In-situ Flow Information Telemetry (iFIT) determines network performance by measuring the packet loss and packet delay of service packets transmitted on an SRv6 or G-SRv6 network. iFIT is easy to deploy and provides an accurate assessment of network performance.

Application scenarios

End-to-end measurement

To measure the packet loss and packet delay on the entire network, use end-to-end measurement. As shown in Figure 1, iFIT measures whether packet loss or packet delay occurs between the ingress node (where the target flow enters the IP network) and the egress node (where the flow leaves the network).

Figure 1 End-to-end measurement

‌

Hop-by-hop measurement

To accurately locate the packet loss and packet delay of each network node, use hop-by-hop measurement. To locate the faulty node, you can divide an end-to-end network into smaller measurement spans. As shown in Figure 2, iFIT measures whether the packet loss and packet delay occurs between the ingress node and egress node, ingress node and transmit node, transmit node and egress node.

Figure 2 Hop-by-hop measurement

‌

iFIT architecture

Figure 1 and Figure 2 show the important iFIT concepts including target flow, transit network, and measurement system.

Target flow

iFIT provides statistics on a per-flow basis. The target flows can be divided into the following types:

· Static flow—A static flow is a service flow that matches a set of criteria configured on the ingress node. The ingress node generates a static flow after you enable iFIT measurement and execute the flow command to configure the flow match criteria on the ingress node. The static flow is uniquely identified by a device ID and a flow ID. The device ID is configured by the device-id command and the flow ID is a number randomly generated on the ingress node in the range of 1 to 1048575. The device ID and flow ID are encapsulated in the iFIT header and passed to the transmit nodes and egress node.

To view the device ID and flow ID of a static flow on the ingress node, execute the display ifit flow static command.

An iFIT header contains fields to carry device ID, flow ID, measurement period, measurement mode, status of packet delay measurement, and status of packet loss measurement.

¡ A device ID uniquely identifies a device in an iFIT measurement network.

¡ A flow ID is automatically generated on the ingress node and passed to the transmit nodes and egress node. A flow ID and a device ID uniquely identify a flow together.

¡ Within a measurement period, the device starts iFIT measurement, collects and reports the measurement data.

¡ The available measurement mode includes end-to-end measurement and hop-by-hop measurement.

· Dynamic flow—A dynamic flow is learnt by the transmit nodes and egress node after they parse the received packets.

The device uses the device ID and flow ID in the iFIT header to identify the flow. If the device does not receive the packets using the same device ID and the same flow ID for a period of time, the device will delete the dynamic flow entry.

Detection point

A detection point is an interface where iFIT measurement is performed. You can specify detection points as required.

Transit network

The transit network only bears target flows. The target flows are not generated or terminated on the transit network. The transit network can only be a Layer 3 network. Each node on the transit network must be reachable.

Measurement system

The measurement system includes the following device role:

· The ingress node refers to the node that the flow enters the transit network. It filters the target flow, adds iFIT headers to the packets of the flow, collects packet statistics and reports packet statistics to the analyzer.

· A transmit node identifies the target flow by the iFIT header and reports the measurement statistics to the analyzer according to the measurement mode in the iFIT header.

· The egress node identifies the target flow by the iFIT header, reports the measurement statistics to the analyzer, and removes the iFIT header from the packet.

· The analyzer collects the statistics reported by the ingress node, transmit nodes, and egress node for data summarization and calculation.

Operating mechanism

Time synchronization mechanism

Before starting the iFIT measurement, make sure all devices are time synchronized. Therefore, all iFIT-enabled devices can use the same measurement period to report the packet statistics to the analyzer. As a best practice, the analyzer and all iFIT-enabled devices are time synchronized to facilitate management and maintenance.

You can use NTP to synchronize time between devices. Time synchronized through NTP is accurate to milliseconds. For more information about NTP, see NTP configuration in Network Management and Monitoring Configuration Guide.

Packet loss measurement mechanism

The number of incoming packets and that of outgoing packets in a network should be equal within a measurement period. If they are not equal, packet loss occurs in the transit network.

Measurement data reporting mechanism

iFIT-enabled devices push the measurement data to the analyzer by using the gRPC protocol.

Currently, only gRPC dial-out mode is supported. In this mode, iFIT-enabled devices act as gRPC clients and the analyzer acts as a gRPC server (also called a gRPC collector in the gRPC protocol), The iFIT-enabled devices will initiates gRPC connections to the analyzer and push iFIT data to the analyzer.

Working mechanism

The following illustrates the working mechanism of hop-by-hop measurement. No transmit nodes exist in end-to-end measurement but end-to-end measurement works similarly as hop-by-hop measurement.

As shown in Figure 3, the flow passes through four devices. Three devices are enabled with iFIT. The iFIT measurement works as follows:

1. The analyzer synchronizes the time with all iFIT-enabled devices through the NTP protocol.

2. The iFIT-enabled devices takes the following actions:

a. The ingress node parses the packets to identify the target flow. It encapsulates iFIT headers to the packets, counts the number of packets, and reports the packet quantity and timestamp to the analyzer through gRPC periodically.

The ingress node is the interface bound to the target flow.

b. A transmit node counts the number of packets containing iFIT headers and reports the packet quantity and timestamp to the analyzer through gRPC periodically.

When the target flow passes through an iFIT-enabled device, the interfaces where the target flow enters the iFIT-enabled device and leaves the iFIT-enabled device are transmit nodes.

c. The egress node parses the packets to identify the target flow. It counts the number of packets containing iFIT headers, reports the packet quantity and timestamp to the analyzer through gRPC periodically, removes iFIT headers from the packets and forwards the packets.

When the target flow leaves the transit network, the interface where the target flow leaves the iFIT-enabled device is the egress point.

3. The analyzer calculates the packet delay for the target flow of the same period and same instance.

Figure 3 Network diagram

‌

Restrictions and guidelines

An iFIT instance monitors only one flow. If you configure flows multiple times for an iFIT instance, the most recent configuration takes effect.

For the flows to be monitored by different instances, the flow attributes must not be identical and cannot conflict to avoid inaccurate measurement result.

As a best practice, configure iFIT first on the transmit nodes and the egress node and then the ingress node. Thus, the measurement results of the previous measurement periods will not affected if iFIT measurement starts on the ingress node but not on the transmit nodes and the egress node.

Modifying the iFIT instance or restarting the ingress node will cause flow ID change, which might cause inaccurate measurement data or no data in several measurement periods.

SRv6/G-SRv6 includes SRv6/G-SRv6 TE and SRv6/G-SRv6 BE networks. The iFIT configuration varies by network type as follows:

· In an SRv6/G-SRv6 TE network, configure iFIT on nodes in a SID list. If a transmit node is not in a SID list, iFIT measurement cannot be performed even after you configure iFIT on the transmit node.

· In an SRv6/G-SRv6 BE network, if you specify hop-by-hop measurement as the measurement mode, iFIT generates iFIT data only on the ingress and egress nodes during SRv6/G-SRv6 forwarding. The transmit nodes only forward IPv6 packets and do not participate in SRv6/G-SRv6 processing, so no iFIT data is generated on the transmit nodes.

Prerequisites

Before configuring iFIT, make sure the analyzer and iFIT-enabled devices are time synchronized through NTP. For more information about NTP, see "Configuring NTP."

To enable the iFIT-enabled devices to report the measurement results to the analyzer, configure gRPC on the analyzer and iFIT-enabled devices. For more information about gRPC, see gRPC configuration in Telemetry Configuration Guide.

Configuring the ingress node

Tasks at a glance

To configure the ingress node, perform the following tasks:

· Configuring iFIT

· Creating an iFIT instance

· Configuring a static flow

· Configuring a detection point

· Configuring a measurement mode

· Configuring a measurement period

· Enabling iFIT measurement

Configuring iFIT

1. Enter system view.

system-view

2. Enable the iFIT functionality globally and enter its view, or enter the existing iFIT view.

ifit enable

By default, the iFIT functionality is disabled.

3. Specify a device ID.

device-id device-id

By default, no device ID is specified.

A device ID is required and uniquely identifies a device in an iFIT measurement network.

Creating an iFIT instance

1. Enter system view.

system-view

2. Enter iFIT view.

ifit enable

3. Create an iFIT instance and enter its view.

instance instance-name

Configuring a static flow

About this task

Static flows are key elements for iFIT measurement. Before starting an iFIT measurement, you must configure a static flow to be measured on the ingress node. You do not need to configure a static flow on the transmit nodes and egress node because the device can automatically learn the static flow through the iFIT header of the packets.

The device can perform iFIT measurement based on the following granularities in different scenarios:

· 5-tuple granularity—Used for measuring communication quality of service flows. You can use 5-tuple elements to match service flows.

· PeerLocator granularity—Used for measuring end-to-end communication quality on the entire network. On an IPv6 network, the peer-locator keyword can specify a tunnel. The device performs iFIT measurement on all service flows through the tunnel.

Procedure

1. Enter system view.

system-view

2. Enter iFIT view.

ifit enable

3. Create an iFIT instance and enter its view.

instance instance-name

4. On an IPv4 over SRv6/G-SRv6 public network, configure a static flow to be monitored by the instance.

¡ iFIT measurement based on 5-tuple granularity:

- IPv4:

flow unidirection source-ip src-ip-address [ src-mask-length ] destination-ip dest-ip-address [ dest-mask-length ] [ protocol { { sctp | tcp | udp } [ source-port src-port-number ] [ destination-port dest-port-number ] | protocol-number } ] [ dscp dscp-value ]

- IPv6:

flow unidirection source-ipv6 src-ipv6-address [ src-prefix-length ] destination-ipv6 dest-ipv6-address [ dest-prefix-length ] [ protocol { { sctp | tcp | udp } [ source-port src-port-number ] [ destination-port dest-port-number ] | protocol-number } ] [ dscp dscp-value ]

¡ iFIT measurement based on PeerLocator granularity:

- IPv4:

flow unidirection source-ip any destination-ip any peer-locator ipv6-address prefix-length

- IPv6:

flow unidirection source-ipv6 any destination-ipv6 any peer-locator ipv6-address prefix-length

By default, no static flow is configured for an iFIT instance.

5. On an L3VPN/EVPN L3VPN over SRv6/G-SRv6 network, configure a static flow to be monitored by the instance.

¡ iFIT measurement based on 5-tuple granularity:

- IPv4:

- IPv6:

¡ iFIT measurement based on PeerLocator granularity:

- IPv4:

flow unidirection source-ip any destination-ip any [ vpn-instance vpn-instance-name ] peer-locator ipv6-address prefix-length

- IPv6:

flow unidirection source-ipv6 any destination-ipv6 any [ vpn-instance vpn-instance-name ] peer-locator ipv6-address prefix-length

By default, no static flow is specified for an iFIT instance.

6. On an EVPN VPLS over SRv6/G-SRv6 network, configure a static flow to be monitored by the instance.

¡ iFIT measurement based on PeerLocator granularity:

flow unidirection vsi vsi-name peer-locator ipv6-address prefix-length

By default, no static flow is configured for an iFIT instance.

7. On an EVPN VPWS over SRv6/G-SRv6 network, configure a static flow to be monitored by the instance.

¡ iFIT measurement based on PeerLocator granularity:

flow unidirection xconnect-group group-name connection connection-name peer-locator ipv6-address prefix-length

By default, no static flow is configured for an iFIT instance.

Configuring a detection point

About this task

Before enabling iFIT measurement on the ingress node of an instance, you must perform this task to bind an interface to the instance. After you bind an interface to an instance, iFIT parses the packets passing through the interface to identify the target packets and add an iFIT header to each target packets. Meanwhile, iFIT will count the number of target packets, and send the packet count and timestamp to the analyzer at intervals through gRPC.

You can configure only one set of flow match criteria for an instance. An instance can be bound to multiple interfaces. Each bound interface matches target flows based on the same set of criteria and assigns different flow IDs to target flows. iFIT measures the delay and packet loss of target flows on a per-interface basis.

Procedure

1. Enter system view.

system-view

2. Enter iFIT view.

ifit enable

3. Create an iFIT instance and enter its view.

instance instance-name

4. Bind an interface to the instance.

bind interface interface-type interface-number

By default, an instance is not bound to any interface.

Before enabling iFIT measurement on the ingress node of an instance, execute this command to bind an interface to the instance.

Configuring a measurement mode

1. Enter system view.

system-view

2. Enter iFIT view.

ifit enable

3. Create an iFIT instance and enter its view.

instance instance-name

4. Specify an iFIT measurement mode.

measure mode { e2e | trace }

By default, end-to-end measurement is used.

Configuring a measurement period

1. Enter system view.

system-view

2. Enter iFIT view.

ifit enable

3. Create an iFIT instance and enter its view.

instance instance-name

4. Specify the measurement period for the iFIT instance.

period period

By default, the measurement period for an iFIT instance is 30 seconds.

Enabling iFIT measurement

1. Enter system view.

system-view

2. Enter iFIT view.

ifit enable

3. Create an iFIT instance and enter its view.

instance instance-name

4. Enable iFIT measurement for the iFIT instance.

measure enable

By default, iFIT measurement for an iFIT instance is disabled.

Configuring a transmit node and the egress node

Tasks at a glance

Transmit nodes are required only for hop-by-hop measurement. For end-to-end measurement, do not configure transmit nodes.

To configure a transmit node or the ingress node, perform the following tasks:

· Creating an iFIT instance

· (Optional.) Managing a dynamic flow

Configuring iFIT

1. Enter system view.

system-view

2. Enable the iFIT functionality globally and enter its view.

ifit enable

By default, the iFIT functionality is disabled.

Managing a dynamic flow

1. Enter system view.

system-view

2. Enable the iFIT functionality globally and enter its view.

ifit enable

3. Specify the aging time for dynamic flows.

dynamic-flow aging-time multi-value

By default, the aging time for dynamic flows is 10 times the measurement period and it cannot be less than 5 minutes.

4. Delete iFIT dynamic flows.

delete dynamic-flow { device-id device-id flow-id flow-id | all }

Display and maintenance commands for iFIT

Execute display commands in any view.

Task	Command
Display dynamic flow information.	display ifit flow dynamic [ device-id device-id flow-id flow-id ]
Display static flow information.	display ifit flow static [ flow-id flow-id ]
Display global information about iFIT target flows.	display ifit global-information
Display iFIT instance information.	display ifit instance [ instance-name ]
Display statistics about an iFIT flow for the most recent 10 measurement periods.	display ifit statistic device-id device-id flow-id flow-id [ verbose ]
Clear iFIT statistics for the most recent 10 measurement periods.	reset ifit statistic [ device-id device-id flow-id flow-id \| instance instance-name]

‌

iFIT configuration examples

Example: Configuring iFIT on an IPv4 L3VPN over SRv6 network

Network configuration

As shown in Figure 4, the backbone network is an IPv6 network, and VPN 1 is an IPv4 network. Deploy MPLS L3VPN over SRv6 between PE 1 and PE 2 and use an SRv6 tunnel to transmit VPNv4 traffic between the PEs.

· Configure EBGP to exchange VPN routing information between the CEs and PEs.

· Configure IPv6 IS-IS on the PEs in the same AS to realize IPv6 network connectivity.

· Configure MP-IBGP to exchange VPNv4 routing information between the PEs.

· Configure iFIT to monitor the occurrence of packet loss and packet delay value when the flow passes through the VPN 1 tunnel.

Figure 4 Network diagram

‌

Prerequisites

1. Configure IPv4 L3VPN over SRv6. (Details not shown.)

For information about configuring MPLS L3VPN over SRv6, see IP L3VPN over SRv6 configuration in Segment Routing Configuration Guide.

2. Configure NTP on PE 1 and PE 2 for clock synchronization. (Details not shown.)

For information about configuring NTP, see "Configuring NTP."

Procedure

1. Configure gRPC:

# Enable the gRPC service.

<PE1> system-view

[PE1] grpc enable

# Create a sensor group named test, and add sensor path ifit/flowstatistics/flowstatistic.

[PE1] telemetry

[PE1-telemetry] sensor-group test

[PE1-telemetry-sensor-group-test] sensor path ifit/flowstatistics/flowstatistic depth 3

[PE1-telemetry-sensor-group-test] quit

# Create a destination group named collector1. Specify a collector that uses IPv6 address 10::10 and port number 50050.

[PE1-telemetry] destination-group collector1

[PE1-telemetry-destination-group-collector1] ipv6-address 10::10 port 50050

[PE1-telemetry-destination-group-collector1] quit

# Configure a subscription named A to bind sensor group test with destination group collector1. Set the sampling interval to 5 seconds.

[PE1-telemetry] subscription A

[PE1-telemetry-subscription-A] sensor-group test sample-interval 5

[PE1-telemetry-subscription-A] destination-group collector1

[PE1-telemetry-subscription-A] quit

[PE1-telemetry] quit

2. Configure iFIT:

# Enable the iFIT functionality.

[PE1] ifit enable

[PE1-ifit] device-id 1

# Configure instance a to monitor the unidirectional flow from source IP 1.1.1.1/24 to destination IP 1.1.3.1/24 with the PE at 3.3.3.9 as the next hop in VPN instance vpn1.

[PE1-ifit] instance a

[PE1-ifit-instance-a] flow unidirection source-ip 1.1.1.1 24 destination-ip 1.1.2.1 24 vpn-instance vpn1

# Bind interface GigabitEthernet1/0 to instance a.

[PE1-ifit-instance-a] bind interface gigabitethernet 1/0

# Specify 10 seconds as the measurement period.

[PE1-ifit-instance-a] period 10

# Enable iFIT measurement.

[PE1-ifit-instance-a] measure enable

[PE1-ifit-instance-a] quit

[PE1-ifit] quit

3. Configure PE 2:

# Configure gRPC.

Use the same procedure to configure gRPC on PE 2 as you configure gRPC on PE 1.

# Enable the iFIT functionality.

<PE2> system-view

[PE2] ifit enable

Verifying the configuration

1. View iFIT statistics on PE 1.

[PE1-ifit-instance-a] display ifit statistic device-id 1 flow-id 2

Period ID Direction PktCount Timestamp(sec, nsec) Interface

163059918 Ingress 4124 1630599180, 1889782 GE1/0

163059919 Ingress 4124 1630599190, 1901494 GE1/0

163059920 Ingress 4124 1630599200, 1912118 GE1/0

2. View iFIT statistics on PE 2.

[PE2] display ifit statistic device-id 1 flow-id 2

Period ID Direction PktCount Timestamp(sec, nsec) Interface

163059918 Egress 4124 1630599180, 1948185 GE1/0

163059919 Egress 4124 1630599190, 1959405 GE1/0

163059920 Egress 4120 1630599200, 1968503 GE1/0

3. Packet loss occurs in period 163059920 by viewing iFIT statistics on the analyzer.

Example: Configuring iFIT on an IPv6 EVPN L3VPN over SRv6 network

Network configuration

As shown in Figure 5, the backbone network is an IPv6 network. Deploy EVPN L3VPN over SRv6 in SRv6-BE mode between PE 1 and PE 2 and use an SRv6 tunnel to transmit EVPN traffic between the PEs.

· Configure EBGP to exchange VPN routing information between the CEs and PEs.

· Configure IPv6 IS-IS on the PEs in the same AS to realize IPv6 network connectivity.

· Configure MP-IBGP to exchange EVPN routing information between the PEs.

· Configure iFIT to monitor the occurrence of packet loss and packet delay value when the flow passes through the VPN 1 tunnel.

Figure 5 Network diagram

‌

Prerequisites

1. Configure IPv6 EVPN L3VPN over SRv6. (Details not shown.)

For information about configuring IPv6 EVPN L3VPN over SRv6, see EVPN L3VPN over SRv6 configuration in Segment Routing Configuration Guide.

2. Configure NTP on PE 1 and PE 2 for clock synchronization. (Details not shown.)

For information about configuring NTP, see "Configuring NTP."

Procedure

1. Configure gRPC:

# Enable the gRPC service.

<PE1> system-view

[PE1] grpc enable

# Create a sensor group named test, and add sensor path ifit/flowstatistics/flowstatistic.

[PE1] telemetry

[PE1-telemetry] sensor-group test

[PE1-telemetry-sensor-group-test] sensor path ifit/flowstatistics/flowstatistic depth 3

[PE1-telemetry-sensor-group-test] quit

# Create a destination group named collector1. Specify a collector that uses IPv6 address 10::10 and port number 50050.

[PE1-telemetry] destination-group collector1

[PE1-telemetry-destination-group-collector1] ipv6-address 10::10 port 50050

[PE1-telemetry-destination-group-collector1] quit

# Configure a subscription named A to bind sensor group test with destination group collector1. Set the sampling interval to 5 seconds.

[PE1-telemetry] subscription A

[PE1-telemetry-subscription-A] sensor-group test sample-interval 5

[PE1-telemetry-subscription-A] destination-group collector1

[PE1-telemetry-subscription-A] quit

[PE1-telemetry] quit

2. Configure iFIT:

# Enable the iFIT functionality.

[PE1] ifit enable

[PE1-ifit] device-id 1

# Configure instance a to monitor the performance parameters of the service flow transmitting in VPN instance vpn1 from source end 2001::1 to destination end 2002::1.

[PE1-ifit] instance a

[PE1-ifit-instance-a] flow unidirection source-ipv6 2001::1 destination-ipv6 2002::1 vpn-instance vpn1

# Bind interface GigabitEthernet1/0 to instance a.

[PE1-ifit-instance-a] bind interface gigabitethernet 1/0

# Specify 10 seconds as the measurement period.

[PE1-ifit-instance-a] period 10

# Enable iFIT measurement.

[PE1-ifit-instance-a] measure enable

[PE1-ifit-instance-a] quit

[PE1-ifit] quit

3. Configure PE 2:

# Configure gRPC.

Use the same procedure to configure gRPC on PE 2 as you configure gRPC on PE 1.

# Enable the iFIT functionality.

<PE2> system-view

[PE2] ifit enable

Verifying the configuration

1. View iFIT statistics on PE 1.

[PE1-ifit-instance-a] display ifit statistic device-id 1 flow-id 2

Period ID Direction PktCount Timestamp(sec, nsec) Interface

163059918 Ingress 4124 1630599180, 1889782 GE1/0

163059919 Ingress 4124 1630599190, 1901494 GE1/0

163059920 Ingress 4124 1630599200, 1912118 GE1/0

2. View iFIT statistics on PE 2.

[PE2] display ifit statistic device-id 1 flow-id 2

Period ID Direction PktCount Timestamp(sec, nsec) Interface

163059918 Egress 4124 1630599180, 1948185 GE1/0

163059919 Egress 4124 1630599190, 1959405 GE1/0

163059920 Egress 4120 1630599200, 1968503 GE1/0

3. Packet loss occurs in period 163059920 by viewing iFIT statistics on the analyzer.

Example: Configuring iFIT on an EVPN VPWS over SRv6 network

Network configuration

As shown in Figure 6, user sites CE 1 and CE 2 connect to PE1 and PE 2, respectively through Ethernet interfaces. Configure CE 1 and CE 2 to communicate through an SRv6 tunnel over the IPv6 backbone network.

The two PEs set up an SRv6 tunnel after assigning End.DX2 SIDs to the cross-connect. On a PE, this SRv6 tunnel is used as an SRv6 PW to encapsulate and forward Layer 2 data packets received from the local site and destined for a remote site.

Configure iFIT to monitor the occurrence of packet loss and packet delay value when the flow passes through the SRv6 tunnel.

Figure 6 Network diagram

‌

Prerequisites

1. Configure EVPN VPWS over SRv6. (Details not shown.)

For information about configuring EVPN VPWS over SRv6, see EVPN VPWS over SRv6 configuration in Segment Routing Configuration Guide.

2. Configure PTP on PE 1 and PE 2 for clock synchronization. (Details not shown.)

For information about configuring PTP, see "Configuring PTP."

Procedure

1. Configure PE 1:

a. Configure gRPC:

# Enable the gRPC service.

<PE1> system-view

[PE1] grpc enable

# Create a sensor group named test, and add sensor path ifit/flowstatistics/flowstatis.

[PE1] telemetry

[PE1-telemetry] sensor-group test

[PE1-telemetry-sensor-group-test] sensor path ifit/flowstatistics/flowstatistic depth 3

[PE1-telemetry-sensor-group-test] quit

# Create a destination group named collector1. Specify a collector that uses IPv6 address 10::10 and port number 50050.

[PE1-telemetry] destination-group collector1

[PE1-telemetry-destination-group-collector1] ipv6-address 10::10 port 50050

[PE1-telemetry-destination-group-collector1] quit

# Configure a subscription named A to bind sensor group test with destination group collector1. Set the sampling interval to 5 seconds.

[PE1-telemetry] subscription A

[PE1-telemetry-subscription-A] sensor-group test sample-interval 5

[PE1-telemetry-subscription-A] destination-group collector1

[PE1-telemetry-subscription-A] quit

[PE1-telemetry] quit

b. Configure iFIT:

# Enable the iFIT functionality.

[PE1] ifit enable

[PE1-ifit] device-id 1

# Configure instance a to monitor the service flow with cross-connect con1 of cross-connect group xca. The PeerlLocator for the service flow is 6:5::.

[PE1-ifit] instance a

[PE1-ifit-instance-a] flow unidirection xconnect-group xca connection con1 peer-locator 6:5:: 96

# Bind interface GigabitEthernet 1/0 to instance a.

[PE1-ifit-instance-a] bind interface gigabitethernet 1/0

# Specify 10 seconds as the measurement period.

[PE1-ifit-instance-a] period 10

# Enable the iFIT functionality.

[PE1-ifit-instance-a] measure enable

[PE1-ifit-instance-a] quit

[PE1-ifit] quit

2. Configure PE 2:

a. Configure gRPC.

Use the same procedure to configure gRPC on PE 2 as you configure gRPC on PE 1.

b. Enable the iFIT functionality.

<PE2> system-view

[PE2] ifit enable

Verifying the configuration

1. View iFIT statistics on PE 1.

[PE1] display ifit statistic device-id 1 flow-id 2

Period ID Direction PktCount Timestamp(sec, nsec) Interface

163059918 Ingress 4124 1630599180, 1889782 GE1/0

163059919 Ingress 4124 1630599190, 1901494 GE1/0

163059920 Ingress 4124 1630599200, 1912118 GE1/0

2. View iFIT statistics on PE 2.

[PE2] display ifit statistic device-id 1 flow-id 2

Period ID Direction PktCount Timestamp(sec, nsec) Interface

163059918 Egress 4124 1630599180, 1948185 GE1/0

163059919 Egress 4124 1630599190, 1959405 GE1/0

163059920 Egress 4120 1630599200, 1968503 GE1/0

3. Packet loss occurs in period 163059920 by viewing iFIT statistics on the analyzer.

Example: Configuring iFIT on an EVPN VPLS over SRv6 network

Network configuration

As shown in Figure 7, user sites CE 1 and CE 2 connect to PE1 and PE 2, respectively through Ethernet interfaces. Configure CE 1 and CE 2 to achieve communicate through EVPN VPLS over SRv6 over the IPv6 backbone network.

PEs set up an SRv6 tunnel by advertising End.DT2M SIDs, End.DT2U SIDs, and End.DX2 SIDs to each other through BGP EVPN routes. On a PE, this SRv6 tunnel is used as a PW to encapsulate and forward Layer 2 data packets received from the local site and destined for a remote site.

Configure iFIT to monitor the occurrence of packet loss and packet delay value when the flow passes through the SRv6 tunnel.

Figure 7 Network diagram

‌

Prerequisites

1. Configure EVPN VPLS over SRv6. (Details not shown.)

For information about configuring EVPN VPLS over SRv6, see EVPN VPLS over SRv6 configuration in EVPN Configuration Guide.

2. Configure PTP on PE 1 and PE 2 for clock synchronization. (Details not shown.)

For information about configuring PTP, see "Configuring PTP."

Procedure

1. Configure PE 1:

a. Configure gRPC:

# Enable the gRPC service.

<PE1> system-view

[PE1] grpc enable

# Create a sensor group named test, and add sensor path ifit/flowstatistics/flowstatis.

[PE1] telemetry

[PE1-telemetry] sensor-group test

[PE1-telemetry-sensor-group-test] sensor path ifit/flowstatistics/flowstatistic depth 3

[PE1-telemetry-sensor-group-test] quit

# Create a destination group named collector1. Specify a collector that uses IPv6 address 10::10 and port number 50050.

[PE1-telemetry] destination-group collector1

[PE1-telemetry-destination-group-collector1] ipv6-address 10::10 port 50050

[PE1-telemetry-destination-group-collector1] quit

# Configure a subscription named A to bind sensor group test with destination group collector1. Set the sampling interval to 5 seconds.

[PE1-telemetry] subscription A

[PE1-telemetry-subscription-A] sensor-group test sample-interval 5

[PE1-telemetry-subscription-A] destination-group collector1

[PE1-telemetry-subscription-A] quit

[PE1-telemetry] quit

b. Configure iFIT:

# Enable the iFIT functionality.

[PE1] ifit enable

[PE1-ifit] device-id 1

# Configure instance a to monitor the service flow with VSI vsi and PeerLocator 6:5::.

[PE1-ifit] instance a

[PE1-ifit-instance-a] flow unidirection vsi vsi1 peer-locator 6:5:: 96

# Bind interface GigabitEthernet 1/0 to instance a.

[PE1-ifit-instance-a] bind interface gigabitethernet 1/0

# Specify 10 seconds as the measurement period.

[PE1-ifit-instance-a] period 10

# Enable the iFIT functionality.

[PE1-ifit-instance-a] measure enable

[PE1-ifit-instance-a] quit

[PE1-ifit] quit

2. Configure PE 2:

a. Configure gRPC:

Use the same procedure to configure gRPC on PE 2 as you configure gRPC on PE 1.

b. Enable the iFIT functionality.

<PE2> system-view

[PE2] ifit enable

Verifying the configuration

1. View iFIT statistics on PE 1.

[PE1] display ifit statistic device-id 1 flow-id 2

Period ID Direction PktCount Timestamp(sec, nsec) Interface

163059918 Ingress 4124 1630599180, 1889782 GE1/0

163059919 Ingress 4124 1630599190, 1901494 GE1/0

163059920 Ingress 4124 1630599200, 1912118 GE1/0

2. View iFIT statistics on PE 2.

[PE2] display ifit statistic device-id 1 flow-id 2

Period ID Direction PktCount Timestamp(sec, nsec) Interface

163059918 Egress 4124 1630599180, 1948185 GE1/0

163059919 Egress 4124 1630599190, 1959405 GE1/0

163059920 Egress 4120 1630599200, 1968503 GE1/0

3. Packet loss occurs in period 163059920 by viewing iFIT statistics on the analyzer.

13-Network Management and Monitoring Configuration Guide

Configuring iFIT

Application scenarios

End-to-end measurement

Hop-by-hop measurement

Target flow

Detection point

Transit network

Measurement system

Time synchronization mechanism

Packet loss measurement mechanism

Measurement data reporting mechanism

Working mechanism

Configuring iFIT

About this task

Procedure

About this task

Procedure

Configuring a measurement period

Display and maintenance commands for iFIT

Network configuration

Prerequisites

Procedure

Verifying the configuration

Network configuration

Prerequisites

Procedure

Verifying the configuration

Network configuration

Prerequisites

Procedure

Verifying the configuration

Network configuration

Prerequisites

Procedure

Verifying the configuration

Intelligent Terminal Products

Product Support Services

Technical Service Solutions

Resource Center

Policy

Online Help

Become a Partner

Partner Policy & Program

Global Learning

Partner Sales Resources

Service Business

News & Events

Contact Us
