Configuring IP forwarding basic settings

About FIB table

A device uses the FIB table to make packet forwarding decisions.

A device selects optimal routes from the routing table, and puts them into the FIB table. Each FIB entry specifies the next hop IP address and output interface for packets destined for a specific subnet or host.

For more information about the routing table, see Layer 3—IP Routing Configuration Guide.

Use the display fib command to display the FIB table. The following example displays the entire FIB table.

<Sysname> display fib

Route destination count: 4

Directly-connected host count: 0



Flag:

  U:Usable   G:Gateway   H:Host   B:Blackhole   D:Dynamic   S:Static

  R:Relay     F:FRR



Destination/Mask   Nexthop         Flag     OutInterface/Token       Label

10.2.0.0/16        10.2.1.1        U        GE1/0/1                  Null

10.2.1.1/32        127.0.0.1       UH       InLoop0                  Null

127.0.0.0/8        127.0.0.1       U        InLoop0                  Null

127.0.0.1/32       127.0.0.1       UH       InLoop0                  Null

A FIB entry includes the following items:

·     Destination—Destination IP address.

·     Mask—Network mask. The mask and the destination address identify the destination network. A logical AND operation between the destination address and the network mask yields the address of the destination network. For example, if the destination address is 192.168.1.40 and the mask 255.255.255.0, the address of the destination network is 192.168.1.0. A network mask includes a certain number of consecutive 1s. It can be expressed in dotted decimal format or by the number of the 1s.

·     Nexthop—IP address of the next hop.

·     Flag—Route flag.

·     OutInterface—Output interface.

·     Token—MPLS Label Switched Path index number.

·     Label—Inner label.

Enabling last hop holding

About this task

Last hop holding implements symmetric routing.

When the interface enabled with this feature receives the first IP packet of a forward flow, this feature implements the following operations:

·     Obtains the forward flow information and last hop information of the packet.

·     Based on the information, records the neighbor information for the reverse flow.

When packets of the reverse flow arrive at the device, the device forwards those packets based on the recorded neighbor information.

As is shown in Figure 1, when the external server sends a request to the internal server, the packet travels through ISP 1 to Interface A on the device. The last hop holding feature on the device ensures that the reply packet follows the same route as the request packet back to ISP 1. If last hop holding is disabled, the reply packet might be sent out of Interface B or Interface C to the external network.

Figure 1 Last hop holding application

‌

Restrictions and guidelines

On a device supporting fast forwarding, the device creates fast forwarding entries based on the flow information and last hop information. In this case, last hop holding is based on fast forwarding entries. If the MAC address of a last hop changes on an Ethernet link, this feature can function correctly only after the fast forwarding entry is updated for the MAC address.

This feature is not applicable to an MPLS network.

Procedure

1.     Enter system view.

system-view

2.     Enter Layer 3 Ethernet interface view or subinterface view.

interface interface-type { interface-number | interface-number.subnumber }

3.     Enable last hop holding.

ip last-hop hold

By default, last hop holding is disabled.

Enabling IPv4 packet forwarding on an interface with no IPv4 address configured

About this task

On a device that supports both IPv4 and IPv6, the next hop of an IPv4 packet might be an IPv4 address or an IPv6 address. If the output interface has no IPv4 address configured, the interface cannot forward the IPv4 packet. To solve this problem, enable this feature on the interface. This feature allows the interface to forward IPv4 packets even though the interface has no IPv4 address configured.

Restrictions and guidelines

You can configure this feature in any view in which an IPv4 address can be configured.

Procedure

1.     Enter system view.

system-view

2.     Enter interface view.

interface interface-type interface-number

3.     Enable IPv4 packet forwarding on an interface that has no IPv4 address configured.

ip forwarding

By default, IPv4 packet forwarding is disabled on an interface that has no IPv4 address configured.

Enabling SNMP notifications for FIB events

About this task

This feature enables the FIB module to generate SNMP notifications for critical FIB events, such as the exceeding of the message queue length threshold. The SNMP notifications are sent to the SNMP module. For the SNMP notifications to be sent correctly, you must also configure SNMP. For more information about SNMP configuration, see Network Management and Monitoring Configuration Guide.

Procedure

1.     Enter system view.

system-view

2.     Enable SNMP notifications for FIB events.

snmp-agent trap enable fib

By default, SNMP notifications for FIB events are enabled.

Display and maintenance commands for IP forwarding basics

Display and maintenance commands for FIB table

·     To display FIB entries, execute the following command in any view:

display fib  [ vpn-instance vpn-instance-name ] [ ip-address [ mask | mask-length ] ] [ slot slot-number  ]

·     To display HPF trace information, use the following command in user view:

display hpf trace filter

Displaying the differences in FIB entries between two slots

·     To display the differences in FIB entries between two slots, execute the following command in any view:

display fib prefix diff [ all | [ vpn-instance vpn-instance-name ] [ ip-address [ mask | mask-length ] ] ] slot slot-number1 slot slot-number2

·     To display the differences in FIB VN entries between two slots, execute the following command in any view:

display fib vn diff [ id id ] slot slot-number1 slot slot-number2
