Configuring WAAS

About WAAS

The Wide Area Application Services (WAAS) feature is a set of services that can optimize WAN traffic. WAAS solves WAN issues such as high delay and low bandwidth by using optimization services. WAAS provides Forward error correction (FEC) and packet duplication UDP optimization services and the following TCP optimization services:

·     FEC

·     Transport Flow Optimization (TFO).

·     Data Redundancy Elimination (DRE).

·     Lempel-Ziv compression (LZ compression).

·     Packet duplication.

RTP is a type of UDP protocol. You must configure FEC optimization for RTP separately.

TCP optimization can speed up file transfer by reducing network delay. UDP optimization can recover lost packets by using generated redundant packets and is used for audio and video services.

TFO

TFO optimizes TCP traffic without modifying packet header information. TFO uses the following optimization methods:

·     Slow start optimization.

·     Increased buffering.

·     Congestion algorithm optimization.

·     Selective acknowledgement.

Slow start optimization

The initial congestion window size for TCP slow start is one TCP segment. During slow start, TCP doubles the congestion window size for each received ACK that acknowledges new data. In this manner, the congestion window will reach an appropriate value by examining the congestion status. In a WAN environment, the congestion window takes a long time to reach an appropriate size because of high delay.

Slow start optimization shortens the slow start process by increasing the initial congestion window size.

Increased buffering

TCP has a maximum buffer size of 64 KB. After the sender sends 64 KB data, it must wait for an ACK from the receiver before continuing to send data. This mechanism wastes bandwidth on a WAN link.

Increased buffering increases the TCP buffer size to a maximum of 16384 KB. This improves link efficiency.

Congestion algorithm optimization

TCP uses the congestion window to control congestion. The window size indicates the size of data that can be sent out before an ACK is received. The window size changes with the congestion status. The greater the window size, the faster the data rate. A higher data rate more likely causes congestion. The smaller the window size, the lower the data rate. A lower data rate causes low link efficiency.

Congestion algorithm optimization achieves a trade-off between the data rate and congestion by selecting the optimum window size.

Selective acknowledgement

TCP uses a cumulative acknowledgement scheme. This scheme forces the sender to either wait a roundtrip time to know each lost packet, or to unnecessarily retransmit segments that have been correctly received. When multiple nonconsecutive segments are lost, this scheme reduces overall TCP throughput.

Selective acknowledgement (SACK) allows the receiver to inform the sender of all segments that have arrived successfully. The sender retransmits only the segments that have been lost.

DRE

DRE reduces the size of transmitted data by replacing repeated data blocks with shorter indexes. A WAAS device synchronizes its data dictionary to its peer devices. A data dictionary stores mappings between repeated data blocks and indexes.

Replacing repeated data blocks with indexes is called DRE compression. Replacing indexes with repeated data blocks is called DRE decompression.

DRE compression process

DRE compresses data in the following process:

1.     The sending WAAS device caches TCP data and sends a large data block to the DRE module.

2.     The DRE module divides the large data block into non-overlapping data blocks.

¡     For a repeated data block, the DRE module performs the following operations:

-     Replaces the data block with its index and creates an MD5 digest for the data block.

-     Sends the index and MD5 digest to the peer.

¡     For a non-repeated data block, the DRE module performs the following operations:

-     Creates an index for the data block and adds it to the local data dictionary.

-     Creates an MD5 digest for the data block and sends the data block, index, and MD5 digest to the peer.

To improve calculation speed and efficiency, DRE uses a sliding window mechanism to segment data and detect data redundancy. This mechanism detects repeated data blocks by using a fixed-size window to compare the original data byte by byte with data blocks in the dictionary.

DRE decompression process

DRE decompresses data in the following process:

1.     The receiving WAAS device reconstructs the original data.

¡     For an index, the device replaces the index with its data block after querying the data dictionary.

If the query fails, the decompression fails, and the receiving WAAS device waits for the peer to retransmit the data.

¡     For an index and a data block, the device creates an entry for them and adds the entry to the local data dictionary.

2.     The receiving WAAS device calculates an MD5 digest for the original data and compares the calculated MD5 digest with the MD5 digest in the packet.

¡     If the two MD5 digests are the same, the decompression succeeds.

¡     If the two MD5 digests are different, the decompression fails, and the receiving WAAS device waits for the peer to retransmit the data.

LZ compression

LZ compression is a lossless compression algorithm that uses a compression dictionary to replace repeated data in the same message. The compression dictionary is carried in the compression result. The sending device uses the sliding window technology to detect repeated data.

Compared with DRE, LZ compression has a lower compression ratio. LZ compression does not require synchronization of compression dictionaries between the local and peer devices. This reduces memory consumption.

FEC

About FEC

The real-time packets (audio and video packets) transported over RTP on the Internet can experience common problems such as out-of-order packets, packet loss, and packet duplication.

Forward error correction (FEC) is a mechanism to control errors during data transmission by adding data redundancy to the transmitted packets. Specifically, the FEC sender encodes original packets and generates redundant packets. The header information of a redundant packet includes the number of original packets, the number of redundant packets, and sequence numbers. The FEC receiver decodes received data and recovers lost packets according to the received original packets and redundant packets.

Basic concepts

·     FEC average ratio—Controls the number of redundant packets generated. The greater the FEC average ratio, the more the redundant packets generated. FEC average ratio must be greater than the actual packet loss ratio.

·     Encoding timeout time—Affects the number of original packets that can be encoded at a time. If the encoding timeout time expires before the maximum number is reached, the number of actually encoded packets are sent.

·     Block size—Specifies the maximum number of original packets that can be encoded at a time. If the block size  is too small, the number of generated redundant packets is small. If the block size is too large, the decoder side will take a long time to recover lost packets.

Both the encoding timeout time and the block size affect the number of original packets that can be encoded at a time. If the maximum number of encoded packets is reached before the encoding timeout time expires, that number applies. If the encoding timeout time expires before the maximum number is reached, the number of actually encoded packets applies.

·     Decoding timeout time—Affects the number of original packets that can be decoded at a time. If the total number of cached original packets and redundant packets is smaller than the block size when the decoding timeout time expires, the decoder sends cached original packets and drops cached redundant packets without decoding any packets.

·     Sampling interval—The decoder regularly sends sampled packets to notify the encoder of the real-time packet loss ratio. The encoder adjusts the FEC average ratio based on the real-time packet loss ratio. This parameter is supported only for A-FEC.

·     Aging time for A-FEC decoder information—If the encoder does not receive sampled packets within the aging time, it deletes the local decoder information and uses the set FEC average ratio.

FEC types

FEC types include adaptive FEC (A-FEC) and determined FEC (D-FEC).

·     A-FEC adjusts the FEC average ratio based on the calculated real-time packet loss ratio. The encoder adds device address information to redundant packets. The decoder regularly sends sampled packet loss ratio to the encoder. The encoder will adjust the number of generated redundant packets to reduce the amount of data transmitted on the WAN link.

·     D-FEC always uses the set FEC average ratio.

How FEC works

FEC processes packets as follows:

1.     The encoder identifies audio or video sessions.

a.     When the device receives an audio or video request packet, it marks an ALG flag for the packet, and generates a session and a relation table. For more information about sessions, see session management in Security Configuration Guide.

b.     When the device receives a data packet, it matches the packet against WAAS policies. If a match is found, the device creates a fast forwarding entry and sets the fast forwarding flag.

2.     The encoder encodes packets.

a.     Caches original packets.

b.     When the number of cached packets reaches the block size or the encoding timeout time expires, the device encodes the cached packets to generate redundant packets, and sends all of them.

3.     The encoder decodes packets.

a.     Caches received original packets and redundant packets.

b.     When the total number of cached original packets and redundant packets reaches or exceeds the set number of original packets before the decoding timeout time expires, the decoder performs the following operations:

i     Decodes the cached packets.

ii     Recovers lost packets.

iii     Sends original packets and recovered packets, and drops redundant packets.

Otherwise, the decoder sends cached original packets and drops cached redundant packets without decoding any packets.

Packet duplication working mechanism

When real-time audio/video interaction is performed on Internet, the links might encounter bandwidth limit, delay, jitter, and error code issues. At the same time, the error correction and retransmission on the transport layer and application layer exacerbate the bandwidth and delay issues, which decreases the audio/video data transmission quality. As a result, the audio/video often gets stuck and then plays fast.

Currently, most LANs access a WAN through multiple WAN links. The packet duplication feature takes the advantage of multiple WAN links to send one packet over two links, which effectively reduces or even avoids the audio/video lag issues caused by packet loss on a single link. The detailed workflow is as follows:

1.     A WAAS policy with the optimization action as packet duplication is applied to a WAN interface.

2.     When a WAN interface receives a packet that matches the criteria, the system looks up for ECMP routes, and duplicates the packet to the link of the first ECMP route. The device forwards the packet on the links of the WAN interface and the outgoing interface of the matching ECMP route at the same time.

3.     The receiver integrates the packets received on the two links and drops the duplicate packet according to the packet characteristics.

Protocols and standards

·     RFC 1323, TCP Extensions for High Performance

·     RFC 3390, Increasing TCP's Initial Window

·     RFC 2581, TCP Congestion Control

·     RFC 2018, TCP Selective Acknowledgment Options

·     RFC 3042, Enhancing TCP's Loss Recovery Using Limited Transmit

·     RFC 2582, The NewReno Modification to TCP's Fast Recovery Algorithm

·     RFC 2733, An RTP Payload Format for Generic Forward Error Correction



Restrictions: Hardware compatibility with WAAS

Hardware

WAAS compatibility

MSR610

No

MSR810, MSR810-W, MSR810-W-DB, MSR810-LM, MSR810-W-LM, MSR810-10-PoE, MSR810-LM-HK, MSR810-W-LM-HK, MSR810-LM-CNDE-SJK, MSR810-CNDE-SJK, MSR810-EI, MSR810-LM-EA, MSR810-LM-EI

Yes

MSR810-LMS, MSR810-LUS

No

MSR810-SI, MSR810-LM-SI

No

MSR810-LMS-EA, MSR810-LME

Yes

MSR1004S-5G, MSR1004S-5G-CN

Yes

MSR1104S-W, MSR1104S-W-CAT6, MSR1104S-5G-CN, MSR1104S-W-5G-CN

Yes

MSR2600-6-X1, MSR2600-15-X1, MSR2600-15-X1-T

Yes

MSR2600-10-X1

Yes

MSR 2630

Yes

MSR3600-28, MSR3600-51

No

MSR3600-28-SI, MSR3600-51-SI

No

MSR3600-28-X1, MSR3600-28-X1-DP, MSR3600-51-X1, MSR3600-51-X1-DP

No

MSR3600-28-G-DP, MSR3600-51-G-DP

No

MSR3610-I-DP, MSR3610-IE-DP, MSR3610-IE-ES, MSR3610-IE-EAD, MSR-EAD-AK770, MSR3610-I-IG, MSR3610-IE-IG

Yes

MSR3610-X1, MSR3610-X1-DP, MSR3610-X1-DC, MSR3610-X1-DP-DC, MSR3620-X1, MSR3640-X1

Yes

MSR 3610, MSR 3620, MSR 3620-DP, MSR 3640, MSR 3660

Yes

MSR3610-G, MSR3620-G

Yes

MSR3640-G

No

MSR3640-X1-HI

No



Hardware

WAAS compatibility

MSR810-W-WiNet, MSR810-LM-WiNet

Yes

MSR830-4LM-WiNet

Yes

MSR830-5BEI-WiNet, MSR830-6EI-WiNet, MSR830-10BEI-WiNet

Yes

MSR830-6BHI-WiNet, MSR830-10BHI-WiNet

Yes

MSR2600-6-WiNet

Yes

MSR2600-10-X1-WiNet

Yes

MSR2630-WiNet

Yes

MSR3600-28-WiNet

No

MSR3610-X1-WiNet

Yes

MSR3610-WiNet, MSR3620-10-WiNet, MSR3620-DP-WiNet, MSR3620-WiNet, MSR3660-WiNet

Yes



Hardware

WAAS compatibility

MSR860-6EI-XS

Yes

MSR860-6HI-XS

Yes

MSR2630-XS

Yes

MSR3600-28-XS

No

MSR3610-XS

Yes

MSR3620-XS

Yes

MSR3610-I-XS

Yes

MSR3610-IE-XS

Yes

MSR3620-X1-XS

Yes

MSR3640-XS

Yes

MSR3660-XS

No



Hardware

WAAS compatibility

MSR810-LM-GL

Yes

MSR810-W-LM-GL

Yes

MSR830-6EI-GL

Yes

MSR830-10EI-GL

Yes

MSR830-6HI-GL

Yes

MSR830-10HI-GL

Yes

MSR1004S-5G-GL

Yes

MSR2600-6-X1-GL

Yes

MSR3600-28-SI-GL

No



Restrictions: Licensing requirements for WAAS

WAAS is available only when a specific license is installed. When the license expires or is removed, all WAAS policies are unavailable. For more information about licensing, see license management in Fundamentals Configuration Guide.

Restrictions and guidelines: WAAS configuration

For the WAAS feature to work correctly, make sure fast forwarding load sharing is disabled. For information about fast forwarding load sharing, see Layer 3IP Services Configuration Guide.

WAAS tasks at a glance

To configure WAAS, perform the following tasks:

1.     Configure TCP optimization:

a.     Configuring a TCP WAAS class

b.     Configuring TFO parameters

c.     Configuring DRE optimization parameters

d.     (Optional.) Configuring the TFO blacklist autodiscovery feature

e.     Configuring a WAAS policy for TCP traffic

f.     Applying a WAAS policy to an interface

2.     Configure FEC optimization:

a.     Configuring an RTP WAAS class

b.     Configuring FEC optimization parameters

c.     Configuring a WAAS policy for RTP traffic

d.     Applying a WAAS policy to an interface

3.     (Optional.) Specifying traffic processing slots for an interface

4.     (Optional.) Configuring WAAS to operate in asymmetric mode

5.     (Optional.) Configuring TCP packet compression or decompression

6.     (Optional.) Configuring UDP message compression or decompression

7.     (Optional.) Restoring predefined WAAS settings

8.     (Optional.) Deleting all WAAS settings

Configuring a TCP WAAS class

1.     Enter system view.

system-view

2.     Create a WAAS class and enter WAAS class view.

waas class class-name

By default, only predefined WAAS classes exist.

3.     Configure a TCP match criterion.

match [ match-id ] tcp any [ ip-address { ip-address [ mask-length | mask ] | object-group ip-object-group-name } | ipv6-address { ipv6-address [ prefix-length ] | object-group ipv6-object-group-name } ] [ port { port-list | object-group port-object-group-name } ]

match [ match-id ] tcp { destination ip-address { ip-address [ mask-length | mask ] | object-group ip-object-group-name } [ port { port-list | object-group port-object-group-name } ] | source ip-address { ip-address [ mask-length | mask ] | object-group ip-object-group-name } [ port { port-list | object-group port-object-group-name } ] } *

match [ match-id ] tcp { destination ipv6-address { ipv6-address [ prefix-length ] | object-group ipv6-object-group-name } [ port { port-list | object-group port-object-group-name } ] | source ipv6-address { ipv6-address [ prefix-length ] | object-group ipv6-object-group-name } [ port { port-list | object-group port-object-group-name } ] } *

match [ match-id ] tcp { destination | source } port { object-group port-object-group-name | port-list }

Configuring a UDP WAAS class

1.     Enter system view.

system-view

2.     Create a WAAS class and enter WAAS class view.

waas class class-name

By default, only predefined WAAS classes exist.

3.     Configure a UDP match criterion.

match [ match-id ] udp any [ ip-address { ip-address [ mask-length | mask ] | object-group ip-object-group-name } | ipv6-address { ipv6-address [ prefix-length ] | object-group ipv6-object-group-name } ] [ port { port-list | object-group port-object-group-name } ]

match [ match-id ] udp { destination ip-address { ip-address [ mask-legnth | mask ] | object-group ip-object-group-name } [ port { port-list | object-group port-object-group-name } ] | source ip-address { ip-address [ mask-legnth | mask ] | object-group ip-object-group-name } [ port { port-list | object-group port-object-group-name } ] } *

match [ match-id ] udp { destination ipv6-address { ipv6-address [ prefix-length ] | object-group ipv6-object-group-name } [ port { port-list | object-group port-object-group-name } ] | source ipv6-address { ipv6-address [ prefix-length ] | object-group ipv6-object-group-name } [ port { port-list | object-group port-object-group-name } ] } *

match [ match-id ] udp { destination | source } port { port-list | object-group port-object-group-name  }

Configuring an RTP WAAS class

1.     Enter system view.

system-view

2.     Create an RTP WAAS class and enter RTP WAAS class view.

waas rtp-class class-name

3.     Configure a UDP match criterion.

match [ match-id ] udp any [ ip-address { ip-address [ mask-length | mask ] | object-group ip-object-group-name } ] [ port { port-list | object-group port-object-group-name } ]

match [ match-id ] udp { destination { ip-address { ip-address [ mask-length | mask ] | object-group ip-object-group-name } [ port { port-list | object-group port-object-group-name } ] } | source { ip-address { ip-address [ mask-length | mask ] | object-group ip-object-group-name } [ port { port-list | object-group port-object-group-name } ] } } *

match [ match-id ] udp { destination | source } port { port-list | object-group port-object-group-name  }

Configuring TFO parameters

About this task

The congestion window size changes with the congestion status and transmission speed. An appropriate initial congestion window size can quickly restore the network to its full transmission capacity after congestion occurs.

After you enable TFO keepalives, the system starts the 2-hour TCP keepalive timer. If the local device does not send or receive any data when the timer expires, it sends a keepalive to the peer to maintain the connection.

The receiving buffer size specifies the size of data that can be received. It affects network throughput.

Different network performance requirements require different TCP congestion control algorithms. Selecting a proper TCP congestion control algorithm enables a network to quickly recover to the maximum transmission capacity. The following TCP congestion control algorithms are supported:

·     Reno—As a best practice, use this algorithm in low-delay, low-bandwidth scenarios. In a high-delay, high-bandwidth scenario, it takes a long time for the transmission rate to increase to the maximum, which reduces bandwidth usage. As an early TCP congestion control algorithm, it uses received ACKs as the basis for increasing the congestion window.

·     BIC—As a best practice, use this algorithm in scenarios with high bandwidth and low packet loss ratio. BIC considers lost packets as a sign of congestion. BIC does not reduce the transmission rate as long as no packet loss occurs, which maximizes the bandwidth usage and improves throughput. The disadvantage of BIC is it has high delay and considers dropped error packets as packets dropped due to congestion.

·     BBR—As a best practice, use this algorithm in scenarios with high bandwidth, high delay, and adequate packet loss ratio. BBR does not consider lost packets as a sign of congestion. In a scenario with high packet loss ratio, BBR can reduce the transmission delay and keep high throughput. BBRv2 provides greater fairness when multiple multicast congestion control algorithms co-exist.

After the maximum number of concurrent connections is reached, WAAS does not optimize traffic for newly established connections.

Procedure

1.     Enter system view.

system-view

2.     Set the initial congestion window size.

waas tfo base-congestion-window segments

The default setting is two segments.

3.     Enable TFO keepalives.

waas tfo keepalive

By default, TFO keepalives are enabled.

4.     Set the receiving buffer size.

waas tfo receive-buffer buffer-size

The default setting is 64 KB.

5.     Specify a TCP congestion control algorithm for the WAN side.

waas tfo congestion-method { bic | reno }

By default, WAAS uses BIC as the TCP congestion control algorithm on the WAN side.

6.     Set the maximum number of concurrent connections.

waas tfo connect-limit limit

The default setting is 10000.

Configuring DRE optimization parameters

About this task

You can tune the following DRE optimization parameters:

·     DRE match offset step—The higher the step level, the lower the match precision. As a best practice, use a higher-level offset step on high-speed links to improve match efficiency. Use a lower-level offset step on low-speed links to ensure match precision.

·     Aging time for entries in the data dictionary—The device polls all data dictionary entries and deletes the entries that are not hit within the aging time. If the number of data dictionary entries reaches the limit, the device no longer creates new entries.

The amount of time used by the device to poll all data dictionary entries depends on the number of data dictionary entries on the device.

Procedure

1.     Enter system view.

system-view

2.     Set the DRE match offset step.

waas dre offset-step { general | fast | fastest | normal }

The default setting is normal.

The following DRE match offset step levels are listed from high to low:

¡     fastest

¡     fast

¡     general

¡     normal

3.     Set the aging time for data dictionary entries.

waas dre cache aging minutes

By default, data dictionary entries are not aged out, and the newly created entry overwrites the oldest entry if the number of data dictionary entries reaches the limit.

Configuring the TFO blacklist autodiscovery feature

About this task

This feature automatically discovers servers that cannot receive TCP packets with options and adds the server IP addresses and port numbers to a blacklist. The system automatically removes blacklist entries after a user-configured aging time.

During the 3-way handshake, the local device determines that the TCP connection attempt fails if either of the following situations occurs:

·     The peer device does not respond within the specified time period.

·     The peer device closes the TCP connection.

Procedure

1.     Enter system view.

system-view

2.     Enable the TFO blacklist autodiscovery feature.

waas tfo auto-discovery blacklist enable

By default, the TFO blacklist autodiscovery feature is disabled.

3.     Set the aging time for blacklist entries.

waas tfo auto-discovery blacklist hold-time minutes

The default setting is 5 minutes.

Configuring FEC optimization parameters

About this task

You can tune the following FEC optimization parameters for better audio and video quality according to the packet loss and traffic rate on your network.

FEC includes adaptive-FEC (A-FEC) and determined-FEC (D-FEC). TCP optimization and UDP optimization support only D-FEC.

Procedure

1.     Enter system view.

system-view

2.     Create a WAAS policy and enter WAAS policy view.

waas policy policy-name

By default, a predefined WAAS policy named waas_default exists.

3.     Specify a class or an RTP WAAS class and enter WAAS policy class view or WAAS policy RTP class view.

¡     class class-name [ insert-before existing-class ]

By default, no WAAS class is specified.

¡     rtp-class class-name [ insert-before existing_class ]

By default, no RTP WAAS class is specified.

4.     Specify an FEC type (available only in WAAS policy RTP class view).

fec loss-recovery-type { adaptive-fec | determined-fec }

The default is determined-fec.

5.     (Optional.) Set the FEC average ratio.

fec average-ratio ratio

The default setting is 35%.

6.     (Optional.) Set the encoding timeout time.

fec encode-timeout milliseconds

The default setting is 5000 milliseconds.

7.     (Optional.) Set the maximum number of original packets that can be encoded at a time.

fec block-size block-size

The default setting is 20.

8.     (Optional.) Set the decoding timeout time.

fec decode-timeout milliseconds

The default setting is 800 milliseconds.

9.     (Optional.) Set the aging time for decoder information (available only in WAAS policy RTP class view).

fec probe aging-time seconds

The default setting is 1 second.

This command is supported only for A-FEC.

10.     (Optional.) Set the sampling interval.

fec sample-interval interval

The default setting is 100 milliseconds.

This command is supported only for A-FEC.

Configuring packet duplication optimization parameters

About this task

When packet duplication optimization is enabled on the device, the sender replicates the packets to be sent and selects an additional path reachable to the destination as the forwarding path for the packets. After receiving the packets, the receiver reorders the packets to ensure the integrity and continuity of the packets.

The sender can select a path by using the packet duplication algorithm, by using the RIR feature, or by using a static path, with different priorities.

·     If packet duplication RIR is enabled, the device selects a path based on the link priority, link quality, and link bandwidth. This method has the highest priority.

·     If a path is manually specified on the device and no path calculated by using the packet duplication RIR algorithm exists, the device uses the manually specified path. A manually specified path has higher priority than the path selected by using the packet duplication algorithm.

·     If the device detects that neither a path selected by using the packet duplication RIR feature nor a manually specified path exists, it selects the first path in the routing table that has the same cost as the original path by using the packet duplication algorithm.

With the packet reorder feature, the sender numbers the packets to be sent based on the order in which the packets will be sent, for example, 1, 2... n, and then replicates and forwards the packets. The receiver discards the packets with the same sequence number and reorders them before forwarding them. If no packet with a smaller sequence number is received, the receiver will cache the received packets and send the packets in sequence after a packet with a smaller sequence number arrives. If the receiver does not receive a packet with a smaller sequence number before the reorder timeout timer expires, the receiver will directly send the cached packets.

Restrictions and guidelines

Packet duplication RIR takes effect only if RIR is enabled on the device. For more information about RIR, see RIR configuration in Layer 3—IP Routing Configuration Guide.

Make sure an SDWAN tunnel exists for a manually specified packet duplication path. If the same SDWAN tunnel is configured as the packet duplication path multiple times, the most recent configuration takes effect. If multiple paths are specified for the same destination, only one path will be selected as the packet duplication path by using a specific algorithm. Manually specifying a packet duplication path is available only in an SDWAN network.

Enabling packet duplication RIR

1.     Enter system view.

system-view

2.     Create a WAAS policy and enter WAAS policy view.

waas policy policy-name

3.     Specify a class and enter WAAS policy class view.

class class-name [ insert-before exiting_class ]

4.     Enable packet duplication RIR.

packet-dup rir enable

By default, packet duplication RIR is disabled.

Manually specifying a packet duplication path in an SDWAN network

1.     Enter system view.

system-view

2.     Manually specify a packet duplication path in an SDWAN network.

waas packet-dup sdwan static-path { destination-ip dest-ipv4-address { dest-mask-length | dest-mask } | destination-ipv6 dest-ipv6-address dest-prefix-length } [ vpn-instance vpn-instance-name ] interface interface-type interface-number peer-site-id peer-site-id peer-device-id peer-device-id peer-interface-id peer-interface-id [ priority priority ]

By default, no packet duplication path is manually specified in an SDWAN network.

Setting the packet duplication reorder timeout timer

1.     Enter system view.

system-view

2.     Create a WAAS policy and enter WAAS policy view.

waas policy policy-name

3.     Specify a class and enter WAAS policy class view.

class class-name [ insert-before exiting_class ]

4.     Set the packet duplication reorder timeout timer.

packet-dup reorder timeout timeout

By default, the packet duplication reorder timeout timer is 100 ms.

Configuring a WAAS policy for TCP traffic

About this task

To configure a WAAS policy for TCP traffic, perform the following tasks:

1.     Create a WAAS policy.

2.     Specify a WAAS class for the WAAS policy.

3.     Configure actions for the WAAS class.

You can configure the following actions for a WAAS class:

·     Optimization actions—Optimize matching TCP traffic by using FEC, TFO, DRE, LZ, and packet duplication.

·     Passthrough action—Allows matching TCP traffic to pass through unoptimized.

Restrictions and guidelines

For an optimization action to take effect, you must enable the corresponding optimization feature.

As a best practice, configure a WAAS policy by modifying the predefined WAAS policy.

Procedure

1.     Enter system view.

system-view

2.     Create a WAAS policy and enter WAAS policy view.

waas policy policy-name

By default, a predefined WAAS policy named waas_default exists.

3.     Specify a WAAS class and enter WAAS policy class view.

class class-name [ insert-before existing_class ]

By default, no WAAS class is specified.

4.     Configure optimization actions or the passthrough action.

¡     optimize { fec | packet-dup | tfo [ dre | lz ] * }

¡     passthrough

By default, no action is configured.

5.     Return to system view.

quit

6.     Enable DRE.

waas tfo optimize dre

By default, DRE is enabled.

7.     Enable LZ compression.

waas tfo optimize lz

By default, LZ compression is enabled.

Configuring a WAAS policy for UDP traffic

About this task

Perform this task to optimize UDP traffic with FEC and packet duplication.

Restrictions and guidelines

For an optimization action to take effect, you must enable the corresponding optimization feature.

As a best practice, configure a WAAS policy by modifying the predefined WAAS policy.

Procedure

1.     Enter system view.

system-view

2.     Create a WAAS policy and enter WAAS policy view.

waas policy policy-name

By default, a predefined WAAS policy named waas_default exists.

3.     Specify a WAAS class and enter WAAS policy class view.

rtp-class class-name [ insert-before existing_class ]

By default, no WAAS class is specified.

4.     Configure an optimization action.

optimize { fec | packet-dup }

By default, no action is configured.

Configuring a WAAS policy for RTP traffic

About this task

Perform this task to optimize RTP traffic with FEC and packet duplication.

Restrictions and guidelines

For an optimization action to take effect, you must enable the corresponding optimization feature.

As a best practice, configure a WAAS policy by modifying the predefined WAAS policy.

Procedure

1.     Enter system view.

system-view

2.     Create a WAAS policy and enter WAAS policy view.

waas policy policy-name

By default, a predefined WAAS policy named waas_default exists.

3.     Specify an RTP WAAS class and enter WAAS policy RTP class view.

rtp-class class-name [ insert-before existing_class ]

By default, no RTP WAAS class is specified.

4.     Configure an optimization action.

optimize { fec | packet-dup }

By default, no action is configured.

Applying a WAAS policy to an interface

About this task

Apply a WAAS policy to an interface that connects to the WAN. The device optimizes or passes through the traffic entering and leaving the WAN according to the configured policy. If the incoming and outgoing interfaces of the traffic are both connected to the WAN, the traffic is not optimized.

Restrictions and guidelines

A WAAS policy can be applied to multiple interfaces. Only one WAAS policy can be applied to an interface.

Procedure

1.     Enter system view.

system-view

2.     Enter interface view.

interface interface-type interface-number

3.     Apply a WAAS policy to the interface.

waas apply policy [ policy-name ]

By default, no WAAS policy is applied to an interface.

Specifying traffic processing slots for an interface

About this task

If a logical interface that spans cards or IRF member devices acts as a WAN interface, specify the slot of any member port in logical interface view as its traffic processing slot.

For high availability, you can specify one primary and one backup traffic processing slot by using the service command and the service standby command, respectively. The primary and backup slots must be different slots.

If you specify both primary and backup slots, the backup slot takes over when the primary slot becomes unavailable. The backup slot continues to process traffic for the interface after the primary slot becomes available again. The switchover will not occur until the backup slot becomes unavailable.

When both primary and backup slots are unavailable, the traffic is processed by the slot at which it arrives. The specified processing slot that first becomes available again takes over.

Restrictions and guidelines

To avoid processing slot switchover, specify the primary slot before specifying the backup slot. If you specify the backup slot before specifying the primary slot, traffic is switched over to the primary slot immediately after you specify the primary slot.

Procedure

1.     Enter system view.

system-view

2.     Enter interface view.

interface interface-type interface-number

3.     Specify the primary traffic processing slot for the interface.

In IRF mode:

service slot slot-number

By default, no primary traffic processing slot is specified for an interface.

For more information about this command, see Layer 2LAN Switching Command Reference.

4.     Specify the backup traffic processing slot for the interface.

In IRF mode:

service standby slot slot-number

By default, no backup traffic processing slot is specified for an interface.

For more information about this command, see Layer 2LAN Switching Command Reference.

Configuring WAAS to operate in asymmetric mode

About this task

If the device sends and receives packets on the same interface, the device should operate in symmetric mode. Perform this task if the device sends and receives packets on different interfaces.

Procedure

1.     Enter system view.

system-view

2.     Configure WAAS to operate in asymmetric mode.

waas asymmetric

By default, WAAS operates in symmetric mode.

Configuring TCP packet compression or decompression

About this task

You configure TCP packet compression on the upstream device and configure TCP packet decompression on the downstream device. The upstream device compresses packets and forwards them to the downstream device. The downstream device decompresses the received packets and then forwards them.

Restrictions and guidelines

Fragmented packets and packets with the Options field are not compressed or decompressed.

You can enable TCP packet compression or decompression for the same destination IP address, but not both.

After you specify an ACL to match TCP packets, the destination IP address and destination port number specified in the waas tcp destination command do not take effect.

Procedure

1.     Enter system view.

system-view

2.     Enable TCP packet compression or decompression.

waas tcp { compress [ max max-number ] | decompress }

By default, TCP packet compression and decompression is disabled.

3.     Specify an ACL to match the TCP packets that can be compressed or decompressed.

waas tcp acl { acl-number | name acl-name }

By default, no ACL is specified.

4.     Specify the destination IP address and destination port number of TCP packets to be compressed or decompressed.

waas tcp destination { ip-address port port-number | object-group ip-object-group-name port object-group port-object-group-name }

By default, no destination IP address and destination port number are specified.

Configuring UDP message compression or decompression

About this task

You configure UDP message compression on the upstream device and configure UDP message decompression on the downstream device. The upstream device compresses packets and forwards them to the downstream device. The downstream device decompresses the received packets and then forwards them.



Restrictions and guidelines

Fragmented packets and packets with the Options field are not compressed or decompressed.

You can enable UDP message compression or decompression for the same destination IP address, but not both.

After you specify an ACL to match UDP messages, the destination IP address and destination port number specified in the waas udp destination command do not take effect.

Procedure

1.     Enter system view.

system-view

2.     Enable UDP message compression or decompression.

waas udp { compress [ max max-number ] | decompress }

By default, UDP message compression and decompression is disabled.

3.     Specify an ACL to matched UDP messages that can be compressed or decompressed.

waas udp acl { acl-number | name acl-name }

By default, no ACL is specified.

4.     Specify the destination IP address and destination port number of UDP messages to be compressed or decompressed.

waas udp destination { ip-address port port-number | object-group ip-object-group-name port object-group port-object-group-name }

By default, no destination IP address and destination port number are specified.

Restoring predefined WAAS settings

About this task

This feature allows you to restore the predefined WAAS policy and WAAS classes to their configurations when the WAAS process starts for the first time.

Restrictions and guidelines

To successfully restore predefined WAAS settings, make sure none of the interfaces has a WAAS policy applied.

Procedure

1.     Enter system view.

system-view

2.     Restore predefined WAAS settings.

waas config restore-default

Setting the reorder timeout timer for load balancing packets

About this task

With load balancing enabled on the device, the sender forwards the packets on all paths with the same cost to the destination. This can cause packet disorder on the receiver. WAAS numbers the packets to be sent based on the order in which the packets will be sent, for example, 1, 2... n. The receiver reorders and forwards the packets. With the load balancing packet reorder timeout timer set, if no packet with a smaller sequence number is received, the receiver will cache the received packets and send the packets in sequence after a packet with a smaller sequence number arrives. If the receiver does not receive a packet with a smaller sequence number before the reorder timeout timer expires, the receiver will directly send the cached packets.

Restrictions and guidelines

This feature is supported only for per-packet load balancing.

Procedure

1.     Enter system view.

system-view

2.     Set the reorder timeout timer for load balancing packets.

waas load-balance reorder timeout timeout

By default, the reorder timeout timer is 100 ms for load balancing packets.

Deleting all WAAS settings

About this task

This feature allows you to delete all configuration data and running data for WAAS and to exit the WAAS process.

Procedure

1.     Enter system view.

system-view

2.     Delete all WAAS settings.

waas config remove-all

Display and maintenance commands for WAAS

Execute display commands in any view and reset commands in user view.



Task

Command

Display WAAS class configuration.

display waas class [ class-name ]

Display the FEC information of peers.

display waas fec ipv4 peer-info [ source-ip source-ip ] [ source-port source-port ] [ destination-ip destination-ip ] [ destination-port destination-port ]

Display WAAS policy configuration.

display waas policy [ policy-name ]

Display RTP WAAS class configuration.

display waas rtp-class [ class-name ]

Display WAAS session information.

In standalone mode:

display waas session { ipv4 | ipv6 } [ client-ip client-ip ] [ client-port client-port ] [ server-ip server-ip ] [ server-port server-port ] [ peer-id peer-id ] [ verbose ]

In IRF mode:

display waas session { ipv4 | ipv6 } [ client-ip client-ip ] [ client-port client-port ] [ server-ip server-ip ] [ server-port server-port ] [ peer-id peer-id ] [ verbose ] [ slot slot-number ]

Display DRE statistics.

In standalone mode:

display waas statistics dre [ peer peer-id ]

In IRF mode:

display waas statistics dre [ peer peer-id ] [ slot slot-number ]

Display FEC packet statistics.

display waas statistics fec

Display load balancing packet statistics.

display waas statistics load-balance

Display packet statistics of packet duplication.

display waas statistics packet-dup { ipv4 | ipv6 }

Display TCP packet compression statistics.

display waas statistics tcp compress

Display UDP message compression statistics.

display waas statistics udp compress

Display the global WAAS status.

display waas status

Display autodiscovered blacklist information.

In standalone mode:

display waas tfo auto-discovery blacklist { ipv4 | ipv6 }

In IRF mode:

display waas tfo auto-discovery blacklist { ipv4 | ipv6 } [ slot slot-number ]

Clear the DRE data dictionary.

reset waas cache dre [ peer-id peer-id ]

Clear DRE statistics.

reset waas statistics dre [ peer-id peer-id ]

Clear FEC packet statistics.

reset waas statistics fec

Clear load balancing packet statistics.

reset waas statistics load-balance

Clear packet statistics of packet duplication.

reset waas statistics packet-dup { ipv4 | ipv6 }

Clear TCP packet compression statistics.

reset waas statistics tcp compress

Clear UDP message compression statistics.

reset waas statistics udp compress

Clear all blacklist entries.

reset waas tfo auto-discovery blacklist



WAAS configuration examples

Example: Applying the predefined WAAS policy

Network configuration

As shown in Figure 1, apply the predefined WAAS policy on Router A and Router B.

The host downloads data from the server. Examine the optimization effect by comparing DRE statistics for the first download and second download.

·     For the first download, both WAAS devices create data dictionary entries and Router A sends both indexes and metadata.

·     For the second download, Router A replaces repeated data with indexes.

Figure 1 Network diagram

Procedure

1.     Configure IP addresses for interfaces. (Details not shown.)

2.     Configure routing protocols to ensure connectivity. (Details not shown.)

3.     Disable fast forwarding load sharing:

# Disable fast forwarding load sharing on Router A.

<RouterA> system-view

[RouterA] undo ip fast-forwarding load-sharing

# Disable fast forwarding load sharing on Router B.

<RouterB> system-view

[RouterB] undo ip fast-forwarding load-sharing

4.     Apply the predefined WAAS policy to GigabitEthernet 1/0/1 on Router A.

[RouterA] interface gigabitethernet 1/0/1

[RouterA-GigabitEthernet1/0/1] waas apply policy

[RouterA-GigabitEthernet1/0/1] quit

[RouterA] quit

5.     Apply the predefined WAAS policy to GigabitEthernet 1/0/1 on Router B.

[RouterB] interface gigabitethernet 1/0/1

[RouterB-GigabitEthernet1/0/1] waas apply policy

6.     Download a test file of 14 MB from the server to the host.

7.     Clear DRE statistics on Router A.

<RouterA> reset waas statistic dre

8.     Download the same file from the server to the host.

Verifying the configuration

# After the first download, display DRE statistics on Router A.

<RouterA> display waas statistic dre

Peer-ID: cc3e-5fd8-5158

Peer version: 1.0

Cache in storage: 12710912 bytes

Index number: 49652

Age: 00 weeks, 00 days, 00 hours, 00 minutes, 35 seconds

Total connections: 1

Active connections: 0

Encode Statistics

  Dre msgs: 2

  Bytes in: 286 bytes

  Bytes out: 318 bytes

  Bypass bytes: 0 bytes

  Bytes Matched: 0 bytes

  Space saved: -11%

  Average latency: 0 usec

Decode Statistics

  Dre msgs: 57050

  Bytes in: 14038391 bytes

  Bytes out: 14079375 bytes

  Bypass bytes: 0 bytes

  Space saved: 0%

  Average latency: 0 usec

# After the second download, display DRE statistics on Router A.

<RouterA> display waas statistic dre

Peer-ID: cc3e-5fd8-5158

Peer version: 1.0

Cache in storage: 12851200 bytes

Index number: 50200

Age: 00 weeks, 00 days, 00 hours, 2 minutes, 56 seconds

Total connections: 1

Active connections: 0

Encode Statistics

  Dre msgs: 2

  Bytes in: 286 bytes

  Bytes out: 60 bytes

  Bypass bytes: 0 bytes

  Bytes Matched: 256 bytes

  Space saved: 79%

  Average latency: 0 usec

Decode Statistics

  Dre msgs: 62791

  Bytes in: 2618457 bytes

  Bytes out: 13972208 bytes

  Bypass bytes: 0 bytes

  Space saved: 81%

  Average latency: 0 usec

In the second download, the number of received bytes for decompression is much more smaller, and the download speed is much faster.

Example: Configuring a user-defined WAAS policy

Network configuration

As shown in Figure 2, configure and apply a user-defined WAAS policy on Router A and Router B.

The host downloads data from the server. Examine the optimization effect by comparing DRE statistics for the first download and second download.

·     For the first download, both WAAS devices need to create data dictionary entries and Router A sends both indexes and metadata.

·     For the second download, Router A replaces repeated data with indexes.

Figure 2 Network diagram

Procedure

1.     Configure IP addresses for interfaces. (Details not shown.)

2.     Configure routing protocols to ensure connectivity. (Details not shown.)

3.     Disable fast forwarding load sharing:

# Disable fast forwarding load sharing on Router A.

<RouterA> system-view

[RouterA] undo ip fast-forwarding load-sharing

# Disable fast forwarding load sharing on Router B.

<RouterB> system-view

[RouterB] undo ip fast-forwarding load-sharing

4.     Configure WAAS classes:

# Create a WAAS class named c1 on Router A, and configure the WAAS class to match any TCP packets.

[RouterA] waas class c1

[RouterA-waasclass-c1] match 1 tcp any

[RouterA-waasclass-c1] quit

# Create a WAAS class named c1 on Router B, and configure the WAAS class to match any TCP packets.

[RouterB] waas class c1

[RouterB-waasclass-c1] match tcp any

[RouterB-waasclass-c1] quit

5.     Configure WAAS policies:

# Create a WAAS policy named p1 on Router A, and specify WAAS class c1. Configure TFO, DRE, and LZ optimization actions for the WAAS class.

[RouterA] waas policy p1

[RouterA-waaspolicy-p1] class c1

[RouterA-waaspolicy-p1-c1] optimize tfo dre lz

[RouterA-waaspolicy-p1-c1] quit

[RouterA-waaspolicy-p1] quit

# Create a WAAS policy named p1 on Router B, and specify WAAS class c1. Configure TFO, DRE, and LZ optimization actions for the WAAS class.

[RouterB] waas policy p1

[RouterB-waaspolicy-p1] class c1

[RouterB-waaspolicy-p1-c1] optimize tfo dre lz

[RouterB-waaspolicy-p1-c1] quit

[RouterB-waaspolicy-p1] quit

6.     Apply WAAS policies:

# Apply WAAS policy p1 to GigabitEthernet 1/0/1 on Router A.

<RouterA> system-view

[RouterA] interface gigabitethernet 1/0/1

[RouterA-GigabitEthernet1/0/1] waas apply policy p1

[RouterA-GigabitEthernet1/0/1] quit

[RouterA] quit

# Apply WAAS policy p1 to GigabitEthernet 1/0/1 on Router B.

[RouterB] interface gigabitethernet 1/0/1

[RouterB-GigabitEthernet1/0/1] waas apply policy p1

[RouterB-GigabitEthernet1/0/1] quit

[RouterB] quit

7.     Download a test file of 14 MB from the server to the host.

8.     Clear DRE statistics on Router A.

<RouterA> reset waas statistic dre

9.     Download the same file from the server to the host.

Verifying the configuration

# After the first download, display DRE statistics on Router A.

<RouterA> display waas statistic dre

Peer-ID: cc3e-5fd8-5158

Peer version: 1.0

Cache in storage: 12718592 bytes

Index number: 49682

Age: 00 weeks, 00 days, 00 hours, 00 minutes, 35 seconds

Total connections: 1

Active connections: 0

Encode Statistics

  Dre msgs: 2

  Bytes in: 286 bytes

  Bytes out: 318 bytes

  Bypass bytes: 0 bytes

  Bytes Matched: 0 bytes

  Space saved: -11%

  Average latency: 0 usec

Decode Statistics

  Dre msgs: 56959

  Bytes in: 13999244 bytes

  Bytes out: 14055291 bytes

  Bypass bytes: 0 bytes

  Space saved: 0%

  Average latency: 0 usec

# After the second download, display DRE statistics on Router A.

<RouterA> display waas statistic dre

Peer-ID: cc3e-5fd8-5158

Peer version: 1.0

Cache in storage: 12857856 bytes

Index number: 50226

Age: 00 weeks, 00 days, 00 hours, 2 minutes, 02 seconds

Total connections: 1

Active connections: 0

Encode Statistics

  Dre msgs: 2

  Bytes in: 286 bytes

  Bytes out: 60 bytes

  Bypass bytes: 0 bytes

  Bytes Matched: 256 bytes

  Space saved: 79%

  Average latency: 0 usec

Decode Statistics

  Dre msgs: 62687

  Bytes in: 2592183 bytes

  Bytes out: 13972208 bytes

  Bypass bytes: 0 bytes

  Space saved: 81%

  Average latency: 0 usec

In the second download, the number of received bytes for decompression is much more smaller, and the download speed is much faster.

Example: Configuring UDP message compression and decompression

Network configuration

As shown in Figure 3, the IP address of the server is 172.16.105.48.

Configure UDP message compression and decompression to meet the following requirements:

·     Router A compresses UDP messages from the host and then forwards them to Router B.

·     Router B decompresses the UDP messages from Router A and then forwards them to the server.

Figure 3 Network diagram

Procedure

1.     Configure IP addresses for interfaces. (Details not shown.)

2.     Configure routing protocols to ensure connectivity. (Details not shown.)

3.     Disable fast forwarding load sharing:

# Disable fast forwarding load sharing on Router A.

<RouterA> system-view

[RouterA] undo ip fast-forwarding load-sharing

# Disable fast forwarding load sharing on Router B.

<RouterB> system-view

[RouterB] undo ip fast-forwarding load-sharing

4.     Configure UDP message compression and decompression:

# Enable UDP message compression on Router A.

<RouterA> system-view

[RouterA] waas udp compress

# Specify that UDP messages with destination IP address 172.16.105.48 and destination port number 5000 are compressed.

[RouterA] waas udp destination 172.16.105.48 port 5000

# Enable UDP message decompression on Router B.

<RouterB> system-view

[RouterB] waas udp decompress

# Specify that UDP messages with destination IP address 172.16.105.48 and destination port number 5000 are decompressed.

[RouterB] waas udp destination 172.16.105.48 port 5000

Verifying the configuration

# Display UDP message compression statistics on Router A.

[RouterA] display waas statistic udp compress

Bytes in                : 30106991182

Bytes out               : 375556018

Saved bandwidth ratio   : 98.75%

Compressed packet ratio : 100.00%

The output shows that the bandwidth is saved by 98.75% through UDP message compression.

Example: Configuring FEC

Network configuration

As shown in Figure 4, configure FEC and Router A and Router B to recover audio packets and video packets lost during transmission from the host to the server.

Figure 4 Network diagram

Procedure

1.     Configure IP addresses for interfaces. (Details not shown.)

2.     Configure routing protocols to ensure connectivity. (Details not shown.)

3.     Configure RTP WAAS classes:

# On Router A, create an RTP WAAS class named waas_rtp, and configure the WAAS class to match the UDP packets with destination IP address 172.16.105.48/24.

<RouterA> system-view

[RouterA] waas rtp-class waas_rtp

[RouterA-waasrtpclass-waas_rtp] match udp destination ip-address 172.16.105.48 24

# On Router B, create an RTP WAAS class named waas_rtp, and configure the WAAS class to match the UDP packets with destination IP address 172.16.105.48/24.

<RouterB> system-view

[RouterB] waas rtp-class waas_rtp

[RouterB-waasrtpclass-waas_rtp] match udp destination ip-address 172.16.105.48 24

4.     Configure WAAS policies:

# On Router A, create a WAAS policy named policy_fec, and specify RTP WAAS class waas_rtp. Configure the FEC optimization action, FEC average ratio 30%, encoding timeout time 200 milliseconds, and block size 40 for the WAAS class.

<RouterA> system-view

[RouterA] waas policy policy_fec

[RouterA-waaspolicy-policy_fec] rtp-class waas_rtp

[RouterA-waaspolicy-policy_fec-waas_rtp] optimize fec

[RouterA-waaspolicy-policy_fec-waas_rtp] fec average-ratio 30

[RouterA-waaspolicy-policy_fec-waas_rtp] fec encode timeout 200

[RouterA-waaspolicy-policy_fec-waas_rtp] fec block-size 40

# On Router B, create a WAAS policy named policy_fec, and specify RTP WAAS class waas_rtp. Configure the FEC optimization action and decoding timeout time 1000 milliseconds for the WAAS class.

<RouterB> system-view

[RouterB] waas policy policy_fec

[RouterB-waaspolicy-policy_fec] rtp-class waas_rtp

[RouterB-waaspolicy-policy_fec-waas_rtp] optimize fec

[RouterB-waaspolicy-policy_fec-waas_rtp] fec decode timeout 1000

5.     Apply WAAS policies:

# Apply WAAS policy policy_fec to GigabitEthernet 1/0/1 on Router A.

<RouterA> system-view

[RouterA] interface gigabitethernet 1/0/1

[RouterA-GigabitEthernet1/0/1] waas apply policy policy_fec

# Apply WAAS policy policy_fec to GigabitEthernet 1/0/1 on Router B.

<RouterB> system-view

[RouterB] interface gigabitethernet 1/0/1

[RouterB-GigabitEthernet1/0/1] waas apply policy policy_fec

Verifying the configuration

# Display FEC packet statistics on Router A.

<RouterA> display waas statistics fec

Encoder:

  Received:

    Total packets                                                     : 5931

  Sent:

    Original packets                                                  : 5915

    Redundant packets                                                 : 3254

    In-order original packets after timeout                           : 15

    Out-of-order original packets after timeout                       : 16

Decoder:

  Received:

    Original packets                                                  : 5611

    Redundant packets                                                 : 3081

    Original packets in different group                               : 0

    Redundant packets in different group from cached redundant packets: 0

    Redundant packets in different group from cached original packets : 10

    Redundant packets with sequence number less than cached ones      : 0

  Sent:

    Original packets                                                  : 5611

    Recovered packets                                                 : 0

    In-order original packets after timeout                           : 0

# Display FEC packet statistics on Router B.

<RouterB> display waas statistics fec

Encoder:

  Received:

    Total packets                                                     : 5610

  Sent:

    Original packets                                                  : 5601

    Redundant packets                                                 : 3081

    In-order original packets after timeout                           : 21

    Out-of-order original packets after timeout                       : 9

Decoder:

  Received:

    Original packets                                                  : 5932

    Redundant packets                                                 : 3254

    Original packets in different group                               : 0

    Redundant packets in different group from cached redundant packets: 0

    Redundant packets in different group from cached original packets : 17

    Redundant packets with sequence number less than cached ones      : 0

  Sent:

    Original packets                                                  : 5932

    Recovered packets                                                 : 0

    In-order original packets after timeout                           : 0



  • Cloud & AI
  • InterConnect
  • Intelligent Computing
  • Security
  • SMB Products
  • Intelligent Terminal Products
  • Product Support Services
  • Technical Service Solutions
All Services
  • Resource Center
  • Policy
  • Online Help
All Support
  • Become a Partner
  • Partner Resources
  • Partner Business Management
All Partners
  • Profile
  • News & Events
  • Online Exhibition Center
  • Contact Us
All About Us
新华三官网
