CLI example: Using vSystems for enterprise network isolation (non-default vSystems have public network interfaces)

Network configuration

As shown in the figure below:

• The device acts as a security gateway.

• The internal network is divided into Network A for the R&D department and Network B for non-R&D departments. Users in Network A and Network B are isolated.

• In Network A, only users in subnet 192.168.1.128/25 can use independent public network interfaces to access the Internet. In Network B, all users can use independent public network interfaces to access the Internet.

Figure-1 Network diagram

Software versions used

This configuration example was created and verified on R9900P2705 of the F5000-AI-55-G device.

Procedures

Configuring vSystem vsys1

1. Create vSystem vsys1 and assign interfaces to the vSystem:

   # Create vSystem vsys1 and configure a description for the vSystem.

   <Device> system-view

   [Device] vsys vsys1

   [Device-vsys-2-vsys1] description vsys-1

   # Assign interfaces GigabitEthernet 1/0/1 and GigabitEthernet 1/0/2 to vSystem vsys1.

   [Device-vsys-2-vsys1] allocate interface gigabitethernet 1/0/1

   Some configurations on the interface are removed.

   [Device-vsys-2-vsys1] allocate interface gigabitethernet 1/0/2

   Some configurations on the interface are removed.

   [Device-vsys-2-vsys1] quit

2. Log in to vSystem vsys1, assign IP addresses to interfaces, and add interfaces to security zones:

   # Log in to vSystem vsys1.

   [Device] switchto vsys vsys1

   <Device-vsys1> system-view

   # Assign IP addresses to interfaces.

   [Device-vsys1] interface gigabitethernet 1/0/1

   [Device-vsys1-GigabitEthernet1/0/1] ip address 1.1.1.1 24

   [Device-vsys1-GigabitEthernet1/0/1] quit

   [Device-vsys1] interface gigabitethernet 1/0/2

   [Device-vsys1-33] ip address 192.168.1.1 24

   [Device-vsys1-33] quit

   # Add interfaces to security zones.

   [Device-vsys1] security-zone name trust

   [Device-vsys1-security-zone-Trust] import interface gigabitethernet 1/0/2

   [Device-vsys1-security-zone-Trust] quit

   [Device-vsys1] security-zone name untrust

   [Device-vsys1-security-zone-Untrust] import interface gigabitethernet 1/0/1

   [Device-vsys1-security-zone-Untrust] quit

3. Configure settings for routing. This example configures a static route. In the route, the next hop IP address is 1.1.1.2 for users in vSystem vsys1 to access the Internet.

   [Device-vsys1] ip route-static 0.0.0.0 0 1.1.1.2

4. Configure a rule named trust-untrust in the IPv4 security policy to allow users in subnet 192.168.1.128/25 to access the Internet.

   [Device-vsys1] security-policy ip

   [Device-vsys1-security-policy-ip] rule name trust-untrust

   [Device-vsys1-security-policy-ip-1-trust-untrust] source-zone trust

   [Device-vsys1-security-policy-ip-1-trust-untrust] destination-zone untrust

   [Device-vsys1-security-policy-ip-1-trust-untrust] source-ip-subnet 192.168.1.128 25

   [Device-vsys1-security-policy-ip-1-trust-untrust] action pass

   [Device-vsys1-security-policy-ip-1-trust-untrust] quit

   [Device-vsys1-security-policy-ip] quit

5. Configure NAT:

   # Configure ACL 2000, and create a rule to permit the packets only from 192.168.1.128/25 to be translated.

   [Device-vsys1] acl basic 2000

   [Device-vsys1-acl-ipv4-basic-2000] rule permit source 192.168.1.128 0.0.0.127

   [Device-vsys1-acl-ipv4-basic-2000] quit

   # Enable outbound dynamic NAT with Easy IP on interface GigabitEthernet 1/0/1 so that NAT translates the source addresses of the packets matching the ACL and destined for the Internet into the IP address of interface GigabitEthernet 1/0/1.

   [Device-vsys1] interface gigabitethernet 1/0/1

   [Device-vsys1-GigabitEthernet1/0/1] nat outbound 2000

6. Return to the default vSystem from vSystem vsys1.

   [Device-vsys1-GigabitEthernet1/0/1] return

   <Device-vsys1> quit

   [Device]

Configuring vSystem vsys2

1. Create vSystem vsys2 and assign interfaces to the vSystem:

   # Create vSystem vsys2 and configure a description for the vSystem.

   [Device] vsys vsys2

   [Device-vsys-3-vsys2] description vsys-2

   # Assign interfaces GigabitEthernet 1/0/3 and GigabitEthernet 1/0/4 to vSystem vsys2.

   [Device-vsys-3-vsys2] allocate interface gigabitethernet 1/0/3

   Some configurations on the interface are removed.

   [Device-vsys-3-vsys2] allocate interface gigabitethernet 1/0/4

   Some configurations on the interface are removed.

   [Device-vsys-3-vsys2] quit

2. Log in to vSystem vsys2, assign IP addresses to interfaces, and add interfaces to security zones:

   # Log in to vSystem vsys2.

   [Device] switchto vsys vsys2

   <Device-vsys2> system-view

   # Assign IP addresses to interfaces.

   [Device-vsys2] interface gigabitethernet 1/0/3

   [Device-vsys2-GigabitEthernet1/0/3] ip address 1.1.2.1 24

   [Device-vsys2-GigabitEthernet1/0/3] quit

   [Device-vsys2] interface gigabitethernet 1/0/4

   [Device-vsys2-GigabitEthernet1/0/4] ip address 192.168.2.1 24

   [Device-vsys2-GigabitEthernet1/0/4] quit

   # Add interfaces to security zones.

   [Device-vsys2] security-zone name trust

   [Device-vsys2-security-zone-Trust] import interface gigabitethernet 1/0/4

   [Device-vsys2-security-zone-Trust] quit

   [Device-vsys2] security-zone name untrust

   [Device-vsys2-security-zone-Untrust] import interface gigabitethernet 1/0/3

   [Device-vsys2-security-zone-Untrust] quit

3. Configure settings for routing. This example configures a static route. In the route, the next hop IP address is 1.1.2.2 for users in vSystem vsys2 to access the Internet.

   [Device-vsys2] ip route-static 0.0.0.0 0 1.1.2.2

4. Configure a rule named trust-untrust in the IPv4 security policy to allow users in subnet 192.168.2.0/24 to access the Internet.

   [Device-vsys2] security-policy ip

   [Device-vsys2-security-policy-ip] rule name trust-untrust

   [Device-vsys2-security-policy-ip-1-trust-untrust] source-zone trust

   [Device-vsys2-security-policy-ip-1-trust-untrust] destination-zone untrust

   [Device-vsys2-security-policy-ip-1-trust-untrust] source-ip-subnet 192.168.2.0 24

   [Device-vsys2-security-policy-ip-1-trust-untrust] action pass

   [Device-vsys2-security-policy-ip-1-trust-untrust] quit

   [Device-vsys2-security-policy-ip] quit

5. Configure NAT:

   # Configure ACL 2000, and create a rule to permit the packets only from 192.168.2.0/24 to be translated.

   [Device-vsys2] acl basic 2000

   [Device-vsys2-acl-ipv4-basic-2000] rule permit source 192.168.2.0 0.0.0.255

   [Device-vsys2-acl-ipv4-basic-2000] quit

   # Enable outbound dynamic NAT with Easy IP on interface GigabitEthernet 1/0/3 so that NAT translates the source addresses of the packets matching the ACL and destined for the Internet into the IP address of interface GigabitEthernet 1/0/3.

   [Device-vsys2] interface gigabitethernet 1/0/3

   [Device-vsys2-GigabitEthernet1/0/3] nat outbound 2000

6. Return to the default vSystem from vSystem vsys2.

   [Device-vsys2-GigabitEthernet1/0/3] return

   <Device-vsys2> quit

   [Device]

Verifying the configuration

# Verify that the vSystems are running correctly on the device. The device has three active vSystems.

[Device] display vsys

ID Name Status Description

1 Admin Active Default

2 vsys1 Active vsys-1

3 vsys2 Active vsys-2

# Verify that users in subnet 192.168.1.128/25 can access the Internet.

C:\> ping 3.3.3.3

Pinging 3.3.3.3 with 32 bytes of data:

Reply from 3.3.3.3: bytes=32 time=51ms TTL=255

Reply from 3.3.3.3: bytes=32 time=44ms TTL=255

Reply from 3.3.3.3: bytes=32 time=1ms TTL=255

Reply from 3.3.3.3: bytes=32 time=1ms TTL=255

Ping statistics for 3.3.3.3:

Packets: Sent = 4, Received = 4, Lost = 0 (0% loss),

Approximate round trip times in milli-seconds:

Minimum = 1ms, Maximum = 51ms, Average = 24ms

# Verify that users in subnet 192.168.2.0/24 can access the Internet.

C:\> ping 3.3.3.3

Pinging 3.3.3.3 with 32 bytes of data:

Reply from 3.3.3.3: bytes=32 time=25ms TTL=255

Reply from 3.3.3.3: bytes=32 time=36ms TTL=255

Reply from 3.3.3.3: bytes=32 time=1ms TTL=255

Reply from 3.3.3.3: bytes=32 time=1ms TTL=255

Ping statistics for 3.3.3.3:

Packets: Sent = 4, Received = 4, Lost = 0 (0% loss),

Approximate round trip times in milli-seconds:

Minimum = 1ms, Maximum = 36ms, Average = 16ms

Configuration files

#

vsys vsys1 id 2

description vsys1

allocate interface GigabitEthernet1/0/1.1

#

vsys vsys2 id 3

description vsys2

allocate interface GigabitEthernet1/0/1.2

#

interface GigabitEthernet1/0/1.1

vlan-type dot1q vid 10

#

interface GigabitEthernet1/0/1.2

vlan-type dot1q vid 20

#

ip route-static vpn-instance vsys1 10.20.0.0 24 vpn-instance vsys2

ip route-static vpn-instance vsys2 10.10.0.0 24 vpn-instance vsys1

#

switchto vsys vsys1

#

security-zone name Trust

import interface GigabitEthernet1/0/1.1

#

security-zone name Untrust

import interface vSys-interface2

#

security-policy ip

rule 0 name vpc1

action pass

source-zone trust

destination-zone untrust

rule 1 name vpc2

action pass

source-zone untrust

destination-zone trust

#

switchto vsys vsys2

#

security-zone name Trust

import interface GigabitEthernet1/0/1.2

#

security-zone name Untrust

import interface vSys-interface3

#

security-policy ip

rule 0 name vpc1

action pass

source-zone trust

destination-zone untrust

rule 1 name vpc2

#
