Authentication, Authorization, and Accounting (AAA) provides a uniform framework for implementing network access management. This feature specifies the following security functions:

· Authentication—Identifies users and verifies their validity.

· Authorization—Grants different users different rights, and controls the users' access to resources and services. For example, you can permit office users to read and print files and prevent guests from accessing files on the device.

· Accounting—Records network usage details of users, including the service type, start time, and traffic. This function enables time-based and traffic-based charging and user behavior auditing.

AAA uses a client/server model. The client runs on the access device, or the network access server (NAS), which authenticates user identities and controls user access. The server maintains user information centrally. See Figure 1.

Figure 1 AAA network diagram

To access networks or resources beyond the NAS, a user sends its identity information to the NAS. The NAS transparently passes the user information to AAA servers and waits for the authentication, authorization, and accounting result. Based on the result, the NAS determines whether to permit or deny the access request.

AAA has various implementations, including RADIUS, HWTACACS, and LDAP. RADIUS is most often used.

The network in Figure 1 has one RADIUS server and one HWTACACS server. You can use different servers to implement different security functions. For example, you can use the HWTACACS server for authentication and authorization, and use the RADIUS server for accounting.

You can choose the security functions provided by AAA as needed. For example, if your company wants employees to be authenticated before they access specific resources, you would deploy an authentication server. If network usage information is needed, you would also configure an accounting server.

The device performs dynamic password authentication.

RADIUS

Remote Authentication Dial-In User Service (RADIUS) is a distributed information interaction protocol that uses a client/server model. The protocol can protect networks against unauthorized access and is often used in network environments that require both high security and remote user access.

The RADIUS authorization process is combined with the RADIUS authentication process, and user authorization information is piggybacked in authentication responses. RADIUS uses UDP port 1812 for authentication and UDP port 1813 for accounting.

RADIUS was originally designed for dial-in user access, and has been extended to support additional access methods, such as Ethernet and ADSL.

Client/server model

The RADIUS client runs on the NASs located throughout the network. It passes user information to RADIUS servers and acts on the responses to, for example, reject or accept user access requests.

The RADIUS server runs on the computer or workstation at the network center and maintains information related to user authentication and network service access.

The RADIUS server operates using the following process:

1. Receives authentication, authorization, and accounting requests from RADIUS clients.

2. Performs user authentication, authorization, or accounting.

3. Returns user access control information (for example, rejecting or accepting the user access request) to the clients.

The RADIUS server can also act as the client of another RADIUS server to provide authentication proxy services.

The RADIUS server maintains the following databases:

· Users—Stores user information, such as the usernames, passwords, applied protocols, and IP addresses.

· Clients—Stores information about RADIUS clients, such as shared keys and IP addresses.

· Dictionary—Stores RADIUS protocol attributes and their values.

Figure 2 RADIUS server databases

Information exchange security mechanism

The RADIUS client and server exchange information between them with the help of shared keys, which are preconfigured on the client and server. A RADIUS packet has a 16-byte field called Authenticator. This field includes a signature generated by using the MD5 algorithm, the shared key, and some other information. The receiver of the packet verifies the signature and accepts the packet only when the signature is correct. This mechanism ensures the security of information exchanged between the RADIUS client and server.

The shared keys are also used to encrypt user passwords that are included in RADIUS packets.

User authentication methods

The RADIUS server supports multiple user authentication methods, such as PAP, CHAP, and EAP.

Basic RADIUS packet exchange process

Figure 3 illustrates the interactions between a user host, the RADIUS client, and the RADIUS server.

Figure 3 Basic RADIUS packet exchange process

RADIUS uses in the following workflow:

1. The host sends a connection request that includes the user's username and password to the RADIUS client.

2. The RADIUS client sends an authentication request (Access-Request) to the RADIUS server. The request includes the user's password, which has been processed by the MD5 algorithm and shared key.

3. The RADIUS server authenticates the username and password. If the authentication succeeds, the server sends back an Access-Accept packet that contains the user's authorization information. If the authentication fails, the server returns an Access-Reject packet.

4. The RADIUS client permits or denies the user according to the authentication result. If the result permits the user, the RADIUS client sends a start-accounting request (Accounting-Request) packet to the RADIUS server.

5. The RADIUS server returns an acknowledgment (Accounting-Response) packet and starts accounting.

6. The user accesses the network resources.

7. The host requests the RADIUS client to tear down the connection.

8. The RADIUS client sends a stop-accounting request (Accounting-Request) packet to the RADIUS server.

9. The RADIUS server returns an acknowledgment (Accounting-Response) and stops accounting for the user.

10. The RADIUS client notifies the user of the termination.

RADIUS packet format

RADIUS uses UDP to transmit packets. The protocol also uses a series of mechanisms to ensure smooth packet exchange between the RADIUS server and the client. These mechanisms include the timer mechanism, the retransmission mechanism, and the backup server mechanism.

Figure 4 RADIUS packet format

Descriptions of the fields are as follows:

· The Code field (1 byte long) indicates the type of the RADIUS packet. Table 1 gives the main values and their meanings.

Table 1 Main values of the Code field

Code	Packet type	Description
1	Access-Request	From the client to the server. A packet of this type includes user information for the server to authenticate the user. It must contain the User-Name attribute and can optionally contain the attributes of NAS-IP-Address, User-Password, and NAS-Port.
2	Access-Accept	From the server to the client. If all attribute values included in the Access-Request are acceptable, the authentication succeeds, and the server sends an Access-Accept response.
3	Access-Reject	From the server to the client. If any attribute value included in the Access-Request is unacceptable, the authentication fails, and the server sends an Access-Reject response.
4	Accounting-Request	From the client to the server. A packet of this type includes user information for the server to start or stop accounting for the user. The Acct-Status-Type attribute in the packet indicates whether to start or stop accounting.
5	Accounting-Response	From the server to the client. The server sends a packet of this type to notify the client that it has received the Accounting-Request and has successfully recorded the accounting information.

· The Identifier field (1 byte long) is used to match response packets with request packets and to detect duplicate request packets. The request and response packets of the same exchange process for the same purpose (such as authentication or accounting) have the same identifier.

· The Length field (2 bytes long) indicates the length of the entire packet (in bytes), including the Code, Identifier, Length, Authenticator, and Attributes fields. Bytes beyond this length are considered padding and are ignored by the receiver. If the length of a received packet is less than this length, the packet is dropped.

· The Authenticator field (16 bytes long) is used to authenticate responses from the RADIUS server and to encrypt user passwords. There are two types of authenticators: request authenticator and response authenticator.

· The Attributes field (variable in length) includes authentication, authorization, and accounting information. This field can contain multiple attributes, each with the following subfields:

¡ Type—Type of the attribute.

¡ Length—Length of the attribute in bytes, including the Type, Length, and Value subfields.

¡ Value—Value of the attribute. Its format and content depend on the Type subfield.

Commonly used RADIUS attributes are defined in RFC 2865, RFC 2866, RFC 2867, and RFC 2868. For more information, see "Commonly used standard RADIUS attributes."

Table 2 Commonly used RADIUS attributes

No.	Attribute	No.	Attribute
1	User-Name	45	Acct-Authentic
2	User-Password	46	Acct-Session-Time
3	CHAP-Password	47	Acct-Input-Packets
4	NAS-IP-Address	48	Acct-Output-Packets
5	NAS-Port	49	Acct-Terminate-Cause
6	Service-Type	50	Acct-Multi-Session-Id
7	Framed-Protocol	51	Acct-Link-Count
8	Framed-IP-Address	52	Acct-Input-Gigawords
9	Framed-IP-Netmask	53	Acct-Output-Gigawords
10	Framed-Routing	54	(unassigned)
11	Filter-ID	55	Event-Timestamp
12	Framed-MTU	56-59	(unassigned)
13	Framed-Compression	60	CHAP-Challenge
14	Login-IP-Host	61	NAS-Port-Type
15	Login-Service	62	Port-Limit
16	Login-TCP-Port	63	Login-LAT-Port
17	(unassigned)	64	Tunnel-Type
18	Reply-Message	65	Tunnel-Medium-Type
19	Callback-Number	66	Tunnel-Client-Endpoint
20	Callback-ID	67	Tunnel-Server-Endpoint
21	(unassigned)	68	Acct-Tunnel-Connection
22	Framed-Route	69	Tunnel-Password
23	Framed-IPX-Network	70	ARAP-Password
24	State	71	ARAP-Features
25	Class	72	ARAP-Zone-Access
26	Vendor-Specific	73	ARAP-Security
27	Session-Timeout	74	ARAP-Security-Data
28	Idle-Timeout	75	Password-Retry
29	Termination-Action	76	Prompt
30	Called-Station-Id	77	Connect-Info
31	Calling-Station-Id	78	Configuration-Token
32	NAS-Identifier	79	EAP-Message
33	Proxy-State	80	Message-Authenticator
34	Login-LAT-Service	81	Tunnel-Private-Group-ID
35	Login-LAT-Node	82	Tunnel-Assignment-id
36	Login-LAT-Group	83	Tunnel-Preference
37	Framed-AppleTalk-Link	84	ARAP-Challenge-Response
38	Framed-AppleTalk-Network	85	Acct-Interim-Interval
39	Framed-AppleTalk-Zone	86	Acct-Tunnel-Packets-Lost
40	Acct-Status-Type	87	NAS-Port-Id
41	Acct-Delay-Time	88	Framed-Pool
42	Acct-Input-Octets	89	(unassigned)
43	Acct-Output-Octets	90	Tunnel-Client-Auth-id
44	Acct-Session-Id	91	Tunnel-Server-Auth-id

Extended RADIUS attributes

The RADIUS protocol features excellent extensibility. The Vendor-Specific attribute (attribute 26) allows a vendor to define extended attributes. The extended attributes can implement functions that the standard RADIUS protocol does not provide.

A vendor can encapsulate multiple subattributes in the TLV format in attribute 26 to provide extended functions. As shown in Figure 5, a subattribute encapsulated in attribute 26 consists of the following parts:

· Vendor-ID—ID of the vendor. The most significant byte is 0. The other three bytes contains a code compliant to RFC 1700.

· Vendor-Type—Type of the subattribute.

· Vendor-Length—Length of the subattribute.

· Vendor-Data—Contents of the subattribute.

The device supports RADIUS subattributes with a vendor ID of 25506. For more information, see "Proprietary RADIUS subattributes (vendor ID 25506)."

Figure 5 Format of attribute 26

HWTACACS

HW Terminal Access Controller Access Control System (HWTACACS) is an enhanced security protocol based on TACACS (RFC 1492). HWTACACS is similar to RADIUS, and uses a client/server model for information exchange between the NAS and the HWTACACS server.

HWTACACS typically provides AAA services for PPP, VPDN, and terminal users. In a typical HWTACACS scenario, terminal users need to log in to the NAS. Working as the HWTACACS client, the NAS sends users' usernames and passwords to the HWTACACS server for authentication. After passing authentication and obtaining authorized rights, a user logs in to the device and performs operations. The HWTACACS server records the operations that each user performs.

Differences between HWTACACS and RADIUS

HWTACACS and RADIUS have many features in common, such as using a client/server model, using shared keys for data encryption, and providing flexibility and scalability. Table 3 lists the primary differences between HWTACACS and RADIUS.

Table 3 Primary differences between HWTACACS and RADIUS

HWTACACS	RADIUS
Uses TCP, which provides reliable network transmission.	Uses UDP, which provides high transport efficiency.
Encrypts the entire packet except for the HWTACACS header.	Encrypts only the user password field in an authentication packet.
Protocol packets are complicated and authorization is independent of authentication. Authentication and authorization can be deployed on different HWTACACS servers.	Protocol packets are simple and the authorization process is combined with the authentication process.
Supports authorization of configuration commands. Access to commands depends on both the user's roles and authorization. A user can use only commands that are permitted by the user roles and authorized by the HWTACACS server.	Does not support authorization of configuration commands. Access to commands solely depends on the user's roles. For more information about user roles, see Fundamentals Configuration Guide.

Basic HWTACACS packet exchange process

Figure 6 describes how HWTACACS performs user authentication, authorization, and accounting for a Telnet user.

Figure 6 Basic HWTACACS packet exchange process for a Telnet user

HWTACACS operates using in the following workflow:

1. A Telnet user sends an access request to the HWTACACS client.

2. The HWTACACS client sends a start-authentication packet to the HWTACACS server when it receives the request.

3. The HWTACACS server sends back an authentication response to request the username.

4. Upon receiving the response, the HWTACACS client asks the user for the username.

5. The user enters the username.

6. After receiving the username from the user, the HWTACACS client sends the server a continue-authentication packet that includes the username.

7. The HWTACACS server sends back an authentication response to request the login password.

8. Upon receipt of the response, the HWTACACS client prompts the user for the login password.

9. The user enters the password.

10. After receiving the login password, the HWTACACS client sends the HWTACACS server a continue-authentication packet that includes the login password.

11. If the authentication succeeds, the HWTACACS server sends back an authentication response to indicate that the user has passed authentication.

12. The HWTACACS client sends a user authorization request packet to the HWTACACS server.

13. If the authorization succeeds, the HWTACACS server sends back an authorization response, indicating that the user is now authorized.

14. Knowing that the user is now authorized, the HWTACACS client pushes its CLI to the user and permits the user to log in.

15. The HWTACACS client sends a start-accounting request to the HWTACACS server.

16. The HWTACACS server sends back an accounting response, indicating that it has received the start-accounting request.

17. The user logs off.

18. The HWTACACS client sends a stop-accounting request to the HWTACACS server.

19. The HWTACACS server sends back a stop-accounting response, indicating that the stop-accounting request has been received.

LDAP

The Lightweight Directory Access Protocol (LDAP) provides standard multiplatform directory service. LDAP was developed on the basis of the X.500 protocol. It improves the following functions of X.500:

· Read/write interactive access.

· Browse.

· Search.

LDAP is suitable for storing data that does not often change. The protocol is used to store user information. For example, LDAP server software Active Directory Server is used in Microsoft Windows operating systems. The software stores the user information and user group information for user login authentication and authorization.

LDAP directory service

LDAP uses directories to maintain the organization information, personnel information, and resource information. The directories are organized in a tree structure and include entries. An entry is a set of attributes with distinguished names (DNs). The attributes are used to store information such as usernames, passwords, emails, computer names, and phone numbers.

LDAP uses a client/server model, and all directory information is stored in the LDAP server. Commonly used LDAP server products include Microsoft Active Directory Server, IBM Tivoli Directory Server, and Sun ONE Directory Server.

LDAP authentication and authorization

AAA can use LDAP to provide authentication and authorization services for users. LDAP defines a set of operations to implement its functions. The main operations for authentication and authorization are the bind operation and search operation.

· The bind operation allows an LDAP client to perform the following operations:

¡ Establish a connection with the LDAP server.

¡ Obtain the access rights to the LDAP server.

¡ Check the validity of user information.

· The search operation constructs search conditions and obtains the directory resource information of the LDAP server.

In LDAP authentication, the client completes the following tasks:

1. Uses the LDAP server administrator DN to bind with the LDAP server. After the binding is created, the client establishes a connection to the server and obtains the right to search.

2. Constructs search conditions by using the username in the authentication information of a user. The specified root directory of the server is searched and a user DN list is generated.

3. Binds with the LDAP server by using each user DN and password. If a binding is created, the user is considered legal.

In LDAP authorization, the client performs the same tasks as in LDAP authentication. When the client constructs search conditions, it obtains both authorization information and the user DN list.

Basic LDAP authentication process

The following example illustrates the basic LDAP authentication process for a Telnet user.

Figure 7 Basic LDAP authentication process for a Telnet user

The following shows the basic LDAP authentication process:

1. A Telnet user initiates a connection request and sends the username and password to the LDAP client.

2. After receiving the request, the LDAP client establishes a TCP connection with the LDAP server.

3. To obtain the right to search, the LDAP client uses the administrator DN and password to send an administrator bind request to the LDAP server.

4. The LDAP server processes the request. If the bind operation is successful, the LDAP server sends an acknowledgment to the LDAP client.

5. The LDAP client sends a user DN search request with the username of the Telnet user to the LDAP server.

6. After receiving the request, the LDAP server searches for the user DN by the base DN, search scope, and filtering conditions. If a match is found, the LDAP server sends a response to notify the LDAP client of the successful search. There might be one or more user DNs found.

7. The LDAP client uses the obtained user DN and the entered user password as parameters to send a user DN bind request to the LDAP server. The server will check whether the user password is correct.

8. The LDAP server processes the request, and sends a response to notify the LDAP client of the bind operation result. If the bind operation fails, the LDAP client uses another obtained user DN as the parameter to send a user DN bind request to the LDAP server. This process continues until a DN is bound successfully or all DNs fail to be bound. If all user DNs fail to be bound, the LDAP client notifies the user of the login failure and denies the user's access request.

9. The LDAP client saves the user DN that has been bound and exchanges authorization packets with the authorization server.

¡ If LDAP authorization is used, see the authorization process shown in Figure 8.

¡ If another method is expected for authorization, the authorization process of that method applies.

10. After successful authorization, the LDAP client notifies the user of the successful login.

Basic LDAP authorization process

The following example illustrates the basic LDAP authorization process for a Telnet user.

Figure 8 Basic LDAP authorization process for a Telnet user

The following shows the basic LDAP authorization process:

1. A Telnet user initiates a connection request and sends the username and password to the device. The device will act as the LDAP client during authorization.

2. After receiving the request, the device exchanges authentication packets with the authentication server for the user:

¡ If LDAP authentication is used, see the authentication process shown in Figure 7.

- If the device (the LDAP client) uses the same LDAP server for authentication and authorization, skip to step 6.

- If the device (the LDAP client) uses different LDAP servers for authentication and authorization, skip to step 4.

¡ If another authentication method is used, the authentication process of that method applies. The device acts as the LDAP client. Skip to step 3.

3. The LDAP client establishes a TCP connection with the LDAP authorization server.

4. To obtain the right to search, the LDAP client uses the administrator DN and password to send an administrator bind request to the LDAP server.

5. The LDAP server processes the request. If the bind operation is successful, the LDAP server sends an acknowledgment to the LDAP client.

6. The LDAP client sends an authorization search request with the username of the Telnet user to the LDAP server. If the user uses the same LDAP server for authentication and authorization, the client sends the request with the saved user DN of the Telnet user to the LDAP server.

7. After receiving the request, the LDAP server searches for the user information by the base DN, search scope, filtering conditions, and LDAP attributes. If a match is found, the LDAP server sends a response to notify the LDAP client of the successful search.

8. After successful authorization, the LDAP client notifies the user of the successful login.

AAA implementation on the device

This section describes AAA user management and methods.

User management based on ISP domains and user access types

AAA manages users based on the users' ISP domains and access types.

On a NAS, each user belongs to one ISP domain. The NAS determines the ISP domain to which a user belongs based on the username entered by the user at login.

Figure 9 Determining the ISP domain for a user by username

AAA manages users in the same ISP domain based on the users' access types. The device supports the following user access types:

· LAN—LAN users must pass 802.1X or MAC authentication to come online.

· Login—Login users include SSH, Telnet, FTP, and terminal users that log in to the device. Terminal users can access through a console port.

· Portal—Portal users must pass portal authentication to access the network.

· HTTP or HTTPS—Users log in to the device through HTTP or HTTPS.

NOTE:

The device also provides authentication modules (such as 802.1X) for implementation of user authentication management policies. If you configure these authentication modules, the ISP domains for users of the access types depend on the configuration of the authentication modules.

AAA methods

AAA supports configuring different authentication, authorization, and accounting methods for different types of users in an ISP domain. The NAS determines the ISP domain and access type of a user. The NAS also uses the methods configured for the access type in the domain to control the user's access.

AAA also supports configuring a set of default methods for an ISP domain. These default methods are applied to users for which no AAA methods are configured.

The device supports the following authentication methods:

· No authentication—This method trusts all users and does not perform authentication. For security purposes, do not use this method.

· Local authentication—The NAS authenticates users by itself, based on the locally configured user information including the usernames, passwords, and attributes. Local authentication allows high speed and low cost, but the amount of information that can be stored is limited by the size of the storage space.

· Remote authentication—The NAS works with a RADIUS, HWTACACS, or LDAP server to authenticate users. The server manages user information in a centralized manner. Remote authentication provides high capacity, reliable, and centralized authentication services for multiple NASs. You can configure backup methods to be used when the remote server is not available.

The device supports the following authorization methods:

· No authorization—The NAS performs no authorization exchange. The following default authorization information applies after users pass authentication:

¡ Non-login users can access the network.

¡ Login users obtain the level-0 user role. For more information about the level-0 user role, see RBAC configuration in Fundamentals Configuration Guide.

¡ The working directory for FTP, SFTP, and SCP login users is the root directory of the NAS. However, the users do not have permission to access the root directory.

· Local authorization—The NAS performs authorization according to the user attributes locally configured for users.

· Remote authorization—The NAS works with a RADIUS, HWTACACS, or LDAP server to authorize users. RADIUS authorization is bound with RADIUS authentication. RADIUS authorization can work only after RADIUS authentication is successful, and the authorization information is included in the Access-Accept packet. HWTACACS authorization is separate from HWTACACS authentication, and the authorization information is included in the authorization response after successful authentication. You can configure backup methods to be used when the remote server is not available.

The device supports the following accounting methods:

· No accounting—The NAS does not perform accounting for the users.

· Local accounting—Local accounting is implemented on the NAS. It counts and controls the number of concurrent users that use the same local user account, but does not provide statistics for charging.

· Remote accounting—The NAS works with a RADIUS server or HWTACACS server for accounting. You can configure backup methods to be used when the remote server is not available.

In addition, the device provides the following login services to enhance device security:

· Command authorization—Enables the NAS to let the authorization server determine whether a command entered by a login user is permitted. Login users can execute only commands permitted by the authorization server. For more information about command authorization, see Fundamentals Configuration Guide.

· Command accounting—When command authorization is disabled, command accounting enables the accounting server to record all valid commands executed on the device. When command authorization is enabled, command accounting enables the accounting server to record all authorized commands. For more information about command accounting, see Fundamentals Configuration Guide.

· User role authentication—Authenticates each user that wants to obtain another user role without logging out or getting disconnected. For more information about user role authentication, see Fundamentals Configuration Guide.

AAA for MPLS L3VPNs

You can deploy AAA across VPNs in an MPLS L3VPN scenario where clients in different VPNs are centrally authenticated. The deployment enables forwarding of RADIUS and HWTACACS packets across MPLS VPNs.

As shown in Figure 10, you can deploy AAA across the VPNs. The left PE connects the user private networks to the MPLS backbone and acts as a NAS. The NAS transparently delivers the AAA packets of private users in VPN 1 and VPN 2 to the AAA servers in VPN 3 for centralized authentication. Authentication packets of private users in different VPNs do not affect each other.

Figure 10 Network diagram

This feature can also help an MCE to implement portal authentication for VPNs. For more information about portal authentication, see "Configuring portal authentication."

Protocols and standards

· RFC 2865, Remote Authentication Dial In User Service (RADIUS)

· RFC 2866, RADIUS Accounting

· RFC 2867, RADIUS Accounting Modifications for Tunnel Protocol Support

· RFC 2868, RADIUS Attributes for Tunnel Protocol Support

· RFC 2869, RADIUS Extensions

· RFC 5176, Dynamic Authorization Extensions to Remote Authentication Dial In User Service (RADIUS)

· RFC 1492, An Access Control Protocol, Sometimes Called TACACS

· RFC 1777, Lightweight Directory Access Protocol

· RFC 2251, Lightweight Directory Access Protocol (v3)

RADIUS attributes

Commonly used standard RADIUS attributes

No.	Attribute	Description
1	User-Name	Name of the user to be authenticated.
2	User-Password	User password for PAP authentication, only present in Access-Request packets when PAP authentication is used.
3	CHAP-Password	Digest of the user password for CHAP authentication, only present in Access-Request packets when CHAP authentication is used.
4	NAS-IP-Address	IP address for the server to use to identify the client. Typically, a client is identified by the IP address of its access interface. This attribute is only present in Access-Request packets.
5	NAS-Port	Physical port of the NAS that the user accesses.
6	Service-Type	Type of service that the user has requested or type of service to be provided.
7	Framed-Protocol	Encapsulation protocol for framed access.
8	Framed-IP-Address	IP address assigned to the user.
11	Filter-ID	Name of the filter list.
12	Framed-MTU	MTU for the data link between the user and NAS. For example, this attribute can be used to define the maximum size of EAP packets allowed to be processed in 802.1X EAP authentication.
14	Login-IP-Host	IP address of the NAS interface that the user accesses.
15	Login-Service	Type of service that the user uses for login.
18	Reply-Message	Text to be displayed to the user, which can be used by the server to communicate information, for example, the authentication failure reason.
26	Vendor-Specific	Vendor-specific proprietary attribute. A packet can contain one or more proprietary attributes, each of which can contain one or more subattributes.
27	Session-Timeout	Maximum service duration for the user before termination of the session.
28	Idle-Timeout	Maximum idle time permitted for the user before termination of the session.
31	Calling-Station-Id	User identification that the NAS sends to the server. For the LAN access service provided by an H3C device, this attribute includes the MAC address of the user.
32	NAS-Identifier	Identification that the NAS uses to identify itself to the RADIUS server.
40	Acct-Status-Type	Type of the Accounting-Request packet. Possible values include: · 1—Start. · 2—Stop. · 3—Interim-Update. · 4—Reset-Charge. · 7—Accounting-On. (Defined in the 3rd Generation Partnership Project.) · 8—Accounting-Off. (Defined in the 3rd Generation Partnership Project.) · 9 to 14—Reserved for tunnel accounting. · 15—Reserved for failed.
45	Acct-Authentic	Authentication method used by the user. Possible values include: · 1—RADIUS. · 2—Local. · 3—Remote.
60	CHAP-Challenge	CHAP challenge generated by the NAS for MD5 calculation during CHAP authentication.
61	NAS-Port-Type	Type of the physical port of the NAS that is authenticating the user. Possible values include: · 15—Ethernet. · 16—Any type of ADSL. · 17—Cable. (With cable for cable TV.) · 19—WLAN-IEEE 802.11. · 201—VLAN. · 202—ATM. If the port is an ATM or Ethernet one and VLANs are implemented on it, the value of this attribute is 201.
64	Tunnel-Type	Tunneling protocols used. The value 13 represents VLAN.
65	Tunnel-Medium-Type	Transport medium type to use for creating a tunnel. For VLAN assignment, the value must be 6 to indicate the 802 media plus Ethernet.
79	EAP-Message	Used to encapsulate EAP packets to allow RADIUS to support EAP authentication.
80	Message-Authenticator	Used for authentication and verification of authentication packets to prevent spoofing Access-Requests. This attribute is present when EAP authentication is used.
81	Tunnel-Private-Group-ID	Group ID for a tunnel session. To assign VLANs, the NAS conveys VLAN IDs by using this attribute.
87	NAS-Port-Id	String for describing the port of the NAS that is authenticating the user.
168	Framed-IPv6-Address	Server-assigned IPv6 address for the NAS to assign to the host. The address must be unique.

Proprietary RADIUS subattributes (vendor ID 25506)

Table 4 lists all RADIUS subattributes with a vendor ID of 25506. Support for these subattributes depends on the device model.

Table 4 RADIUS subattributes (vendor ID 25506)

No.	Subattribute	Description
1	Input-Peak-Rate	Peak rate in the direction from the user to the NAS, in bps.
2	Input-Average-Rate	Average rate in the direction from the user to the NAS, in bps.
3	Input-Basic-Rate	Basic rate in the direction from the user to the NAS, in bps.
4	Output-Peak-Rate	Peak rate in the direction from the NAS to the user, in bps.
5	Output-Average-Rate	Average rate in the direction from the NAS to the user, in bps.
6	Output-Basic-Rate	Basic rate in the direction from the NAS to the user, in bps.
15	Remanent_Volume	Total amount of data available for the connection, in different units for different server types.
17	ISP-ID	ISP domain where the user obtains authorization information.
20	Command	Operation for the session, used for session control. Possible values include: · 1—Trigger-Request. · 2—Terminate-Request. · 3—SetPolicy. · 4—Result. · 5—PortalClear.
25	Result_Code	Result of the Trigger-Request or SetPolicy operation, zero for success and any other value for failure.
26	Connect_ID	Index of the user connection.
27	PortalURL	PADM redirect URL assigned to PPPoE users.
28	Ftp_Directory	FTP, SFTP, or SCP user working directory. When the RADIUS client acts as the FTP, SFTP, or SCP server, this attribute is used to set the working directory for an FTP, SFTP, or SCP user on the RADIUS client.
29	Exec_Privilege	EXEC user priority.
32	NAT-IP-Address	Public IP address assigned to the user when the source IP address and port are translated.
33	NAT-Start-Port	Start port number of the port range assigned to the user when the source IP address and port are translated.
34	NAT-End-Port	End port number of the port range assigned to the user when the source IP address and port are translated.
59	NAS_Startup_Timestamp	Startup time of the NAS in seconds, which is represented by the time elapsed after 00:00:00 on Jan. 1, 1970 (UTC).
60	Ip_Host_Addr	User IP address and MAC address included in authentication and accounting requests, in the format A.B.C.D hh:hh:hh:hh:hh:hh. A space is required between the IP address and the MAC address.
61	User_Notify	Information that must be sent from the server to the client transparently.
62	User_HeartBeat	Hash value assigned after an 802.1X user passes authentication, which is a 32-byte string. This attribute is stored in the user list on the NAS and verifies the handshake packets from the 802.1X user. This attribute only exists in Access-Accept and Accounting-Request packets.
98	Multicast_Receive_Group	IP address of the multicast group that the user's host joins as a receiver. This subattribute can appear multiple times in a multicast packet to indicate that the user belongs to multiple multicast groups.
100	IP6_Multicast_Receive_Group	IPv6 address of the multicast group that the user's host joins as a receiver. This subattribute can appear multiple times in a multicast packet to indicate that the user belongs to multiple multicast groups.
101	MLD-Access-Limit	Maximum number of MLD multicast groups that the user can join concurrently.
102	local-name	L2TP local tunnel name.
103	IGMP-Access-Limit	Maximum number of IGMP multicast groups that the user can join concurrently.
104	VPN-Instance	MPLS L3VPN instance to which a user belongs.
105	ANCP-Profile	ANCP profile name.
135	Client-Primary-DNS	IP address of the primary DNS server.
136	Client-Secondary-DNS	IP address of the secondary DNS server.
140	User_Group	User groups assigned after the SSL VPN user passes authentication. A user can belong to multiple user groups that are separated by semicolons. This attribute is used to work with the SSL VPN device.
144	Acct_IPv6_Input_Octets	Bytes of IPv6 packets in the inbound direction. The measurement unit depends on the configuration on the device.
145	Acct_IPv6_Output_Octets	Bytes of IPv6 packets in the outbound direction. The measurement unit depends on the configuration on the device.
146	Acct_IPv6_Input_Packets	Number of IPv6 packets in the inbound direction. The measurement unit depends on the configuration on the device.
147	Acct_IPv6_Output_Packets	Number of IPv6 packets in the outbound direction. The measurement unit depends on the configuration on the device.
148	Acct_IPv6_Input_Gigawords	Bytes of IPv6 packets in the inbound direction. The measurement unit is 4G bytes.
149	Acct_IPv6_Output_Gigawords	Bytes of IPv6 packets in the outbound direction. The measurement unit is 4G bytes.
155	User-Roles	List of space-separated user roles.
210	Av-Pair	Vendor-specific attribute pair. Available attribute pairs include: · Server-assigned voice VLAN in the format of device-traffic-class=voice. · Server-assigned user role in the format of shell:role=xxx. · Server-assigned ACL in the format of url-redirect-acl=xxx. · Server-assigned Web redirect URL in the format of url-redirect=xxx. · Server-deployed command to reboot a port, in the format of subscriber:command=bounce-host-port. · Server-assigned port shutdown duration in the format of bounce:seconds=xxx. · Server-deployed command to shut down a port, in the format of subscriber:command=disable-host-port. · VSI-based ACL resource assignment capability in the format of ACL:match-by-vsiindex=x. Value 1 of x indicates that this feature is supported, and the other values of x are reserved.
215	Accounting-Level	ITA traffic level in the range of 1 to 8.
216	Ita-Policy	ITA policy name.
230	NAS-Port-Name	Interface through which the user is connected to the NAS.
246	Auth_Detail_Result	Accounting details. The server sends Access-Accept packets with subattributes 246 and 250 in the following situations: · 1—The subscriber charge is overdue. The subscriber is allowed to access network resources in the whitelist. If the subscriber accesses other network resources, the device redirects it to the URL specified by subattribute 250. · 2—The broadband lease of the subscriber expires. The device redirects the subscriber to the URL specified by subattribute 250 when the subscriber requests to access webpages for the first time.
247	Input-Committed-Burst-Size	Committed burst size from the user to the NAS, in bits. The total length cannot exceed 4 bytes for this field. This subattribute must be assigned together with the Input-Average-Rate attribute.
248	Output-Committed-Burst-Size	Committed burst size from the NAS to the user, in bits. The total length cannot exceed 4 bytes for this field. This subattribute must be assigned together with the Output-Average-Rate attribute.
249	authentication-type	Authentication type. The value can be: · 1—Intranet access authentication. · 2—Internet access authentication. If the packet does not contain this subattribute, common authentication applies.
250	WEB-URL	Redirect URL for users.
251	Subscriber-ID	Family plan ID.
252	Subscriber-Profile	QoS policy name for the family plan of the subscriber.
255	Product_ID	Product name.

FIPS compliance

The device supports the FIPS mode that complies with NIST FIPS 140-2 requirements. Support for features, commands, and parameters might differ in FIPS mode (see "Configuring FIPS") and non-FIPS mode.

AAA configuration considerations and task list

To configure AAA, complete the following tasks on the NAS:

1. Configure the required AAA schemes:

¡ Local authentication—Configure local users and the related attributes, including the usernames and passwords, for the users to be authenticated.

¡ Remote authentication—Configure the required RADIUS, HWTACACS, and LDAP schemes.

2. Configure AAA methods for the users' ISP domains. Remote AAA methods need to use the configured RADIUS, HWTACACS, and LDAP schemes.

Figure 11 AAA configuration procedure

To configure AAA, perform the following tasks:

Tasks at a glance
(Required.) Perform a minimum one of the following tasks to configure local users or AAA schemes: · Configuring local users · Configuring RADIUS schemes · Configuring HWTACACS schemes · Configuring LDAP schemes
(Required.) Configure AAA methods for ISP domains: 1. (Required.) Creating an ISP domain 2. (Optional.) Configuring ISP domain attributes 3. (Required.) Perform a minimum one of the following tasks to configure AAA authentication, authorization, and accounting methods for the ISP domain: ¡ Configuring authentication methods for an ISP domain ¡ Configuring authorization methods for an ISP domain ¡ Configuring accounting methods for an ISP domain
(Optional.) Configuring the RADIUS session-control feature
(Optional.) Configuring the RADIUS DAS feature
(Optional.) Changing the DSCP priority for RADIUS packets
(Optional.) Configuring the RADIUS attribute translation feature
(Optional.) Setting the maximum number of concurrent login users
(Optional.) Configuring a NAS-ID profile
(Optional.) Configuring the device ID
(Optional.) Configuring the connection recording policy

Configuring AAA schemes

This section includes information on configuring local users, RADIUS schemes, HWTACACS schemes, and LDAP schemes.

Configuring local users

To implement local authentication, authorization, and accounting, create local users and configure user attributes on the device. The local users and attributes are stored in the local user database on the device. A local user is uniquely identified by the combination of a username and a user type. Local users are classified into the following types:

· Device management user—User that logs in to the device for device management.

· Network access user—User that accesses network resources through the device.

The following shows the configurable local user attributes:

· Description—Descriptive information of the user.

· Service type—Services that the user can use. Local authentication checks the service types of a local user. If none of the service types is available, the user cannot pass authentication.

Service types include FTP, HTTP, HTTPS, LAN access, portal, SSH, Telnet, and terminal.

· User state—Whether or not a local user can request network services. There are two user states: active and blocked. A user in active state can request network services, but a user in blocked state cannot.

· Upper limit of concurrent logins using the same user name—Maximum number of users that can concurrently access the device by using the same user name. When the number reaches the upper limit, no more local users can access the device by using the user name.

· User group—Each local user belongs to a local user group and has all attributes of the group. The attributes include the password control attributes and authorization attributes. For more information about local user group, see "Configuring user group attributes."

· Binding attributes—Binding attributes control the scope of users, and are checked during local authentication of a user. If the attributes of a user do not match the binding attributes configured for the local user account, the user cannot pass authentication. Binding attributes include the IP address, access port, MAC address, and native VLAN. For support and usage information about binding attributes, see "Configuring local user attributes."

· Authorization attributes—Authorization attributes indicate the user's rights after it passes local authentication. For support information about authorization attributes, see "Configuring local user attributes."

Configure the authorization attributes based on the service type of local users.

You can configure an authorization attribute in user group view or local user view. The setting of an authorization attribute in local user view takes precedence over the attribute setting in user group view.

¡ The attribute configured in user group view takes effect on all local users in the user group.

¡ The attribute configured in local user view takes effect only on the local user.

· Password control attributes—Password control attributes help control password security for device management users. Password control attributes include password aging time, minimum password length, password composition checking, password complexity checking, and login attempt limit.

You can configure a password control attribute in system view, user group view, or local user view. A password control attribute with a smaller effective range has a higher priority. For more information about password management and global password configuration, see "Configuring password control."

· Validity period—Time period in which a network access user is considered valid for authentication.

Local user configuration task list

Tasks at a glance
(Required.) Configuring local user attributes
(Optional.) Configuring user group attributes
(Optional.) Configuring the auto-delete feature of local users

Configuring local user attributes

When you configure local user attributes, follow these guidelines:

· If password control is enabled globally by using the password-control enable command, the device does not display local user passwords or retain them in the running configuration. When you globally disable the password control feature, local user passwords are automatically restored to the running configuration. To display the running configuration, use the display current-configuration command.

· You can configure authorization attributes and password control attributes in local user view or user group view. The setting in local user view takes precedence over the setting in user group view.

· Configure the location binding attribute based on the service types of users.

¡ For 802.1X users, specify the 802.1X-enabled Layer 2 Ethernet interfaces through which the users access the device.

¡ For MAC authentication users, specify the MAC authentication-enabled Layer 2 Ethernet interfaces through which the users access the device.

¡ For portal users, specify the portal-enabled interfaces through which the users access the device. Specify the Layer 2 Ethernet interfaces if portal is enabled on VLAN interfaces and the portal roaming enable command is not configured.

To configure local user attributes:

Step	Command	Remarks
1. Enter system view.	system-view	N/A
2. Add a local user and enter local user view.	local-user user-name [ class { manage \| network } ]	By default, no local users exist.
3. (Optional.) Configure a password for the local user.	· For a network access user: password { cipher \| simple } string · For a device management user: ¡ In non-FIPS mode: password [ { hash \| simple } string ] ¡ In FIPS mode: password	The default settings are as follows: · In non-FIPS mode, no password is configured for a local user. A local user can pass authentication after entering the correct username and passing attribute checks. · In FIPS mode, no password is configured for a local user. A local user cannot pass authentication.
4. (Optional.) Configure a description for the local user.	description text	By default, no description is configured for a local user. You can configure descriptions only for network access users.
5. Assign services to the local user.	· For a network access user: service-type { lan-access \| portal } · For a device management user: ¡ In non-FIPS mode: service-type { ftp \| { http \| https \| ssh \| telnet \| terminal } * } ¡ In FIPS mode: service-type { https \| ssh \| terminal } *	By default, no services are authorized to a local user.
6. (Optional.) Place the local user in the active or blocked state.	state { active \| block }	By default, a local user is in active state and can request network services.
7. (Optional.) Set the upper limit of concurrent logins using the local user name.	access-limit max-user-number	By default, the number of concurrent logins is not limited for the local user. This command takes effect only when local accounting is configured for the local user. It does not apply to FTP, SFTP, or SCP users. These users do not support accounting.
8. (Optional.) Configure binding attributes for the local user.	bind-attribute { ip ip-address \| location interface interface-type interface-number \| mac mac-address \| vlan vlan-id } *	By default, no binding attributes are configured for a local user.
9. (Optional.) Configure authorization attributes for the local user.	authorization-attribute { acl acl-number \| idle-cut minutes \| ip-pool ipv4-pool-name \| ipv6-pool ipv6-pool-name \| session-timeout minutes \| user-profile profile-name \| user-role role-name \| vlan vlan-id \| work-directory directory-name } *	The following default settings apply: · The working directory for FTP, SFTP, and SCP users is the root directory of the NAS. However, the users do not have permission to access the root directory. · The network-operator user role is assigned to local users that are created by a network-admin or level-15 user.
10. (Optional.) Configure password control attributes for the local user.	· Set the password aging time: password-control aging aging-time · Set the minimum password length: password-control length length · Configure the password composition policy: password-control composition type-number type-number [ type-length type-length ] · Configure the password complexity checking policy: password-control complexity { same-character \| user-name } check · Configure the maximum login attempts and the action to take if there is a login failure: password-control login-attempt login-times [ exceed { lock \| lock-time time \| unlock } ]	By default, the local user uses password control attributes of the user group to which the local user belongs. Only device management users support the password control feature.
11. (Optional.) Assign the local user to a user group.	group group-name	By default, a local user belongs to the user group system.
12. Configure the validity period for the local user.	validity-datetime { from start-date start-time to expiration-date expiration-time \| from start-date start-time \| to expiration-date expiration-time }	By default, a local user does not expire. You can configure validity periods only for network access users.

Configuring user group attributes

User groups simplify local user configuration and management. A user group contains a group of local users and has a set of local user attributes. You can configure local user attributes for a user group to implement centralized user attributes management for the local users in the group. Local user attributes that are manageable include authorization attributes.

By default, every new local user belongs to the default user group system and has all attributes of the group. To assign a local user to a different user group, use the group command in local user view.

To configure user group attributes:

Step	Command	Remarks
1. Enter system view.	system-view	N/A
2. Create a user group and enter user group view.	user-group group-name	By default, a system-defined user group exists. The group name is system.
3. Configure authorization attributes for the user group.	authorization-attribute { acl acl-number \| idle-cut minutes \| ip-pool ipv4-pool-name \| ipv6-pool ipv6-pool-name \| session-timeout minutes \| user-profile profile-name \| vlan vlan-id \| work-directory directory-name } *	By default, no authorization attributes are configured for a user group.
4. (Optional.) Configure password control attributes for the user group.	· Set the password aging time: password-control aging aging-time · Set the minimum password length: password-control length length · Configure the password composition policy: password-control composition type-number type-number [ type-length type-length ] · Configure the password complexity checking policy: password-control complexity { same-character \| user-name } check · Configure the maximum login attempts and the action to take for login failures: password-control login-attempt login-times [ exceed { lock \| lock-time time \| unlock } ]	By default, the user group uses the global password control settings. For more information, see "Configuring password control."

Configuring the auto-delete feature of local users

This feature enables the device to examine the validity of local users at fixed time periods of 10 minutes and automatically delete expired local users.

To configure the auto-delete feature of local users:

Step	Command	Remarks
1. Enter system view	system-view	N/A
2. Enable the local user auto-delete feature.	local-user auto-delete enable	By default, the feature is disabled.

Displaying and maintaining local users and local user groups

Execute display commands in any view.

Task	Command
Display local user configuration and online user statistics.	display local-user [ class { manage \| network ] } \| idle-cut { disable \| enable } \| service-type { ftp \| http \| https \| lan-access \| portal \| ssh \| telnet \| terminal } \| state { active \| block } \| user-name user-name class { manage \| network ] } \| vlan vlan-id ]
Display user group configuration information.	display user-group { all \| name group-name }

Configuring RADIUS schemes

A RADIUS scheme specifies the RADIUS servers that the device can work with and defines a set of parameters. The device uses the parameters to exchange information with the RADIUS servers, including the server IP addresses, UDP port numbers, shared keys, and server types.

Configuration task list

Tasks at a glance
(Optional.) Configuring a test profile for RADIUS server status detection
(Required.) Creating a RADIUS scheme
(Required.) Specifying the RADIUS authentication servers
(Optional.) Specifying the RADIUS accounting servers and the relevant parameters
(Optional.) Specifying the shared keys for secure RADIUS communication
(Optional.) Specifying an MPLS L3VPN instance for the scheme
(Optional.) Setting the username format and traffic statistics units
(Optional.) Setting the maximum number of RADIUS request transmission attempts
(Optional.) Setting the status of RADIUS servers
(Optional.) Enabling the RADIUS server load sharing feature
(Optional.) Specifying the source IP address for outgoing RADIUS packets
(Optional.) Setting RADIUS timers
(Optional.) Enabling forcibly sending stop-accounting packets
(Optional.) Configuring the RADIUS accounting-on feature
(Optional.) Interpreting the RADIUS class attribute as CAR parameters
(Optional.) Configuring the Login-Service attribute check method for SSH, FTP, and terminal users
(Optional.) Configuring the MAC address format for RADIUS attribute 31
(Optional.) Setting the data measurement unit for the Remanent_Volume attribute
(Optional.) Enabling SNMP notifications for RADIUS

Configuring a test profile for RADIUS server status detection

Use a test profile to detect whether a RADIUS authentication server is reachable at a detection interval. To detect the RADIUS server status, you must configure the RADIUS server to use this test profile in a RADIUS scheme.

With the test profile specified, the device sends a detection packet to the RADIUS server within each detection interval. The detection packet is a simulated authentication request that includes the specified user name and password in the test profile.

· If the device receives a response from the server within the interval, it sets the server to the active state.

· If the device does not receive any response from the server within the interval, it sets the server to the blocked state.

The device refreshes the RADIUS server status at each detection interval according to the detection result.

The device stops detecting the status of the RADIUS server when one of the following operations is performed:

· The RADIUS server is removed from the RADIUS scheme.

· The test profile configuration is removed for the RADIUS server in RADIUS scheme view.

· The test profile is deleted.

· The RADIUS server is manually set to the blocked state.

· The RADIUS scheme is deleted.

To configure a test profile for RADIUS server status detection:

Step	Command	Remarks
1. Enter system view.	system-view	N/A
2. Configure a test profile for detecting the status of RADIUS authentication servers.	radius-server test-profile profile-name username name [ password { cipher \| simple } string ] [ interval interval ]	By default, no test profiles exist. You can configure multiple test profiles in the system.

Step

Command

Remarks

1. Enter system view.

system-view

N/A

2. Configure a test profile for detecting the status of RADIUS authentication servers.

radius-server test-profile profile-name username name [ password { cipher | simple } string ] [ interval interval ]

By default, no test profiles exist.

You can configure multiple test profiles in the system.

Creating a RADIUS scheme

Create a RADIUS scheme before performing any other RADIUS configurations. You can configure a maximum of 16 RADIUS schemes. A RADIUS scheme can be used by multiple ISP domains.

To create a RADIUS scheme:

Step	Command	Remarks
1. Enter system view.	system-view	N/A
2. Create a RADIUS scheme and enter RADIUS scheme view.	radius scheme radius-scheme-name	By default, no RADIUS schemes exist.

Specifying the RADIUS authentication servers

A RADIUS authentication server completes authentication and authorization together, because authorization information is piggybacked in authentication responses sent to RADIUS clients.

You can specify one primary authentication server and a maximum of 16 secondary authentication servers for a RADIUS scheme. Secondary servers provide AAA services when the primary server becomes unavailable. The device searches for an active server in the order the secondary servers are configured.

If redundancy is not required, specify only the primary server. A RADIUS authentication server can function as the primary authentication server for one scheme and a secondary authentication server for another scheme at the same time.

When RADIUS server load sharing is enabled, the device distributes the workload over all servers without considering the primary and secondary server roles. The device checks the weight value and number of currently served users for each active server, and then determines the most appropriate server in performance to receive an authentication request.

To specify RADIUS authentication servers for a RADIUS scheme:

Step	Command	Remarks
1. Enter system view.	system-view	N/A
2. Enter RADIUS scheme view.	radius scheme radius-scheme-name	N/A
3. Specify RADIUS authentication servers.	· Specify the primary RADIUS authentication server: primary authentication { host-name \| ipv4-address \| ipv6 ipv6-address } [ port-number \| key { cipher \| simple } string \| test-profile profile-name \| vpn-instance vpn-instance-name \| weight weight-value ] * · Specify a secondary RADIUS authentication server: secondary authentication { host-name \| ipv4-address \| ipv6 ipv6-address } [ port-number \| key { cipher \| simple } string \| test-profile profile-name \| vpn-instance vpn-instance-name \| weight weight-value ] *	By default, no authentication servers are specified. To support server status detection, specify an existing test profile for the RADIUS authentication server. If the test profile does not exist, the device cannot detect the server status. Two authentication servers in a scheme, primary or secondary, cannot have the same combination of host name, IP address, port number, and VPN instance. The weight keyword takes effect only when the RADIUS server load sharing feature is enabled for the RADIUS scheme.

Specifying the RADIUS accounting servers and the relevant parameters

You can specify one primary accounting server and a maximum of 16 secondary accounting servers for a RADIUS scheme. Secondary servers provide AAA services when the primary server becomes unavailable. The device searches for an active server in the order the secondary servers are configured.

If redundancy is not required, specify only the primary server. A RADIUS accounting server can function as the primary accounting server for one scheme and a secondary accounting server for another scheme at the same time.

If you specify a maximum number of realtime accounting attempts, the device will disconnect users from which no accounting responses are received within the permitted attempts.

The device sends RADIUS stop-accounting requests when it receives connection teardown requests from hosts or connection teardown commands from an administrator. However, the device might fail to receive a response for a stop-accounting request in a single transmission. Enable the device to buffer RADIUS stop-accounting requests that have not received responses from the accounting server. The device will resend the requests until responses are received.

To limit the transmission times, set a maximum number of transmission attempts that can be made for individual RADIUS stop-accounting requests. When the maximum attempts are made for a request, the device discards the buffered request.

RADIUS does not support accounting for FTP, SFTP, and SCP users.

To specify RADIUS accounting servers and the relevant parameters for a RADIUS scheme:

Step	Command	Remarks
1. Enter system view.	system-view	N/A
2. Enter RADIUS scheme view.	radius scheme radius-scheme-name	N/A
3. Specify RADIUS accounting servers.	· Specify the primary RADIUS accounting server: primary accounting { host-name \| ipv4-address \| ipv6 ipv6-address } [ port-number \| key { cipher \| simple } string \| vpn-instance vpn-instance-name \| weight weight-value ] * · Specify a secondary RADIUS accounting server: secondary accounting { host-name \| ipv4-address \| ipv6 ipv6-address } [ port-number \| key { cipher \| simple } string \| vpn-instance vpn-instance-name \| weight weight-value ] *	By default, no accounting servers are specified. Two accounting servers in a scheme, primary or secondary, cannot have the same combination of host name, IP address, port number, and VPN instance. The weight keyword takes effect only when the RADIUS server load sharing feature is enabled for the RADIUS scheme.
4. (Optional.) Set the maximum number of real-time accounting attempts.	retry realtime-accounting retries	The default setting is 5.
5. (Optional.) Enable buffering of RADIUS stop-accounting requests to which no responses have been received.	stop-accounting-buffer enable	By default, the buffering feature is enabled.
6. (Optional.) Set the maximum number of transmission attempts for individual RADIUS stop-accounting requests.	retry stop-accounting retries	The default setting is 500.

Specifying the shared keys for secure RADIUS communication

The RADIUS client and server use the MD5 algorithm and shared keys to generate the Authenticator value for packet authentication and user password encryption. The client and server must use the same key for each type of communication.

A key configured in this task is for all servers of the same type (accounting or authentication) in the scheme. The key has a lower priority than a key configured individually for a RADIUS server.

To specify a shared key for secure RADIUS communication:

Step	Command	Remarks
1. Enter system view.	system-view	N/A
2. Enter RADIUS scheme view.	radius scheme radius-scheme-name	N/A
3. Specify a shared key for secure RADIUS communication.	key { accounting \| authentication } { cipher \| simple } string	By default, no shared key is specified for secure RADIUS communication. The shared key configured on the device must be the same as the shared key configured on the RADIUS server.

Specifying an MPLS L3VPN instance for the scheme

The VPN instance specified for a RADIUS scheme applies to all authentication and accounting servers in that scheme. If a VPN instance is also configured for an individual RADIUS server, the VPN instance specified for the RADIUS scheme does not take effect on that server.

To specify a VPN instance for a scheme:

Step	Command	Remarks
1. Enter system view.	system-view	N/A
2. Enter RADIUS scheme view.	radius scheme radius-scheme-name	N/A
3. Specify a VPN instance for the RADIUS scheme.	vpn-instance vpn-instance-name	By default, a RADIUS scheme belongs to the public network.

Setting the username format and traffic statistics units

A username is in the userid@isp-name format, where the isp-name argument represents the user's ISP domain name. By default, the ISP domain name is included in a username. However, older RADIUS servers might not recognize usernames that contain the ISP domain names. In this case, you can configure the device to remove the domain name of each username to be sent.

If two or more ISP domains use the same RADIUS scheme, configure the RADIUS scheme to keep the ISP domain name in usernames for domain identification.

The device reports online user traffic statistics in accounting packets. The traffic measurement units are configurable, but they must be the same as the traffic measurement units configured on the RADIUS accounting servers.

To set the username format and the traffic statistics units for a RADIUS scheme:

Step	Command	Remarks
1. Enter system view.	system-view	N/A
2. Enter RADIUS scheme view.	radius scheme radius-scheme-name	N/A
3. Set the format for usernames sent to the RADIUS servers.	user-name-format { keep-original \| with-domain \| without-domain }	By default, the ISP domain name is included in a username.
4. (Optional.) Set the data flow and packet measurement units for traffic statistics.	data-flow-format { data { byte \| giga-byte \| kilo-byte \| mega-byte } \| packet { giga-packet \| kilo-packet \| mega-packet \| one-packet } } *	By default, traffic is counted in bytes and packets.

Setting the maximum number of RADIUS request transmission attempts

RADIUS uses UDP packets to transfer data. Because UDP communication is not reliable, RADIUS uses a retransmission mechanism to improve reliability. A RADIUS request is retransmitted if the NAS does not receive a server response for the request within the response timeout timer. For more information about the RADIUS server response timeout timer, see "Setting RADIUS timers."

You can set the maximum number for the NAS to retransmit a RADIUS request to the same server. When the maximum number is reached, the NAS tries to communicate with other RADIUS servers in active state. If no other servers are in active state at the time, the NAS considers the authentication or accounting attempt a failure.

To set the maximum number of RADIUS request transmission attempts:

Step	Command	Remarks
1. Enter system view.	system-view	N/A
2. Enter RADIUS scheme view.	radius scheme radius-scheme-name	N/A
3. Set the maximum number of RADIUS request transmission attempts.	retry retries	The default setting is 3.

Setting the status of RADIUS servers

To control the RADIUS servers with which the device communicates when the current servers are no longer available, set the status of RADIUS servers to blocked or active. You can specify one primary RADIUS server and multiple secondary RADIUS servers. The secondary servers function as the backup of the primary server. When the RADIUS server load sharing feature is disabled, the device chooses servers based on the following rules:

· When the primary server is in active state, the device communicates with the primary server.

· If the primary server fails, the device performs the following operations:

¡ Changes the server status to blocked.

¡ Starts a quiet timer for the server.

¡ Tries to communicate with a secondary server in active state that has the highest priority.

· If the secondary server is unreachable, the device performs the following operations:

¡ Changes the server status to blocked.

¡ Starts a quiet timer for the server.

¡ Tries to communicate with the next secondary server in active state that has the highest priority.

· The search process continues until the device finds an available secondary server or has checked all secondary servers in active state. If no server is available, the device considers the authentication or accounting attempt a failure.

· When the quiet timer of a server expires or you manually set the server to the active state, the status of the server changes back to active. The device does not check the server again during the authentication or accounting process.

· When you remove a server in use, communication with the server times out. The device looks for a server in active state by first checking the primary server, and then checking secondary servers in the order they are configured.

· When all servers are in blocked state, the device only tries to communicate with the primary server.

· When one or more servers are in active state, the device tries to communicate with these active servers only, even if the servers are unavailable.

· When a RADIUS server's status changes automatically, the device changes this server's status accordingly in all RADIUS schemes in which this server is specified.

· When a RADIUS server is manually set to blocked, server detection is disabled for the server, regardless of whether a test profile has been specified for the server. When the RADIUS server is set to active state, server detection is enabled for the server on which an existing test profile is specified.

By default, the device sets the status of all RADIUS servers to active. However, in some situations, you must change the status of a server. For example, if a server fails, you can change the status of the server to blocked to avoid communication attempts to the server.

In RADIUS server load sharing, once the device sends a start-accounting request to a server for a user, it forwards all subsequent accounting requests of the user to the same server. If the accounting server is unreachable, the device returns an accounting failure message rather than searching for another active accounting server.

To set the status of RADIUS servers:

Step	Command	Remarks
1. Enter system view.	system-view	N/A
2. Enter RADIUS scheme view.	radius scheme radius-scheme-name	N/A
3. Set the RADIUS server status.	· Set the status of the primary RADIUS authentication server: state primary authentication { active \| block } · Set the status of the primary RADIUS accounting server: state primary accounting { active \| block } · Set the status of a secondary RADIUS authentication server: state secondary authentication [ { host-name \| ipv4-address \| ipv6 ipv6-address } [ port-number \| vpn-instance vpn-instance-name ] * ] { active \| block } · Set the status of a secondary RADIUS accounting server: state secondary accounting [ { host-name \| ipv4-address \| ipv6 ipv6-address } [ port-number \| vpn-instance vpn-instance-name ] * ] { active \| block }	By default, a RADIUS server is in active state. The configured server status cannot be saved to any configuration file, and can only be viewed by using the display radius scheme command. After the device restarts, all servers are restored to the active state.

Enabling the RADIUS server load sharing feature

By default, the device communicates with RADIUS servers based on the server roles. It first attempts to communicate with the primary server, and, if the primary server is unavailable, it then searches for the secondary servers in the order they are configured. The first secondary server in active state is used for communication. In this process, the workload is always placed on the active server.

Use the RADIUS server load sharing feature to dynamically distribute the workload over multiple servers regardless of their server roles. The device forwards an AAA request to the most appropriate server of all active servers in the scheme after it compares the weight values and numbers of currently served users. Specify a weight value for each RADIUS server based on the AAA capacity of the server. A larger weight value indicates a higher AAA capacity.

To enable the RADIUS server load sharing feature:

Step	Command	Remarks
1. Enter system view.	system-view	N/A
2. Enter RADIUS scheme view.	radius scheme radius-scheme-name	N/A
3. Enable the RADIUS server load sharing feature.	server-load-sharing enable	By default, this feature is disabled.

Specifying the source IP address for outgoing RADIUS packets

The source IP address of RADIUS packets that a NAS sends must match the IP address of the NAS configured on the RADIUS server. A RADIUS server identifies a NAS by its IP address. Upon receiving a RADIUS packet, a RADIUS server checks whether the source IP address of the packet is the IP address of a managed NAS.

· If it is the IP address of a managed NAS, the server processes the packet.

· If it is not the IP address of a managed NAS, the server drops the packet.

The source address of outgoing RADIUS packets is typically the IP address of an egress interface on the NAS to communicate with the RADIUS server. However, in some situations, you must change the source IP address. For example, when VRRP is configured for stateful failover, configure the virtual IP of the uplink VRRP group as the source address.

You can specify a source IP address for outgoing RADIUS packets in RADIUS scheme view or in system view.

· The IP address specified in RADIUS scheme view applies only to one RADIUS scheme.

· The IP address specified in system view applies to all RADIUS schemes in which the RADIUS servers are in a VPN or the public network.

Before sending a RADIUS packet, the NAS selects a source IP address in the following order:

1. The source IP address specified for the RADIUS scheme.

2. The source IP address specified in system view for the VPN or public network, depending on where the RADIUS server resides.

3. The IP address of the outbound interface specified by the route.

To specify a source IP address for all RADIUS schemes in a VPN or the public network:

Step	Command	Remarks
1. Enter system view.	system-view	N/A
2. Specify a source IP address for outgoing RADIUS packets.	radius nas-ip { ipv4-address \| ipv6 ipv6-address } [ vpn-instance vpn-instance-name ]	By default, the primary IP address of the RADIUS packet outbound interface is used as the source IP address.

To specify a source IP address for a RADIUS scheme:

Step	Command	Remarks
1. Enter system view.	system-view	N/A
2. Enter RADIUS scheme view.	radius scheme radius-scheme-name	N/A
3. Specify a source IP address for outgoing RADIUS packets.	nas-ip { ipv4-address \| ipv6 ipv6-address }	By default, the source IP address specified by using the radius nas-ip command in system view is used. If the source IP address is not specified, the primary IP address of the outbound interface is used.

Setting RADIUS timers

The device uses the following types of timers to control communication with a RADIUS server:

· Server response timeout timer (response-timeout)—Defines the RADIUS request retransmission interval. The timer starts immediately after a RADIUS request is sent. If the device does not receive a response from the RADIUS server before the timer expires, it resends the request.

· Server quiet timer (quiet)—Defines the duration to keep an unreachable server in blocked state. If one server is not reachable, the device changes the server status to blocked, starts this timer for the server, and tries to communicate with another server in active state. After the server quiet timer expires, the device changes the status of the server back to active.

· Real-time accounting timer (realtime-accounting)—Defines the interval at which the device sends real-time accounting packets to the RADIUS accounting server for online users.

When you set RADIUS timers, follow these guidelines:

· Consider the number of secondary servers when you configure the maximum number of RADIUS packet transmission attempts and the RADIUS server response timeout timer. If the RADIUS scheme includes many secondary servers, the retransmission process might be too long and the client connection in the access module, such as Telnet, can time out.

· When the client connections have a short timeout period, a large number of secondary servers can cause the initial authentication or accounting attempt to fail. In this case, reconnect the client rather than adjusting the RADIUS packet transmission attempts and server response timeout timer. Typically, the next attempt will succeed, because the device has blocked the unreachable servers to shorten the time to find a reachable server.

· Make sure the server quiet timer is set correctly. A timer that is too short might result in frequent authentication or accounting failures. This is because the device will continue to attempt to communicate with an unreachable server that is in active state. A timer that is too long might temporarily block a reachable server that has recovered from a failure. This is because the server will remain in blocked state until the timer expires.

· A short real-time accounting interval helps improve accounting precision but requires many system resources. When there are 1000 or more users, set the interval to 15 minutes or longer.

To set RADIUS timers:

Step	Command	Remarks
1. Enter system view.	system-view	N/A
2. Enter RADIUS scheme view.	radius scheme radius-scheme-name	N/A
3. Set the RADIUS server response timeout timer.	timer response-timeout seconds	The default setting is 3 seconds.
4. Set the quiet timer for the servers.	timer quiet minutes	The default setting is 5 minutes.
5. Set the real-time accounting timer.	timer realtime-accounting interval [ second ]	The default setting is 12 minutes.

Enabling forcibly sending stop-accounting packets

Typically, if the device does not send a start-accounting packet to the RADIUS server for an authenticated user, it does not send a stop-accounting packet when the user goes offline. If the server has generated a user entry for the user without start-accounting packets, it does not release the user entry when the user goes offline. This feature forces the device to send stop-accounting packets to the RADIUS server when the user goes offline for timely releasing the user entry on the server.

To enable forcibly sending stop-accounting packets:

Step	Command	Remarks
1. Enter system view.	system-view	N/A
2. Enter RADIUS scheme view.	radius scheme radius-scheme-name	N/A
3. Enable the device to send stop-accounting packets when users for which no start-accounting packets are sent go offline.	stop-accounting-packet send-force	By default, forcibly sending stop-accounting packets is disabled. The device does not send stop-accounting packets when users for which no start-accounting packets are sent go offline.

Configuring the RADIUS accounting-on feature

When the accounting-on feature is enabled, the device automatically sends an accounting-on packet to the RADIUS server after the entire device reboots. Upon receiving the accounting-on packet, the RADIUS server logs out all online users so they can log in again through the device. Without this feature, users cannot log in again after the reboot, because the RADIUS server considers them to come online.

You can configure the interval for which the device waits to resend the accounting-on packet and the maximum number of retries.

The extended accounting-on feature enhances the accounting-on feature in a distributed architecture. For the extended accounting-on feature to take effect, the RADIUS server must run on IMC and the accounting-on feature must be enabled.

The extended accounting-on feature is applicable to LAN users. The user data is saved to the IRF member devices through which the users access the system. When the extended accounting-on feature is enabled, the system automatically sends an accounting-on packet to the RADIUS server after a member device reboots. The packet contains the member device identifier. Upon receiving the accounting-on packet, the RADIUS server logs out all online users that access the system through the member device. If no users have come online through the member device, the IRF fabric does not send an accounting-on packet after the member device reboots.

To configure the accounting-on feature for a RADIUS scheme:

Step	Command	Remarks
1. Enter system view.	system-view	N/A
2. Enter RADIUS scheme view.	radius scheme radius-scheme-name	N/A
3. Enable accounting-on.	accounting-on enable [ interval interval \| send send-times ] *	By default, the accounting-on feature is disabled.
4. (Optional.) Enable extended accounting-on.	accounting-on extended	By default, extended accounting-on is disabled.

Interpreting the RADIUS class attribute as CAR parameters

A RADIUS server may deliver CAR parameters for user-based traffic monitoring and control by using the RADIUS class attribute (attribute 25) in RADIUS packets. You can configure the device to interpret the class attribute to CAR parameters.

To configure the device to interpret the RADIUS class attribute as CAR parameters:

Step	Command	Remarks
1. Enter system view.	system-view	N/A
2. Enter RADIUS scheme view.	radius scheme radius-scheme-name	N/A
3. Interpret the RADIUS class attribute as CAR parameters.	attribute 25 car	By default, the RADIUS class attribute is not interpreted as CAR parameters.

Configuring the Login-Service attribute check method for SSH, FTP, and terminal users

The device supports the following check methods for the Login-Service attribute (RADIUS attribute 15) of SSH, FTP, and terminal users:

· Strict—Matches Login-Service attribute values 50, 51, and 52 for SSH, FTP, and terminal services, respectively.

· Loose—Matches the standard Login-Service attribute value 0 for SSH, FTP, and terminal services.

An Access-Accept packet received for a user must contain the matching attribute value. Otherwise, the user cannot log in to the device.

Use the loose check method only when the server does not issue Login-Service attribute values 50, 51, and 52 for SSH, FTP, and terminal users.

To configure the Login-Service attribute check method for SSH, FTP, and terminal users:

Step	Command	Remarks
1. Enter system view.	system-view	N/A
2. Enter RADIUS scheme view.	radius scheme radius-scheme-name	N/A
3. Configure the Login-Service attribute check method for SSH, FTP, and terminal users.	attribute 15 check-mode { loose \| strict }	The default check method is strict.

Configuring the MAC address format for RADIUS attribute 31

RADIUS servers of different types might have different requirements for the MAC address format in RADIUS attribute 31. Configure the MAC address format for RADIUS attribute 31 to meet the requirements of the RADIUS servers.

To configure the MAC address format for RADIUS attribute 31:

Step	Command	Remarks
1. Enter system view.	system-view	N/A
2. Enter RADIUS scheme view.	radius scheme radius-scheme-name	N/A
3. Configure the MAC address format for RADIUS attribute 31.	attribute 31 mac-format section { six \| three } separator separator-character { lowercase \| uppercase }	By default, a MAC address is in the format of HH-HH-HH-HH-HH-HH. The MAC address is separated by hyphen (-) into six sections with letters in upper case.

Setting the data measurement unit for the Remanent_Volume attribute

The RADIUS server uses Remanent_Volume attribute in authentication or real-time accounting responses to notify the device of the current amount of data available for online users.

Perform this task to set the data measurement unit for the Remanent_Volume attribute. Make sure the configured measurement unit is the same as the user data measurement unit on the RADIUS server.

To set the data measurement unit for the Remanent_Volume attribute:

Step	Command	Remarks
1. Enter system view.	system-view	N/A
2. Enter RADIUS scheme view.	radius scheme radius-scheme-name	N/A
3. Set the data measurement unit for the Remanent_Volume attribute.	attribute remanent-volume unit { byte \| giga-byte \| kilo-byte \| mega-byte }	By default, the data measurement unit is kilobyte.

Enabling SNMP notifications for RADIUS

When SNMP notifications are enabled for RADIUS, the SNMP agent supports the following notifications generated by RADIUS:

· RADIUS server unreachable notification—The RADIUS server cannot be reached. RADIUS generates this notification if it does not receive a response to an accounting or authentication request within the specified number of RADIUS request transmission attempts.

· RADIUS server reachable notification—The RADIUS server can be reached. RADIUS generates this notification for a previously blocked RADIUS server after the quiet timer expires.

· Excessive authentication failures notification—The number of authentication failures compared to the total number of authentication attempts exceeds the specified threshold.

For RADIUS SNMP notifications to be sent correctly, you must also configure SNMP on the device. For more information about SNMP configuration, see the network management and monitoring configuration guide for the device.

To enable SNMP notifications for RADIUS:

Step	Command	Remarks
1. Enter system view.	system-view	N/A
2. Enable SNMP notifications for RADIUS.	snmp-agent trap enable radius [ accounting-server-down \| accounting-server-up \| authentication-error-threshold \| authentication-server-down \| authentication-server-up ] *	By default, all SNMP notifications are disabled for RADIUS.

Displaying and maintaining RADIUS

Execute display commands in any view and reset commands in user view.

Task	Command
Display the RADIUS scheme configuration.	display radius scheme [ radius-scheme-name ]
Display RADIUS packet statistics.	display radius statistics
Display information about buffered RADIUS stop-accounting requests to which no responses have been received.	display stop-accounting-buffer { radius-scheme radius-scheme-name \| session-id session-id \| time-range start-time end-time \| user-name user-name }
Clear RADIUS statistics.	reset radius statistics
Clear the buffered RADIUS stop-accounting requests to which no responses have been received.	reset stop-accounting-buffer { radius-scheme radius-scheme-name \| session-id session-id \| time-range start-time end-time \| user-name user-name }

Configuring HWTACACS schemes

Configuration task list

Tasks at a glance
(Required.) Creating an HWTACACS scheme
(Required.) Specifying the HWTACACS authentication servers
(Optional.) Specifying the HWTACACS authorization servers
(Optional.) Specifying the HWTACACS accounting servers
(Required.) Specifying the shared keys for secure HWTACACS communication
(Optional.) Specifying an MPLS L3VPN instance for the scheme
(Optional.) Setting the username format and traffic statistics units
(Optional.) Specifying the source IP address for outgoing HWTACACS packets
(Optional.) Setting HWTACACS timers

Creating an HWTACACS scheme

Create an HWTACACS scheme before performing any other HWTACACS configurations. You can configure a maximum of 16 HWTACACS schemes. An HWTACACS scheme can be used by multiple ISP domains.

To create an HWTACACS scheme:

Step	Command	Remarks
1. Enter system view.	system-view	N/A
2. Create an HWTACACS scheme and enter HWTACACS scheme view.	hwtacacs scheme hwtacacs-scheme-name	By default, no HWTACACS schemes exist.

Specifying the HWTACACS authentication servers

You can specify one primary authentication server and a maximum of 16 secondary authentication servers for an HWTACACS scheme. When the primary server is not available, the device searches for the secondary servers in the order they are configured. The first secondary server in active state is used for communication.

If redundancy is not required, specify only the primary server. An HWTACACS server can function as the primary authentication server in one scheme and as the secondary authentication server in another scheme at the same time.

To specify HWTACACS authentication servers for an HWTACACS scheme:

Step	Command	Remarks
1. Enter system view.	system-view	N/A
2. Enter HWTACACS scheme view.	hwtacacs scheme hwtacacs-scheme-name	N/A
3. Specify HWTACACS authentication servers.	· Specify the primary HWTACACS authentication server: primary authentication { host-name \| ipv4-address \| ipv6 ipv6-address } [ port-number \| key { cipher \| simple } string \| single-connection \| vpn-instance vpn-instance-name ] * · Specify a secondary HWTACACS authentication server: secondary authentication { host-name \| ipv4-address \| ipv6 ipv6-address } [ port-number \| key { cipher \| simple } string \| single-connection \| vpn-instance vpn-instance-name ] *	By default, no authentication servers are specified. Two HWTACACS authentication servers in a scheme, primary or secondary, cannot have the same combination of host name, IP address, port number, and VPN instance.

Specifying the HWTACACS authorization servers

You can specify one primary authorization server and a maximum of 16 secondary authorization servers for an HWTACACS scheme. When the primary server is not available, the device searches for the secondary servers in the order they are configured. The first secondary server in active state is used for communication.

If redundancy is not required, specify only the primary server. An HWTACACS server can function as the primary authorization server of one scheme and as the secondary authorization server of another scheme at the same time.

To specify HWTACACS authorization servers for an HWTACACS scheme:

Step	Command	Remarks
1. Enter system view.	system-view	N/A
2. Enter HWTACACS scheme view.	hwtacacs scheme hwtacacs-scheme-name	N/A
3. Specify HWTACACS authorization servers.	· Specify the primary HWTACACS authorization server: primary authorization { host-name \| ipv4-address \| ipv6 ipv6-address } [ port-number \| key { cipher \| simple } string \| single-connection \| vpn-instance vpn-instance-name ] * · Specify a secondary HWTACACS authorization server: secondary authorization { host-name \| ipv4-address \| ipv6 ipv6-address } [ port-number \| key { cipher \| simple } string \| single-connection \| vpn-instance vpn-instance-name ] *	By default, no authorization servers are specified. Two HWTACACS authorization servers in a scheme, primary or secondary, cannot have the same combination of host name, IP address, port number, and VPN instance.

Specifying the HWTACACS accounting servers

You can specify one primary accounting server and a maximum of 16 secondary accounting servers for an HWTACACS scheme. When the primary server is not available, the device searches for the secondary servers in the order they are configured. The first secondary server in active state is used for communication.

If redundancy is not required, specify only the primary server. An HWTACACS server can function as the primary accounting server of one scheme and as the secondary accounting server of another scheme at the same time.

The device sends HWTACACS stop-accounting requests when it receives connection teardown requests from hosts or connection teardown commands from an administrator. However, the device might fail to receive a response for a stop-accounting request in a single transmission. Enable the device to buffer HWTACACS stop-accounting requests that have not received responses from the accounting server. The device will resend the requests until responses are received.

To limit the transmission times, set a maximum number of attempts that can be made for transmitting individual HWTACACS stop-accounting requests. When the maximum attempts are made for a request, the device discards the buffered request.

HWTACACS does not support accounting for FTP, SFTP, and SCP users.

To specify HWTACACS accounting servers for an HWTACACS scheme:

Step	Command	Remarks
1. Enter system view.	system-view	N/A
2. Enter HWTACACS scheme view.	hwtacacs scheme hwtacacs-scheme-name	N/A
3. Specify HWTACACS accounting servers.	· Specify the primary HWTACACS accounting server: primary accounting { host-name \| ipv4-address \| ipv6 ipv6-address } [ port-number \| key { cipher \| simple } string \| single-connection \| vpn-instance vpn-instance-name ] * · Specify a secondary HWTACACS accounting server: secondary accounting { host-name \| ipv4-address \| ipv6 ipv6-address } [ port-number \| key { cipher \| simple } string \| single-connection \| vpn-instance vpn-instance-name ] *	By default, no accounting servers are specified. Two HWTACACS accounting servers in a scheme, primary or secondary, cannot have the same combination of host name, IP address, port number, and VPN instance.
4. (Optional.) Enable buffering of HWTACACS stop-accounting requests to which no responses have been received.	stop-accounting-buffer enable	By default, the buffering feature is enabled.
5. (Optional.) Set the maximum number of transmission attempts for individual HWTACACS stop-accounting requests.	retry stop-accounting retries	The default setting is 100.

Specifying the shared keys for secure HWTACACS communication

The HWTACACS client and server use the MD5 algorithm and shared keys to generate the Authenticator value for packet authentication and user password encryption. The client and server must use the same key for each type of communication.

Perform this task to configure shared keys for servers in an HWTACACS scheme. The keys take effect on all servers for which a shared key is not individually configured.

To specify a shared key for secure HWTACACS communication:

Step	Command	Remarks
1. Enter system view.	system-view	N/A
2. Enter HWTACACS scheme view.	hwtacacs scheme hwtacacs-scheme-name	N/A
3. Specify a shared key for secure HWTACACS authentication, authorization, or accounting communication.	key { accounting \| authentication \| authorization } { cipher \| simple } string	By default, no shared key is specified for secure HWTACACS communication. The shared key configured on the device must be the same as the shared key configured on the HWTACACS server.

Specifying an MPLS L3VPN instance for the scheme

The VPN instance specified for an HWTACACS scheme applies to all servers in that scheme. If a VPN instance is also configured for an individual HWTACACS server, the VPN instance specified for the HWTACACS scheme does not take effect on that server.

To specify a VPN instance for an HWTACACS scheme:

Step	Command	Remarks
1. Enter system view.	system-view	N/A
2. Enter HWTACACS scheme view.	hwtacacs scheme hwtacacs-scheme-name	N/A
3. Specify a VPN instance for the HWTACACS scheme.	vpn-instance vpn-instance-name	By default, an HWTACACS scheme belongs to the public network.

Setting the username format and traffic statistics units

A username is typically in the userid@isp-name format, where the isp-name argument represents the user's ISP domain name. By default, the ISP domain name is included in a username. If HWTACACS servers do not recognize usernames that contain ISP domain names, you can configure the device to send usernames without domain names to the servers.

If two or more ISP domains use the same HWTACACS scheme, configure the HWTACACS scheme to keep the ISP domain name in usernames for domain identification.

To set the username format and traffic statistics units for an HWTACACS scheme:

Step	Command	Remarks
1. Enter system view.	system-view	N/A
2. Enter HWTACACS scheme view.	hwtacacs scheme hwtacacs-scheme-name	N/A
3. Set the format of usernames sent to the HWTACACS servers.	user-name-format { keep-original \| with-domain \| without-domain }	By default, the ISP domain name is included in a username.
4. (Optional.) Set the data flow and packet measurement units for traffic statistics.	data-flow-format { data { byte \| giga-byte \| kilo-byte \| mega-byte } \| packet { giga-packet \| kilo-packet \| mega-packet \| one-packet } } *	By default, traffic is counted in bytes and packets.

Specifying the source IP address for outgoing HWTACACS packets

The source IP address of HWTACACS packets that a NAS sends must match the IP address of the NAS configured on the HWTACACS server. An HWTACACS server identifies a NAS by IP address. When the HWTACACS server receives a packet, it checks whether the source IP address of the packet is the IP address of a managed NAS.

· If it is the IP address of a managed NAS, the server processes the packet.

· If it is not the IP address of a managed NAS, the server drops the packet.

To communicate with the HWTACACS server, the source address of outgoing HWTACACS packets is typically the IP address of an egress interface on the NAS. However, in some situations, you must change the source IP address. For example, when VRRP is configured for stateful failover, configure the virtual IP of the uplink VRRP group as the source address.

You can specify the source IP address for outgoing HWTACACS packets in HWTACACS scheme view or in system view.

· The IP address specified in HWTACACS scheme view applies to one HWTACACS scheme.

· The IP address specified in system view applies to all HWTACACS schemes in which the HWTACACS servers are in a VPN or the public network.

Before sending an HWTACACS packet, the NAS selects a source IP address in the following order:

1. The source IP address specified for the HWTACACS scheme.

2. The source IP address specified in system view for the VPN or public network, depending on where the HWTACACS server resides.

3. The IP address of the outbound interface specified by the route.

To specify a source IP address for all HWTACACS schemes of a VPN or the public network:

Step	Command	Remarks
1. Enter system view.	system-view	N/A
2. Specify a source IP address for outgoing HWTACACS packets.	hwtacacs nas-ip { ipv4-address \| ipv6 ipv6-address } [ vpn-instance vpn-instance-name ]	By default, the primary IP address of the HWTACACS packet outbound interface is used as the source IP address.

To specify a source IP address for an HWTACACS scheme:

Step	Command	Remarks
1. Enter system view.	system-view	N/A
2. Enter HWTACACS scheme view.	hwtacacs scheme hwtacacs-scheme-name	N/A
3. Specify the source IP address of outgoing HWTACACS packets.	nas-ip { ipv4-address \| ipv6 ipv6-address }	By default, the source IP address specified by using the hwtacacs nas-ip command in system view is used. If the source IP address is not specified, the primary IP address of the outbound interface is used.

Setting HWTACACS timers

The device uses the following timers to control communication with an HWTACACS server:

· Server response timeout timer (response-timeout)—Defines the HWTACACS server response timeout timer. The device starts this timer immediately after an HWTACACS authentication, authorization, or accounting request is sent. If the device does not receive a response from the server within the timer, it sets the server to blocked. Then, the device sends the request to another HWTACACS server.

· Real-time accounting timer (realtime-accounting)—Defines the interval at which the device sends real-time accounting packets to the HWTACACS accounting server for online users.

· Server quiet timer (quiet)—Defines the duration to keep an unreachable server in blocked state. If a server is not reachable, the device changes the server status to blocked, starts this timer for the server, and tries to communicate with another server in active state. After the server quiet timer expires, the device changes the status of the server back to active.

The server quiet timer setting affects the status of HWTACACS servers. If the scheme includes one primary HWTACACS server and multiple secondary HWTACACS servers, the device communicates with the HWTACACS servers based on the following rules:

· When the primary server is in active state, the device communicates with the primary server.

· If the primary server fails, the device performs the following operations:

¡ Changes the server status to blocked.

¡ Starts a quiet timer for the server.

¡ Tries to communicate with a secondary server in active state that has the highest priority.

· If the secondary server is unreachable, the device performs the following operations:

¡ Changes the server status to blocked.

¡ Starts a quiet timer for the server.

¡ Tries to communicate with the next secondary server in active state that has the highest priority.

· When the quiet timer of a server expires, the status of the server changes back to active. The device does not check the server again during the authentication, authorization, or accounting process.

· When all servers are in blocked state, the device only tries to communicate with the primary server.

· When one or more servers are in active state, the device tries to communicate with these servers only, even if they are unavailable.

· When an HWTACACS server's status changes automatically, the device changes this server's status accordingly in all HWTACACS schemes in which this server is specified.

To set HWTACACS timers:

Step	Command	Remarks
1. Enter system view.	system-view	N/A
2. Enter HWTACACS scheme view.	hwtacacs scheme hwtacacs-scheme-name	N/A
3. Set the HWTACACS server response timeout timer.	timer response-timeout seconds	By default, the HWTACACS server response timeout timer is 5 seconds.
4. Set the real-time accounting interval.	timer realtime-accounting minutes	By default, the real-time accounting interval is 12 minutes. A short interval helps improve accounting precision but requires many system resources. When there are 1000 or more users, set a longer interval.
5. Set the server quiet timer.	timer quiet minutes	By default, the server quiet timer is 5 minutes.

Displaying and maintaining HWTACACS

Execute display commands in any view and reset commands in user view.

Task	Command
Display the configuration or server statistics of HWTACACS schemes.	display hwtacacs scheme [ hwtacacs-scheme-name [ statistics ] ]
Display information about buffered HWTACACS stop-accounting requests to which no responses have been received.	display stop-accounting-buffer hwtacacs-scheme hwtacacs-scheme-name
Clear HWTACACS statistics.	reset hwtacacs statistics { accounting \| all \| authentication \| authorization }
Clear the buffered HWTACACS stop-accounting requests to which no responses have been received.	reset stop-accounting-buffer hwtacacs-scheme hwtacacs-scheme-name

Configuring LDAP schemes

Configuration task list

Tasks at a glance
Configuring an LDAP server: · (Required.) Creating an LDAP server · (Required.) Configuring the IP address of the LDAP server · (Optional.) Specifying the LDAP version · (Optional.) Setting the LDAP server timeout period · (Required.) Configuring administrator attributes · (Required.) Configuring LDAP user attributes
(Optional.) Configuring an LDAP attribute map
(Required.) Creating an LDAP scheme
(Required.) Specifying the LDAP authentication server
(Optional.) Specifying the LDAP authorization server
(Optional.) Specifying an LDAP attribute map for LDAP authorization

Creating an LDAP server

Step	Command	Remarks
1. Enter system view.	system-view	N/A
2. Create an LDAP server and enter LDAP server view.	ldap server server-name	By default, no LDAP servers exist.

Configuring the IP address of the LDAP server

Step	Command	Remarks
1. Enter system view.	system-view	N/A
2. Enter LDAP server view.	ldap server server-name	N/A
3. Configure the IP address of the LDAP server.	{ ip ip-address \| ipv6 ipv6-address } [ port port-number ] [ vpn-instance vpn-instance-name ]	By default, an LDAP server does not have an IP address. You can configure either an IPv4 address or an IPv6 address for an LDAP server. The most recent configuration takes effect.

Specifying the LDAP version

Specify the LDAP version on the NAS. The device supports LDAPv2 and LDAPv3. The LDAP version specified on the device must be consistent with the version specified on the LDAP server.

To specify the LDAP version:

Step	Command	Remarks
1. Enter system view.	system-view	N/A
2. Enter LDAP server view.	ldap server server-name	N/A
3. Specify the LDAP version.	protocol-version { v2 \| v3 }	By default, LDAPv3 is used. A Microsoft LDAP server supports only LDAPv3.

Setting the LDAP server timeout period

If the device sends a bind or search request to an LDAP server without receiving the server's response within the server timeout period, the authentication or authorization request times out. Then, the device tries the backup authentication or authorization method. If no backup method is configured in the ISP domain, the device considers the authentication or authorization attempt a failure.

To set the LDAP server timeout period:

Step	Command	Remarks
1. Enter system view.	system-view	N/A
2. Enter LDAP server view.	ldap server server-name	N/A
3. Set the LDAP server timeout period.	server-timeout time-interval	By default, the LDAP server timeout period is 10 seconds.

Configuring administrator attributes

To configure the administrator DN and password for binding with the LDAP server during LDAP authentication:

Step	Command	Remarks
1. Enter system view.	system-view	N/A
2. Enter LDAP server view.	ldap server server-name	N/A
3. Specify the administrator DN.	login-dn dn-string	By default, no administrator DN is specified. The administrator DN specified on the device must be the same as the administrator DN configured on the LDAP server.
4. Configure the administrator password.	login-password { cipher \| simple } string	By default, no administrator password is specified.

Configuring LDAP user attributes

To authenticate a user, an LDAP client must complete the following operations:

1. Establish a connection to the LDAP server.

2. Obtain the user DN from the LDAP server.

3. Use the user DN and the user's password to bind with the LDAP server.

LDAP provides a DN search mechanism for obtaining the user DN. According to the mechanism, an LDAP client sends search requests to the server based on the search policy determined by the LDAP user attributes of the LDAP client.

The LDAP user attributes include:

· Search base DN.

· Search scope.

· Username attribute.

· Username format.

· User object class.

If the LDAP server contains many directory levels, a user DN search starting from the root directory can take a long time. To improve efficiency, you can change the start point by specifying the search base DN.

To configure LDAP user attributes:

Step	Command	Remarks
1. Enter system view.	system-view	N/A
2. Enter LDAP server view.	ldap server server-name	N/A
3. Specify the user search base DN.	search-base-dn base-dn	By default, no user search base DN is specified.
4. (Optional.) Specify the user search scope.	search-scope { all-level \| single-level }	By default, the user search scope is all-level.
5. (Optional.) Specify the username attribute.	user-parameters user-name-attribute { name-attribute \| cn \| uid }	By default, the username attribute is cn.
6. (Optional.) Specify the username format.	user-parameters user-name-format { with-domain \| without-domain }	By default, the username format is without-domain.
7. (Optional.) Specify the user object class.	user-parameters user-object-class object-class-name	By default, no user object class is specified, and the default user object class on the LDAP server is used. The default user object class for this command varies by LDAP server model.

Configuring an LDAP attribute map

Configure an LDAP attribute map to define a list of LDAP-AAA attribute mapping entries. To apply the LDAP attribute map, specify the name of the LDAP attribute map in the LDAP scheme used for authorization.

The LDAP attribute map feature enables the device to convert LDAP attributes obtained from an LDAP authorization server to device-recognizable AAA attributes based on the mapping entries. Because the device ignores unrecognized LDAP attributes, configure the mapping entries to include important LDAP attributes that should not be ignored.

An LDAP attribute can be mapped only to one AAA attribute. Different LDAP attributes can be mapped to the same AAA attribute.

To configure an LDAP attribute map:

Step	Command	Remarks
1. Enter system view.	system-view	N/A
2. Create an LDAP attribute map and enter LDAP attribute map view.	ldap attribute-map map-name	By default, no LDAP attribute maps exist.
3. Configure a mapping entry.	map ldap-attribute ldap-attribute-name [ prefix prefix-value delimiter delimiter-value ] aaa-attribute { user-group \| user-profile }	By default, an LDAP attribute map does not have any mapping entries. Repeat this command to configure multiple mapping entries.

Creating an LDAP scheme

You can configure a maximum of 16 LDAP schemes. An LDAP scheme can be used by multiple ISP domains.

To create an LDAP scheme:

Step	Command	Remarks
1. Enter system view.	system-view	N/A
2. Create an LDAP scheme and enter LDAP scheme view.	ldap scheme ldap-scheme-name	By default, no LDAP schemes exist.

Specifying the LDAP authentication server

Step	Command	Remarks
1. Enter system view.	system-view	N/A
2. Enter LDAP scheme view.	ldap scheme ldap-scheme-name	N/A
3. Specify the LDAP authentication server.	authentication-server server-name	By default, no LDAP authentication server is specified.

Specifying the LDAP authorization server

Step	Command	Remarks
1. Enter system view.	system-view	N/A
2. Enter LDAP scheme view.	ldap scheme ldap-scheme-name	N/A
3. Specify the LDAP authorization server.	authorization-server server-name	By default, no LDAP authorization server is specified.

Specifying an LDAP attribute map for LDAP authorization

Specify an LDAP attribute map for LDAP authorization to convert LDAP attributes obtained from the LDAP authorization server to device-recognizable AAA attributes.

You can specify only one LDAP attribute map in an LDAP scheme.

To specify an LDAP attribute map for LDAP authorization:

Step	Command	Remarks
1. Enter system view.	system-view	N/A
2. Enter LDAP scheme view.	ldap scheme ldap-scheme-name	N/A
3. Specify an LDAP attribute map.	attribute-map map-name	By default, no LDAP attribute map is specified.

Displaying and maintaining LDAP

Execute display commands in any view.

Task	Command
Display the configuration of LDAP schemes.	display ldap scheme [ ldap-scheme-name ]

Configuring AAA methods for ISP domains

You configure AAA methods for an ISP domain by specifying configured AAA schemes in ISP domain view. Each ISP domain has a set of system-defined AAA methods, which are local authentication, local authorization, and local accounting. If you do not configure any AAA methods for an ISP domain, the device uses the system-defined AAA methods for users in the domain.

AAA is available to login users after you enable scheme authentication for the users. For more information about the login authentication modes, see Fundamentals Configuration Guide.

Configuration prerequisites

To use local authentication for users in an ISP domain, configure local user accounts on the device first. See "Configuring local user attributes."

To use remote authentication, authorization, and accounting, create the required RADIUS, HWTACACS, or LDAP schemes. For more information about the scheme configuration, see "Configuring RADIUS schemes," "Configuring HWTACACS schemes," and "Configuring LDAP schemes."

Creating an ISP domain

In a networking scenario with multiple ISPs, the device can connect to users of different ISPs. These users can have different user attributes, such as different username and password structures, different service types, and different rights. To manage users of different ISPs, configure AAA methods and domain attributes for each ISP domain as needed.

The device supports a maximum of 16 ISP domains, including the system-defined ISP domain system. You can specify one of the ISP domains as the default domain.

On the device, each user belongs to an ISP domain. If a user does not provide an ISP domain name at login, the device considers the user belongs to the default ISP domain.

The device chooses an authentication domain for each user in the following order:

1. The authentication domain specified for the access module.

2. The ISP domain in the username.

3. The default ISP domain of the device.

If the chosen domain does not exist on the device, the device searches for the ISP domain that accommodates users assigned to nonexistent domains. If no such ISP domain is configured, user authentication fails.

NOTE:

Support for the authentication domain configuration depends on the access module.

When you configure an ISP domain, follow these restrictions and guidelines:

· An ISP domain cannot be deleted when it is the default ISP domain. Before you use the undo domain command, change the domain to a non-default ISP domain by using the undo domain default enable command.

· You can modify the settings of the system-defined ISP domain system, but you cannot delete the domain.

· To avoid RADIUS authentication, authorization, or accounting failures, use short domain names to ensure that usernames containing a domain name do not exceed 253 characters.

· To avoid RADIUS accounting failures, make sure the domain name contained in usernames sent to the RADIUS server does not exceed 247 characters.

To create an ISP domain:

Step	Command	Remarks
1. Enter system view.	system-view	N/A
2. Create an ISP domain and enter ISP domain view.	domain isp-name	By default, a system-defined ISP domain exists. The domain name is system.
3. Return to system view.	quit	N/A
4. (Optional.) Specify the default ISP domain.	domain default enable isp-name	By default, the default ISP domain is the system-defined ISP domain system.
5. (Optional.) Specify the ISP domain to accommodate users that are assigned to nonexistent domains.	domain if-unknown isp-domain-name	By default, no ISP domain is specified to accommodate users that are assigned to nonexistent domains.

Configuring ISP domain attributes

In an ISP domain, you can configure the following attributes:

· Domain status—By placing the ISP domain in active or blocked state, you allow or deny network service requests from users in the domain.

· Authorization attributes—The device assigns the authorization attributes in the ISP domain to the authenticated users that do not receive these attributes from the server. The device supports the following authorization attributes:

¡ Authorization ACL—The device restricts authenticated users to access only the network resources permitted by the ACL. For portal users, the authorization ACL can be configured in a preauthentication domain to authorize access to network resources before users pass authentication.

¡ Authorization CAR action—The attribute controls the traffic flow of authenticated users. For portal users, the authorization CAR action can be configured in a preauthentication domain to control traffic flow before users pass authentication.

¡ IPv4 address pool—The device assigns IPv4 addresses from the pool to authenticated users in the domain.

¡ Default authorization user profile—When a user passes authentication, it typically obtains an authorization user profile from the local or remote server. If the user does not obtain any user profile, the device authorizes the default user profile of the ISP domain to the user. The device will restrict the user's behavior based on the profile. For portal users, the authorization user profile can be configured in a preauthentication domain to restrict user behaviors before users pass authentication.

¡ IPv6 address pool—The device assigns IPv6 addresses from the pool to authenticated users in the domain.

¡ Redirect URL—The device redirects users in the domain to the URL after they pass authentication.

¡ Authorization user group—Authenticated users in the domain obtain all attributes of the user group.

¡ Maximum number of multicast groups—The attribute restricts the maximum number of multicast groups that an authenticated user can join concurrently.

· User online duration including idle timeout period—If a user goes offline due to connection failure or malfunction, the user's online duration sent to the server includes the idle timeout period. The online duration that is generated on the server is longer than the actual online duration of the user.

Typically, the idle timeout period is authorized by the authorization server after users pass authentication. However, the authorization idle timeout period is not supported by portal users. For portal users, the user's online duration sent to the server includes the idle timeout period set for the online portal user detection feature. For more information about online detection for portal users, see "Configuring portal authentication."

To configure ISP domain attributes:

Step	Command	Remarks
1. Enter system view.	system-view	N/A
2. Enter ISP domain view.	domain isp-name	N/A
3. Place the ISP domain in active or blocked state.	state { active \| block }	By default, an ISP domain is in active state, and users in the domain can request network services.
4. Configure authorization attributes for authenticated users in the ISP domain.	authorization-attribute { acl acl-number \| car inbound cir committed-information-rate [ pir peak-information-rate ] outbound cir committed-information-rate [ pir peak-information-rate ] \| igmp max-access-number max-access-number \| ip-pool pool-name \| ipv6-pool ipv6-pool-name \| mld max-access-number max-access-number \| url url-string \| user-group user-group-name \| user-profile profile-name }	The default settings are as follows: · An IPv4 user can concurrently join a maximum of four IGMP multicast groups. · An IPv6 user can concurrently join a maximum of four MLD multicast groups. · No other authorization attributes exist.
5. Configure the device to include the idle timeout period in the user online duration to be sent to the server.	session-time include-idle-time	By default, the user online duration sent to the server excludes the idle timeout period.

Configuring authentication methods for an ISP domain

Configuration prerequisites

Before configuring authentication methods, complete the following tasks:

1. Determine the access type or service type to be configured. With AAA, you can configure an authentication method for each access type and service type.

2. Determine whether to configure the default authentication method for all access types or service types. The default authentication method applies to all access users. However, the method has a lower priority than the authentication method that is specified for an access type or service type.

Configuration guidelines

When configuring authentication methods, follow these guidelines:

· To improve high availability, you can specify one primary authentication method and multiple backup authentication methods. When the primary method is invalid, the device attempts to use the backup methods in sequence.

For example, the radius-scheme radius-scheme-name local none options specify a primary RADIUS authentication method and two backup methods (local authentication and no authentication). The device performs RADIUS authentication preferentially and performs local authentication when the RADIUS server is invalid. The device does not perform authentication when both of the previous methods are invalid.

· If the authentication method uses a RADIUS scheme and the authorization method does not use a RADIUS scheme, AAA accepts only the authentication result from the RADIUS server. The Access-Accept message from the RADIUS server also includes the authorization information, but the device ignores the information.

· If an HWTACACS scheme is specified, the device uses the entered username for role authentication. If a RADIUS scheme is specified, the device uses the username $enabn$ on the RADIUS server for role authentication. The variable n represents a user role level. For more information about user role authentication, see Fundamentals Configuration Guide.

Configuration procedure

To configure authentication methods for an ISP domain:

Step	Command	Remarks
1. Enter system view.	system-view	N/A
2. Enter ISP domain view.	domain isp-name	N/A
3. Specify default authentication methods for all types of users.	authentication default { hwtacacs-scheme hwtacacs-scheme-name [ radius-scheme radius-scheme-name ] [ local ] [ none ] \| ldap-scheme ldap-scheme-name [ local ] [ none ] \| local [ none ] \| none \| radius-scheme radius-scheme-name [ hwtacacs-scheme hwtacacs-scheme-name ] [ local ] [ none ] }	By default, the default authentication method is local. The none keyword is not supported in FIPS mode.
4. Specify authentication methods for LAN users.	authentication lan-access { ldap-scheme ldap-scheme-name [ local ] [ none ] \| local [ none ] \| none \| radius-scheme radius-scheme-name [ local ] [ none ] }	By default, the default authentication methods are used for LAN users. The none keyword is not supported in FIPS mode.
5. Specify authentication methods for login users.	authentication login { hwtacacs-scheme hwtacacs-scheme-name [ radius-scheme radius-scheme-name ] [ local ] [ none ] \| ldap-scheme ldap-scheme-name [ local ] [ none ] \| local [ none ] \| none \| radius-scheme radius-scheme-name [ hwtacacs-scheme hwtacacs-scheme-name ] [ local ] [ none ] }	By default, the default authentication methods are used for login users. The none keyword is not supported in FIPS mode.
6. Specify authentication methods for portal users.	authentication portal { ldap-scheme ldap-scheme-name [ local ] [ none ] \| local [ none ] \| none \| radius-scheme radius-scheme-name [ local ] [ none ] }	By default, the default authentication methods are used for portal users. The none keyword is not supported in FIPS mode.
7. Specify authentication methods for obtaining a temporary user role.	authentication super { hwtacacs-scheme hwtacacs-scheme-name \| radius-scheme radius-scheme-name } *	By default, the default authentication methods are used for obtaining a temporary user role.

Configuring authorization methods for an ISP domain

Configuration prerequisites

Before configuring authorization methods, complete the following tasks:

1. Determine the access type or service type to be configured. With AAA, you can configure an authorization scheme for each access type and service type.

2. Determine whether to configure the default authorization method for all access types or service types. The default authorization method applies to all access users. However, the method has a lower priority than the authorization method that is specified for an access type or service type.

Configuration guidelines

When configuring authorization methods, follow these guidelines:

· To improve high availability, you can specify one primary authorization method and multiple backup authorization methods. When the primary method is invalid, the device attempts to use the backup methods in sequence. For example, the radius-scheme radius-scheme-name local none options specify a primary RADIUS authorization method and two backup methods (local authorization and no authorization ). The device performs RADIUS authorization preferentially and performs local authorization when the RADIUS server is invalid. The device does not perform authorization when both of the previous methods are invalid.

· The device supports HWTACACS authorization but not LDAP authorization.

· To use a RADIUS scheme as the authorization method, specify the name of the RADIUS scheme that is configured as the authentication method for the ISP domain. If an invalid RADIUS scheme is specified as the authorization method, RADIUS authentication and authorization fail.

Configuration procedure

To configure authorization methods for an ISP domain:

Step	Command	Remarks
1. Enter system view.	system-view	N/A
2. Enter ISP domain view.	domain isp-name	N/A
3. Specify default authorization methods for all types of users.	authorization default { hwtacacs-scheme hwtacacs-scheme-name [ radius-scheme radius-scheme-name ] [ local ] [ none ] \| local [ none ] \| none \| radius-scheme radius-scheme-name [ hwtacacs-scheme hwtacacs-scheme-name ] [ local ] [ none ] }	By default, the authorization method is local. The none keyword is not supported in FIPS mode.
4. Specify command authorization methods.	authorization command { hwtacacs-scheme hwtacacs-scheme-name [ local ] [ none ] \| local [ none ] \| none }	By default, the default authorization methods are used for command authorization. The none keyword is not supported in FIPS mode.
5. Specify authorization methods for LAN users.	authorization lan-access { local [ none ] \| none \| radius-scheme radius-scheme-name [ local ] [ none ] }	By default, the default authorization methods are used for LAN users. The none keyword is not supported in FIPS mode.
6. Specify authorization methods for login users.	authorization login { hwtacacs-scheme hwtacacs-scheme-name [ radius-scheme radius-scheme-name ] [ local ] [ none ] \| local [ none ] \| none \| radius-scheme radius-scheme-name [ hwtacacs-scheme hwtacacs-scheme-name ] [ local ] [ none ] }	By default, the default authorization methods are used for login users. The none keyword is not supported in FIPS mode.
7. Specify authorization methods for portal users.	authorization portal { local [ none ] \| none \| radius-scheme radius-scheme-name [ local ] [ none ] }	By default, the default authorization methods are used for portal users. The none keyword is not supported in FIPS mode.

Configuring accounting methods for an ISP domain

Configuration prerequisites

Before configuring accounting methods, complete the following tasks:

1. Determine the access type or service type to be configured. With AAA, you can configure an accounting method for each access type and service type.

2. Determine whether to configure the default accounting method for all access types or service types. The default accounting method applies to all access users. However, the method has a lower priority than the accounting method that is specified for an access type or service type.

Configuration guidelines

When configuring accounting methods, follow these guidelines:

· To improve high availability, you can specify one primary accounting method and multiple backup accounting methods. When the primary method is invalid, the device attempts to use the backup methods in sequence. For example, the radius-scheme radius-scheme-name local none options specify a primary RADIUS accounting method and two backup methods (local accounting and no accounting). The device performs RADIUS accounting preferentially and performs local accounting when the RADIUS server is invalid. The device does not perform accounting when both of the previous methods are invalid.

· FTP, SFTP, and SCP users do not support accounting.

· Local accounting does not provide statistics for charging. It only counts and controls the number of concurrent users that use the same local user account. The threshold is configured by using the access-limit command.

Configuration procedure

To configure accounting methods for an ISP domain:

Step	Command	Remarks
1. Enter system view.	system-view	N/A
2. Enter ISP domain view.	domain isp-name	N/A
3. Specify default accounting methods for all types of users.	accounting default { hwtacacs-scheme hwtacacs-scheme-name [ radius-scheme radius-scheme-name ] [ local ] [ none ] \| local [ none ] \| none \| radius-scheme radius-scheme-name [ hwtacacs-scheme hwtacacs-scheme-name ] [ local ] [ none ] }	By default, the accounting method is local. The none keyword is not supported in FIPS mode.
4. Specify the command accounting method.	accounting command hwtacacs-scheme hwtacacs-scheme-name	By default, the default accounting methods are used for command accounting.
5. Specify accounting methods for LAN users.	accounting lan-access { broadcast radius-scheme radius-scheme-name1 radius-scheme radius-scheme-name2 [ local ] [ none ] \| local [ none ] \| none \| radius-scheme radius-scheme-name [ local ] [ none ] }	By default, the default accounting methods are used for LAN users. The none keyword is not supported in FIPS mode.
6. Specify accounting methods for login users.	accounting login { hwtacacs-scheme hwtacacs-scheme-name [ radius-scheme radius-scheme-name ] [ local ] [ none ] \| local [ none ] \| none \| radius-scheme radius-scheme-name [ hwtacacs-scheme hwtacacs-scheme-name ] [ local ] [ none ] }	By default, the default accounting methods are used for login users. The none keyword is not supported in FIPS mode.
7. Specify accounting methods for portal users.	accounting portal { broadcast radius-scheme radius-scheme-name1 radius-scheme radius-scheme-name2 [ local ] [ none ] \| local [ none ] \| none \| radius-scheme radius-scheme-name [ local ] [ none ] }	By default, the default accounting methods are used for portal users. The none keyword is not supported in FIPS mode.
8. Configure access control for users that encounter accounting-start failures.	accounting start-fail { offline \| online }	By default, the device allows users that encounter accounting-start failures to stay online.
9. Configure access control for users that have failed all their accounting-update attempts.	accounting update-fail { [ max-times max-times ] offline \| online }	By default, the device allows users that have failed all their accounting-update attempts to stay online.
10. Configure access control for users that have used up their data or time accounting quotas.	accounting quota-out { offline \| online }	By default, the device logs off users that have used up their accounting quotas.
11. Specify the accounting method for dual-stack users.	accounting dual-stack { merge \| separate }	By default, the merge method is used.

Configuring the RADIUS session-control feature

The RADIUS session-control feature can only work with the RADIUS server running on IMC. Enable this feature for the RADIUS server to dynamically change the user authorization information (such as authorization ACL, VLAN, user group, VSI, and blackhole MAC address) or forcibly disconnect users by using session-control packets. This task enables the device to receive RADIUS session-control packets on UDP port 1812.

To verify the session-control packets sent from a RADIUS server, specify the RADIUS server as a session-control client to the device. The IP, VPN instance, and shared key settings of the session-control client must be the same as the corresponding settings of the RADIUS server.

You can specify multiple session-control clients on the device.

The device matches a session-control packet to a session-control client based on IP and VPN instance settings, and then uses the shared key of the matched client to validate the packet.

The device searches the session-control client settings prior to searching all RADIUS settings for a server with matching IP and VPN instance settings. This process narrows the search scope for finding the matched RADIUS server.

The session-control client configuration takes effect only when the session-control feature is enabled.

To configure the RADIUS session-control feature:

Step	Command	Remarks
1. Enter system view.	system-view	N/A
2. Enable the RADIUS session-control feature.	radius session-control enable	By default, the RADIUS session-control feature is disabled.
3. Specify a RADIUS session-control client.	radius session-control client { ip ipv4-address \| ipv6 ipv6-address } [ key { cipher \| simple } string \| vpn-instance vpn-instance-name ] *	By default, no RADIUS session-control clients are specified. The device searches all RADIUS scheme settings to verify session-control packets.

Configuring the RADIUS DAS feature

Dynamic Authorization Extensions (DAE) to RADIUS, defined in RFC 5176, can perform the following operations:

· Log off online users.

· Change online user authorization information.

· Shut down or reboot the online user access ports.

· Reauthenticate online users.

DAE uses the client/server model.

In a RADIUS network, the RADIUS server typically acts as the DAE client (DAC) and the NAS acts as the DAE server (DAS).

When the RADIUS DAS feature is enabled, the NAS performs the following operations:

1. Listens to the default or specified UDP port to receive DAE requests.

2. Logs off online users that match the criteria in the requests, changes their authorization information, shuts down or reboots their access ports, or reauthenticates the users.

3. Sends DAE responses to the DAC.

DAE defines the following types of packets:

· Disconnect Messages (DMs)—The DAC sends DM requests to the DAS to log off specific online users.

· Change of Authorization Messages (CoA Messages)—The DAC sends CoA requests to the DAS to change the authorization information of specific online users, shut down or reboot the user access ports, or reauthenticate the users.

To configure the RADIUS DAS feature:

Step	Command	Remarks
1. Enter system view.	system-view	N/A
2. Enable the RADIUS DAS feature and enter RADIUS DAS view.	radius dynamic-author server	By default, the RADIUS DAS feature is disabled.
3. Specify a RADIUS DAC.	client { ip ipv4-address \| ipv6 ipv6-address } [ key { cipher \| simple } string \| vpn-instance vpn-instance-name ] *	By default, no RADIUS DACs are specified.
4. Specify the RADIUS DAS port.	port port-number	By default, the RADIUS DAS port is 3799.

Changing the DSCP priority for RADIUS packets

The DSCP priority in the ToS field determines the transmission priority of RADIUS packets. A larger value represents a higher priority.

To change the DSCP priority for RADIUS packets:

Step	Command	Remarks
1. Enter system view.	system-view	N/A
2. Change the DSCP priority for RADIUS packets.	radius [ ipv6 ] dscp dscp-value	By default, the DSCP priority is 0 for RADIUS packets.

Configuring the RADIUS attribute translation feature

The RADIUS attribute translation feature enables the device to work correctly with the RADIUS servers of different vendors that support RADIUS attributes incompatible with the device.

RADIUS attribute translation has the following implementations:

· Attribute conversion—Converts source RADIUS attributes into destination RADIUS attributes based on RADIUS attribute conversion rules.

· Attribute rejection—Rejects RADIUS attributes based on RADIUS attribute rejection rules.

When the RADIUS attribute translation feature is enabled, the device processes RADIUS packets as follows:

· For the sent RADIUS packets:

¡ Deletes the rejected attributes from the packets.

¡ Uses the destination RADIUS attributes to replace the attributes that match RADIUS attribute conversion rules in the packets.

· For the received RADIUS packets:

¡ Ignores the rejected attributes in the packets.

¡ Interprets the attributes that match RADIUS attribute conversion rules as the destination RADIUS attributes.

To identify proprietary RADIUS attributes, you can define the attributes as extended RADIUS attributes, and then convert the extended RADIUS attributes to device-supported attributes.

To configure the RADIUS attribute translation feature for a RADIUS scheme:

Step	Command	Remarks
1. Enter system view.	system-view	N/A
2. (Optional.) Define an extended RADIUS attribute.	radius attribute extended attribute-name [ vendor vendor-id ] code attribute-code type { binary \| date \| integer \| interface-id \| ip \| ipv6 \| ipv6-prefix \| octets \| string }	By default, no user-defined extended RADIUS attributes exist. Repeat this command to define multiple extended RADIUS attributes.
3. Enter RADIUS scheme view.	radius scheme radius-scheme-name	N/A
4. Enable the RADIUS attribute translation feature.	attribute translate	By default, this feature is disabled.
5. Configure a RADIUS attribute conversion rule.	attribute convert src-attr-name to dest-attr-name { { access-accept \| access-request \| accounting } * \| { received \| sent } * }	By default, no RADIUS attribute conversion rules exist. Repeat this command to add multiple RADIUS attribute conversion rules.
6. Configure a RADIUS attribute rejection rule.	attribute reject attr-name { { access-accept \| access-request \| accounting } * \| { received \| sent } * }	By default, no RADIUS attribute rejection rules exist. Repeat this command to add multiple RADIUS attribute rejection rules.

To configure the RADIUS attribute translation feature for a RADIUS DAS:

Step	Command	Remarks
1. Enter system view.	system-view	N/A
2. (Optional.) Define an extended RADIUS attribute.	radius attribute extended attribute-name [ vendor vendor-id ] code attribute-code type { binary \| date \| integer \| interface-id \| ip \| ipv6 \| ipv6-prefix \| octets \| string }	By default, no user-defined extended RADIUS attributes exist. Repeat this command to define multiple extended RADIUS attributes.
3. Enter RADIUS DAS view.	radius dynamic-author server	N/A
4. Enable the RADIUS attribute translation feature.	attribute translate	By default, this feature is disabled.
5. Configure a RADIUS attribute conversion rule.	attribute convert src-attr-name to dest-attr-name { { coa-ack \| coa-request } * \| { received \| sent } * }	By default, no RADIUS attribute conversion rules exist. Repeat this command to add multiple RADIUS attribute conversion rules.
6. Configure a RADIUS attribute rejection rule.	attribute reject attr-name { { coa-ack \| coa-request } * \| { received \| sent } * }	By default, no RADIUS attribute rejection rules exist. Repeat this command to add multiple RADIUS attribute rejection rules.

Setting the maximum number of concurrent login users

Perform this task to set the maximum number of concurrent users that can log on to the device through a specific protocol, regardless of their authentication methods. The authentication methods include no authentication, local authentication, and remote authentication.

To set the maximum number of concurrent login users:

Step

Command

Remarks

1. Enter system view.

system-view

N/A

2. Set the maximum number of concurrent login users.

· In non-FIPS mode:
aaa session-limit { ftp | http | https | ssh | telnet } max-sessions

· In FIPS mode:
aaa session-limit { https | ssh } max-sessions

By default, the maximum number of concurrent login users is 32 for each user type.

Configuring a NAS-ID profile

By default, the device sends its device name in the NAS-Identifier attribute of all RADIUS requests.

A NAS-ID profile enables you to send different NAS-Identifier attribute strings in RADIUS requests from different VLANs. The strings can be organization names, service names, or any user categorization criteria, depending on the administrative requirements.

For example, map the NAS-ID companyA to all VLANs of company A. The device will send companyA in the NAS-Identifier attribute for the RADIUS server to identify requests from any Company A users.

You can apply a NAS-ID profile to portal- or port security-enabled interfaces. For more information, see "Configuring portal authentication" and "Configuring port security."

A NAS-ID can be bound with more than one VLAN, but a VLAN can be bound with only one NAS-ID.

To configure a NAS-ID profile:

Step	Command	Remarks
1. Enter system view.	system-view	N/A
2. Create a NAS-ID profile and enter NAS-ID profile view.	aaa nas-id profile profile-name	By default, no NAS-ID profiles exist.
3. Configure a NAS-ID and VLAN binding in the profile.	nas-id nas-identifier bind vlan vlan-id	By default, no NAS-ID and VLAN bindings exist.

Configuring the device ID

RADIUS uses the value of the Acct-Session-ID attribute as the accounting ID for a user. The device generates an Acct-Session-ID value for each online user based on the system time, random digits, and device ID.

To configure the device ID:

Step	Command	Remarks
1. Enter system view.	system-view	N/A
2. Configure the device ID.	aaa device-id device-id	By default, the device ID is 0.

Configuring the connection recording policy

Use this feature on scenarios where the device acts as an FTP, SSH, SFTP, or Telnet login client to establish a connection with a login server. This feature enables the device to provide an accounting server with the connection start and termination information. When the login client establishes a connection with the login server, the system sends a start-accounting request to the accounting server. When the connection is terminated, the system sends a stop-accounting request to the accounting server.

The device includes the username entered by a user in the accounting packets to be sent to the AAA server for connection recording. The username format configured by using the user-name-format command in the accounting scheme does not take effect.

To configure the connection recording policy:

Step	Command	Remarks
1. Enter system view.	system-view	N/A
2. Create a connection recording policy and enter its view.	aaa connection-recording policy	By default, the connection recording policy does not exist.
3. Specify the accounting method for the connection recording policy.	accounting hwtacacs-scheme hwtacacs-scheme-name	By default, no accounting method is specified for the connection recording policy.

Displaying and maintaining AAA

Execute display commands in any view.

Task	Command
Display the connection recording policy configuration.	display aaa connection-recording policy
Display the configuration of ISP domains.	display domain [ isp-name ]

AAA configuration examples

AAA for SSH users by an HWTACACS server

Network requirements

As shown in Figure 12, configure the switch to meet the following requirements:

· Use the HWTACACS server for SSH user authentication, authorization, and accounting.

· Assign the default user role network-operator to SSH users after they pass authentication.

· Exclude domain names from the usernames sent to the HWTACACS server.

· Use expert as the shared keys for secure HWTACACS communication.

Figure 12 Network diagram

Configuration procedure

1. Configure the HWTACACS server:

# Set the shared keys to expert for secure communication with the switch. (Details not shown.)

# Add an account for the SSH user and specify the password. (Details not shown.)

2. Configure the switch:

# Configure IP addresses for the interfaces. (Details not shown.)

# Create an HWTACACS scheme.

<Switch> system-view

[Switch] hwtacacs scheme hwtac

# Specify the primary authentication server.

[Switch-hwtacacs-hwtac] primary authentication 10.1.1.1 49

# Specify the primary authorization server.

[Switch-hwtacacs-hwtac] primary authorization 10.1.1.1 49

# Specify the primary accounting server.

[Switch-hwtacacs-hwtac] primary accounting 10.1.1.1 49

# Set the shared keys to expert in plaintext form for secure HWTACACS communication.

[Switch-hwtacacs-hwtac] key authentication simple expert

[Switch-hwtacacs-hwtac] key authorization simple expert

[Switch-hwtacacs-hwtac] key accounting simple expert

# Exclude domain names from the usernames sent to the HWTACACS server.

[Switch-hwtacacs-hwtac] user-name-format without-domain

[Switch-hwtacacs-hwtac] quit

# Create an ISP domain named bbb and configure the domain to use the HWTACACS scheme for authentication, authorization, and accounting of login users.

[Switch-isp-bbb] authentication login hwtacacs-scheme hwtac

[Switch-isp-bbb] authorization login hwtacacs-scheme hwtac

[Switch-isp-bbb] accounting login hwtacacs-scheme hwtac

[Switch-isp-bbb] quit

# Create local RSA and DSA key pairs.

[Switch] public-key local create rsa

[Switch] public-key local create dsa

# Enable the SSH service.

[Switch] ssh server enable

# Enable scheme authentication for user lines VTY 0 through VTY 63.

[Switch] line vty 0 63

[Switch-line-vty0-63] authentication-mode scheme

[Switch-line-vty0-63] quit

# Enable the default user role feature to assign authenticated SSH users the default user role network-operator.

[Switch] role default-role enable

Verifying the configuration

# Initiate an SSH connection to the switch, and enter the correct username and password. The user logs in to the switch. (Details not shown.)

# Verify that the user can use the commands permitted by the network-operator user role. (Details not shown.)

Local authentication, HWTACACS authorization, and RADIUS accounting for SSH users

Network requirements

As shown in Figure 13, configure the switch to meet the following requirements:

· Perform local authentication for SSH users.

· Use the HWTACACS server and RADIUS server for SSH user authorization and accounting, respectively.

· Exclude domain names from the usernames sent to the servers.

· Assign the default user role network-operator to SSH users after they pass authentication.

Configure an account named hello for the SSH user. Configure the shared keys to expert for secure communication with the HWTACACS server and RADIUS server.

Figure 13 Network diagram

Configuration procedure

1. Configure the HWTACACS server. (Details not shown.)

2. Configure the RADIUS server. (Details not shown.)

3. Configure the switch:

# Configure IP addresses for interfaces. (Details not shown.)

# Create local RSA and DSA key pairs.

<Switch> system-view

[Switch] public-key local create rsa

[Switch] public-key local create dsa

# Enable the SSH service.

[Switch] ssh server enable

# Enable scheme authentication for user lines VTY 0 through VTY 63.

[Switch] line vty 0 63

[Switch-line-vty0-63] authentication-mode scheme

[Switch-line-vty0-63] quit

# Configure an HWTACACS scheme.

[Switch] hwtacacs scheme hwtac

[Switch-hwtacacs-hwtac] primary authorization 10.1.1.2 49

[Switch-hwtacacs-hwtac] key authorization simple expert

[Switch-hwtacacs-hwtac] user-name-format without-domain

[Switch-hwtacacs-hwtac] quit

# Configure a RADIUS scheme.

[Switch] radius scheme rd

[Switch-radius-rd] primary accounting 10.1.1.1 1813

[Switch-radius-rd] key accounting simple expert

[Switch-radius-rd] user-name-format without-domain

[Switch-radius-rd] quit

# Create a device management user.

[Switch] local-user hello class manage

# Assign the SSH service to the local user.

[Switch-luser-manage-hello] service-type ssh

# Set the password to 123456TESTplat&! in plaintext form for the local user. In FIPS mode, you must set the password in interactive mode.

[Switch-luser-manage-hello] password simple 123456TESTplat&!

[Switch-luser-manage-hello] quit

# Create an ISP domain named bbb and configure the login users to use local authentication, HWTACACS authorization, and RADIUS accounting.

[Switch] domain bbb

[Switch-isp-bbb] authentication login local

[Switch-isp-bbb] authorization login hwtacacs-scheme hwtac

[Switch-isp-bbb] accounting login radius-scheme rd

[Switch-isp-bbb] quit

# Enable the default user role feature to assign authenticated SSH users the default user role network-operator.

[Switch] role default-role enable

Verifying the configuration

# Initiate an SSH connection to the switch, and enter username hello@bbb and the correct password. The user logs in to the switch. (Details not shown.)

# Verify that the user can use the commands permitted by the network-operator user role. (Details not shown.)

Authentication and authorization for SSH users by a RADIUS server

Network requirements

As shown in Figure 14, configure the switch to meet the following requirements:

· Use the RADIUS server for SSH user authentication and authorization.

· Include domain names in the usernames sent to the RADIUS server.

· Assign the default user role network-operator to SSH users after they pass authentication.

The RADIUS server runs on IMC. Add an account named hello@bbb on the RADIUS server.

The RADIUS server and the switch use expert as the shared key for secure RADIUS communication. The ports for authentication and accounting are 1812 and 1813, respectively.

Figure 14 Network diagram

Configuration procedure

1. Configure the RADIUS server on IMC 5.0:

NOTE:

In this example, the RADIUS server runs on IMC PLAT 5.0 (E0101) and IMC UAM 5.0 (E0101).

# Add the switch to the IMC Platform as an access device:

Log in to IMC, click the Service tab, and select User Access Manager > Access Device Management > Access Device from the navigation tree. Then, click Add to configure an access device as follows:

a. Set the shared key to expert for secure RADIUS communication.

b. Set the ports for authentication and accounting to 1812 and 1813, respectively.

c. Select Device Management Service from the Service Type list.

d. Select H3C from the Access Device Type list.

e. Select an access device from the device list or manually add an access device. In this example, the device IP address is 10.1.1.2.

f. Use the default values for other parameters and click OK.

The IP address of the access device specified here must be the same as the source IP address of the RADIUS packets sent from the switch. The source IP address is chosen in the following order on the switch:

¡ IP address specified by using the nas-ip command.

¡ IP address specified by using the radius nas-ip command.

¡ IP address of the outbound interface (the default).

Figure 15 Adding the switch as an access device

# Add an account for device management:

Click the User tab, and select Access User View > Device Mgmt User from the navigation tree. Then, click Add to configure a device management account as follows:

a. Enter account name hello@bbb and specify the password.

b. Select SSH from the Service Type list.

c. Specify 10.1.1.0 to 10.1.1.255 as the IP address range of hosts to be managed.

d. Click OK.

NOTE:

The IP address range must contain the IP address of the switch.

Figure 16 Adding an account for device management

2. Configure the switch:

# Configure the IP addresses for interfaces. (Details not shown.)

# Create local RSA and DSA key pairs.

<Switch> system-view

[Switch] public-key local create rsa

[Switch] public-key local create dsa

# Enable the SSH service.

[Switch] ssh server enable

# Enable scheme authentication for user lines VTY 0 through VTY 63.

[Switch] line vty 0 63

[Switch-line-vty0-63] authentication-mode scheme

[Switch-line-vty0-63] quit

# Enable the default user role feature to assign authenticated SSH users the default user role network-operator.

[Switch] role default-role enable

# Create a RADIUS scheme.

[Switch] radius scheme rad

# Specify the primary authentication server.

[Switch-radius-rad] primary authentication 10.1.1.1 1812

# Set the shared key to expert in plaintext form for secure communication with the server.

[Switch-radius-rad] key authentication simple expert

# Include domain names in the usernames sent to the RADIUS server.

[Switch-radius-rad] user-name-format with-domain

[Switch-radius-rad] quit

# Create an ISP domain named bbb and configure authentication, authorization, and accounting methods for login users.

[Switch] domain bbb

[Switch-isp-bbb] authentication login radius-scheme rad

[Switch-isp-bbb] authorization login radius-scheme rad

[Switch-isp-bbb] accounting login none

[Switch-isp-bbb] quit

Verifying the configuration

# Initiate an SSH connection to the switch, and enter username hello@bbb and the correct password. The user logs in to the switch. (Details not shown.)

# Verify that the user can use the commands permitted by the network-operator user role. (Details not shown.)

Authentication for SSH users by an LDAP server

Network requirements

As shown in Figure 17, the LDAP server uses domain ldap.com.

Configure the switch to meet the following requirements:

· Use the LDAP server to authenticate SSH users.

· Assign the default user role level-0 to SSH users after they pass authentication.

On the LDAP server, set the administrator password to admin!123456, add a user named aaa, and set the user's password to ldap!123456.

Figure 17 Network diagram

Configuration procedure

1. Configure the LDAP server:

NOTE:

In this example, the LDAP server runs Microsoft Windows 2003 Server Active Directory.

# Add a user named aaa and set the password to ldap!123456:

a. On the LDAP server, select Start > Control Panel > Administrative Tools.

b. Double-click Active Directory Users and Computers.

The Active Directory Users and Computers window is displayed.

c. From the navigation tree, click Users under the ldap.com node.

d. Select Action > New > User from the menu to display the dialog box for adding a user.

e. Enter logon name aaa and click Next.

Figure 18 Adding user aaa

f. In the dialog box, enter password ldap!123456, select options as needed, and click Next.

Figure 19 Setting the user's password

g. Click OK.

# Add user aaa to group Users:

a. From the navigation tree, click Users under the ldap.com node.

b. In the right pane, right-click user aaa and select Properties.

c. In the dialog box, click the Member Of tab and click Add.

Figure 20 Modifying user properties

d. In the Select Groups dialog box, enter Users in the Enter the object names to select field, and click OK.

User aaa is added to group Users.

Figure 21 Adding user aaa to group Users

# Set the administrator password to admin!123456:

a. In the right pane, right-click user Administrator and select Set Password.

b. In the dialog box, enter the administrator password. (Details not shown.)

2. Configure the switch:

# Configure the IP addresses for interfaces. (Details not shown.)

# Create local RSA and DSA key pairs.

<Switch> system-view

[Switch] public-key local create rsa

[Switch] public-key local create dsa

# Enable the SSH service.

[Switch] ssh server enable

# Enable scheme authentication for user lines VTY 0 through VTY 63.

[Switch] line vty 0 63

[Switch-line-vty0-63] authentication-mode scheme

[Switch-line-vty0-63] quit

# Configure an LDAP server.

[Switch] ldap server ldap1

# Specify the IP address of the LDAP authentication server.

[Switch-ldap-server-ldap1] ip 10.1.1.1

# Specify the administrator DN.

[Switch-ldap-server-ldap1] login-dn cn=administrator,cn=users,dc=ldap,dc=com

# Specify the administrator password.

[Switch-ldap-server-ldap1] login-password simple admin!123456

# Configure the base DN for user search.

[Switch-ldap-server-ldap1] search-base-dn dc=ldap,dc=com

[Switch-ldap-server-ldap1] quit

# Create an LDAP scheme.

[Switch] ldap scheme ldap-shm1

# Specify the LDAP authentication server.

[Switch-ldap-ldap-shm1] authentication-server ldap1

[Switch-ldap-ldap-shm1] quit

# Create an ISP domain named bbb and configure authentication, authorization, and accounting methods for login users.

[Switch] domain bbb

[Switch-isp-bbb] authentication login ldap-scheme ldap-shm1

[Switch-isp-bbb] authorization login none

[Switch-isp-bbb] accounting login none

[Switch-isp-bbb] quit

Verifying the configuration

# Initiate an SSH connection to the switch, and enter username aaa@bbb and password ldap!123456. The user logs in to the switch. (Details not shown.)

# Verify that the user can use the commands permitted by the level-0 user role. (Details not shown.)

AAA for 802.1X users by a RADIUS server

Network requirements

As shown in Figure 22, configure the switch to meet the following requirements:

· Use the RADIUS server for authentication, authorization, and accounting of 802.1X users.

· Use MAC-based access control on Ten-GigabitEthernet 1/0/1 to authenticate all 802.1X users on the port separately.

· Include domain names in the usernames sent to the RADIUS server.

On the RADIUS server, perform the following tasks:

· Add a service that charges 120 dollars for up to 120 hours per month and assigns authenticated users to VLAN 4.

· Configure a user account named dot1x@bbb and assign the service to the user.

Set the shared keys to expert for secure RADIUS communication. Set the ports for authentication and accounting to 1812 and 1813, respectively.

Figure 22 Network diagram

Configuration procedure

1. Configure interfaces and VLANs, so the host promptly obtains a new IP address to access resources in the authorized VLAN after passing authentication. (Details not shown.)

2. If you are using IMC PLAT 3.20, configure the RADIUS server as follows:

NOTE:

In this section, the RADIUS authentication and accounting servers are IMC UAM 3.60-E6206 and IMC CAMS 3.60-E6206, respectively. They are running on IMC PLAT 3.20-R2606.

# Add the switch to the IMC Platform as an access device:

Log in to IMC, click the Service tab, and select Access Service > Access Device from the navigation tree. Then, click Add to configure an access device as follows:

a. Set the shared key to expert for secure authentication and accounting communication.

b. Set the ports for authentication and accounting to 1812 and 1813, respectively.

c. Select LAN Access Service from the Service Type list.

d. Select H3C from the Access Device Type list.

e. Select an access device from the device list or manually add an access device. In this example, the device IP address is 10.1.1.2.

f. Use the default values for other parameters and click OK.

¡ IP address specified by using the nas-ip command.

¡ IP address specified by using the radius nas-ip command.

¡ IP address of the outbound interface (the default).

Figure 23 Adding the switch as an access device

# Add a charging plan:

Click the Service tab, and select Charging Service > Charging Plans from the navigation tree to enter the charging plan configuration page. Then, click Add to configure a charging plan as follows:

a. Add a plan named UserAcct.

b. Select Flat rate from the Charging Template list.

c. Select time for Charge Based on, select Monthly for Billing Term, and enter 120 in the Fixed Fee field.

d. Enter 120 in the Usage Threshold field and select hr (hours) for the in field. The configuration allows the user to access the Internet for up to 120 hours per month.

e. Use the default values for other parameters and click OK.

Figure 24 Adding a charging plan

# Add a service:

Click the Service tab, and select Access Service > Service Configuration from the navigation tree. Then, click Add to configure a service as follows:

a. Add a service named Dot1x auth, and set the service suffix to bbb, the authentication domain for the 802.1X user. With the service suffix configured, you must configure the access device to send usernames that include domain names to the RADIUS server.

b. Select UserAcct from the Charging Plan list.

c. Select Deploy VLAN and set the ID of the VLAN to be assigned to 4.

d. Configure other parameters as needed.

e. Click OK.

Figure 25 Adding a service

# Add a user:

Click the User tab, and select Access User View > All Access Users from the navigation tree to enter the All Access Users page. Then, click Add to configure a user as follows:

a. Select the user or add a user named test.

b. Specify the account name as dot1x and configure the password.

c. Select Dot1x auth in the Access Service area.

d. Configure other parameters as needed and click OK.

Figure 26 Adding an access user account

3. If you are using IMC PLAT 5.0, configure the RADIUS server as follows:

NOTE:

In this section, the authentication and accounting RADIUS servers are IMC UAM 5.0 (E0101) and IMC CAMS 5.0 (E0101), respectively. They are running on IMC PLAT 5.0 (E0101).

# Add the switch to the IMC Platform as an access device:

Log in to IMC, click the Service tab, and select User Access Manager > Access Device Management > Access Device from the navigation tree. Then, click Add to configure an access device as follows:

a. Set the shared key to expert for secure authentication and accounting communication.

b. Set the ports for authentication and accounting to 1812 and 1813, respectively.

c. Select LAN Access Service from the Service Type list.

d. Select H3C(General) from the Access Device Type list.

e. Select an access device from the device list or manually add an access device. In this example, the device IP address is 10.1.1.2.

f. Use the default values for other parameters and click OK.

¡ IP address specified by using the nas-ip command.

¡ IP address specified by using the radius nas-ip command.

¡ IP address of the outbound interface (the default).

Figure 27 Adding the switch as an access device

# Add a charging plan:

Click the Service tab, and select Accounting Manager > Charging Plans from the navigation tree to enter the charging plan configuration page. Then, click Add to configure a charging plan as follows:

a. Add a plan named UserAcct.

b. Select Flat rate from the Charging Template list.

c. Select time for Charge Based on, select Monthly for Billing Term, and enter 120 in the Fixed Fee field.

d. Enter 120 in the Usage Threshold field and select hr (hours) for the in field. The configuration allows the user to access the Internet for up to 120 hours per month.

e. Use the default values for other parameters and click OK.

Figure 28 Adding a charging plan

# Add a service:

Click the Service tab, and select User Access Manager > Service Configuration from the navigation tree. Then, click Add to configure a service as follows:

b. Select UserAcct from the Charging Plan list.

c. Select Deploy VLAN and set the ID of the VLAN to be assigned to 4.

d. Configure other parameters as needed.

e. Click OK.

Figure 29 Adding a service

# Add a user:

Click the User tab, and select Access User View > All Access Users from the navigation tree to enter the All Access Users page. Then, click Add to configure a user as follows:

a. Select the user or add a user named hello.

b. Specify the account name as dot1x and configure the password.

c. Select Dot1x auth in the Access Service area.

d. Configure other parameters as needed and click OK.

Figure 30 Adding an access user account

4. Configure the switch:

a. Configure a RADIUS scheme:

# Create a RADIUS scheme named rad and enter RADIUS scheme view.

<Switch> system-view

[Switch] radius scheme rad

# Specify the primary authentication server and primary accounting server, and configure the keys for communication with the servers.

[Switch-radius-rad] primary authentication 10.1.1.1

[Switch-radius-rad] primary accounting 10.1.1.1

[Switch-radius-rad] key authentication simple expert

[Switch-radius-rad] key accounting simple expert

# Include domain names in the usernames sent to the RADIUS server.

[Switch-radius-rad] user-name-format with-domain

[Switch-radius-rad] quit

b. Configure an authentication domain:

# Create an ISP domain named bbb and enter ISP domain view.

[Switch] domain bbb

# Configure the ISP domain to use RADIUS scheme rad for authentication, authorization, and accounting of LAN users.

[Switch-isp-bbb] authentication lan-access radius-scheme rad

[Switch-isp-bbb] authorization lan-access radius-scheme rad

[Switch-isp-bbb] accounting lan-access radius-scheme rad

[Switch-isp-bbb] quit

c. Configure 802.1X authentication:

# Enable 802.1X globally.

[Switch] dot1x

# Enable 802.1X for Ten-GigabitEthernet 1/0/1.

[Switch] interface ten-gigabitethernet 1/0/1

[Switch-Ten-GigabitEthernet1/0/1] dot1x

# Configure the access control method. By default, an 802.1X-enabled port uses the MAC-based access control.

[Switch-Ten-GigabitEthernet1/0/1] dot1x port-method macbased

Verifying the configuration

1. On the host, use account dot1x@bbb to pass 802.1X authentication:

# If the host runs the Windows XP 802.1X client, configure the network connection properties as follows:

a. Click the Authentication tab of the properties window.

b. Select the Enable IEEE 802.1X authentication for this network option.

c. Select MD5 challenge as the EAP type.

d. Click OK.

The user passes authentication after entering the correct username and password on the authentication page.

# If the host runs the iNode client, no advanced authentication options are required. The user can pass authentication after entering username dot1x@bbb and the correct password on the client property page.

2. On the switch, verify that the server assigns the port connecting the client to VLAN 4 after the user passes authentication. (Details not shown.)

3. Display the connection information on the switch.

[Switch] display dot1x connection

Troubleshooting RADIUS

RADIUS authentication failure

Symptom

User authentication always fails.

Analysis

Possible reasons include:

· A communication failure exists between the NAS and the RADIUS server.

· The username is not in the userid@isp-name format, or the ISP domain is not correctly configured on the NAS.

· The user is not configured on the RADIUS server.

· The password entered by the user is incorrect.

· The RADIUS server and the NAS are configured with different shared keys.

Solution

To resolve the problem:

1. Verify the following items:

¡ The NAS and the RADIUS server can ping each other.

¡ The username is in the userid@isp-name format and the ISP domain is correctly configured on the NAS.

¡ The user is configured on the RADIUS server.

¡ The correct password is entered.

¡ The same shared key is configured on both the RADIUS server and the NAS.

2. If the problem persists, contact H3C Support.

RADIUS packet delivery failure

Symptom

RADIUS packets cannot reach the RADIUS server.

Analysis

Possible reasons include:

· A communication failure exists between the NAS and the RADIUS server.

· The NAS is not configured with the IP address of the RADIUS server.

· The authentication and accounting UDP ports configured on the NAS are incorrect.

· The RADIUS server's authentication and accounting port numbers are being used by other applications.

Solution

To resolve the problem:

1. Verify the following items:

¡ The link between the NAS and the RADIUS server works well at both the physical and data link layers.

¡ The IP address of the RADIUS server is correctly configured on the NAS.

¡ The authentication and accounting UDP port numbers configured on the NAS are the same as those of the RADIUS server.

¡ The RADIUS server's authentication and accounting port numbers are available.

2. If the problem persists, contact H3C Support.

RADIUS accounting error

Symptom

A user is authenticated and authorized, but accounting for the user is not normal.

Analysis

The accounting server configuration on the NAS is not correct. Possible reasons include:

· The accounting port number configured on the NAS is incorrect.

· The accounting server IP address configured on the NAS is incorrect. For example, the NAS is configured to use a single server to provide authentication, authorization, and accounting services, but in fact the services are provided by different servers.

Solution

To resolve the problem:

1. Verify the following items:

¡ The accounting port number is correctly configured.

¡ The accounting server IP address is correctly configured on the NAS.

2. If the problem persists, contact H3C Support.

Troubleshooting HWTACACS

Similar to RADIUS troubleshooting. See "Troubleshooting RADIUS."

Troubleshooting LDAP

LDAP authentication failure

Symptom

User authentication fails.

Analysis

Possible reasons include:

· A communication failure exists between the NAS and the LDAP server.

· The LDAP server IP address or port number configured on the NAS is not correct.

· The username is not in the userid@isp-name format, or the ISP domain is not correctly configured on the NAS.

· The user is not configured on the LDAP server.

· The password entered by the user is incorrect.

· The administrator DN or password is not configured.

· Some user attributes (for example, the username attribute) configured on the NAS are not consistent with those configured on the server.

· No user search base DN is specified for the LDAP scheme.

Solution

To resolve the problem:

1. Verify the following items:

¡ The NAS and the LDAP server can ping each other.

¡ The IP address and port number of the LDAP server configured on the NAS match those of the server.

¡ The username is in the correct format and the ISP domain for the user authentication is correctly configured on the NAS.

¡ The user is configured on the LDAP server.

¡ The correct password is entered.

¡ The administrator DN and the administrator password are correctly configured.

¡ The user attributes (for example, the username attribute) configured on the NAS are consistent with those configured on the LDAP server.

¡ The user search base DN for authentication is specified.

2. If the problem persists, contact H3C Support.

09-Security Configuration Guide

Client/server model

Information exchange security mechanism

User authentication methods

RADIUS packet format

Extended RADIUS attributes

HWTACACS

LDAP directory service

LDAP authentication and authorization

Basic LDAP authorization process

AAA implementation on the device

User management based on ISP domains and user access types

AAA methods

AAA for MPLS L3VPNs

Configuring AAA schemes

Local user configuration task list

Configuration task list

Creating a RADIUS scheme

Specifying the RADIUS authentication servers

Specifying the RADIUS accounting servers and the relevant parameters

Setting the username format and traffic statistics units

Setting RADIUS timers

Configuring the RADIUS accounting-on feature

Configuring the Login-Service attribute check method for SSH, FTP, and terminal users

Creating an HWTACACS scheme

Specifying the shared keys for secure HWTACACS communication

Specifying an MPLS L3VPN instance for the scheme

Setting the username format and traffic statistics units

Creating an LDAP server

Configuring administrator attributes

Creating an ISP domain

Configuration prerequisites

Configuration guidelines

Configuration procedure

Configuration prerequisites

Configuration guidelines

Configuration procedure

Configuration prerequisites

Configuration procedure

Configuring the RADIUS DAS feature

Configuring a NAS-ID profile

AAA configuration examples

Network requirements

Configuration procedure

Verifying the configuration

Network requirements

Configuration procedure

Verifying the configuration

Network requirements

Configuration procedure

Verifying the configuration

Authentication for SSH users by an LDAP server

Network requirements

Configuration procedure

Verifying the configuration

Network requirements

Configuration procedure

Verifying the configuration

Troubleshooting RADIUS

RADIUS authentication failure

Symptom

Analysis

Solution

Symptom

Analysis

Solution

Symptom

Analysis

Solution

Symptom

Analysis

Solution

Cloud & AI

InterConnect
