CLI方式：在OSPF中引入IS-IS路由时应用路由策略典型配置

使用版本

本举例是在T5030的R9900版本版本上进行配置和验证的。

组网需求

如下图所示，Device B与Device A之间通过OSPF协议交换路由信息，与Device C之间通过IS-IS协议交换路由信息。

要求在Device B上配置路由引入，将IS-IS路由引入到OSPF中去，并同时使用路由策略设置路由的属性。其中，设置172.17.1.0/24的路由的开销为100，设置172.17.2.0/24的路由的Tag属性为20。

图-1 在OSPF中引入IS-IS路由时应用路由策略配置组网图

配置步骤

  1. 配置各接口的IP地址（略）

  2. 根据组网图中规划的信息，将Device B的各接口加入对应的安全域。

    <DeviceB> system-view

    [DeviceB] security-zone name ospf

    [DeviceB-security-zone-ospf] import interface gigabitethernet 1/0/1

    [DeviceB-security-zone-ospf] quit

    [DeviceB] security-zone name isis

    [DeviceB-security-zone-isis] import interface gigabitethernet 1/0/2

    [DeviceB-security-zone-isis] quit

  3. 配置安全策略

    1. 配置安全策略放行ospf与Local安全域之间的流量，用于Device A与Device B之间建立OSPF会话。

      # 配置名称为ospflocalin的安全策略规则，使Device B可以接收来自Device A的OSPF协议报文。

      [DeviceB] security-policy ip

      [DeviceB-security-policy-ip] rule name ospflocalin

      [DeviceB-security-policy-ip-0-ospflocalin] source-zone ospf

      [DeviceB-security-policy-ip-0-ospflocalin] destination-zone local

      [DeviceB-security-policy-ip-0-ospflocalin] service ospf

      [DeviceB-security-policy-ip-0-ospflocalin] action pass

      [DeviceB-security-policy-ip-0-ospflocalin] quit

      # 配置名称为ospflocalout的安全策略规则，使Device B可以向Device A发送OSPF协议报文。

      [DeviceB-security-policy-ip] rule name ospflocalout

      [DeviceB-security-policy-ip-1-ospflocalout] source-zone local

      [DeviceB-security-policy-ip-1-ospflocalout] destination-zone ospf

      [DeviceB-security-policy-ip-1-ospflocalout] service ospf

      [DeviceB-security-policy-ip-1-ospflocalout] action pass

      [DeviceB-security-policy-ip-1-ospflocalout] quit

    2. 配置安全策略放行Local与isis安全域之间的流量，用于Device B与Device C之间建立IS-IS会话。

      # 配置名称为isislocalout的安全策略规则，使Device B可以向Device C发送IS-IS协议的报文。

      [DeviceB-security-policy-ip] rule name isislocalout

      [DeviceB-security-policy-ip-2-isislocalout] source-zone local

      [DeviceB-security-policy-ip-2-isislocalout] destination-zone isis

      [DeviceB-security-policy-ip-2-isislocalout] action pass

      [DeviceB-security-policy-ip-2-isislocalout] quit

      # 配置名称为isislocalin的安全策略规则，使Device B可以接收来自Device C的IS-IS协议的报文。

      [DeviceB-security-policy-ip] rule name isislocalin

      [DeviceB-security-policy-ip-3-isislocalin] source-zone isis

      [DeviceB-security-policy-ip-3-isislocalin] destination-zone local

      [DeviceB-security-policy-ip-3-isislocalin] action pass

      [DeviceB-security-policy-ip-3-isislocalin] quit

    3. 配置安全策略放行ospf与isis安全域之间的流量，使得Device A可以访问Device B的直连网段172.17.1.0/24、172.17.2.0/24和172.17.3.0/24。

      [DeviceB-security-policy-ip] rule name ospf-isis

      [DeviceB-security-policy-ip-4-ospf-isis] source-zone ospf

      [DeviceB-security-policy-ip-4-ospf-isis] destination-zone isis

      [DeviceB-security-policy-ip-4-ospf-isis] source-ip-subnet 192.168.1.0 24

      [DeviceB-security-policy-ip-4-ospf-isis] destination-ip-subnet 172.17.1.0 24

      [DeviceB-security-policy-ip-4-ospf-isis] destination-ip-subnet 172.17.2.0 24

      [DeviceB-security-policy-ip-4-ospf-isis] destination-ip-subnet 172.17.3.0 24

      [DeviceB-security-policy-ip-4-ospf-isis] action pass

      [DeviceB-security-policy-ip-4-ospf-isis] quit

      [DeviceB-security-policy-ip] quit

  4. 配置IS-IS路由协议

    # 配置Device C。

    <DeviceC> system-view

    [DeviceC] isis

    [DeviceC-isis-1] is-level level-2

    [DeviceC-isis-1] network-entity 10.0000.0000.0001.00

    [DeviceC-isis-1] quit

    [DeviceC] interface gigabitethernet 1/0/1

    [DeviceC-GigabitEthernet1/0/1] isis enable

    [DeviceC-GigabitEthernet1/0/1] quit

    [DeviceC] interface gigabitethernet 1/0/2

    [DeviceC-GigabitEthernet1/0/2] isis enable

    [DeviceC-GigabitEthernet1/0/2] quit

    [DeviceC] interface gigabitethernet 1/0/3

    [DeviceC-GigabitEthernet1/0/3] isis enable

    [DeviceC-GigabitEthernet1/0/3] quit

    [DeviceC] interface gigabitethernet 1/0/4

    [DeviceC-GigabitEthernet1/0/4] isis enable

    [DeviceC-GigabitEthernet1/0/4] quit

    # 配置Device B。

    <DeviceB> system-view

    [DeviceB] isis

    [DeviceB-isis-1] is-level level-2

    [DeviceB-isis-1] network-entity 10.0000.0000.0002.00

    [DeviceB-isis-1] quit

    [DeviceB] interface gigabitethernet 1/0/2

    [DeviceB-GigabitEthernet1/0/2] isis enable

    [DeviceB-GigabitEthernet1/0/2] quit

  5. 配置OSPF路由协议及路由引入

    # 配置Device A，启动OSPF。

    <DeviceA> system-view

    [DeviceA] ospf

    [DeviceA-ospf-1] area 0

    [DeviceA-ospf-1-area-0.0.0.0] network 192.168.1.0 0.0.0.255

    [DeviceA-ospf-1-area-0.0.0.0] quit

    [DeviceA-ospf-1] quit

    # 配置DeviceB，启动OSPF，并引入IS-IS路由。

    [DeviceB] ospf

    [DeviceB-ospf-1] area 0

    [DeviceB-ospf-1-area-0.0.0.0] network 192.168.1.0 0.0.0.255

    [DeviceB-ospf-1-area-0.0.0.0] quit

    [DeviceB-ospf-1] import-route isis 1

    [DeviceB-ospf-1] quit

    # 查看Device A的OSPF路由表，可以看到引入的路由。

    [DeviceA] display ospf routing

    OSPF Process 1 with Device ID 192.168.1.1

    Routing Tables

    Routing for Network

    Destination Cost Type NextHop AdvDevice Area

    192.168.1.0/24 1 Transit 192.168.1.1 192.168.1.1 0.0.0.0

    Routing for ASEs

    Destination Cost Type Tag NextHop AdvDevice

    172.17.1.0/24 1 Type2 1 192.168.1.2 192.168.2.2

    172.17.2.0/24 1 Type2 1 192.168.1.2 192.168.2.2

    172.17.3.0/24 1 Type2 1 192.168.1.2 192.168.2.2

    Total Nets: 4

    Intra Area: 1 Inter Area: 0 ASE: 3 NSSA: 0

  6. 配置过滤列表

    # 配置编号为2002的基本ACL，允许172.17.2.0/24的路由通过。

    [DeviceB] acl basic 2002

    [DeviceB-acl-ipv4-basic-2002] rule permit source 172.17.2.0 0.0.0.255

    [DeviceB-acl-ipv4-basic-2002] quit

    # 配置名为prefix-a的地址前缀列表，允许172.17.1.0/24的路由通过。

    [DeviceB] ip prefix-list prefix-a index 10 permit 172.17.1.0 24

  7. 配置路由策略

    [DeviceB] route-policy isis2ospf permit node 10

    [DeviceB-route-policy-isis2ospf-10] if-match ip address prefix-list prefix-a

    [DeviceB-route-policy-isis2ospf-10] apply cost 100

    [DeviceB-route-policy-isis2ospf-10] quit

    [DeviceB] route-policy isis2ospf permit node 20

    [DeviceB-route-policy-isis2ospf-20] if-match ip address acl 2002

    [DeviceB-route-policy-isis2ospf-20] apply tag 20

    [DeviceB-route-policy-isis2ospf-20] quit

    [DeviceB] route-policy isis2ospf permit node 30

    [DeviceB-route-policy-isis2ospf-30] quit

  8. 在路由引入时应用路由策略

    # 配置Device B，设置在路由引入时应用路由策略。

    [DeviceB] ospf

    [DeviceB-ospf-1] import-route isis 1 route-policy isis2ospf

    [DeviceB-ospf-1] quit

    # 查看Device A的OSPF路由表，可以看到目的地址为172.17.1.0/24的路由的开销为100，目的地址为172.17.2.0/24的路由的标记域（Tag）为20，而其他外部路由没有变化。

    [DeviceA] display ospf routing

    OSPF Process 1 with Device ID 192.168.1.1

    Routing Tables

    Routing for Network

    Destination Cost Type NextHop AdvDevice Area

    192.168.1.0/24 1 Transit 192.168.1.1 192.168.1.1 0.0.0.0

    Routing for ASEs

    Destination Cost Type Tag NextHop AdvDevice

    172.17.1.0/24 100 Type2 1 192.168.1.2 192.168.2.2

    172.17.2.0/24 1 Type2 20 192.168.1.2 192.168.2.2

    172.17.3.0/24 1 Type2 1 192.168.1.2 192.168.2.2

    Total Nets: 4

    Intra Area: 1 Inter Area: 0 ASE: 3 NSSA: 0

配置文件

Device A

#

interface GigabitEthernet1/0/1

ip address 192.168.1.1 255.255.255.0

#

ospf 1

area 0.0.0.0

network 192.168.1.0 0.0.0.255

#

Device B

#

interface GigabitEthernet1/0/1

ip address 192.168.1.2 255.255.255.0

#

interface GigabitEthernet1/0/2

ip address 192.168.2.2 255.255.255.0

isis enable 1

#

security-zone name ospf

import interface GigabitEthernet1/0/1

#

security-zone name isis

import interface GigabitEthernet1/0/2

#

security-policy ip

rule 0 name ospflocalin

action pass

source-zone ospf

destination-zone local

service ospf

rule 1 name ospflocalout

action pass

source-zone local

destination-zone ospf

service ospf

rule 2 name isislocalout

action pass

source-zone local

destination-zone isis

rule 3 name isislocalin

action pass

source-zone isis

destination-zone local

rule 4 name ospf-isis

action pass

source-zone ospf

destination-zone isis

source-ip-subnet 192.168.1.0 255.255.255.0

destination-ip-subnet 172.17.1.0 255.255.255.0

destination-ip-subnet 172.17.2.0 255.255.255.0

destination-ip-subnet 172.17.3.0 255.255.255.0

#

isis 1

is-level level-2

network-entity 10.0000.0000.0002.00

#

ospf 1

import-route isis 1 route-policy isis2ospf

area 0.0.0.0

network 192.168.1.0 0.0.0.255

#

acl basic 2002

rule 0 permit source 172.17.2.0 0.0.0.255

#

ip prefix-list prefix-a index 10 permit 172.17.1.0 24

#

route-policy isis2ospf permit node 10

if-match ip address prefix-list prefix-a

apply cost 100

#

route-policy isis2ospf permit node 20

if-match ip address acl 2002

apply tag 20

#

route-policy isis2ospf permit node 30

#

Device C

#

interface GigabitEthernet1/0/1

ip address 172.17.1.1 255.255.255.0

isis enable 1

#

interface GigabitEthernet1/0/2

ip address 172.17.1.2. 255.255.255.0

isis enable 1

#

interface GigabitEthernet1/0/3

ip address 172.17.1.3 255.255.255.0

isis enable 1

#

interface GigabitEthernet1/0/4

ip address 192.168.2.1 255.255.255.0

isis enable 1

#

isis 1

is-level level-2

network-entity 10.0000.0000.0001.00

#
