctrl+Z: Access EXTENDED ASSISTANT MENU

Ctrl+F: Format File System

Ctrl+C: Display Copyright

Ctrl+Y: Change AP Mode

Enter your choice(0-9):

# Press Ctrl + Y at the main menu.

Please select the new mode

Current mode is Cloud Mode

=======================================================================

|NO.  Mode                                                             |

|1    Fit Mode                                                         |

|2    Anchor-AC   (Virtual AC Mode)                                    |

|3    Cloud Mode                                                       |

|0    Exit                                                             |

=======================================================================

# Select a number as needed. The switching is successful when the following message displayed.

Enter your choice(0-3):1

Changed to fit mode successfully!

Pressing the Reset button to switch the operating mode

This method enables you to switch the operating mode for an AP only from fit to cloud.

If the AP has only one LED, that LED indicates the operating mode of the AP. If the AP has multiple LEDs, the power LED indicates the operating mode of the AP.

Procedure

Press the Reset button for a minimum of 30 seconds and release the button when the LED on the AP flashes green at 4 Hz. The AP will restart and switch to cloud mode.

Table 5 Determining the operating mode by LEDs

Time (Sec)

Status

Description

0 to 5 seconds

Steady green

Reset

5 to 20 seconds

Flashes green twice every second

Restore to the default setting

20 to 30 seconds

Flashes yellow once every two seconds

Fit mode

Flashes twice every second

Anchor-AC mode

Flashes four times every second

Cloud mode

> 30 seconds

Flashes yellow twice every second

Anchor-AC mode

Flashes four times every second

Cloud mode

Flashes green four times every second

Switching to cloud mode.

NOTE:

Releasing the button will restart the AP for the switching to take effect. This operation takes effect only on the switching from fit mode to cloud mode.



FAQ

How do I know whether an AP supports fast operating mode switching?

1.     Log in to the H3C website at https://www.h3c.com/en/.

2.     Select Support > Resource Center > Software Download > Wireless.

3.     In the H3C 802.11ax Series Access Points area, select an AP model to check the software version of the AP. If the AP uses a software version of 2442 or higher, the AP supports fast operating mode switching.

How do I know the operating mode of an AP?

Log in to the H3C website at https://www.h3c.com/en/, and check the release notes for the AP for the supported operating modes of the AP.

How can I switch the operating mode of an AP if I do not have a console cable or the console port is faulty?

Associate the AP with the AC or log in to the AP through Telnet, and select an operating mode switching method as required:

·     If the AP is operating in fit mode, it will automatically switch to cloud mode after it associates with the Cloudnet platform for the first time. Alternatively, you can switch the AP to cloud from the CLI of the AC or to anchor-AC mode through automatic election.

·     If the AP is operating in cloud mode, you can switch it to fit mode from the CLI of the AC.

·     If the AP is operating in anchor AC mode, you can switch it to fit mode from the CLI of the AP. If the AP is not enabled with the persistent mode, you can associate the AP with the AC, and the AP will automatically switch to fit mode. Alternatively, you can configure anchor AP election for the AP to automatically switch to fit mode.

For more information about anchor AP election, see AP Management Configuration Guide in H3C Access Points Anchor AC Mode Configuration Guides(E2442 R2442)-6W100.

  • Cloud & AI
  • InterConnect
  • Intelligent Computing
  • Security
  • SMB Products
  • Intelligent Terminal Products
  • Product Support Services
  • Technical Service Solutions
All Services
  • Resource Center
  • Policy
  • Online Help
All Support
  • Become a Partner
  • Partner Resources
  • Partner Business Management
All Partners
  • Profile
  • News & Events
  • Online Exhibition Center
  • Contact Us
All About Us
新华三官网
