User FAQ
This document contains the most frequently asked questions about H3C Aolynk series routers. The management functions supported by different models of devices may be different, so the applicable FAQs may also be different. Please refer to the actual display on the web page for accuracy.
Device management
Q. How can I bind a device to the cloud platform?
A. To bind a device to the cloud platform:
1. After you complete UWEB network-wide startup, log in to Aolynk Cloud at aolynkcloud.h3c.com to create a new project.
2. Add the SN of any Aolynk device in the network.
After verification, the cloud platform will add the remaining devices automatically.
Q. How can I unbind a device from the cloud platform?
A. To unbind a device from the cloud platform, use either of the following methods:
· Delete the device or the corresponding project from Aolynk Cloud (aolynkcloud.h3c.com). If you delete the corresponding project, all devices in the project are unbound from the cloud platform.
· Restore the factory settings for a device in the network. This operation unbinds the device from the cloud platform.
Q. For the first device access, which port should be used to connect the PC, and what is the login address?
A. For the first device access, connect the PC to the LAN port on the device and the login address is the management address on the device label.
Q. What is the default login username and password?
A. The default username and password are both admin. You must change the default password after first login.
Q. How to change the default login address of the device, which is the IP address of the LAN port?
A. To resolve the issue, change the IP address of VLAN-interface 1:
1. Log in to the Web interface of the device, navigate to Network Settings > LAN Settings.
2. Click the VLAN Settings tab. Click the edit icon in the Actions column for interface VLAN1.
3. In the dialog box that opens, enter a new IP address in the IP Address field. This IP address will be used as the new login address of the device.
Q. How to change the password for logging in to the Web interface of the device?
A. After you log in to the Web management interface, click Administrator > Change Password in the upper right of the page. In the dialog box that opens, change the password as needed.
Q. What are the functions of the reset button?
A. The functions of the reset button include:
· Restart the device: Press and hold the reset button for less than 5 seconds.
· Restore the default Web login password: Press and hold the reset button for 5 to 10 seconds until the SYS LED flashes yellow slowly.
· Restore the factory settings and restart the device: Press and hold the reset button for 10 to 15 seconds until the SYS LED flashes yellow rapidly.
· Perform no action: Press and hold the reset button for more than 15 seconds until the SYS LED returns to steady green.
Q. What can I do if I forget the login password?
A. To resolve the issue, restore the default password (admin) for logging in to the Web management interface. Press and hold the reset button on the front panel of the device for 5 to 10 seconds until the SYS LED is flashing slowly in yellow.
Q. What can I do if I cannot log in to the Web interface of the device according to the quick start guide?
A. To resolve the issue:
1. Verify that the network port of the PC is connected to the LAN port on the device successfully.
2. Verify that IP settings on the PC are configured correctly.
For the first device access, select Obtain an IP address automatically on the PC.
3. Verify that the browser is recommended.
As a best practice, use Chrome 64 and higher, Firefox 78 and higher, or Edge 79 and higher to access the Web management interface.
4. Verify that you have entered the default login address of the device correctly.
By default, the login address of the device is the management address on the device label.
5. Verify that you have entered the login username and password correctly.
By default, the login username and password are both admin.
Q. How to obtain the device model?
A. Use one of the following methods to view the device model:
· View the device model below the H3C logo on the front panel of the device.
· Log in to the Web interface of the device and view the device model on the right of the System Info page.
Q. How to obtain the software version of the device?
A. Log in to the Web interface of the device, and then view the software version on the right of the System Info page.
Q. How to restore the factory defaults of the device?
A. Use one of the following methods to restore the factory defaults of the device:
· To restore the factory defaults from the Web interface:
a. On the Web interface of the device, navigate to System Tool > Configuration Management.
You are placed on the Default Configuration Restoration tab.
b. Click Restore Factory Defaults.
c. In the dialog box that opens, select Reboot Device, and then click Apply to restore the factory defaults and reboot the device.
· Press and hold the reset button on the front panel for 10 to 15 seconds until the SYS LED is flashing rapidly in yellow. Then, the device will immediately restore the factory defaults and reboot.
Restoring the factory defaults removes all user-configured settings. Make sure you are fully aware of the impact of this operation. As a best practice, back up the configuration files of the device before restoring the factory defaults.
Q. How to immediately reboot the device?
A. Use one of the following methods to reboot the device:
· To reboot the device from the Web interface:
a. On the Web interface of the device, navigate to System Tool > Reboot.
You are placed on the Reboot Immediately tab.
b. Click Reboot Device. In the dialog box that opens, click Apply.
· Press and hold the reset button on the front panel of the device for less than 5 seconds.
· Re-connect the power cord of the device.
Q. How to schedule a device reboot?
A. Before scheduling a device reboot, make sure the device can automatically synchronize the date and time with the network.
To schedule a device reboot:
1. On the Web interface of the device, navigate to System Tool > Reboot.
2. Click the Scheduled Reboot tab.
3. Configure the parameters as required, and then click Apply.
Network settings
Q. How can I resolve the issue that PCs on the LAN cannot access Internet?
A. To resolve this issue, perform the following tasks:
1. Verify that the cables are correctly connected.
a. Verify that the external network broadband cables are connected to the WAN interfaces on the device, and verify that the LED for each interface is normal.
b. Verify that the attached switches or PCs are connected to LAN interfaces on the device, and verify that the LED for each interface is normal.
2. Verify external network connectivity.
Connect the external network broadband cable to the PC, set the PC according to the network access method provided by the carrier, and check the external network connectivity.
¡ If the PC can access the external network normally, the external network broadband cable is connected normally. Proceed with the following steps to resolve this issue.
¡ If the PC cannot access the external network, contact the carrier to check the external network broadband.
3. Verify that the network access settings of the device are correct.
According to the network access method provided by the carrier, check the network access settings:
¡ When the external network connection mode is DHCP, identify whether the external network IP address is on the same subnet as the internal network IP address. If they are on the same subnet, modify the internal network IP address.
¡ When the external network connection mode is fixed IP, verify that the external network IP address, subnet mask, gateway address, and DNS server IPs are configured correctly.
¡ When the external network connection mode is PPPoE, verify that the account and password entered for network access are the same as those provided by the carrier.
4. Identify whether invalid DHCP servers exist on the internal network.
Identify whether the IP address of the PC that cannot access the external network is assigned by the device and whether the gateway address of the PC is correct. If the IP address obtained by the PC is not assigned by the device, it means that invalid DHCP servers exist on the internal network. To resolve this issue:
¡ If switches on the internal network support DHCP snooping, enable DHCP snooping on these switches to deny invalid DHCP packets.
¡ If switches on the internal network do not support DHCP snooping, manually locate the invalid DHCP servers and remove them.
Q. How can I change the DHCP address pool range?
A. To change the DHCP address pool range:
1. On the Web interface for the device, access the Network Settings > LAN Settings page.
2. Click the VLAN Settings tab.
3. Click the Edit icon in the Actions column for the interface for which you want to change the address pool range or mask.
The page for editing the VLAN opens.
4. Edit the start IP address and end IP address of the address pool and edit the subnet mask, and click Apply.
Q. How can I forward Internet access traffic from different endpoints through different WAN interfaces in the multi-WAN scenario?
A. To meet the requirements, configure a routing policy as follows:
1. On the Web interface for the device, access the Advanced Settings > Policy-Based Routing page.
2. On the Policy-Based Routing page that opens, click Add.
3. On the page that opens, configure parameters as needed, and click Apply.
Q. How can I divide VLANs and disable access between VLANs?
A. The following example describes how to divide VLAN and disable access between the VLANs.
Network diagram
Network configuration
As shown in the figure above, unmanaged switch Switch A connects to interface LAN1 on the device, and managed switch Switch B connects to interface LAN2 on the device. Configure VLANs to meet the following requirements:
All clients attached to Switch A can obtain IP addresses from the VLAN 2 address pool.
Two VLAN interfaces (VLAN-interface 3:192.168.3.0/24 and VLAN-interface 4:192.168.4.0/24) exist on Switch B and correspond to two departments. The two departments cannot access each other.
Procedure
1. On the Web interface for the device, access the Network Settings > LAN Settings page. Click the VLAN Settings tab. On this tab, add the following three VLANs:
¡ VLAN 2: Configure the VLAN interface IP address as 192.168.2.1 and subnet mask as 255.255.255.0.
¡ VLAN 3: Configure the VLAN interface IP address as 192.168.3.1 and subnet mask as 255.255.255.0.
¡ VLAN 4: Configure the VLAN interface IP address as 192.168.4.1 and subnet mask as 255.255.255.0.
2. On the Web interface for the device, access the Network Settings > LAN Settings page. Click the VLAN Division tab. Click the Edit icon in the Actions column for interface LAN1. The Detailed Port Settings page opens. Modify both the PVID and permitted VLANs to VLAN 2 for interface LAN1. If other interfaces are also connected to unmanaged devices to implement similar functions, configure these interfaces in a similar way.
3. On the Web interface for the device, access the Network Settings > LAN Settings page. Click the VLAN Division tab. Click the Edit icon in the Actions column for interface LAN2. The Detailed Port Settings page opens. On both Switch A and Switch B, add VLAN 3 and VLAN 4 to the selected VLANs. If more VLANs exist on a managed switch, add them to the permitted VLANs.
4. For users in the LAN to dynamically obtain IP addresses from the corresponding network segments through DHCP, perform the following tasks: On the Web interface for the device, access the Network Settings > LAN Settings page. Click the VLAN Settings tab. Click the Edit icon in the Actions column for a VLAN interface, and configure DHCP for the VLAN interface.
5. To disable the gateway of VLAN 3 and the gateway of VLAN 4 from accessing each other, add firewall rules in the firewall configuration of the device. Disable all services with source IP addresses 192.168.3.2 through 192.168.3.254 from accessing all services with destination IP addresses 192.168.4.2 through 192.168.4.254.
Network behavior management
Q. How can I prevent some endpoints from accessing the external network?
A. You can use the following methods to do that:
· Method 1: ARP static binding
On the left navigation pane, select Network Security > Endpoint Access. Select Allow only users with static ARP entries to access the external network. Users not in the start ARP table cannot access the external network.
· Method 2: DHCP
On the left navigation pane, select Network Security > Endpoint Access. Select Allow only clients of which the addresses are obtained through DHCP allocation to access the external network. Users not assigned IP addresses through DHCP cannot access the external network.
System tools
Q. How can I upgrade the device software?
A. You can use the following methods to upgrade the device software:
· Manual upgrade.
Before a manual upgrade, access the H3C official website to download the software in the latest version and save it to your PC.
To perform a manual upgrade, navigate to the System Tools > System Upgrade > Manual Upgrade page. Click Manual Upgrade, and then configure the parameters.
· Immediate upgrade.
To perform an immediate upgrade, navigate to the System Tools > System Upgrade > Auto Upgrade page. Click Auto Upgrade System Software, and then click Apply.
· Scheduled upgrade.
To perform a scheduled upgrade, navigate to the System Tools > System Upgrade > Auto Upgrade page. Enable the scheduled upgrade and configure the parameters.
Q. How can I troubleshoot manual software upgrade failures?
A. To troubleshoot manual software upgrade failures:
· If the system prompts that the file is incorrect, identify whether the selected file for software upgrading is a .bin software version file.
· If the system prompts a file content error, perform the following tasks:
¡ Identify whether the device model identified in the software version file name is the same as that where the software is to be upgraded.
¡ Identify whether the download software version file has been edited.
LEDs
Q. What is the meaning of each LED status?
|
LED |
LED status |
Description |
|
System status LED (SYS) |
Steady green |
The device is operating correctly. |
|
Steady yellow |
The system is faulty or an alarm has occurred. |
|
|
Slowly flashing yellow |
The default Web login password will be restored for the device. |
|
|
Rapidly flashing yellow |
The device will be restored to factory settings and restart |
|
|
Off |
The power supply or system hardware is faulty, or the device has no power input. |
|
|
10/100/1000Base-T copper port LED |
Steady green |
The port is connected to a device and operating at 10/100/1000 Mbps. |
|
Flashing green |
The port is sending or receiving data at 10/100/1000 Mbps. |
|
|
Off |
The port is not connected to any device. |
|
|
PoE-MAX LED |
Steady green |
The power supplied by the PoE router is within the protected power range. |
|
Off |
The power supplied by the PoE router fails to reach the lower limit of the protected power range. |
Q. What can I do if the system status LED (SYS) is not on?
A. To resolve the issue:
1. Verify that the power cord is connected correctly.
2. Verify that the power cord connector is inserted tightly.
3. If the issue persists, access the H3C official website, and navigate to the Support > Online Help > Service Hotlines page for help.
Q. What can I do if the link status LED (LINK/ACT) of a LAN or WAN port is not on?
A. To resolve the issue:
1. Verify that the network cable is connected to the WAN or LAN port tightly.
2. Reconnect the network cable to the ports at the two ends, or remake the RJ-45 connector according to the 568B standard wiring sequence.
3. Verify that the network cable is not defective. You can connect each end of the network cable to a LAN port on the router. If the LEDs for the ports are on, the network cable is not defective. If the LEDs are not on, the network cable is defective. Replace it with a known-good cable.
4. Verify that the connection speed and duplex mode settings of the port are incorrect. Navigate to the Network Settings > Ports page and set the connection speed and duplex mode of the port to be consistent with that of the peer port. As a best practice, configure speed and duplex mode auto-sensing for the ports at the two ends.
