CLI example: Configuring security zone-based attack detection and prevention

Network configuration

As shown in Figure 1, the device is the gateway for the internal network.

Configure an attack defense policy and apply the policy to security zone Untrust to meet the following requirements:

Provide low-level scanning attack detection for the internal network. If a scanning attack is detected, log the attack and keep the attacker on the blacklist for 10 minutes.

Protect internal hosts and servers against smurf attacks. If a smurf attack is detected, log the attack.

Protect the internal server against SYN flood attacks. If the number of SYN packets sent to the server per second reaches or exceeds 5000, log the attack and drop subsequent packets.

Figure 1 Network diagram

Software versions used

This configuration example was created and verified on E8371 of the F5000-AI160 device.

Procedures

Assign IP addresses to interfaces:

Assign an IP address to interface GigabitEthernet 1/0/1.

<Device> system-view

[Device] interface gigabitethernet 1/0/1

[Device-GigabitEthernet1/0/1] ip address 192.168.1.1 255.255.0.0

[Device-GigabitEthernet1/0/1] quit

# Assign IP addresses to other interfaces in the same way. (Details not shown.)

Add interfaces to security zones.

[Device] security-zone name trust

[Device-security-zone-Trust] import interface gigabitethernet 1/0/1

[Device-security-zone-Trust] quit

[Device] security-zone name untrust

[Device-security-zone-Untrust] import interface gigabitethernet 1/0/2

[Device-security-zone-Untrust] quit

[Device] security-zone name dmz

[Device-security-zone-DMZ] import interface gigabitethernet 1/0/3

[Device-security-zone-DMZ] quit

Configure a security policy:

# Configure a rule named trust-untrust to allow hosts in security zone trust to access the Internet.

[Device] security-policy ip

[Device-security-policy-ip] rule name trust-untrust

[Device-security-policy-ip-1-trust-untrust] source-zone trust

[Device-security-policy-ip-1-trust-untrust] destination-zone untrust

[Device-security-policy-ip-1-trust-untrust] source-ip-subnet 192.168.0.0 16

[Device-security-policy-ip-1-trust-untrust] action pass

[Device-security-policy-ip-1-trust-untrust] quit

# Configure a rule named untrust-dmz to allow hosts on the Internet to access the server.

[Device-security-policy-ip] rule name untrust-dmz

[Device-security-policy-ip-2-untrust-dmz] source-zone untrust

[Device-security-policy-ip-2-untrust-dmz] destination-zone dmz

[Device-security-policy-ip-2-untrust-dmz] destination-ip-host 10.1.1.2

[Device-security-policy-ip-2-untrust-dmz] action pass

[Device-security-policy-ip-2-untrust-dmz] quit

[Device-security-policy-ip] quit

Configure an attack defense policy:

# Create attack defense policy a1.

[Device] attack-defense policy a1

# Configure signature detection for smurf attacks, and specify logging as the prevention action.

[Device-attack-defense-policy-a1] signature detect smurf action logging

# Configure low-level scanning attack detection, specify logging and block-source as the prevention actions, and set the blacklist entry aging time to 10 minutes.

[Device-attack-defense-policy-a1] scan detect level low action logging block-source timeout 10

# Configure SYN flood attack detection for 10.1.1.2, set the attack prevention triggering threshold to 5000, and specify logging and drop as the prevention actions.

[Device-attack-defense-policy-a1] syn-flood detect ip 10.1.1.2 threshold 5000 action logging drop

[Device-attack-defense-policy-a1] quit

# Apply attack defense policy a1 to security zone Untrust.

[Device] security-zone name untrust

[Device-security-zone-Untrust] attack-defense apply policy a1

[Device-security-zone-Untrust] quit

# Enable the global blacklist feature.

[Device] blacklist global enable

Verifying the configuration

# Verify that attack defense policy a1 is successfully configured.

[Device] display attack-defense policy a1

Attack-defense Policy Information

--------------------------------------------------------------------------

Policy name : a1

Applied list : Untrust

--------------------------------------------------------------------------

Exempt IPv4 ACL : Not configured

Exempt IPv6 ACL : Not configured

--------------------------------------------------------------------------

Actions: CV-Client verify BS-Block source L-Logging D-Drop N-None

Signature attack defense configuration:

Signature name Defense Level Actions

Fragment Disabled low L

Impossible Disabled medium L,D

Teardrop Disabled medium L,D

Tiny fragment Disabled low L

IP option abnormal Disabled medium L,D

Smurf Enabled medium L

Traceroute Disabled low L

Ping of death Disabled medium L,D

Large ICMP Disabled info L

Max length 4000 bytes

Large ICMPv6 Disabled info L

Max length 4000 bytes

TCP invalid flags Disabled medium L,D

TCP null flag Disabled medium L,D

TCP all flags Disabled medium L,D

TCP SYN-FIN flags Disabled medium L,D

TCP FIN only flag Disabled medium L,D

TCP Land Disabled medium L,D

Winnuke Disabled medium L,D

UDP Bomb Disabled medium L,D

UDP Snork Disabled medium L,D

UDP Fraggle Disabled medium L,D

IP option record route Disabled info L

IP option internet timestamp Disabled info L

IP option security Disabled info L

IP option loose source routing Disabled info L

IP option stream ID Disabled info L

IP option strict source routing Disabled info L

IP option route alert Disabled info L

ICMP echo request Disabled info L

ICMP echo reply Disabled info L

ICMP source quench Disabled info L

ICMP destination unreachable Disabled info L

ICMP redirect Disabled info L

ICMP time exceeded Disabled info L

ICMP parameter problem Disabled info L

ICMP timestamp request Disabled info L

ICMP timestamp reply Disabled info L

ICMP information request Disabled info L

ICMP information reply Disabled info L

ICMP address mask request Disabled info L

ICMP address mask reply Disabled info L

ICMPv6 echo request Disabled info L

ICMPv6 echo reply Disabled info L

ICMPv6 group membership query Disabled info L

ICMPv6 group membership report Disabled info L

ICMPv6 group membership reduction Disabled info L

ICMPv6 destination unreachable Disabled info L

ICMPv6 time exceeded Disabled info L

ICMPv6 parameter problem Disabled info L

ICMPv6 packet too big Disabled info L

IPv6 extension header abnormal Disabled Info L

IPv6 extension header exceeded Disabled Info L

Limit 7

Scan attack defense configuration:

Defense : Enabled

Level : low

Actions : L,BS(10)

Flood attack defense configuration:

Flood type Global thres(pps) Global actions Service ports Non-specific

DNS flood 1000 - 53 Disabled

HTTP flood 1000 - 80 Disabled

SIP flood 1000 - 5060 Disabled

SYN flood 5000 L,D - Enabled

ACK flood 1000 - - Disabled

SYN-ACK flood 1000 - - Disabled

RST flood 1000 - - Disabled

FIN flood 1000 - - Disabled

UDP flood 1000 - - Disabled

ICMP flood 1000 - - Disabled

ICMPv6 flood 1000 - - Disabled

Flood attack defense for protected IP addresses:

Address VPN instance Flood type Thres(pps) Actions Ports

10.1.1.2 -- SYN-FLOOD 5000 L,D -

# Verify that the attack detection and prevention takes effect on security zone Untrust.

[Device] display attack-defense statistics security-zone untrust

Attack policy name: a1

Scan attack defense statistics:

AttackType AttackTimes Dropped

Port scan 2 0

IP sweep 3 0

Flood attack defense statistics:

AttackType AttackTimes Dropped

SYN flood 1 5000

Signature attack defense statistics:

AttackType AttackTimes Dropped

Smurf 1 0

# Verify that the IPv4 blacklist collaborates with the scanning attack detection.

[Device] display blacklist ip

IP address VPN instance DS-Lite tunnel peer Type TTL(sec) Dropped

5.5.5.5 -- -- Dynamic 600 353452

Configuration files

interface GigabitEthernet1/0/1

port link-mode route

ip address 192.168.1.1 255.255.0.0

interface GigabitEthernet1/0/2

port link-mode route

ip address 202.1.0.1 255.255.0.0

interface GigabitEthernet1/0/3

port link-mode route

ip address 10.1.1.1 255.255.255.0

security-zone name Trust

import interface GigabitEthernet1/0/1

security-zone name DMZ

import interface GigabitEthernet1/0/3

security-zone name Untrust

import interface GigabitEthernet1/0/2

attack-defense apply policy a1

blacklist global enable

attack-defense policy a1

scan detect level low action logging block-source

syn-flood detect ip 10.1.1.2 threshold 5000 action logging drop

signature detect smurf action logging

security-policy ip

rule 1 name trust-untrust

action pass

source-zone trust

destination-zone untrust

source-ip-subnet 192.168.0.0 255.255.0.0

rule 2 name untrust-dmz

action pass

source-zone untrust

destination-zone dmz

destination-ip-host 10.1.1.2
